Welcome to HUAWEI
Quick Start Guide
HUAWEI H882L

Phone at a Glance
All the pictures in this guide are for your reference only. Your phone's
actual display features may be different to those described here,
depending on its software version.
Key Functions at Your Fingertips
• Press and hold to power on your mobile phone.
• When your mobile phone is powered on, press and hold this
button to display the options menu. You can then choose to
power off the phone or perform shortcut operations.
• Press to lock the screen when your mobile phone is active.
Touch to open the menu on an active screen.
• Touch to return to the Home screen.
• Touch and hold to display recently used applications.
Headset jack Power
Charger/
Data port
Speaker
Earpiece
Volume
key
Back Home Menu
Front camera
Status
indicator Rear
camera
Flashlight

Inserting a SIM card
To install a SIM card, perform the operations shown in the following figures.
1. Remove the battery cover.
2. Insert the SIM card into the SIM card slot with its metal contacts facing
down.
Installing the microSD card
You can insert a microSD card to expand your phone's storage capacity. To
do so, perform the operations shown in the following figure.
To remove the microSD card:
1. On the home screen, touch > Settings and then the All tab.
2. Touch Storage > Unmount SD card .
3. Carefully remove the microSD card.
• Touch to return to the previous screen or exit the application
you are running.
• Touch to hide the keyboard.

Installing the battery
To install the battery, perform the operations shown in the following figures.
1. Align the battery's metal contacts with those at the bottom of the battery
compartment (refer to position a in the preceding figure).
2. Press the other end of the battery (position b in the preceding figure)
against your phone to fix it to the battery compartment.
3. Close the battery cover.
Charging the battery
1. Connect your charger to the provided USB cable.
2. Connect the charger to a power outlet.
3. Connect your phone to the USB cable to start charging.
Battery indicator light
The battery indicator shows your phone's battery level.
• Blinking red: The battery level is lower than 10%.
• Steady red (when charging): The battery level is lower than 10%.
• Steady yellow (when charging): The battery level is higher than 10%.
a
b

• Steady green (when charging): The battery level is almost or already full.
The charging is complete when the screen shows that the battery level is
100%.
Gestures
Touch : Touch to select an item or open an application.
Touch and hold : Touch and leave your finger on the
screen for 2 seconds or longer. You can touch and
hold an application, a widget, or a blank area to display
the related option menu.
Flick : Where applicable, swipe your finger in the
direction you want the screen to move. For example,
you can flick left or right across the notification panel to
dismiss a notification.
Drag : Touch and hold an item and then drag it to
another position. You can re-arrange icons on the
home screen this way.

Home Screen
You can set up the Home screen according to your own preferences, for
example by adding a shortcut or a widget to your Home screen, changing
the wallpaper, or setting the number of Home screen extensions.
To return to the Home screen from any of its extensions, press .
When a new notification icon appears on the notification bar, place your
finger on the notification bar and flick down to open the notification panel.
Moving an Application Icon
1. On the Home screen, touch and hold the icon you want to move.
2. Drag the icon to the desired location and release it.
To move additional icons, repeat the preceding steps.
Pinch : Pinch two fingers together to zoom out or
stretch them apart to zoom in on a map, web page, or
picture.
10:23

Copying contacts
1. On the home screen, touch > People .
2. On the People screen, touch .
3. Touch Manage contacts > Copy contacts .
4. From the displayed option menu, select where the contacts you wish to
copy are from.
5. Touch the contact you wish to copy or touch Select all to select all
contacts.
6. Touch Copy and select the account to which you wish to copy the
contacts.
Adding a Contact
1. In the contact list, touch .
2. From the screen displayed, create a contact in your mobile phone, SIM
card or your account. Add a new account if you do not have one.
3. Enter the contact's name, and then add detailed information such as
phone numbers and address.
4. Touch DONE to save the contact information.
To save a contact from your call log, touch and hold the desired phone
number to display the options menu, and then touch Add to contacts .
Smart dialing
Smart dialing lets you quickly find contacts by entering their names or
numbers.
1. On the home screen, touch > Phone .
2. Enter a phone number or contact name.
Matching contacts in your phone and phone numbers in your call log
are then displayed in a list.
3. From the list, select the contact you wish to call.
4. To end the call, touch .

Creating and Sending a Multimedia
Message
You can use multimedia messages to make everyday communications very
special. You can record a message and send it as an audio file, for
example, sing "Happy Birthday" and send it to a friend, or send a slideshow
of photographs of a special event. The possibilities are enormous.
1. Touch > Messaging , then .
2. Enter a phone number in the To field, or touch to select a contact
from People .
3. Touch the composition text box to start composing your message.
4. Perform the following steps to convert a text message into a multimedia
message:
• Touch > Add subject to add the message subject. Your mobile
phone is now in multimedia message mode.
• Touch to attach a picture, an audio file, or a video clip to the
message.
5. When you are ready to send the message, touch Send MMS .
Connecting Internet
Get online using your phone's Wi-Fi to save your money.
Connecting to a Wi-Fi
®
network
1. On the home screen, touch > Settings and then the All tab.
2. In the WIRELESS & NETWORKS area, touch the Wi-Fi switch to turn
on Wi-Fi.
3. In the WIRELESS & NETWORKS area, touch Wi-Fi .
Your phone then scans for available Wi-Fi networks and displays them
if any.

4. Choose the Wi-Fi network you wish to access and touch Connect .
For an encrypted Wi-Fi network, enter the password when prompted.
If Wi-Fi and mobile data are both enabled, your phone connects to the
Wi-Fi network preferentially. When Wi-Fi becomes unavailable, your
phone automatically switches to the mobile data connection.
Browsing web pages
1. On the home screen, touch > Browser .
2. Enter a website address in the address box.
Your phone displays matching websites as you type.
3. Touch the website you wish to visit to open it.
Enabling data services
1. On the home screen, flick down from the status bar to open the
notification panel.
2. Touch to enable your phone's data services.
When you don't need to access the Internet, disable data services to
save battery power and reduce data usage.
Play Store
Play Store is application market provided by Google, where you can
download applications, games, and view and update downloaded content.
Installing an application
1. On the home screen, touch > Play Store .
2. Find the desired application.
3. Follow the onscreen instructions to download and install it.

Uninstalling an Application
You cannot uninstall the applications that are pre-installed on the
system.
1. On the home screen, touch > Settings and then the All tab.
2. Touch Manage apps
3. Touch an application, and then touch Uninstall .
Opening Your Camera
You can take and share photos using the camera. Your camera supports
multiple capture modes and photo effects. After taking a picture, access the
Gallery to view it. For information on how to share photos and videos, see
the User Guide.
Photo taking screen
• Drag the slider to to switch to photo mode.
• Drag the slider to to switch to video mode.
1
2
3
4
5
6
78
