HP OmniBook 5000 User manual

This guide is for experienced HP Response
Center personnel, CEs, and reseller
technicians, such as personnel who have
already completed the HP Vectra PC family
training course, or equivalent, and have at least
six months of experience servicing the HP
Vectra PCs.
It is a self-paced guide designed to train you to
install, configure, and repair the OmniBook
Notebook PC and/or Accessories. You can
follow it without having any equipment
available.
HP OmniBook 5000/5500 Docking System
Familiarization Guide

__________
2
Notice
In a continuing effort to improve the quality of our products, technical and
environmental information in this document is subject to change without
notice.
Last revision date: 09/13/96 4:56 PM
Hewlett-Packard makes no warranty of any kind with regard to this
material, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Hewlett-Packard shall
not be liable for errors contained herein or for incidental or consequential
damages in connection with the furnishing, performance, or use of this
material.
Hewlett-Packard assumes no responsibility for the use or reliability of its
software on equipment that is not furnished by Hewlett-Packard.
As an ENERGY STAR partner, HP has determined that these products
meet the ENERGY STAR guidelines for energy efficiency.
All Certifications may not be completed at product introduction. Please
check with your HP reseller for certification status.
This equipment is subject to FCC rules. It will comply with the appropriate
FCC rules before final delivery to the buyer.
ENERGY STAR is a service mark of the U.S. Environmental Protection
Agency. IBM and OS/2 are registered trademarks of International
Business Machines Corporation. Pentium and the Intel Inside logo are
registered trademarks of Intel Corporation. Photo CD is a registered
trademark of Kodak Corporation. Microsoft, MS-DOS, and Windows are
registered trademarks, and the Genuine Microsoft Products logo is a
trademark of Microsoft Corporation in the United States of America and in
other countries. Sound Blaster is a trademark of Creative Technology Ltd.
Hewlett-Packard Company 1996.
All Rights Reserved. Reproduction, adaptation, or translation without prior
written permission is prohibited except as allowed under copyright laws.
Printed in U.S.A.
F1189-90008

__________
3
Table of Contents
Product Features.........................................................................................................................5
Description.............................................................................................................................5
Input/Output Connectors.........................................................................................................5
Hot Docking............................................................................................................................5
Expandability..........................................................................................................................5
Security..................................................................................................................................5
Controls..................................................................................................................................5
Dimensions ............................................................................................................................6
Power.....................................................................................................................................6
Software.................................................................................................................................6
Environment...........................................................................................................................6
Warranty................................................................................................................................6
Ordering Information ..............................................................................................................6
Notebook Hardware Structure......................................................................................................7
Field Replaceable Assemblies................................................................................................7
Case Cover, Cover ISA, Leg Tilts, and Screw Cover (End User Replaceable)........................7
Case Top, Case Right, and Case Left (HP Authorized Support Providers Only)......................8
Arm Eject Lever, Case Deck Assembly, and Top Shield Assembly (HP Authorized Support
Providers Only) ......................................................................................................................9
Docking Station PCA, Docking Mechanism Assembly, and Control PCA (HP Authorized
Support Providers Only).......................................................................................................10
Troubleshooting and Repair.......................................................................................................12
Appendix A: Part Numbers........................................................................................................13
Appendix B: Additional Resources.............................................................................................14

__________
4
Table of Figures
Figure 1 - Case Cover, Cover ISA, Leg Tilts, and Screw Cover................................................7
Figure 2 - Case Top, Case Right, and Case Left.......................................................................8
Figure 3 - Arm Eject Lever, Case Deck Assembly, and Top Shield Assembly...........................9
Figure 4 - Docking Station PCA, Docking Mechanism Assembly, and Control PCA................10
Figure 5 - Control Harness Placement....................................................................................11

__________
5
Product Features
Description The docking system for the HP OmniBook 5000/5500 provides simple and
convenient connectivity to your desktop peripherals. It lets you make a
single-action connection to networks, monitors, keyboards, mice and other
peripherals present at your desktop. A monitor stand and riser provide
space-saving support for an external monitor. The riser lifts the unit above
a standard keyboard offering easy access to the battery and floppy drive.
Input/Output
Connectors
• 9-pin, 115,000 b/s, RS-232 port
• 15-pin SVGA-out (up to 1024x768x256 colors)
• PS/2 keyboard port
• Headphone/stereo-out port
• MIDI/joystick port
• 25-pin bidirectional parallel port
• PS/2 mouse port
• Two stereo-in ports
• SCSI-2 port
Hot Docking Supported under docking- enabled operating systems such as Microsoft®
Windows 95
Expandability 1 full-length ISA slots
1 full-length PCI/ISA
Security Kensington lock slot
Optional user-defined password to undock
Secure interlock to OmniBook
Controls Power: turns your OmniBook on or off
Power
Audio out
Parallelport
A
u
d
i
o
i
n
Mute/Enable
notebook
speakers
Serialport
SCSIport
Joystick/
MIDIport
Mouseport
Keyboard port
VGAout
CDaudioin

__________
6
Reset: resets your OmniBook
Mute/enable notebook speakers: controls OmniBook's built-in stereo
speakers
Undock: initiates undocking process
Indicators Hard drive activity
Power adapter attached
Password active
Floppy drive activity
Unit docked
Dimensions
Footprint: 45.7 x 43.7 x 8.4 cm (18.0 x 17.2 x 3.3 in)
With monitor
stand and riser in
place: 45.7 x 43.7 x 13.5 cm (18.0 x 17.2 x 5.3 in)
Weight:
Docking System: 4.0 kg (8.8 lb)
Monitor Stand: 1.9 kg (4.1 lb)
Riser: 1.1 kg (2.4 lb)
Total: 7.0 kg (15.3 lb)
Power AC adapter: 100 to 240 Vac,
60-watt
Software No additional software is required for the OmniBook 5500 to take advantage
of the docking system. Software is included with the Docking System for
the OmniBook 5000.
Environment
Operating
temperature: 0 to 50°C (32 to 122°F)
Storage
temperature: 0 to 65°C (32 to 149°F)
Operating and
storage humidity: 90% relative humidity at 40°C (104°F) maximum
Warranty 1-year limited warranty
Ordering Information F1189B docking system for the OmniBook 5000 (Includes a monitor stand
and riser)
F1140-60901 replacement AC adapter for F1189B docking system

__________
7
Notebook Hardware Structure
Field Replaceable Assemblies
Case Cover, Cover ISA, Leg Tilts, and Screw Cover
(End User Replaceable)
Remove and/or replace the covers and Leg Tilts as indicated in Figure 1. Note, the Screw Cover
will be destroyed and must be replaced.
Screw Cover
(Qty 2)
Leg Tilt
(Qty 2)
Cover ISA
Case Cover
Figure 1- Case Cover, Cover ISA, Leg Tilts, and Screw Cover

__________
8
Case Top, Case Right, and Case Left
(HP Authorized Support Providers Only)
Case Top:
1. Remove the three screws depicted in Figure 2.
2. Lift the Case Top up from the back, push in the front panel, and pull away towards the front.
3. Reverse the above steps to reassemble.
Case Right and Left:
1. Remove the four screws for the Case Right and Case Left as depicted in Figure 2.
2. Lift the Case Right and Case Left away from the unit.
3. Reverse the above steps to reassemble.
Screw 6-32 L=0.188
Case Top
Case Left
Case Right
Screw 6-32
L=0.188
Screw 6-32
L=0.188
Screw 6-32 L=0.250
Screw 6-32
L=0.250
Figure 2- Case Top, Case Right, and Case Left

__________
9
Arm Eject Lever, Case Deck Assembly, and Top Shield Assembly
(HP Authorized Support Providers Only)
Case Deck Assembly:
1. Remove the two screws shown in Figure 3.
2. Remove the Arm Eject Lever by gently pulling the front plastic guide forward and lifting the
lever away to the left.
3. Reverse the above steps to reassemble.
Top Shield Assembly:
1. Remove the four screws shown in Figure 3.
2. Slide the Top Shield Assembly forward to remove.
3. Reverse the above steps to reassemble.
Top Shield Assy
Screw 6-32 L=0.188
Arm Eject Lever
Case Deck Assy
Screw 6-32
L=0.188
Screw 6-32
L=0.250
Screw 6-32 L=0.250
Figure 3- Arm Eject Lever, Case Deck Assembly, and Top Shield Assembly

__________
10
Docking Station PCA, Docking Mechanism Assembly, and
Control PCA
(HP Authorized Support Providers Only)
Docking Station PCA:
1. Disconnect the Control Harness from the Docking Station PCA (see Figure 4).
2. Remove the two 6-32 L=0.188 screws from front corners of the Docking Station PCA (screws
not shown in Figure 4).
3. Disconnect the cable connecting the Docking Mechanism Assy to the Docking System PCA.
4. Turn the Docking Station PCA over and remove the four screws from the bottom. This will
free the Docking Mechanism Assembly.
5. The Control PCA simply lifts out at this point. Refer to Figure 5 for proper placement of
the Control Harness. Improper placement will crimp the harness and may result in
loss of control button functionality.
6. Reverse the above steps to reassemble.
Docking Mechanism
Assy
Docking System
PCA
Rod Switch
Plunger
Plunger Spring
Control PCA
Control Harness Base Assy
Screw 6-32
L=0.188
(Qty 4)
Editor’s Note: A
small washer is
located on this
raised standoff/
screwhole.
Figure 4- Docking Station PCA, Docking Mechanism Assembly, and Control PCA

__________
11
Figure 5- Control Harness Placement

__________
12
Troubleshooting and Repair
• The floppy drive module F1195A will not work on the dock parallel port - only on the
OmniBook parallel port.
• The OmniBook 5500 PCMCIA ports are not accessible when docked in the F1189A Docking
System - use the F1189B.
• To update an F1189A to an F1189B, the Case Deck Assy must be replaced.
The PCMCIA slots on the OmniBook 5500 are positioned 7mm closer to the back of the
computer than the OmniBook 5000. This difference causes a physical interference when
adding/removing cards in the PCMCIA slots while docked in the F1189A (see diagram
below). The update will accommodate the case deck assembly plastic change which
eliminates this interference.
F1189A F1189B
To update the Docking System, replace the Case Deck Assy, and the two Screw Covers..
Upon completion of the update, use a black permanent marker and an arrow and the letter
“B” next to “F1098A.” The regulatory label should appear as “F1098A →→ B” on the bottom of
the product.

__________
13
Appendix A: Part Numbers
Part Description Part Number Exchange Part
Number
PCA Docking System PCA F1189-60901 F1189-69001
Control PCA F1189-60902
Mechanism Docking Mechanism Assy. F1189-60903
Shielding Base Assy F1189-60904
Top Shield Assy F1189-60905
Cover ISA F1189-60907
Plastic Rod Switch Plunger F1189-60908
Case Deck Assy F1189-60909
Case Right F1189-60910
Case Left F1189-60911
Case Cover F1189-60912
Case Top F1189-60913
Leg Tilt F1189-60914
Keyboard Riser F1189-60915
Monitor Stand F1189-60916
Screws Screw M2.5x.45 L=6 F1189-60917
Screw 6-32 L=0.188 F1189-60918
Screw 6-32 L=0.250 F1189-60919
Misc Control Harness F1189-60921
Screw Cover F1189-60922
Plunger Spring F1189-60923
Arm Reject Lever F1189-60924
Spacer Foam F1189-60925
Rubber Foot 20x2.0 F1189-60926
Rubber Foot 22x4.2 F1189-60927
Rubber Foot 15x2.5 F1189-60920
I/O Panel Label F1189-60928
AC/DC Adapter F1140-60901

__________
14
Appendix B: Additional Resources
The following table contains resources for additional product related information.
Resource Number/Address Comments
HP External Web http://hpcc998.external.hp.com/mcd/ No usage restriction
HP-MCD Internal Web http://webmcd.cv.hp.com Restricted to HP internet
access only
HP MCD Service
Engineer [email protected] Email address for service related questions and
issues
