Huawei Y210 C User manual

Welcome to HUAWEI
Quick Start Guide
HUAWEI Y210 C
Model: H868C
TracFone part number: XXXXXXXX

1
Phone at a Glance
All the pictures in this guide are for your reference only. Your phone's
actual display features may be different to those described here,
depending on its software version.
Key Functions at Your Fingertips
• Press and hold to power on your mobile phone.
• When your mobile phone is powered on, press and hold this
button to display the options menu. You can then choose to
power off the phone or perform shortcut operations.
• Press to lock the screen when your mobile phone is active.
Touch to open the menu on an active screen.
• Touch to return to the Home screen.
• Touch and hold to display recently used applications.
Volume
key
Earpiece
Charger/
Data port
Speaker
Power key Headset jack
Back
Home
Menu
Microphone
Camera

2
Installing the microSD™ Card
Your mobile phone is already equipped with a large-volume built-in embedded
MultiMediaCard (eMMC). If you want to expand your phone memory, you can
also insert a microSD card.
1. Remove the battery cover.
2. Insert the microSD card into the card slot as shown in the diagram.
Installing the Battery
1. Angle the edge labeled a (with the contacts) into the bottom end of the
battery compartment.
2. Push the edge labeled b into the compartment until the battery clicks
firmly into place.
• Touch to return to the previous screen or exit the application
you are running.
• Touch to hide the keyboard.
12
a
b

3
Charging the Battery
Before charging the battery, ensure that it has been properly installed on your
phone.
1. Connect the USB cable that came with your mobile phone to the charger.
2. Connect the other end of the USB cable to your mobile phone. Then, to
start charging, plug the charger into an electrical outlet.
If you charge your mobile phone while it is powered on, the battery icon on the
notification bar indicates the charging status. When the battery icon changes
to , your mobile phone is fully charged.
Status Indicator
The color of the status indicator tells you the status of your mobile phone's
battery.
Status Indicator
Green: Fully charged (when connected to charger).
Orange: Charging in progress (when connected to charger).
Red: Battery low.

4
Touchscreen Actions
Using your finger on the touchscreen, you can operate your phone
conveniently.
Home Screen
You can set up the Home screen according to your own preferences, for
example by adding a shortcut or a widget to your Home screen, changing the
wallpaper, or setting the number of Home screen extensions.
To return to the Home screen from any of its extensions, press .
When a new notification icon appears on the notification bar, place your finger
on the notification bar and flick down to open the notification panel.
Drag
TouchTouch & hold Double touch
Rotate Flick
Flick your finger left or right across the Home screen.
10:23

5
Adding a New Home Screen Item
1. On the Home screen, touch to display the application list.
2. Press and hold an application icon, and then drag the icon to a blank area
on the Home screen.
Removing an Icon from the Home Screen
1. Touch and hold an item on the Home screen that you want to remove until
your mobile phone vibrates.
2. Without lifting your finger, drag the item to the trash can. Wait until the
item and the trash can turn red.
3. Release the item.
Adding a Contact
1. In the contact list, touch .
2. From the screen displayed, create a contact in your mobile phone, or your
account. Add a new account if you do not have one.
3. Enter the contact's name, and then add detailed information such as
phone numbers and address.
4. Touch DONE to save the contact information.
To save a contact from your call log, touch and hold the desired phone
number to display the options menu, and then touch Add to contacts .
Making a Call with the Phone
Application
1. On the Home screen, touch > Phone . If the dialer is not displayed,
touch .
2. Enter the phone number.
3. Touch to initiate the call.

6
Creating and Sending a Multimedia
Message
You can use multimedia messages to make everyday communications very
special. You can record a message and send it as an audio file, for example,
sing "Happy Birthday" and send it to a friend, or send a slideshow of
photographs of a special event. The possibilities are enormous.
1. Touch > Messaging , then .
2. Enter a phone number in the To field, or touch to select a contact
from People .
3. Touch the composition text box to start composing your message.
4. Touch to attach a picture, an audio file, or a video clip to the
message.
5. When you are ready to send the message, touch Send MMS .
Connecting Internet
Get online using your phone's Wi-Fi to save your money.
Turning On Wi-Fi
®
1. Touch > Settings .
2. Under WIRELESS & NETWORKS , touch the button next to Wi-Fi .
Basic Operations
Touch > Browser to open the home page.
When known or open Wi-Fi networks and mobile data networks are
available at the same time, your phone will preferably select a Wi-Fi
network for Internet access.
Touch on the upper section of the screen, and all web pages currently
open are displayed. You can:
• Touch one page to enlarge it.
• Touch the cross sign (×) to close that page.
• Touch (+) to open a new browser window.

7
Opening a Webpage
1. In a browser window, touch the URL field at the top of the screen.
2. Use the keyboard to enter a webpage address. You can touch to
enter the web page address by voice.
3. As you enter the address, matching webpage addresses will appear on
the screen. If you see the address you want, touch it and go directly to
that webpage or complete entering your desired webpage.
Turning Off Your Data Service
When you are not using your data service, to eliminate unwanted data traffic,
you can turn it off quickly.
1. Open the notification bar.
2. Touch at the top of the screen to switch data services on or off.
Play Store
Android Play Store provides direct access to applications and games which
you can download and install on your phone.
Opening Play Store
1. On the Home screen, touch > Play Store .
2. When you open Play Store for the first time, the Google Play Terms of
Service window will appear. Touch Accept to continue.
Installing an Application
1. In the Play Store , select a category, and then touch the application you
want to download.
2. To install the application, touch Download (if it is free) or touch the button
with its price (if it is not free), and confirm your download or purchase.
After the application has been downloaded and installed on your mobile
phone, the content download icon appears in the notification bar.
If you want to install a non-Play Store application, touch > Settings
> Security , and then select the Unknown sources check box to allow
installation of the non-Play Store application.

8
Uninstalling an Application
You cannot uninstall the applications that are pre-installed on the system.
1. On the Settings screen, touch Apps .
2. Touch an application, and then touch Uninstall .
Opening Your Camera
You can take and share photos using the camera. Your camera supports
multiple capture modes and photo effects. After taking a picture, access the
Gallery to view it. For information on how to share photos and videos, see the
User Guide.
Using the microSD™ Card as a USB
Mass Storage
1. Connect your mobile phone to your PC with the USB cable provided.
Your PC will detect the microSD card as a removable storage device.
2. Open the notification bar, and then touch USB connected .
3. Touch Turn on USB storage in the dialog box that opens to confirm that
you want to transfer files.
You can now transfer files from your PC to your mobile phone's microSD card.
Thumbnail of last
photo. Touch to
preview the photos
or videos.
Touch to take a
photo.
Touch to customize the camera settings.
Drag up to take
photos, drag down
to record videos.
AutoAuto

9
Synchronizing Information
Some applications on your mobile phone give you access to the same
personal information that you can add, view, and edit on your computer. If you
add, change, or delete your information in any of these applications on the
web, the updated information also appears on your mobile phone.
This is made possible through over-the-air data synchronization. The process
occurs in the background and does not interfere with use of your mobile
phone. When your phone is synchronizing, a data synchronization icon will be
shown in the notification bar.
For more information, see the User Guide.
FAQs
How Can I Use a microSD Card to Import Contacts to My Phone from
Another Phone?
Your mobile phone supports contact files in the .vcf format only.
1. Save the contacts you want to import to your mobile phone to a microSD
as a .vcf file.
2. Insert the microSD card into your mobile phone and find the .vcf file using
File Manager .
3. Touch the .vcf file. The mobile phone displays a message asking whether
you want to import the contacts.
4. Touch OK to import the contacts.
Compatibility problems may occur with .vcf files created by different
phones, and certain contact information may be lost when contacts are
imported.
How Do I Disable Automatic Change of Screen Orientation When
Rotating My Phone?
On the Home screen, touch > Settings > Display , and then clear the
Auto-rotate screen check box to disable this function.
How Do I Set an Unlock Pattern?
On the Home screen, touch > Settings > Security > Screen lock >
Pattern .
