Huawei Y625-U21 Technical specifications

HUAWEI Y625 Smart Phone
Product Description
For Y625-U13、Y625-U21、Y625-U32、Y625-U43
Version V1.5
Date 2015-01-13
Huawei Technologies Co., Ltd

Version1.5(2015-01-13) Commercial in Confidence Page 2 of 12
Huawei Technologies Co., Ltd. provides customers with comprehensive technical support and service.
Please feel free to contact our local office or company headquarters.
Huawei Technologies Co., Ltd.
Address: Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website: http://www.huawei.com
Email: [e-mail]
Copyright © Huawei Technologies Co., Ltd. 2012.All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarks and Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute the warranty of any kind, express or implied.

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 3 of 12
History
Issue Details Date Author Approved by
V1.0 Initial draft version completed. 2014-10-05 Chenlizhong
V1.1 1. 2.1 Hardware add SIM1 support
WCDMA/GSM, SIM2 support GSM
only.
2. 2.1 Hardware Certification: sorted the
Certifications according to the projects.
2014-10-08 Chenlizhong
V1.2 1. Support DRM. 2014-11-06 Chenlizhong
V1.3 1. Weight (with battery) is about 160g. 2014-11-06 Chenlizhong
V1.4 1. Change “Bluetooth v4.0 LE” to
“Bluetooth v4.0”
2. Operating temperature change to: 0℃
~ +35℃
2014-12-19 Chenlizhong
V1.5 1. Remove Ascend strings. 2015-01-13 Chenlizhong

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 4 of 12
Contents
1 Overview…………………………………………………………………………………………5
1.1 Overview…………………………………………………………………………………………………..5
1.2 ID/MD……………………………………………………………………………………………… ..6.
2 Technical Specifications………………………………………………………………………7
2.1 Hardware…………………………………………………………………………………………………..7
2.2 Software…………………………………………………………………………………………………...9
3 Packing List...................................................................................................................12

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 5 of 12
1 Overview
1.1 Overview
HUAWEI Y625 are Android powered smart mobile phones developed by Huawei
with the latest Android 4.4 Kitkat OS from Google™. All including in a slim touch
phone:
•LatestAndroid 4.4 kitkat OS
•Qualcomm MSM8212, Quad core, 1.2 GHz, Cortex A7 CPU
•High speed HSDPA +/HSUPA network up to 42Mbps/5.76Mbps
•8 MP Auto Focus rear camera with LED Flash+ 2MP Fix Focus front camera.
Support Panorama, Audio note, Andio control, Water mark, Filter, Touch to
capture, burst shoot etc.
•5.0 inch FWVGA(854X480) IPS screen, full touch screen supporting 2 point
multi-touch
•Y625-U13, Y625-U43 support UMTS: 850/1900/2100 MHz
Y625-U21, Y625-U32 support UMTS: 900/2100 MHz
All of them support GSM/GPRS/EDGE: 850/900/1800/1900 MHz
•WCDMA+GSM , 3FF size SIM card standard (Micro sim card)
Y625-U13, Y625-U21 has only one SIM Card slot, but Y625-U32, Y625-U43
support Dual-SIM Card slot and dual standby
•Wi-Fi 802.11 b/g/n, support Wi-Fi hotspot, Wi-Fi direct
•Bluetooth v4.0
•GPS/AGPS
•G-sensor for auto-rotate
•Proximity sensor for auto LCD backlight turn-off
•Ambient light sensor for auto LCD backlight adjusting
•2000mAh Battery
•EMUI2.3 Lite
•Abundant Google applications(preinstalled according to google’s policy)

HUAWEI U9000 Smart Phone
Version1.
5
(201
5
-
01
-
13
)
Commercial
in Confidence
Page
6
of
12
1.2 ID
Figure 1 ID with black and white color

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 7 of 12
2 Technical Specifications
2.1 Hardware
Table 2-1 lists the hardware specifications.
Table 2-1 Hardware specifications
Item Specifications
Shape Full Touch Bar
LCD Size: 5.0 inch IPS LCD
Resolution: FWVGA 854×480
Colors: 16M colors
Full touch screen supporting 2 point multi-touch
Colors Black and White
Dimensions 142mm（L）×72.6mm（W）×9.6mm（H）
Weight (with
battery) About 160g
Processor Qualcomm MSM8212, Quad core, 1.2 GHz, Cortex A7 CPU
Memory ROM: 4GB eMMC, User available is about 1.6GB
RAM: 1GB DDR2
Camera Rear Side: 8 MP Auto Focus with LED Flash
Front Side: 2MP Fix Focus
FM Built-in FM
GPS GPS/AGPS
Bluetooth Bluetooth v4.0
Sensor G-sensor, proximity, ambient light sensor.
NFC Not Support.
Wi-Fi 802.11b/g/n, support Wi-Fi hotspot, Wi-Fi direct
USB USB2.0 High Speed; 480Mbps

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 8 of 12
Item Specifications
Device
Control Capacitive soft keys: Back, Home, Menu
Physical Power key, Volume key, headset key
Technical
Standards WCDMA/HSDPA+/ HSUPA: 3GPP Release 8
GSM/GPRS/EDGE: 3GPP R6
Frequency
band GSM:
GSM 850 MHz: 824–849 MHz (UL), 869–894 MHz (DL)
GSM 900 MHz: 880–915 MHz (UL), 925–960 MHz (DL)
GSM 1800 MHz: 1710–1785 MHz (UL), 1805–1880 MHz (DL)
GSM 1900 MHz: 1850–1910 MHz (UL), 1930–1990 MHz (DL)
UMTS:
1) Y625-U21, Y625-U32:
UMTS Band VIII[900 MHz]: 880-915 MHz (UL), 925-960 MHz
(DL)
UMTS Band I [2100 MHz]: 1920–1980 MHz (UL), 2110–2170
MHz (DL)
Or
2) Y625-U13, Y625-U43:
UMTS Band V [850 MHz]: 824–849 MHz (UL), 869–894 MHz
(DL)
UMTS Band II[1900 MHz]: 1850-1910 MHz (UL), 1930-1990
MHz (DL)
UMTS Band I [2100 MHz]: 1920–1980 MHz (UL), 2110–2170
MHz (DL)
Network
Access 3G-WCDMA：Radio Bearer UL/DL：384Kbit/s
HSDPA+：DL data rate：42Mbit/s，UL data rate：5.76Mbit/s
GPRS：Multi-slot classes：Class 12
EDGE：Multi-slot classes：Class 12
SIM/USIM
card interface Standard 3FF size 6-pin Micro SIM card interface
Supporting the 1.8/3V SIM card
Single-SIM card phone: Y625-U13, Y625-U21
Dual-SIM Card phone: Y625-U32, Y625-U43 supporting dual card
dual standby. SIM1 support WCDMA/GSM, SIM2 support GSM
only.
External
interfaces Standard Micro USB
Micro SD Card slot
3.5mm headset jack

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 9 of 12
Item Specifications
External
Memory
support
Micro SD Card (up to 32GB)
Temperature Operating temperature: 0℃~ +35℃
Store temperature: -20℃~ +70℃
Relative
humidity Working humidity: 5% - 95%
Battery 2000mAh, Removable:
Standby time, 2G: up to 310hrs 3G: up to 250hrs
Talking time, 2G: up to 450 mins 3G:up to 500 mins
Standby time and Talking time depends on the usage and
network status
Charging Time: <4 hours with supplied charger
RF Maximum
transmitter
power
WCDMA 900/2100 MHz: +24dBm (Power Class 3)
WCDMA 850/1900/2100: +24dBm (Power Class 3)
GSM/GPRS 850/900MHz: +33dBm (Power Class 4)
GSM/GPRS 1800MHz/1900MHz: +30dBm (Power Class 1)
RF Static
sensitivity WCDMA 850 MHz: better than -104 dBm/3.84 MHz
WCDMA 900 MHz: better than -104 dBm/3.84 MHz
WCDMA 1900 MHz: better than -106 dBm/3.84 MHz
WCDMA 2100 MHz: better than -106 dBm/3.84 MHz
GSM 850/900/1800/1900 MHz: better than -104.5 dBm/200 KHz
Antenna Built-in antenna
Power supply 100V-240V, 50/60Hz
Certification Y625-U13: CTS, FCC, BQB, Wi-Fi, PI966, WHQL, ROSH
Y625-U21: CTS, CE, GCF, BQB, Wi-Fi, PI966, WHQL,
ROSH/Reach
Y625-U32: CTS, CE, BQB, Wi-Fi, PI966, WHQL, ROSH
Y625-U43: CTS, FCC, BQB, Wi-Fi, PI966, WHQL, ROSH

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 10 of 12
2.2 Software
Table 2-2 lists the software specifications.
Table 2-2 software specifications
Item Specifications
Operating
System Android™ 4.4(KitKat)
Multi Language Support 46 Languages:
Simplified Chinese, Hongkong Traditional Chinese,
Taiwan Traditional Chinese, US English,
Latin American Spanish, Brazil Portuguese,
European Spanish, European Portuguese, French,
German, Russian, Italian, Swedish, Norwegian, Danish,
Czech, Hungarian, Slovak, Polish, Romanian, Greek,
Serbia, Bosnian, Macedonian, Bulgarian, Finnish,
Estonia, Latvia, Lithuania, Slovenia, Croatian, Ukraine,
Turkish, Vietnamese, Indonesian, Arabic, Farsi, Dutch, Thai,
Malaysia, Catalonia, Hindi, United Kindom English, Burma,
Korean, Hebrew
Input method Touchpal IME , Android™ keyboard
UI EMUI2.3 Lite(Part of the EMUI2.3 module)
Browser Android default browser, based on Android Webkit
Messaging SMS and MMS
Email POP3/IMAP/Exchange, based on Android default email
MultiMedia Audio encode：AMR
Audio decode：WAV，MP3，AMR，MIDI，Vorbis，AAC，AAC+，
FLAC, OGG, PCM
Audio file format: MP3，WAV，OGG，MID，AMR
Video encode：MP4，3GP
Video decode：MP4，H.264，H.263, VC-1，DIVX，XVID，RV,
MKV, WebM
Video file format：MP4，3GP
Image format: BMP, PNG, GIF, JPG
System Update HOTA
SD card

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 11 of 12
Item Specifications
Camera & Video
Resolution Rear side camera:
Photo: 8M (3264X2448) (4:3), 6M (3264X1836) (16:9), 5M
(2592X1944) (4:3), 3.8M (2592X1456) (16:9), 0.3M (640x480)
(4:3), Support Panorama, Audio note, Andio control, Water
mark, Filter, Touch to capture, burst shoot etc.
Video: HD 720P(1280X720), VGA (640X480),
QVGA(320X240), MMS (176X144)
Front side camera:
Photo: 2M (1600x1200) (4:3), 1.5M (1600×900) (16:9), 0.9M
(1280×720) (16:9), 0.3M (640x480) (4:3)
Video: HD 720P(1280X720), VGA (640X480),
QVGA(320X240), MMS (176X144)
Ring tone Huawei ringtone
DRM support
USB function MTP
PTP
USB Tethering
PC suite
Charging
Preinstall
Applications
EMUI 2.3 lite:
Launcher, Screen lock, Camera, Gallery, Music, File Manager,
Calender, Notes, Themes, Caculator, Flashlight, Video,
Backup, Weather, Wi-Fi Direct, HOTA
Android Native:
Dialor, Contacts, Messaging, Browser, Email, Clock,
Soundrecorder, Radio, Downloads
Third party:
WPS Office, Touchpal IME
GMS: (preinstalled according to google’s policy)
Search, Gmail, ContactSync, CalendarSync, Hangouts/ Talk,
Chrome, Drive, Google+, Maps, StreetView, YouTube,
GooglePlayStore, GooglePlayGames, GooglePlayBooks,
GooglePlayMovies, GooglePlayNewsstand,
GooglePlayMusic, Widevine, ConfigUpdater, SetupWizard

HUAWEI U9000 Smart Phone
Version1.5(2015-01-13) Commercial in Confidence Page 12 of 12
3 Packing List
This chapter describes the items contained in the package of the Y625.
Table 3-1 lists the items contained in the package of the Y625.
Table 3-1 Packing list of the Y625
Item Spec. Quantity Remarks
Handset 1pcs Mandatory
Battery 2000mAh 1pcs Mandatory
Charger 5V/1A 1pcs Mandatory
USB cable Micro USB 1pcs Mandatory
Quick Start
Guide 1pcs Mandatory
Warranty Card 1pcs Optional, according to
the requirement of
front-line.
