HTC Touch Diamond DIAM400 User manual

User Manual

2
Please Read Before Proceeding
THE BATTERY IS NOT CHARGED WHEN YOU TAKE IT OUT OF THE BOX.
DO NOT REMOVE THE BATTERY PACK WHEN THE DEVICE IS CHARGING.
YOUR WARRANTY IS INVALIDATED IF YOU OPEN OR TAMPER WITH THE DEVICE’S OUTER
CASING.
PRIVACY RESTRICTIONS
Some countries require full disclosure of recorded telephone conversations, and stipulate that you must
inform the person with whom you are speaking that the conversation is being recorded. Always obey the
relevant laws and regulations of your country when using the recording feature of your PDA Phone.
INTELLECTUAL PROPERTY RIGHT INFORMATION
Copyright © 2009 HTC Corporation. All Rights Reserved.
HTC, the HTC logo, HTC Innovation, ExtUSB, TouchFLO, Touch Diamond and HTC Care are trademarks and/or
service marks of HTC Corporation.
Microsoft, MS-DOS, Windows, Windows NT, Windows Server, Windows Mobile, Windows XP, Windows Vista,
ActiveSync, Windows Mobile Device Center, Internet Explorer, MSN, Hotmail, Windows Live, Outlook, Excel,
PowerPoint, Word, OneNote and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Bluetooth and the Bluetooth logo are trademarks owned by Bluetooth SIG, Inc.
Copyright © 2009, Adobe Systems Incorporated. All Rights Reserved.
microSD is a trademark of SD Card Association.
Opera® Mobile from Opera Software ASA. Copyright 1995-2009 Opera Software ASA. All Rights Reserved.
Google is a registered trademark of Google, Inc. in the United States and other countries.
YouTube is a trademark of Google, Inc.
Copyright © 2001-2009, Spb Software House. All Rights Reserved.
Copyright © 2009, Esmertec AG. All Rights Reserved.
Copyright © 2003-2009, ArcSoft, Inc. and its licensors. All Rights Reserved. ArcSoft and the ArcSoft logo are
registered trademarks of ArcSoft, Inc. in the United States and/or other countries.
Copyright © 2004-2009, Ilium Software, Inc. All Rights Reserved.
All other company, product and service names mentioned herein are trademarks, registered trademarks or
service marks of their respective owners.
HTC shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or
consequential damages resulting from furnishing this material. The information is provided“as is” without
warranty of any kind and is subject to change without notice. HTC also reserves the right to revise the content
of this document at any time without prior notice.
No part of this document may be reproduced or transmitted in any form or by any means, electronic or
mechanical, including photocopying, recording or storing in a retrieval system, or translated into any
language in any form without prior written permission of HTC.

3
Disclaimers
THE WEATHER INFORMATION, DATA AND DOCUMENTATION ARE PROVIDED “AS IS” AND WITHOUT WARRANTY
OR TECHNICAL SUPPORT OF ANY KIND FROM HTC. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE
LAW, HTC AND ITS AFFILIATES expressly disclaim any and all representations and warranties, express or
implied, arising by law or otherwise, regarding the Weather Information, Data, Documentation, or any other
Products and services, including without limitation any express or implied warranty of merchantability,
express or implied warranty of fitness for a particular purpose, non-infringement, quality, accuracy,
completeness, effectiveness, reliability, usefulness, that the Weather Information, Data and/or Documentation
will be error-free, or implied warranties arising from course of dealing or course of performance.
Without limiting the foregoing, it is further understood that HTC and its Providers are not responsible for Your
use or misuse of the Weather Information, Data and/or Documentation or the results from such use. HTC and
its Providers make no express or implied warranties, guarantees or affirmations that weather information
will occur or has occurred as the reports, forecasts, data, or information state, represent or depict and it shall
have no responsibility or liability whatsoever to any person or entity, parties and non-parties alike, for any
inconsistency, inaccuracy, or omission for weather or events predicted or depicted, reported, occurring or
occurred. WITHOUT LIMITING THE GENERALITY OF THE FOREGOING, YOU ACKNOWLEDGE THAT THE WEATHER
INFORMATION, DATA AND/OR DOCUMENTATION MAY INCLUDE INACCURACIES AND YOU WILL USE COMMON
SENSE AND FOLLOW STANDARD SAFETY PRECAUTIONS IN CONNECTION WITH THE USE OF THE WEATHER
INFORMATION, DATA OR DOCUMENTATION.
Limitation of Damages
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HTC OR ITS PROVIDERS
BE LIABLE TO USER OR ANY THIRD PARTY FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, INCIDENTAL OR
PUNITIVE DAMAGES OF ANY KIND, IN CONTRACT OR TORT, INCLUDING, BUT NOT LIMITED TO, INJURY, LOSS OF
REVENUE, LOSS OF GOODWILL, LOSS OF BUSINESS OPPORTUNITY, LOSS OF DATA, AND/OR LOSS OF PROFITS
ARISING OUT OF, OR RELATED TO, IN ANY MANNER, OR THE DELIVERY, PERFORMANCE OR NONPERFORMANCE
OF OBLIGATIONS, OR USE OF THE WEATHER INFORMATION, DATA OR DOCUMENTATION HEREUNDER
REGARDLESS OF THE FORESEEABILITY THEREOF.
Important Health Information and Safety Precautions
When using this product, the safety precautions below must be taken to avoid possible legal liabilities and
damages.
Retain and follow all product safety and operating instructions. Observe all warnings in the operating
instructions on the product.
To reduce the risk of bodily injury, electric shock, fire, and damage to the equipment, observe the following
precautions.
ELECTRICAL SAFETY
This product is intended for use when supplied with power from the designated battery or power supply unit.
Other usage may be dangerous and will invalidate any approval given to this product.
SAFETY PRECAUTIONS FOR PROPER GROUNDING INSTALLATION
CAUTION: Connecting to an improperly grounded equipment can result in an electric shock to your device.
This product equipped with a USB Cable for connecting with desktop or notebook computer. Be sure your
computer is properly grounded (earthed) before connecting this product to the computer. The power supply
cord of a desktop or notebook computer has an equipment-grounding conductor and a grounding plug. The
plug must be plugged into an appropriate outlet which is properly installed and grounded in accordance with
all local codes and ordinances.

4
SAFETY PRECAUTIONS FOR POWER SUPPLY UNIT
Use the correct external power source
A product should be operated only from the type of power source indicated on the electrical ratings
label. If you are not sure of the type of power source required, consult your authorized service provider
or local power company. For a product that operates from battery power or other sources, refer to the
operating instructions that are included with the product.
Handle battery packs carefully
This product contains a Li-ion battery. There is a risk of fire and burns if the battery pack is handled
improperly. Do not attempt to open or service the battery pack. Do not disassemble, crush, puncture,
short external contacts or circuits, dispose of in fire or water, or expose a battery pack to temperatures
higher than 60˚C (140˚F).
WARNING: Danger of explosion if battery is incorrectly replaced. To reduce risk of fire or burns, do not
disassemble, crush, puncture, short external contacts, expose to temperature above 60° C (140° F), or
dispose of in fire or water. Replace only with specified batteries. Recycle or dispose of used batteries
according to the local regulations or reference guide supplied with your product.
Take extra precautions
Keep the battery or device dry and away from water or any liquid as it may cause a short circuit.
Keep metal objects away so they don’t come in contact with the battery or its connectors as it may
lead to short circuit during operation.
The phone should be only connected to products that bear the USB-IF logo or have completed the
USB-IF compliance program.
Do not use a battery that appears damaged, deformed, or discolored, or the one that has any rust
on its casing, overheats, or emits a foul odor.
Always keep the battery out of the reach of babies and small children, to avoid swallowing of the
battery. Consult the doctor immediately if the battery is swallowed.
Only use the battery with a charging system that has been qualified with the system per this
standard, IEEE-Std-1725-2006. Use of an unqualified battery or charger may present a risk of fire,
explosion, leakage or other hazard.
Replace the battery only with another battery that has been qualified with the system per this
standard, IEEE-Std-1725-2006. Use of an unqualified battery may present a risk of fire, explosion,
leakage or other hazard.
Avoid dropping the phone or battery. If the phone or battery is dropped, especially on a hard
surface, and the user suspects damage, take it to a service centre for inspection.
If the battery leaks:
Do not allow the leaking fluid to come in contact with skin or clothing. If already in contact,
flush the affected area immediately with clean water and seek medical advice.
Do not allow the leaking fluid to come in contact with eyes. If already in contact, DO NOT rub;
rinse with clean water immediately and seek medical advice.
Take extra precautions to keep a leaking battery away from fire as there is a danger of ignition
or explosion.
SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT
Keep this product away from excessive moisture and extreme temperatures. Do not leave the product or
its battery inside a vehicle or in places where the temperature may exceed 60°C (140°F), such as on a car
dashboard, window sill, or behind a glass that is exposed to direct sunlight or strong ultraviolet light for
extended periods of time. This may damage the product, overheat the battery, or pose a risk to the vehicle.
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

5
PREVENTION OF HEARING LOSS
CAUTION: Avoid potential hearing loss
Prolonged exposure to loud sounds (including music) is the most common cause of preventable hearing
loss. Some scientific research suggests that using portable audio devices, such as portable music players and
cellular telephones, at high volume settings for long durations may lead to permanent noise-induced hearing
loss. This includes the use of headphones (including headsets, earbuds and Bluetooth® or other wireless
devices). Exposure to very loud sound has also been associated in some studies with tinnitus (a ringing in the
ear), hypersensitivity to sound and distorted hearing. Individual susceptibility to noise-induced hearing loss
and other potential hearing problems varies.
The amount of sound produced by a portable audio device varies depending on the nature of the sound, the
device, the device settings and the headphones. You should follow some commonsense recommendations
when using any portable audio device:
Set the volume in a quiet environment and select the lowest volume at which you can hear adequately.
When using headphones, turn the volume down if you cannot hear the people speaking near you or if
the person sitting next to you can hear what you are listening to.
Do not turn the volume up to block out noisy surroundings. If you choose to listen to your portable
device in a noisy environment, use noise-cancelling headphones to block out background
environmental noise.
Limit the amount of time you listen. As the volume increases, less time is required before your hearing
could be affected.
Avoid using headphones after exposure to extremely loud noises, such as rock concerts, that might
cause temporary hearing loss. Temporary hearing loss might cause unsafe volumes to sound normal.
Do not listen at any volume that causes you discomfort. If you experience ringing in your ears, hear
muffled speech or experience any temporary hearing difficulty after listening to your portable audio
device, discontinue use and consult your doctor.
You can obtain additional information on this subject from the following sources:
American Academy of Audiology
11730 Plaza American Drive, Suite 300
Reston, VA 20190
Voice: [phone]
Email: [e-mail]
Internet: www.audiology.org
National Institute on Deafness and Other Communication Disorders
National Institutes of Health
31 Center Drive, MSC 2320
Bethesda, MD USA 20892-2320
Voice: [phone]
Email: [email protected]v
Internet: http://www.nidcd.nih.gov/health/hearing
National Institute for Occupational Safety and Health
Hubert H. Humphrey Bldg.
200 Independence Ave., SW
Washington, DC 20201
Voice: 1-800-35-NIOSH (1-800-356-4674)
Internet: http://www.cdc.gov/niosh/topics/noise/default.html
SAFETY IN AIRCRAFT
Due to the possible interference caused by this product to an aircraft’s navigation system and its
communications network, using this device’s phone function on board an airplane is against the law in most
countries. If you want to use this device when on board an aircraft, remember to turn off your phone by
switching to Airplane Mode.
•
•
•
•
•
•

6
ENVIRONMENT RESTRICTIONS
Do not use this product in gas stations, fuel depots, chemical plants or where blasting operations are in
progress, or in potentially explosive atmospheres such as fuelling areas, fuel storehouses, below deck
on boats, chemical plants, fuel or chemical transfer or storage facilities, and areas where the air contains
chemicals or particles, such as grain, dust, or metal powders. Please be aware that sparks in such areas could
cause an explosion or fire resulting in bodily injury or even death.
EXPLOSIVE ATMOSPHERES
When in any area with a potentially explosive atmosphere or where flammable materials exist, the product
should be turned off and the user should obey all signs and instructions. Sparks in such areas could cause
an explosion or fire resulting in bodily injury or even death. Users are advised not to use the equipment at
refueling points such as service or gas stations, and are reminded of the need to observe restrictions on the
use of radio equipment in fuel depots, chemical plants, or where blasting operations are in progress. Areas
with a potentially explosive atmosphere are often, but not always, clearly marked. These include fueling areas,
below deck on boats, fuel or chemical transfer or storage facilities, and areas where the air contains chemicals
or particles, such as grain, dust, or metal powders.
ROAD SAFETY
Vehicle drivers in motion are not permitted to use telephony services with handheld devices, except in the
case of emergency. In some countries, using hands-free devices as an alternative is allowed.
SAFETY PRECAUTIONS FOR RF EXPOSURE
Avoid using your phone near metal structures (for example, the steel frame of a building).
Avoid using your phone near strong electromagnetic sources, such as microwave ovens, sound
speakers, TV and radio.
Use only original manufacturer-approved accessories, or accessories that do not contain any metal.
Use of non-original manufacturer-approved accessories may violate your local RF exposure guidelines
and should be avoided.
INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS
This product may cause medical equipment to malfunction. The use of this device is forbidden in most
hospitals and medical clinics.
If you use any other personal medical device, consult the manufacturer of your device to determine if they
are adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this
information.
Turn your phone OFF in health care facilities when any regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment that could be sensitive to external RF energy.
HEARING AIDS
Some digital wireless phones may interfere with some hearing aids. In the event of such interference, you may
want to consult your service provider, or call the customer service line to discuss alternatives.
NONIONIZING RADIATION
Your device has an internal antenna. This product should be operated in its normal-use position to ensure
the radiative performance and safety of the interference. As with other mobile radio transmitting equipment,
users are advised that for satisfactory operation of the equipment and for the safety of personnel, it is
recommended that no part of the human body be allowed to come too close to the antenna during operation
of the equipment.
Use only the supplied integral antenna. Use of unauthorized or modified antennas may impair call quality and
damage the phone, causing loss of performance and SAR levels exceeding the recommended limits as well as
result in non-compliance with local regulatory requirements in your country.
•
•
•
•

7
To assure optimal phone performance and ensure
human exposure to RF energy is within the guidelines
set forth in the relevant standards, always use your
device only in its normal-use position. Contact with the
antenna area may impair call quality and cause your
device to operate at a higher power level than needed.
Avoiding contact with the antenna area when the
phone is IN USE optimizes the antenna performance
and the battery life.
Antenna location
General Precautions
• Avoid applying excessive pressure to the device
Do not apply excessive pressure on the screen and the device to prevent damaging them and remove the
device from your pants’ pocket before sitting down. It is also recommended that you store the device in a
protective case and only use the device stylus or your finger when interacting with the touch screen. Cracked
display screens due to improper handling are not covered by the warranty.
•Device getting warm after prolonged use
When using your device for prolonged periods of time, such as when you’re talking on the phone, charging
the battery or browsing the web, the device may become warm. In most cases, this condition is normal and
therefore should not be interpreted as a problem with the device.
• Heed service markings
Except as explained elsewhere in the Operating or Service documentation, do not service any product
yourself. Service needed on components inside the device should be done by an authorized service
technician or provider.
• Damage requiring service
Unplug the product from the electrical outlet and refer servicing to an authorized service technician or
provider under the following conditions:
Liquid has been spilled or an object has fallen onto the product.
The product has been exposed to rain or water.
The product has been dropped or damaged.
There are noticeable signs of overheating.
The product does not operate normally when you follow the operating instructions.
• Avoid hot areas
The product should be placed away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
• Avoid wet areas
Never use the product in a wet location.
• Avoid using your device after a dramatic change in temperature
When you move your device between environments with very different temperature and/or humidity ranges,
condensation may form on or within the device. To avoid damaging the device, allow sufficient time for the
moisture to evaporate before using the device.
NOTICE: When taking the device from low-temperature conditions into a warmer environment or from high-temperature
conditions into a cooler environment, allow the device to acclimate to room temperature before turning on
power.
•
•
•
•
•

8
• Avoid pushing objects into product
Never push objects of any kind into cabinet slots or other openings in the product. Slots and openings are
provided for ventilation. These openings must not be blocked or covered.
• Mounting accessories
Do not use the product on an unstable table, cart, stand, tripod, or bracket. Any mounting of the product
should follow the manufacturer’s instructions, and should use a mounting accessory recommended by the
manufacturer.
•Avoid unstable mounting
Do not place the product with an unstable base.
• Use product with approved equipment
This product should be used only with personal computers and options identified as suitable for use with
your equipment.
• Adjust the volume
Turn down the volume before using headphones or other audio devices.
• Cleaning
Unplug the product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a
damp cloth for cleaning, but NEVER use water to clean the LCD screen.

9
Contents
Chapter 1 Getting Started 15
1.1 Getting to Know Your Touch Phone and Accessories............................... 16
Top panel...................................................................................................................................................16
Front panel................................................................................................................................................16
Bottom panel ...........................................................................................................................................16
Left panel...................................................................................................................................................17
Back panel.................................................................................................................................................17
Right panel................................................................................................................................................17
Package Contents...................................................................................................................................17
1.2 Installing the Battery, and Storage Card .................................................. 18
Battery ........................................................................................................................................................18
Storage card .............................................................................................................................................19
1.3 Charging the Battery.................................................................................. 19
1.4 Starting Up.................................................................................................. 19
Turn your device on and off................................................................................................................19
Switch to Sleep mode when not in use..........................................................................................20
1.5 Navigating on Your Device......................................................................... 20
Finger-touch control .............................................................................................................................20
Stylus...........................................................................................................................................................21
Navigation Control.................................................................................................................................21
1.6 Home Screen............................................................................................... 22
1.7 Status Icons................................................................................................. 22
1.8 Start Menu .................................................................................................. 24
1.9 Quick Menu ................................................................................................. 24
1.10 LED Alerts.................................................................................................. 25
1.11 Adjusting the Volume .............................................................................. 25
1.12 When Connecting Your Device to a Computer ....................................... 26
Chapter 2 Using Phone Features 27
2.1 Using the Phone ......................................................................................... 28
The Phone screen ...................................................................................................................................28
2.2 Voice Call ..................................................................................................... 28
Make a call.................................................................................................................................................28
Answer a call.............................................................................................................................................29
End a call ...................................................................................................................................................30
Call History................................................................................................................................................30
Speed Dial .................................................................................................................................................30
Turn the phone function on and off................................................................................................31
2.3 Smart Dial ................................................................................................... 31
Make a call or send a text message using Smart Dial................................................................32

10
Chapter 3 TouchFLO™ 3D 33
3.1 About TouchFLO™ 3D ................................................................................. 34
3.2 Using the TouchFLO 3D Home Screen....................................................... 34
Home ..........................................................................................................................................................35
My Favorites..............................................................................................................................................36
Messaging.................................................................................................................................................37
Music...........................................................................................................................................................37
Email............................................................................................................................................................39
Browser.......................................................................................................................................................40
Photos and Videos..................................................................................................................................40
My Applications ......................................................................................................................................41
Weather......................................................................................................................................................41
Settings ......................................................................................................................................................42
3.3 Finger Gestures........................................................................................... 43
Finger scrolling........................................................................................................................................43
Finger zooming.......................................................................................................................................43
Finger panning........................................................................................................................................43
Chapter 4 Entering Text 45
4.1 Selecting an Input Method ........................................................................ 46
4.2 Using the Full QWERTY .............................................................................. 46
4.3 Using the Compact QWERTY ..................................................................... 47
4.4 Using the Phone Keypad............................................................................ 48
4.5 Using Multitap and T9 Modes.................................................................... 48
Multitap mode.........................................................................................................................................48
T9 mode.....................................................................................................................................................48
4.6 Using Numeric and Symbol Mode............................................................. 49
4.7 Using Block Recognizer.............................................................................. 50
4.8 Using Letter Recognizer............................................................................. 50
4.9 Using Transcriber........................................................................................ 50
Chapter 5 Synchronizing Information With Your Computer 53
5.1 About Synchronization .............................................................................. 54
Ways to synchronize..............................................................................................................................54
5.2 Setting Up Windows Mobile® Device Center on Windows Vista®............ 55
Set up synchronization in Windows Mobile Device Center ....................................................55
Use Windows Mobile Device Center................................................................................................55
5.3 Setting Up ActiveSync® on Windows XP® ................................................. 56
Install ActiveSync....................................................................................................................................56
Set up synchronization in ActiveSync.............................................................................................56
5.4 Synchronizing With Your Computer.......................................................... 56
Start and stop synchronization .........................................................................................................56

11
Change which information is synchronized.................................................................................57
Troubleshoot sync connection problem........................................................................................57
5.5 Synchronizing via Bluetooth ..................................................................... 57
5.6 Synchronizing Music and Video ................................................................ 58
Chapter 6 Exchanging Messages 59
6.1 Messaging ................................................................................................... 60
6.2 Text Messages ............................................................................................. 60
Create a new text message.................................................................................................................60
Compose and send a text message.................................................................................................61
Manage text messages.........................................................................................................................61
6.3 MMS Messages ........................................................................................... 62
Create and send MMS messages ......................................................................................................62
View and reply picture and video messages................................................................................64
6.4 Types of E-mail Accounts ........................................................................... 64
Set up your device to synchronize Outlook e-mail with the computer..............................64
Add an e-mail account .........................................................................................................................65
6.5 E-mail Setup Wizard ................................................................................... 65
Set up an Internet e-mail account....................................................................................................65
Set up a custom domain e-mail ........................................................................................................66
6.6 Using E-mail ................................................................................................ 67
Create a new e-mail message ............................................................................................................67
Compose and send an e-mail ............................................................................................................67
Filter the Inbox message list...............................................................................................................68
View and reply to messages ...............................................................................................................68
Synchronize e-mails...............................................................................................................................69
Customize e-mail settings...................................................................................................................69
Chapter 7 Working With Company E-mails and Meeting
Appointments 71
7.1 Synchronizing with the Exchange Server................................................. 72
Set up an Exchange Server connection..........................................................................................72
Start synchronization............................................................................................................................72
7.2 Working With Company E-mails ................................................................ 73
Automatic synchronization through Direct Push.......................................................................73
Scheduled synchronization ................................................................................................................73
Instant download through Fetch Mail ............................................................................................73
Search for e-mails on the Exchange Server...................................................................................74
Flag your messages ...............................................................................................................................74
7.3 Managing Meeting Requests..................................................................... 75
Out-of-office auto-reply.......................................................................................................................75
7.4 Finding Contacts in the Company Directory ............................................ 76

12
Chapter 8 Internet 77
8.1 Ways of Connecting to the Internet .......................................................... 78
Wi-Fi.............................................................................................................................................................78
Dial-up........................................................................................................................................................80
8.2 Starting a Data Connection ....................................................................... 80
8.3 Using Opera Mobile™ ................................................................................. 81
View Web pages......................................................................................................................................82
Opera Mobile menu ..............................................................................................................................82
8.4 Using YouTube™.......................................................................................... 83
Browse for videos ...................................................................................................................................83
Watching videos .....................................................................................................................................84
Bookmarks ................................................................................................................................................85
History ........................................................................................................................................................85
8.5 Using Your Device As a Tethered Modem ................................................. 86
Using VZAccess Manager.....................................................................................................................86
Using Modem Link.................................................................................................................................86
Create a modem dial-up connection ..............................................................................................88
Dial up and connect to the Internet ................................................................................................90
Chapter 9 Bluetooth 91
9.1 Bluetooth Modes ........................................................................................ 92
Supported Profiles .................................................................................................................................92
9.2 Bluetooth Partnerships.............................................................................. 93
9.3 Connecting a Bluetooth Hands-free or Stereo Headset .......................... 93
9.4 Beaming Information Using Bluetooth .................................................... 94
9.5 Bluetooth Explorer and Bluetooth File Sharing....................................... 95
9.6 Printing Files via Bluetooth ....................................................................... 96
Chapter 10 Navigating on the Road 97
10.1 Guidelines and Preparation for Using GPS ............................................ 98
Chapter 11 Experiencing Multimedia 99
11.1 Taking Photos and Videos...................................................................... 100
Capture modes..................................................................................................................................... 100
Camera controls................................................................................................................................... 101
On-screen controls and indicators ................................................................................................ 101
Menu Panel............................................................................................................................................ 102
Zooming ................................................................................................................................................. 103
The Review screen............................................................................................................................... 104
Advanced Options .............................................................................................................................. 104
11.2 Viewing Photos and Videos Using Album ............................................ 106
Select a photo or video to view...................................................................................................... 106
View an image ...................................................................................................................................... 107

13
Play back video..................................................................................................................................... 109
Close Album .......................................................................................................................................... 109
11.3 Using Windows Media® Player Mobile.................................................. 109
About the controls .............................................................................................................................. 110
About the screens and menus........................................................................................................ 110
Synchronize video and audio files................................................................................................. 110
Play media.............................................................................................................................................. 111
Playlists.................................................................................................................................................... 112
Troubleshooting .................................................................................................................................. 112
11.4 Using Audio Booster .............................................................................. 112
11.5 Using MP3 Trimmer................................................................................ 113
Chapter 12 Programs on your Device 115
12.1 Programs on your Device....................................................................... 116
Programs in the Start Menu............................................................................................................. 116
Programs screen .................................................................................................................................. 116
12.2 Adding and Removing Programs.......................................................... 117
12.3 Adobe® Reader® LE................................................................................. 118
12.4 Calendar.................................................................................................. 118
Create appointments ......................................................................................................................... 118
View appointments ............................................................................................................................ 119
Send appointments............................................................................................................................ 119
12.5 Contacts .................................................................................................. 120
Add new contacts................................................................................................................................ 120
Organize and search contacts......................................................................................................... 121
Share contact information ............................................................................................................... 121
12.6 Comm Manager ...................................................................................... 122
12.7 Microsoft® Office Mobile ....................................................................... 123
12.8 Notes ....................................................................................................... 124
12.9 Tasks ........................................................................................................ 125
12.10 Voice Recorder...................................................................................... 126
12.11 ZIP.......................................................................................................... 127
Chapter 13 Managing Your Device 129
13.1 Copying and Managing Files................................................................. 130
13.2 Settings on Your Device ......................................................................... 131
Personal tab........................................................................................................................................... 131
System tab ............................................................................................................................................. 131
Connections tab................................................................................................................................... 132
13.3 Changing Basic Settings ........................................................................ 133
Date and time ....................................................................................................................................... 133
Regional settings................................................................................................................................. 133

14
Display settings.................................................................................................................................... 133
Device name.......................................................................................................................................... 133
Ringer settings...................................................................................................................................... 134
Alarms and notifications................................................................................................................... 134
Phone services...................................................................................................................................... 135
13.4 Using Task Manager ............................................................................... 136
13.5 Protecting Your Device........................................................................... 137
Protect your device with a password ........................................................................................... 137
Encrypt files on your storage card................................................................................................. 137
13.6 Managing Memory................................................................................. 138
13.7 Resetting Your Device ............................................................................ 138
Soft reset................................................................................................................................................. 138
Hard reset............................................................................................................................................... 139
Clear Storage......................................................................................................................................... 139
13.8 Windows Update .................................................................................... 140
13.9 Battery Saving Tips ................................................................................ 141
Appendix 143
A.1 Specifications ........................................................................................... 144
A.2 Regulatory Notices................................................................................... 145
Regulatory Agency Identifications................................................................................................ 145
Federal Communication Commission Interference Statement.......................................... 145
FCC Hearing-Aid Compatibility (HAC) Regulations for Wireless Devices ........................ 145
SAR Information................................................................................................................................... 146
Body-worn Operation ........................................................................................................................ 147
Telecommunications & Internet Association (TIA) Safety Information............................ 147
WEEE Notice .......................................................................................................................................... 148
RoHS Compliance................................................................................................................................ 148
A.3 Additional Safety Information................................................................ 148
When Driving........................................................................................................................................ 148
When Using Your Device Near Other Electronic Devices...................................................... 149
Turn Off Your Device Before Flying ............................................................................................... 150
Turn Off Your Device in Dangerous Areas................................................................................... 150
General Safety....................................................................................................................................... 150
Antenna Safety..................................................................................................................................... 150
Battery Safety........................................................................................................................................ 151
Adapter/Charger.................................................................................................................................. 151
Index 153

Chapter 1
Getting Started
1.1 Getting to Know Your Touch Phone and
Accessories
1.2 Installing the Battery, and Storage Card
1.3 Charging the Battery
1.4 Starting Up
1.5 Navigating on Your Device
1.6 Home Screen
1.7 Status Icons
1.8 Start Menu
1.9 Quick Menu
1.10 LED Alerts
1.11 Adjusting the Volume
1.12 When Connecting Your Device to a
Computer

16 Getting Started
1.1 Getting to Know Your Touch Phone and Accessories
Top panel
POWER
Press to turn off the display temporarily. To turn off
the power, press and hold for about 5 seconds.
For more information, see “Starting Up”in this chapter.
Speaker
Front panel
Earpiece
Listen to a phone call
from here.
Touch Screen
HOME
Press to return to the
Home screen.
See Chapter 3 for details.
BACK
Press to return to
the previous screen.
Navigation Control
See “Touch-sensitive navigation control”
later in this chapter for details.
TALK/SEND
Press to answer an incoming
call or dial a number.
During a call, press and hold
to toggle the speakerphone
on and off.
•
•
END
Press to end a call or return to
the Home screen.
Press and hold to lock the
device. (See“Long Press End Key”
under “Settings on your Device”
in Chapter 13 for details.)
•
•
Bottom panel
Sync Connector/Earphone Jack
Connect the supplied USB cable to synchronize information or plug in the
AC adapter to recharge the battery. You can also connect the supplied USB
stereo headset for hands-free conversation or for listening to audio media.
Microphone
Note When using the four buttons — HOME, BACK, TALK/SEND, and END — and the Navigation Control, please observe
the following precautions:
• Make sure to press on the icons of the four buttons for the best accuracy. When pressing on the Navigation
Control, make sure to press the outer areas near the ENTER button for directional control.
• For best results, press with your fingertip. Do not wear gloves.

Getting Started 17
Left panel Back panel Right panel
VOLUME UP
During a call or when playing
music, press this button to increase
the volume.
VOLUME DOWN
During a call or when
playing music, press
this button to lower the
volume.
Back Cover
Push the back cover upward
to remove it.
3.2 Megapixel Camera
See “Taking Photos and Videos”
in Chapter 11 for details.
Stylus
(See “Stylus” in this
chapter for details.)
Package Contents
The product package includes the following items and accessories:
Standard Lithium Ion Battery
AC Charger
Mini USB Cable
Multifunction Audio Cable
Spare Stylus
VZAccess Manager CD
Getting Started CD
RF Brochure
Read First Poster
Quick Reference Guide
Quick Start Guide
•
•
•
•
•
•
•
•
•
•
•

18 Getting Started
1.2 Installing the Battery, and Storage Card
Always turn off your device before installing or replacing the battery. You also need to remove the back cover
before you can install these components.
To remove the back cover
1. Make sure your device is turned off.
2. Hold the device with both hands and the front panel facing
down.
3. Push the back cover up with your thumb until it disengages
from the device and then slide it up to remove.
Battery
Your device comes with a rechargeable Lithium-ion or Lithium-ion polymer battery and is designed to use
only manufacturer-specified original batteries and accessories. Battery performance depends on many
factors, including network configuration, signal strength, the temperature of the environment in which you
operate your device, the features and/or settings you select and use, items attached to connecting ports, and
your voice, data, and other program usage patterns.
Battery life estimates (approximations):
Standby time: Up to 350 hours
Talk time: Up to 250 minutes
Note Battery life is subject to network and phone usage.
Warning! To reduce risk of fire or burns:
• Do not attempt to open, disassemble, or service the battery pack.
• Do not crush, puncture, short external contacts, or dispose of in fire or water.
• Do not expose to temperatures above 60oC (140oF).
• Replace only with the battery pack designated for this product.
• Recycle or dispose of used battery as stipulated by local regulations.
To install the battery
1. Align the battery’s exposed copper contacts with the
battery connectors inside the battery compartment.
2. Insert the contact’s side of the battery first and then gently
push the battery into place.
3. Replace the back cover.
Battery grip
To remove the battery
1. Make sure your device is turned off.
2. Remove the back cover.
3. The top right side of the battery has a protruding grip.
Lift the protruding grip to remove the battery.
•
•

Getting Started 19
Storage card
To have additional storage for your images, videos, music, and files, you can purchase a microSD™ card and
install it into your device.
To install a microSD card
Insert the microSD card into the slot with its gold contacts facing
down and push until it clicks in place.
Note To remove the microSD card, press it to eject it from the slot.
1.3 Charging the Battery
New batteries are shipped partially charged. Before you start using your device, it is recommended that you
install and charge the battery. Some batteries perform best after several full charge/discharge cycles.
To charge the battery
1. Connect the USB connector of the AC adapter to the
sync connector on your device.
2. Plug in the AC adapter to an electrical outlet to start
charging the battery.
Note Only the AC adapter and USB sync cable provided with your
device must be used to charge the device.
1
2
Charging is indicated by a “breathing” white light around the Navigation Control. As the battery is being
charged while the power is on, a charging icon ( ) also appears in the title bar of the Home screen.
After the battery has been fully charged, the Navigation Control LED shows a solid white light and a full
battery icon ( ) appears in the title bar of the Home screen.
For more information about the Navigation Control LED, see “LED Alerts” in this chapter.
Warning! • Do not remove the battery from the device while you are charging it using the AC or car adapter.
• As a safety precaution, the battery stops charging when it overheats.
1.4 Starting Up
After installing and charging the battery, you can now power on and start using your device.
Turn your device on and off
To turn on the power
1. Press and hold the POWER button for a few seconds.
2. When you turn on your device for the first time, a Quick Start Wizard guides you to set up regional
settings, date and time, and password. For more information about these settings, see Chapter 13.
After the Quick Start Wizard finishes, you may start using your device.
To turn off the power
1. Press and hold the POWER button for a few seconds.
2. Tap Yes when a message prompts you to choose whether or not to turn off the device completely.

20 Getting Started
Switch to Sleep mode when not in use
Press and immediately release the POWER button to turn off the display temporarily and switch your device
to Sleep mode. Sleep mode suspends your device to a low power state while the display is off in order to save
battery power.
Your device automatically goes into Sleep mode when you leave the device idle after a certain period of time.
You will still be able to receive messages and calls while your device is in Sleep mode. Pressing the POWER
button again, removing the stylus, or incoming calls/messages will wake up your device.
1.5 Navigating on Your Device
There are different ways you can navigate and interact with the interface of your device.
Finger-touch control
A quick and easy way to interact with the Today screen and the whole interface of your device is by touch.
Basically, the following are the types of actions, called finger gestures, you would use when interacting with
your device:
Touch or tap
When selecting items on the screen, such as the Today screen items, Start menu, programs and settings icons,
and large on-screen buttons, simply touch them with your finger. Apply some pressure with your finger pad
when touching an item on the screen.
Tapping means to touch lightly and quickly with your finger pad or fingertip. On screens that display smaller-
size items, you can more accurately select an item by tapping it with your fingertip or the stylus.
Swipe
To swipe means to drag your finger vertically or horizontally across the screen. The following are some
instances when you would use swiping:
Flipping on the Home screen
If you have TouchFLO 3D enabled, you can swipe your finger vertically on the Home screen to flip
through favorite contacts, messages, music albums, photos, and more. For more information, see“Using
the TouchFLO 3D Home Screen” in Chapter 3.
Scrolling
When browsing the contacts list, web pages, documents, and certain selection lists on the Home screen
(such as the All Programs list), slowly swipe your finger vertically across the screen to scroll. This allows
you to scroll by page and to view the content or available selections as you scroll.
The direction of swiping resembles the way you move a printed document as you are reading it. For
detailed instructions, see “Finger scrolling” in Chapter 3.
Slide
Sliding on the touch screen also involves dragging with your finger, but you need to press and hold your
finger with some pressure before you start to drag. While dragging, do not release your finger until you have
reached the target position.
The following are some instances when you would use sliding:
Switching between Home screen tabs
Slide your finger left and right to switch between the Home screen tabs. For more information, see
“Using the TouchFLO 3D Home screen“ in Chapter 3.
Advancing playback
In players that have a progress bar, such as the Home screen’s Music tab and Windows Media® Player
Mobile, slide your finger horizontally on the progress bar to advance forward or move backward in the
music or video you are playing.
For more information about the Home screen’s Music tab, see “Music” in Chapter 3.
For more information about Windows Media® Player Mobile, see “Using Windows Media® Player Mobile” in
Chapter 11.
•
•
•
•
