Huawei ME909s-120 Installation instructions

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
Issue
03
Date
2017-12-11

Copyright © Huawei Technologies Co., Ltd. 2017. All rights reserved.
No part of this manual may be reproduced or transmitted in any form or by any means without prior written
consent of Huawei Technologies Co., Ltd. and its affiliates ("Huawei").
The product described in this manual may include copyrighted software of Huawei and possible licensors.
Customers shall not in any manner reproduce, distribute, modify, decompile, disassemble, decrypt, extract,
reverse engineer, lease, assign, or sublicense the said software, unless such restrictions are prohibited by
applicable laws or such actions are approved by respective copyright holders.
Trademarks and Permissions
, , and are trademarks or registered trademarks of Huawei Technologies Co., Ltd.
LTE is a trade mark of ETSI.
Other trademarks, product, service and company names mentioned may be the property of their respective
owners.
Notice
Some features of the product and its accessories described herein rely on the software installed, capacities
and settings of local network, and therefore may not be activated or may be limited by local network
operators or network service providers.
Thus, the descriptions herein may not exactly match the product or its accessories which you purchase.
Huawei reserves the right to change or modify any information or specifications contained in this manual
without prior notice and without any liability.
DISCLAIMER
ALL CONTENTS OF THIS MANUAL ARE PROVIDED “AS IS”. EXCEPT AS REQUIRED BY APPLICABLE
LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT
LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS
MANUAL.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL HUAWEI BE
LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOSS OF
PROFITS, BUSINESS, REVENUE, DATA, GOODWILL SAVINGS OR ANTICIPATED SAVINGS
REGARDLESS OF WHETHER SUCH LOSSES ARE FORSEEABLE OR NOT.
THE MAXIMUM LIABILITY (THIS LIMITATION SHALL NOT APPLY TO LIABILITY FOR PERSONAL
INJURY TO THE EXTENT APPLICABLE LAW PROHIBITS SUCH A LIMITATION) OF HUAWEI ARISING
FROM THE USE OF THE PRODUCT DESCRIBED IN THIS MANUAL SHALL BE LIMITED TO THE
AMOUNT PAID BY CUSTOMERS FOR THE PURCHASE OF THIS PRODUCT.
Import and Export Regulations
Customers shall comply with all applicable export or import laws and regulations and be responsible to
obtain all necessary governmental permits and licenses in order to export, re-export or import the product
mentioned in this manual including the software and technical data therein.

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
About This Document
Issue 03 (2017-12-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
3
About This Document
Revision History
Document
Version
Date
Chapter
Description
01
2015-07-23
-
Creation
02
2017-08-22
2.1
Updated Figure 2-3 Medium
carton
2.2
Updated the Figure 2-5 ME909s-
120 Mini PCIe label
03
2017-12-11
Deleted privacy policy

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
Contents
Issue 03 (2017-12-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
4
Contents
1 Introduction....................................................................................................................................5
1.1 Purpose............................................................................................................................................ 5
1.2 Scope ............................................................................................................................................... 5
2 Acceptance Inspection..................................................................................................................6
2.1 Packaging Modes and Appearance ................................................................................................. 6
2.2 Label Inspection............................................................................................................................... 8
2.3 Performance Inspection ................................................................................................................... 8
2.4 Repack the Module after Inspection............................................................................................... 12

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
Introduction
Issue 03 (2017-12-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
5
1 Introduction
1.1 Purpose
This document describes the methods of inspecting Huawei's shipments of ME909s-
120 Mini PCIe module. Customers can refer to this document when formulating
inspection guides for accepting HUAWEI ME909s-120 Mini PCIe module.
1.2 Scope
This guide is applicable to the acceptance inspection of HUAWEI ME909s-120 Mini
PCIe module. The inspection methods provided in this guide are recommendations,
which can be modified by customers if necessary.

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
Acceptance Inspection
Issue 03 (2017-12-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
6
2 Acceptance Inspection
2.1 Packaging Modes and Appearance
The first-layer packages for the ME909s-120 Mini PCIe module are large cartons; the
second-layer packages are medium cartons, and the third-layer packages are
vacuum bags, as shown in the following figures.
Figure 2-1 Large carton packaging
Carton ID
Weight Label
Delivery Label
Check whether the package has serious damage or has been opened.
Check whether the number of Carton ID labels attached on the large carton is consistent
with the number of medium cartons in the large carton.

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
Acceptance Inspection
Issue 03 (2017-12-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
Figure 2-2 Medium carton
Figure 2-3 Medium carton
Figure 2-4 Shockproof bag and ESD (Electrostatic Discharge) bag
ESD bag
Shockproof bag

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
Acceptance Inspection
Issue 03 (2017-12-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8
Check whether the packaging modes are consistent with those shown in the previous
figures.
The ME909s-120 Mini PCIe modules are packed in medium cartons. Check the medium
cartons for damage.
2.2 Label Inspection
Figure 2-5 ME909s-120 Mini PCIe label
Check whether the information on the label of an ME909s-120 Mini PCIe module is
consistent with the label shown in Figure 2-5 .
Use a 2D barcode scanner to read the 2D barcode and check whether the number read
from the barcode is consistent with the IMEI number printed on the label.
It is recommended to take ESD protection during the inspection, for examlple, wearing ESD
wrist straps, ESD gloves, or ESD finger cots.
2.3 Performance Inspection
Testing tools: USB cable, development kit and PC
Testing system: Windows 8/Windows 8.1
The following is the procedure:
Step 1 Plug the module onto the development kit and connect the development kit to the PC
by USB cable.
Step 2 Enter Program Manager.

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
Acceptance Inspection
Issue 03 (2017-12-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
Step 3 Click Settings on Charm Bar.

HUAWEI ME909s-120 LTE Mini PCIe Module
Acceptance Inspection Guide
Acceptance Inspection
Issue 03 (2017-12-11)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
10
Step 4 Click Change PC settings in Settings.
Step 5 Click Network in PC settings.
