Huawei Ascend G 330 User manual

Welcome to HUAWEI
Quick Start Guide
HUAWEI Ascend G 330

1
Phone at a Glance
All the pictures in this guide are for your reference only. Your
phone's actual display features may be different to those
described here, depending on its software version.
Key Functions at Your Fingertips
• Press and hold to power on your mobile phone.
• When your mobile phone is powered on, press and
hold this button to display the options menu. You
can then choose to power off the phone or perform
shortcut operations.
• Press to lock the screen when your mobile phone
is active.
Touch to open the menu on an active screen.
Headset jack
Earpiece
Camera
Volume
key
Flash
Speaker
Charger/Data port
Power Key

2
Installing the SIM Card
There are two steps to install the SIM card:
1. Remove the battery cover.
2. Insert the SIM card.
Installing the microSD Card
Your mobile phone is already equipped with a large-volume built-in
embedded MultiMediaCard (eMMC). If you want to expand your
phone memory, you can also insert a microSD card.
1. Remove the battery cover.
2. Insert the microSD card into the card slot as shown in the
diagram.
• Touch to return to the Home screen.
• Touch and hold to display recently used
applications.
• Touch to return to the previous screen or exit the
application you are running.
• Touch to hide the keyboard.

3
Installing the Battery
1. Angle the edge labeled a (with the contacts) into the bottom end
of the battery compartment.
2. Push the edge labeled b into the compartment until the battery
clicks firmly into place.
Charging the Battery
Before charging the battery, ensure that it has been properly installed
on your phone.
1. Connect the USB cable that came with your mobile phone to
the charger.
2. Connect the other end of the USB cable to your mobile phone.
Then, to start charging, plug the charger into an electrical outlet.
If you charge your mobile phone while it is powered on, the battery
icon on the notification bar indicates the charging status. When the
battery icon changes to , your mobile phone is fully charged.
b
a

4
Status Indicator
The color of the status indicator tells you the status of your mobile
phone's battery.
Touchscreen Actions
Using your finger on the touchscreen, you can operate your phone
conveniently.
Status Indicator
Green: Fully charged (when connected to charger).
Orange: Charging in progress (when connected to charger).
Red: Battery low.
Touch & hold Touch Double touch
Rotate Flick Drag
