Huawei TP48200A User manual

TP48200A
V100R008C01
Installation Guide
Issue Draft B
Date 2014-01-20
HUAWEI TECHNOLOGIES CO., LTD.

Copyright © Huawei Technologies Co., Ltd. 2014. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and the
customer. All or part of the products, services and features described in this document may not be within the
purchase scope or the usage scope. Unless otherwise specified in the contract, all statements, information,
and recommendations in this document are provided "AS IS" without warranties, guarantees or representations
of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: [email protected]
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
i

About This Document
Overview
This document describes the procedure for installing the cabinet, boards, modules, and cables
when a DBS3900 uses a TP48200A cabinet. It also provides a hardware installation checklist.
Product Version
The following table lists the product versions related to this document.
Product Name Product Version
DBS3900 V100R008C01
The mapping single-mode base station version
is:
eNodeB: V100R006C01
Intended Audience
This document is intended for:
lBTS installation personnel
Organization
1 Change History
This chapter describes the changes in different document versions.
2 Preparing for Installation
This section describes the tools and meters that need to be available before the installation. It
also describes the skills and qualifications that the installation engineers must possess.
3 Information to Be Known Before the Installation
TP48200A
Installation Guide About This Document
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
ii

Familiarize yourself with this information as well as the cabinet interior and relevant space
requirements before installing the cabinets.
4 Installing Procedure
In this scenario, the TP48200A, components in the TP48200A, and related cables must be
installed onsite. In addition, optional components may be required according to the onsite
condition.
5 Checking Installed Components and Cables
Components and cables in the cabinet have been installed before delivery. You need to check
whether the components and cables are installed securely.
6 Installing the Cabinet
This section describes the procedures and precautions to be taken for installing the cabinet.
7 Installing a PGND Cable
A PGND cable connects the PGND screws on the cabinet and the ground bar to ensure proper
grounding of the cabinet.
8 Installing Components
This section describes the procedure for installing components of the TP48200A.
9 Installing Cables
This section describes how to install cables for the cabinet and other mandatory components.
10 Installation Checklist
After the cabinets and devices are installed, you need to check the installation items, installation
environment, and cable-related items.
11 Powering On a Base Station
This section describes how to power on a base station and handle power-on failures.
12 Follow-up Operations
This chapter describes the operations that need to be performed after the installation, which
include sealing the cable outlets on the cabinet and repainting the cabinet.
Conventions
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
TP48200A
Installation Guide About This Document
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iii

Symbol Description
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in equipment damage, data loss,
performance deterioration, or unanticipated results.
NOTICE is used to address practices not related to personal
injury.
Calls attention to important information, best practices and
tips.
NOTE is used to address information not related to personal
injury, equipment damage, and environment deterioration.
General Conventions
The general conventions that may be found in this document are defined as follows.
Convention Description
Times New Roman Normal paragraphs are in Times New Roman.
Boldface Names of files, directories, folders, and users are in
boldface. For example, log in as user root.
Italic Book titles are in italics.
Courier New Examples of information displayed on the screen are in
Courier New.
Command Conventions
The command conventions that may be found in this document are defined as follows.
Convention Description
Boldface The keywords of a command line are in boldface.
Italic Command arguments are in italics.
[ ] Items (keywords or arguments) in brackets [ ] are optional.
{ x | y | ... } Optional items are grouped in braces and separated by
vertical bars. One item is selected.
TP48200A
Installation Guide About This Document
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
iv

Convention Description
[ x | y | ... ] Optional items are grouped in brackets and separated by
vertical bars. One item is selected or no item is selected.
{ x | y | ... }*Optional items are grouped in braces and separated by
vertical bars. A minimum of one item or a maximum of all
items can be selected.
[ x | y | ... ]*Optional items are grouped in brackets and separated by
vertical bars. Several items or no item can be selected.
GUI Conventions
The GUI conventions that may be found in this document are defined as follows.
Convention Description
Boldface Buttons, menus, parameters, tabs, window, and dialog titles
are in boldface. For example, click OK.
>Multi-level menus are in boldface and separated by the ">"
signs. For example, choose File > Create > Folder.
Keyboard Operations
The keyboard operations that may be found in this document are defined as follows.
Format Description
Key Press the key. For example, press Enter and press Tab.
Key 1+Key 2 Press the keys concurrently. For example, pressing Ctrl+Alt
+A means the three keys should be pressed concurrently.
Key 1, Key 2 Press the keys in turn. For example, pressing Alt, A means
the two keys should be pressed in turn.
Mouse Operations
The mouse operations that may be found in this document are defined as follows.
Action Description
Click Select and release the primary mouse button without moving
the pointer.
TP48200A
Installation Guide About This Document
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
v

Action Description
Double-click Press the primary mouse button twice continuously and
quickly without moving the pointer.
Drag Press and hold the primary mouse button and move the
pointer to a certain position.
TP48200A
Installation Guide About This Document
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vi

Contents
About This Document.....................................................................................................................ii
1 Change History..............................................................................................................................1
2 Preparing for Installation.............................................................................................................2
2.1 Document Preparations...................................................................................................................................................3
2.2 Tools and Instruments....................................................................................................................................................3
2.3 Skills and Requirements for Onsite Personnel...............................................................................................................4
3 Information to Be Known Before the Installation..................................................................5
3.1 TP48200A Configurations..............................................................................................................................................6
3.2 Space Requirements.......................................................................................................................................................8
4 Installing Procedure....................................................................................................................10
5 Checking Installed Components and Cables.........................................................................12
6 Installing the Cabinet.................................................................................................................16
7 Installing a PGND Cable...........................................................................................................20
8 Installing Components...............................................................................................................22
8.1 Installing a Rectifier.....................................................................................................................................................23
8.2 Installing Storage Batteries...........................................................................................................................................23
8.3 Installing a BBU...........................................................................................................................................................27
9 Installing Cables..........................................................................................................................30
9.1 Cabling Requirements..................................................................................................................................................31
9.2 Cable Outlets................................................................................................................................................................37
9.3 Installing the AC Input Power Cable............................................................................................................................39
9.4 Installing BBU Equipotential Cables...........................................................................................................................42
9.5 Installing BBU Power Cables.......................................................................................................................................44
9.6 Installing RRU Power Cables.......................................................................................................................................45
9.7 Installing FE/GE Optical Fibers...................................................................................................................................48
9.8 Installing Monitoring Signal Cables.............................................................................................................................51
9.9 Installing CPRI Optical Fibers.....................................................................................................................................52
10 Installation Checklist................................................................................................................55
TP48200A
Installation Guide Contents
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
vii

11 Powering On a Base Station....................................................................................................58
12 Follow-up Operations...............................................................................................................62
TP48200A
Installation Guide Contents
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
viii

1 Change History
This chapter describes the changes in different document versions.
Draft B (2014-01-20)
This is draft B.
Compared with draft A (2013-12-30), this issue does not include any new information.
Compared with draft A (2013-12-30), this issue includes the following changes.
Topic Description
9.6 Installing RRU Power Cables Modified the installation procedure.
No information in draft A (2013-12-30) is deleted from this issue.
Draft A (2013-12-30)
This is draft A.
TP48200A
Installation Guide 1 Change History
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
1

2 Preparing for Installation
About This Chapter
This section describes the tools and meters that need to be available before the installation. It
also describes the skills and qualifications that the installation engineers must possess.
2.1 Document Preparations
This section lists the documents that must be obtained before the installation.
2.2 Tools and Instruments
This section lists the tools and instruments that must be obtained before installation.
2.3 Skills and Requirements for Onsite Personnel
Onsite personnel must be qualified and trained. Before performing any operation, onsite
personnel must be familiar with correct operation methods and safety precautions.
TP48200A
Installation Guide 2 Preparing for Installation
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2

2.1 Document Preparations
This section lists the documents that must be obtained before the installation.
Before the installation, familiarize yourself with related information in the following documents:
lSafety Precautions
lInstallation Reference
lTP48200A Hardware Description
lBBU Hardware Description
2.2 Tools and Instruments
This section lists the tools and instruments that must be obtained before installation.
Marker Phillips screwdriver (M3 to
M6)
Flat-head screwdriver (M3 to
M6)
Diagonal pliers
32 mm (1.26 in.)
combination wrench
Socket wrench Torque wrench
Power cable crimping tool RJ45 crimping tool Cable cutter
Rubber mallet Soldering iron Wire stripper
Hammer drill (Φ16) Heat gun Level
TP48200A
Installation Guide 2 Preparing for Installation
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3

Multimeter Measuring tape Vacuum cleaner
ESD wrist strap ESD gloves Torque screwdriver
Gloves Utility knife Hydraulic pliers
Torx screwdriver - -
2.3 Skills and Requirements for Onsite Personnel
Onsite personnel must be qualified and trained. Before performing any operation, onsite
personnel must be familiar with correct operation methods and safety precautions.
Before the installation, pay attention to the following items:
lThe customer's technical engineers must be trained by Huawei and be familiar with the
proper installation and operation methods.
lThe number of onsite personnel depends on the engineering schedule and installation
environment. Generally, only three to five onsite personnel are necessary.
TP48200A
Installation Guide 2 Preparing for Installation
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4

3 Information to Be Known Before the
Installation
About This Chapter
Familiarize yourself with this information as well as the cabinet interior and relevant space
requirements before installing the cabinets.
3.1 TP48200A Configurations
This section describes the hardware configurations in a TP48200A cabinet.
3.2 Space Requirements
This section describes the space required for maintaining the TP48200A cabinet and routing
cables.
TP48200A
Installation Guide 3 Information to Be Known Before the Installation
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5

3.1 TP48200A Configurations
This section describes the hardware configurations in a TP48200A cabinet.
The following figure shows the TP48200A interior.
Figure 3-1 Interior of the TP48200A
The following table describes the components in the TP48200A.
TP48200A
Installation Guide 3 Information to Be Known Before the Installation
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6

Table 3-1 Components in the TP48200A
No. Component Mandatory or
Optional
Maximum
Number of
Boards or
Modules
Configured in
a Single
Cabinet
Remarks
1DC PDU Mandatory 1 The DC PDU
distributes DC
power to
components in
the cabinet.
2 SMU02B Mandatory 1 The SMU02B
monitors
parameters
about each
running
component,
identifies the
running status,
and reports
alarms.
3 Battery switch Mandatory 1 The battery
switch is used to
manually and
temporarily
power on
batteries.
4 BBU Mandatory 3 The BBU
processes the
baseband
signals of the
base station.
5 AC PDU Mandatory 1 An AC PDU
feeds external
AC power into
the cabinet.
6 Storage
batteries
Mandatory 4 Storage
batteries
provide DC load
power when the
input AC power
is interrupted
and the rectifier
stops working.
TP48200A
Installation Guide 3 Information to Be Known Before the Installation
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7

No. Component Mandatory or
Optional
Maximum
Number of
Boards or
Modules
Configured in
a Single
Cabinet
Remarks
7UIM02C Mandatory 1 The UIM02C
supports eight
dry contact
outputs, nine
dry contact
inputs, and three
analog
parameter
inputs.
8 Rectifier Mandatory 1 The rectifier
converts 220 V
AC or 380 V AC
power into -48
V DC power.
9 MUX Mandatory 1 The MUX
connects CPRI
optical fibers.
10 Power splitter Optional 1 The power
splitter divides
one GPS signal
input into
multiple GPS
signals.
3.2 Space Requirements
This section describes the space required for maintaining the TP48200A cabinet and routing
cables.
The space requirements for installing a TP48200A cabinet are as follows:
lA minimum of 1500 mm clearance in front of the cabinet must be reserved.
lA minimum of 100 mm clearance behind the cabinet must be reserved.
lA minimum of 200 mm clearance on the left of the cabinet must be reserved.
lA minimum of 200 mm clearance on the right of the cabinet must be reserved.
lA minimum of 150 mm clearance on top of the cabinet must be reserved.
The following figure shows the space requirements for installing a TP48200A cabinet.
TP48200A
Installation Guide 3 Information to Be Known Before the Installation
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8

Figure 3-2 Space requirements
TP48200A
Installation Guide 3 Information to Be Known Before the Installation
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9

4 Installing Procedure
In this scenario, the TP48200A, components in the TP48200A, and related cables must be
installed onsite. In addition, optional components may be required according to the onsite
condition.
NOTE
When installing components or cables, take proper electrostatic discharge (ESD) protection measures, for
example, wear ESD gloves, to prevent electrostatic damage to the boards or electronic components.
The following flowchart describes the procedure for installing a TP48200A.
TP48200A
Installation Guide 4 Installing Procedure
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10

Figure 4-1 Installing procedure
TP48200A
Installation Guide 4 Installing Procedure
Issue Draft B (2014-01-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
