Huawei G3620 User manual

G3620
GSM Mobile Phone
User Guide

Copyright © Huawei Technologies Co., Ltd. 2011. All
rights reserved.
Trademarks and Permissions
, , and are trademarks or
registered trademarks of Huawei Technologies Co., Ltd.
Other trademarks, product, service and company names mentioned
are the property of their respective owners.
NO WARRANTY
THE CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT
AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY
KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED
TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE
ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO
CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY
SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES,
OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR
ANTICIPATED SAVINGS.

1
Features marked with "optional" are optional. These features
may vary according to service providers. For details, contact
your service provider.
1 Getting to Know Your Phone
Your Phone
The following figure shows the appearance of your phone.
9
10
11
12
13
14
1
2
3
4
5
6
7
89
1 Torch 8 Microphone
2 Earpiece 9 Number keys
3 Screen 10 End/Power key
4 Navigation keys 11 Music key

2
5 Left soft key 12 Right soft key
6 Call/Answer key 2 13 Confirm key
7 Call/Answer key 1 14 Charger jack
Keys and Functions
Press…
To…
Make a call from subscriber identity module (SIM)
card 1.
Answer a call.
View call logs for SIM card 1 in standby mode.
Make a call from SIM card 2.
Answer a call.
View call logs for SIM card 2 in standby mode.
Power the phone on or off (press and hold the key
for about 3 seconds).
End or reject a call.
Return to standby mode.
Access the audio player in standby mode.
Access the main menu in standby mode.
Select the option displayed in the lower left corner of
the screen.
Access Contact list in standby mode.
Select the option displayed in the lower right corner
of the screen.
Access the main menu in standby mode.
Confirm a selection.

3
Press…
To…
Access Calendar (press ) in standby mode.
Access Alarm (press ) in standby mode.
Access User profiles (press ) in standby mode.
Access Write message (press ) in standby mode.
Increase the volume (press ) during a call.
Decrease the volume (press ) during a call.
through
Enter numbers, letters, and symbols.
Call voicemail in standby mode (press and hold the 1
key for about 3 seconds).
Speed-dial phone numbers in standby mode (press
and hold the 2–9keys for about 3 seconds).
Select an option labeled with the corresponding
number.
Enter * (press the key once), + (press the key twice), P
(press the key three times), and W(press the key four
times) in standby mode.
Display the symbol list in editing mode.
Turn the flashlight on or off in standby mode (press
and hold the key for about 3 seconds).
Enter #.
Switch between text input methods in editing mode.
Lock the keypad in standby mode (press and hold the
key for about 3 seconds).

4
Screen Icons
Icon Indicates…
Signal strength.
General Packet Radio Service (GPRS) signal.
Ring only enabled.
(optional) Vib. only enabled.
(optional) Vib. and ring enabled.
(optional) Vib. then ring enabled.
Silence profile activated.
Headset profile activated.
Missed calls.
Call forwarding enabled.
New text messages.
New multimedia messages.
New push messages.
Alarms enabled.
Keypad locked.
Battery level.
(optional) Bluetooth activated.

5
2 Getting Started
Installing the SIM Cards and the Battery
You can install up to two SIM cards in the phone at the same time.
When installing a SIM card, ensure that the gold contact area faces
down, and that the beveled edge of the SIM card aligns with that of
the SIM card slot.
Removing the Battery and the SIM Cards
Before removing the battery and the SIM cards, ensure that your
phone is powered off.

6
Installing the microSD Card
Before installing or removing a microSD card, power the
phone off. When the phone is powered back on, it indicates
whether the microSD card has been installed correctly.
You can expand your phone's memory capacity by installing a
microSD card. When installing a microSD card, ensure that the gold
contact area faces down.
Charging the Battery
1. Connect the charger to an AC power socket.
2. Connect the charger to the charger jack on the phone.
3. Wait until the battery is completely charged.
During the charging process, the charging icon is displayed in
animation. When the charging icon becomes static, the battery is
fully charged.
4. Disconnect the charger from the phone.
5. Disconnect the charger from the AC power socket.
Navigating the Main Menu
1. In standby mode, press (Menu) or .

7
2. Press to scroll to the desired application and press
(OK) or to access the application.
3. Press or to scroll to the desired option, and press
(OK) or to access the option.
4. Press (Back) to return to the previous menu.
To return to standby mode, press .
Phone Lock
The phone lock protects your phone from unauthorized use. By
default, the phone lock is disabled. Once the phone lock is enabled,
you must enter the phone unlock code each time you power on the
phone. The preset phone unlock code is 1234. You can change this
code into any numeric string between four and eight digits.
If you forget the phone unlock code, contact your service provider.
PIN and PUK
The personal identification number (PIN) protects your SIM card from
unauthorized use. The PIN unblocking key (PUK) unlocks a blocked
PIN. Both the PIN and the PUK are provided with the SIM card. For
details, contact your service provider.
To enable the PIN lock:
1. Select Menu > Settings > Security settings > SIM1 or SIM2
security >PIN lock.
2. Enter the PIN and press (OK).
If you enter the incorrect PIN a specified number of times, the phone
prompts you to enter the PUK.

8
If you enter the incorrect PUK a specified number of times, the SIM
card will become permanently invalid. If this occurs, contact your
service provider for a new SIM card.
Locking and Unlocking the Keypad
To lock the keypad, press and hold in standby mode. To
unlock the keypad, press (Unlock) and .
If the Auto keypad lock function is enabled and the phone is in
standby mode for a preset period, the phone automatically locks the
keypad.
When the keypad is locked, you can press and
to answer a call or make an emergency call.
My Files
The My Files manages multimedia files stored on the phone and its
microSD card. Using My Files, you can view the size and creation
date of an ebook, image, or audio clip and open a multimedia file.
3 Voice Services
Making a Call
1. In standby mode, enter the phone number.
To make an international call, press twice to enter the
plus sign (+). Then enter the country or region code, area code,
and phone number.

9
To call an extension number, enter the phone number, press
three times to enter P, and enter the extension number.
2. Press or to dial the number.
3. Press to end the call.
You can also make a call from the call log, contacts, or
messaging screen.
During a call, you can press or to adjust the
volume.
Answering a Call
When there is an incoming call, you can:
Press or to answer the call.
Press or (Reject) to reject the call.
Press (Options) and select Answer to answer the call.
Press (Mute) to mute the speaker, and press
(Reject) again to reject it.
Press (Answer) to answer it.
If the Any Key answer function is enabled, you can press any key
except , , , and to answer a call.

10
4 Text Input
Changing the Text Input Mode
The current text input mode indicator is displayed in the upper left
corner of the screen. You can press to switch between text
input modes.
Indicator Text Input Mode
ABC and abc Multi-tap input modes
s ABC and s abc Predictive input modes
123 Number input mode
Press (Clear) once to delete the last character
entered or press and hold (Clear) for about 3
seconds to delete all the characters.
In any input mode except the number input mode and the
predictive input mode, press once to enter a space
and twice to enter 0.
Entering a Word
To enter a word in multi-tap input mode, repeatedly press the
keys labeled with the letters that spell the word until the desired
letters are entered.
To enter a word in predictive input mode:

11
1. Press each key once according to the spelling sequence of the
desired word.
The phone displays words associated with the sequence entered.
2. Press the navigation keys to scroll to the desired word.
3. Press to enter the word.
Entering a Digit
In number input mode, press the number key labeled with the
desired digit.
Entering a Symbol
1. Press to display the symbol list.
2. Press to scroll to the desired symbol.
3. Press to enter the symbol.
5 Messages
Writing and Sending a Text Message
1. Press (Menu) and select Messages > Write
message >SMS.
2. Write the message.
3. Press (Options), select Send to, and enter the
recipient's phone number or add a recipient from Contacts.
To add multiple recipients, repeat this step.
4. Scroll to the desired recipient and press (Options) for
the following options:

12
Send: sends the message to the recipient.
Edit recipient: allows you to change the recipient.
Remove recipient:removes the recipient from receiving the
message.
Remove all recipients: removes all recipients from receiving the
message.
Save to Drafts: saves the message to Drafts.
Writing and Sending a Multimedia Message
1. Press (Menu) and select Messages > Write message >
MMS.
2. Edit the content of the message.
You can add images, audio clips, and attachments to the
message. You can also preview the message add slides to the
message, and set the playing interval between two slides.
3. Press (Options), select Send to, and enter the
recipient's phone number or add a recipient from Contacts.
To add multiple recipients, repeat this step.
4. Scroll to the desired recipient and press (Options) for
the following options:
Send: sends the message to the recipient.
Send options: allows you to set the sending options.
Edit recipient: allows you to change the recipient.
Remove recipient:removes the recipient from receiving the
message.
Remove all recipients: removes all recipients from receiving the
message.
Change to CC: copies the message to the recipient.
Change to Bcc: blind copies the message to the recipient.

13
Save to Drafts: saves the message to Drafts.
Contact your service provider to determine the availability of
the Multimedia Messaging Service (MMS) and how to
subscribe to this service.
Open multimedia messages with caution. Objects in
multimedia messages may contain viruses and malicious
software that can damage your phone.
To configure the network settings provided by your service
provider, select Menu > Network Services > Data account >
Add account, and then select Messages> Message setting>
MMS> Data account > SIM1 or SIM 2 > OK.
6 Contacts
Creating a Contact
1. Press (Menu) and select Contacts > Add new contact.
2. Select To SIM1, To SIM2, or To phone for saving the contact.
3. Edit the contact information.
4. Press and (Yes) to save the contact.
Searching for a Contact
1. Press (Menu) and select Contacts.
2. Enter the first letter of the contact name in the search bar.
Contacts who have names that start with this letter will be
displayed.

14
7 Multimedia
Camera
1. Press (Menu) and select Multimedia > Camera to
launch the camera.
2. Press (Options) to view images or configure the
relevant settings.
3. Press to take a picture.
4. Press (Options) to send or delete the picture, or press
(Back) to save the picture.
Image Album
1. Press (Menu) and select Multimedia > Image Album to
launch the image album.
2. Press to view images.
3. Press (Options) for options such as View, Image
information, Browse style, Send, Use as, Rename, Delete, Sort by,
Delete all, and Storage.
Audio Player
1. Press (Menu) and select Multimedia > Audio Player.
2. Select an audio clip.
3. Press to play the clip.
When the clip is being played:

15
Press to pause or continue.
Press or to adjust the volume.
Press and hold or to fast-forward or rewind the clip.
Press or to go back to the previous clip or advance to the
next one.
4. If background playback is enabled, press (Back) to exit
the audio player screen and play the audio clip in the
background.
Video Recorder
1. Press (Menu) and select Multimedia > Video recorder
to launch the video recorder.
2. Press (Options) to configure the relevant settings.
3. Press to start recording a video clip.
4. Press and (Yes) to save the video clip.
Video Player
1. Press (Menu) and select Multimedia > Video player to
launch the video player.
2. Select a video clip.
3. Press to start playing the video clip.
4. Press (Options) for options such as Play, Send, Rename,
Delete, Delete all, Sort by, and Storage.

16
FM Radio (Optional)
If your phone comes with a built-in antenna, you can listen to the
radio without a headset. If the headset is included in the product
package, you can also use the headset to listen to the FM radio.
If your phone does not support the built-in antenna, you should use
the headset to listen to the FM radio. Connect the compatible
headset to the phone before accessing the FM radio. The headset
functions as an antenna. To ensure the best possible reception and
therefore audio quality, do not unplug the headset or bend the
headset cable.
1. Press (Menu) and select Multimedia > FM radio to
access the frequency modulation (FM) radio.
2. On the FM radio screen:
Press to turn the FM radio on or off.
Press or to adjust the volume.
Press or to switch to the previous or next channel.
Press (Options) for options such as Channel list,
Manual input, Auto search, Settings, Sound recorder, Append,
and File list.
Sound Recorder
1. Press (Menu) and select Multimedia > Sound recorder.
2. Press (Options) and select New record.
While recording, you can press (or ) to pause or
continue.
3. Press (Stop) to stop recording.

17
8 Bluetooth (Optional)
Your phone supports Bluetooth. You can synchronize data between
your phone and a personal computer (PC), exchange data with other
Bluetooth devices, and connect a Bluetooth headset to your phone.
You can turn on Bluetooth by configuring Bluetooth settings.
Connecting a Bluetooth Headset to Your
Phone
1. Select Menu > Organizer> Bluetooth > Activate Bluetooth> On to
turn on Bluetooth.
2. Select Search hands-free device to search for available Bluetooth
headsets.
3. Scroll to the desired Bluetooth headset and press (Pair).
4. Enter the password to pair the Bluetooth headset with your
phone.
When the Bluetooth headset is connected to your phone, the
headset icon is displayed on the standby screen, indicating that you
can use the headset.
A Bluetooth headset is not included in the product package
and must be purchased separately.
Transferring Data
1. Select Menu > Organizer> Bluetooth > Activate Bluetooth> On to
turn on Bluetooth.
2. Select Search for Bluetooth device to search for available
Bluetooth devices.

18
3. Scroll to the desired Bluetooth device and press (Pair).
When you pair your phone with the device for the first time, a
password is required.
4. Exchange data between your phone and the Bluetooth device.
9 WAP
You can use your phone to access Wireless Application Protocol
(WAP) sites and use WAP-based services. To browse WAP pages, you
must subscribe to the corresponding service from your service
provider and configure your phone's relevant settings.
For details about services and charges, contact your service provider.
Network Settings
To access the WAP sites on your phone, you need to set your data
account and WAP parameters first.
Setting the Connection Profile
1. Press (Menu) and select Network Services > Data
account.
2. Select the network type, press (Options), and select
Add account.
3. Press (OK) and select Yes to save the settings.
