Huawei SUN2000-63KTL-JPH0 User manual

SUN2000-63KTL-JPH0
User Manual
Issue
04
Date
2019-06-30
HUAWEI TECHNOLOGIES CO., LTD.

Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
i
Copyright © Huawei Technologies Co., Ltd. 2019. All rights reserved.
No part of this document may be reproduced or transmitted in any form or by any means without prior
written consent of Huawei Technologies Co., Ltd.
Trademarksand Permissions
and other Huawei trademarks are trademarks of Huawei Technologies Co., Ltd.
All other trademarks and trade names mentioned in this document are the property of their respective
holders.
Notice
The purchased products, services and features are stipulated by the contract made between Huawei and
the customer. All or part of the products, services and features described in this document may not be
within the purchase scope or the usage scope. Unless otherwise specified in the contract, all statements,
information, and recommendations in this document are provided "AS IS" without warranties,guarantees or
representations of any kind, either express or implied.
The information in this document is subject to change without notice. Every effort has been made in the
preparation of this document to ensure accuracy of the contents, but all statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Huawei Technologies Co., Ltd.
Address:
Huawei Industrial Base
Bantian, Longgang
Shenzhen 518129
People's Republic of China
Website:
http://e.huawei.com

SUN2000-63KTL-JPH0
User Manual
About This Document
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
ii
About This Document
Purpose
This document describes the SUN2000-63KTL-JPH0 (SUN2000 for short) in terms of their
installation, electrical connections, commissioning, maintenance, and troubleshooting. Read
this document through, understand the safety information, and get familiar with the functions
and features of the SUN2000 before installing and operating it.
Intended Audience
This document is intended for photovoltaic (PV) power plant personnel and qualified
electrical technicians.
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol
Remarks
Indicates an imminently hazardous situation which, if
not avoided, will result in serious injury or death.
Indicates a potentially hazardous situation which, if
not avoided, could result in serious injury or death.
Indicates a potentially hazardous situation which, if
not avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if
not avoided, could result in equipment damage, data
loss, performance deterioration, or unanticipated
results.
NOTICE is used to address practices not related to
personal injury.

SUN2000-63KTL-JPH0
User Manual
About This Document
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
iii
Symbol
Remarks
Calls attention to important information, best
practices and tips.
NOTE is used to address information not related to
personal injury, equipment damage, or environment
deterioration.
Change History
Changes between document issues are cumulative. The latest document issue contains all
updates made in previous issues.
Issue 04 (2019-06-30)
1. Modified 5.6 Installing the DC Input Power Cable.
2. Modified 7 Man-Machine Interactions.
3. Modified A Technical Data.
Issue 03 (2018-09-27)
1. Modified 4.3 Determining the Installation Position.
2. Modified 5.2 Preparing Cables.
Issue 02 (2018-08-20)
1. Modified 2.1 Models.
2. Modified 7.1 App Introduction.
3. Modified A Technical Data.
Issue 01 (2018-05-30)
This issue is used for first office application (FOA).

SUN2000-63KTL-JPH0
User Manual
Contents
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
iv
Contents
About This Document ............................................................................................................ ii
1 Safety Precautions .................................................................................................................1
2 Overview................................................................................................................................4
2.1 Models ...................................................................................................................................................................................4
2.2 Product Introduction.............................................................................................................................................................6
2.3 Product Appearance..............................................................................................................................................................8
2.3.1 Appearance.........................................................................................................................................................................8
2.3.2 Indicator Status ................................................................................................................................................................11
2.3.3 Label Description.............................................................................................................................................................13
2.4 Working Principles..............................................................................................................................................................14
2.4.1 Circuit Diagram ...............................................................................................................................................................14
2.4.2 Working Modes................................................................................................................................................................15
3 Storage.................................................................................................................................. 18
4 Installation ........................................................................................................................... 20
4.1 Checking Before Installation..............................................................................................................................................20
4.2 Tool Preparation..................................................................................................................................................................21
4.3 Determining the Installation Position................................................................................................................................22
4.4 Installing the Mounting Bracket ........................................................................................................................................27
4.4.1 Support-Mounted Installation.........................................................................................................................................27
4.4.2 Wall-Mounted Installation...............................................................................................................................................28
4.5 Installing the SUN2000......................................................................................................................................................29
5 Electrical Connections......................................................................................................... 34
5.1 Precautions..........................................................................................................................................................................34
5.2 Preparing Cables.................................................................................................................................................................34
5.3 Installing the PE Cable.......................................................................................................................................................39
5.4 Opening the Maintenance Compartment Door.................................................................................................................39
5.5 Installing the AC Output Power Cable..............................................................................................................................40
5.6 Installing the DC Input Power Cable.................................................................................................................................45
5.7 Connecting the RS485 Communications Cable................................................................................................................48
5.8 Closing the Maintenance Compartment Door ..................................................................................................................50

SUN2000-63KTL-JPH0
User Manual
Contents
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
v
6 Commissioning.................................................................................................................... 52
6.1 Checking Before Power-On...............................................................................................................................................52
6.2 Powering On the SUN2000................................................................................................................................................52
7 Man-Machine Interactions ................................................................................................. 54
7.1 App Introduction.................................................................................................................................................................54
7.2 Downloading and Installing the App.................................................................................................................................58
7.3 Logging In to the App.........................................................................................................................................................58
7.4 Operations Related to the Common User..........................................................................................................................60
7.4.1 Setting User Parameters ..................................................................................................................................................60
7.4.2 Starting and Shutting Down the SUN2000....................................................................................................................61
7.5 Operations Related to the Advanced User.........................................................................................................................61
7.5.1 Parameter Settings...........................................................................................................................................................61
7.5.1.1 Setting Grid Parameters ...............................................................................................................................................61
7.5.1.2 Setting Protection Parameters......................................................................................................................................62
7.5.1.3 Setting Feature Parameters...........................................................................................................................................63
7.5.1.4 Setting User Parameters ...............................................................................................................................................67
7.5.1.5 Setting Communications Parameters...........................................................................................................................69
7.5.1.6 Setting the Support System..........................................................................................................................................70
7.5.1.7 Setting a File Save Path................................................................................................................................................71
7.5.2 System Maintenance........................................................................................................................................................72
7.5.2.1 Starting and Shutting Down the SUN2000.................................................................................................................72
7.5.2.2 Restoring Factory Settings...........................................................................................................................................72
7.5.2.3 Resetting the SUN2000................................................................................................................................................73
7.5.2.4 Resetting Alarms...........................................................................................................................................................73
7.5.2.5 Clearing Historical Energy Yield Data........................................................................................................................73
7.5.2.6 Managing the License ..................................................................................................................................................73
7.5.2.7 Device inspection .........................................................................................................................................................74
7.5.3 SUN2000 Upgrade ..........................................................................................................................................................75
7.5.4 Device Logs .....................................................................................................................................................................76
7.6 Operations Related to the Special User.............................................................................................................................76
7.6.1 Parameter Settings...........................................................................................................................................................76
7.6.1.1 Setting Grid Parameters ...............................................................................................................................................76
7.6.1.2 Setting Protection Parameters......................................................................................................................................78
7.6.1.3 Setting Feature Parameters...........................................................................................................................................80
7.6.1.4 Setting Power Adjustment Parameters........................................................................................................................82
7.6.1.5 Setting Reactive Power Control...................................................................................................................................85
7.6.1.6 Setting User Parameters ...............................................................................................................................................86
7.6.1.7 Setting a File Save Path................................................................................................................................................86
7.6.2 System Maintenance........................................................................................................................................................86
7.6.2.1 Starting and Shutting Down the SUN2000.................................................................................................................86
7.6.2.2 Restoring Factory Settings...........................................................................................................................................87

SUN2000-63KTL-JPH0
User Manual
Contents
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
vi
7.6.3 SUN2000 Upgrade ..........................................................................................................................................................87
7.6.4 Device Logs .....................................................................................................................................................................88
7.7 Querying the Status.............................................................................................................................................................89
7.7.1 Querying Alarm Records.................................................................................................................................................89
7.7.2 Querying SUN2000 Running Information.....................................................................................................................89
7.7.3 Querying Energy Yield Data...........................................................................................................................................90
7.7.4 Viewing System Version Information.............................................................................................................................90
7.8 Tool Kit................................................................................................................................................................................90
7.8.1 Scanning SN Bar Codes..................................................................................................................................................90
7.8.2 SUN2000 Maintenance Script ........................................................................................................................................90
7.8.3 File Manager ....................................................................................................................................................................90
7.8.4 About................................................................................................................................................................................90
7.9 Operations with a USB Flash Drive ..................................................................................................................................90
7.9.1 Exporting Configurations................................................................................................................................................90
7.9.2 Importing Configurations................................................................................................................................................90
7.9.3 Exporting Data.................................................................................................................................................................90
7.9.4 Upgrading.........................................................................................................................................................................90
7.10 Troubleshooting the SUN2000App ................................................................................................................................91
8 Maintenance......................................................................................................................... 91
8.1 Powering Off the SUN2000...............................................................................................................................................91
8.2 Routine Maintenance..........................................................................................................................................................91
8.3 Checking Spot-check Terminals ........................................................................................................................................93
8.4 Troubleshooting ..................................................................................................................................................................93
9 Handling the Inverter........................................................................................................ 101
9.1 Removing the SUN2000 ..................................................................................................................................................101
9.2 Packing the SUN2000 ......................................................................................................................................................101
9.3 Disposing of the SUN2000 ..............................................................................................................................................101
A Technical Data .................................................................................................................. 102
B Grid Codes......................................................................................................................... 105
C Acronyms and Abbreviations.......................................................................................... 106

SUN2000-63KTL-JPH0
User Manual
1 Safety Precautions
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
1
1 Safety Precautions
General Safety
Before performing operations, read through this manual and follow all the precautions to
prevent accidents. The "DANGER", "WARNING", "CAUTION", and "NOTICE" marks
in this document do not represent all the safety instructions. They are only supplements to
the safety instructions.
The personnel responsible for installing, connecting cables for, commissioning,
maintaining, and troubleshooting Huawei products should be qualified and trained to
master the correct operation methods and the knowledge of safety precautions.
When operating Huawei equipment, in addition to following the general precautions in this
document, follow the specific safety instructions given by Huawei. The safety precautions
provided in this document do not cover all the safety precautions. Huawei shall not be liable
for any consequence caused by the violation of the safety operation regulations and design,
production, and usage standards.
Disclaimer
Huawei shall not be liable for any consequence caused by any of the following events:
Transportation damage
Violation of the storage requirements specified in this document
Incorrect storage, installation, or use
Installation or use by unqualified personnel
Failure to obey the operation instructions and safety precautions in this document
Operation in extreme environments which are not covered in this document
Operation beyond specified ranges
Unauthorized modifications to the product or software code or removal of the product
Device damage due to force majeure (such as lightning, earthquake, fire, and storm)
The warranty expires and the warranty service is not extended.
Installation or use in environments which are not specified in related international
standards

SUN2000-63KTL-JPH0
User Manual
1 Safety Precautions
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
2
Personnel Requirements
Only certified electricians are allowed to install, connect cables for, commission, maintain,
troubleshoot, and replace the SUN2000. Operation personnel must meet the following
requirements:
Receive professional training.
Read through this document and follow all the precautions.
Be familiar with the safety specifications about the electrical system.
Understand the components and functioning of a grid-tied PV system, and be familiar
with relevant local standards.
Wear proper personal protective equipment (PPE) during any operation on the SUN2000.
Protect Labels
Do not scrawl, damage, or block the labels on the SUN2000 enclosure.
Do not scrawl, damage, or block the nameplate on the side of the SUN2000 enclosure.
Installation
Never work under power during installation.
Ensure that the SUN2000 is not connected to a power supply or powered on before
finishing installation.
Ensure that the SUN2000 is installed in a well-ventilated environment.
Ensure that the SUN2000 heat sinks are free from blockage.
Never open the host panel cover of the SUN2000.
Never remove the terminals and cable glands at the bottom of the SUN2000.
Electrical Connections
Before connecting cables to the SUN2000, ensure that the SUN2000 is secured in position
and not damaged in any way. Otherwise, electric shocks or fire may occur.
Ensure that all electrical connections comply with local electrical standards.
Obtain approval from the local electric utility before using the SUN2000 to generate
electricity in grid-tied mode.
Ensure that the cables used in a grid-tied PV system are properly connected and insulated
and meet all specification requirements.
Operation

SUN2000-63KTL-JPH0
User Manual
1 Safety Precautions
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
3
High voltage may cause an electric shock, which results in serious injury, death or serious
property damage from the SUN2000 in operation. Strictly comply with the safety precautions
in this document and associated documents to operate the SUN2000.
Do not touch an energized SUN2000 because the heat sink has a high temperature.
Follow local laws and regulations when operating the SUN2000.
Maintenance and Replacement
High voltage may cause an electric shock, which results in serious injury, death or serious
property damage from the SUN2000 in operation. Prior to maintenance, power off the
SUN2000 and strictly comply with the safety precautions in this document and associated
documents to operate the SUN2000.
Maintain the SUN2000 with sufficient knowledge of this document, proper tools, and
testing equipment.
Before performing maintenance tasks, power off the SUN2000 and wait at least 15
minutes.
Temporary warning labels or fences must be placed to prevent unauthorized people
entering the site.
Rectify any faults that may compromise the SUN2000 security performance before
powering on the SUN2000 again.
Observe electrostatic discharge (ESD) precautions during maintenance.

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
4
2 Overview
2.1 Models
Model Number Description
Figure 2-1 Model number
Table 2-1 Model number description
No.
Meaning
Description
1
Product
SUN2000: grid-tied PV inverter
2
Power
63K: The power level is 62.5 kW.
3
Topology
TL: transformerless
4
Region
JP: Japan
5
Design code
H0: the product series with the 1500 V DC input voltage
Model Identification
You can query the SUN2000 number by the model label on the external package and the
nameplate on the side of the enclosure.

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
5
Figure 2-2 Label position on the externalpackage
(1) Position of the model label
Figure 2-3 Nameplate
(1) Trademark and product model
(2) Important technical specifications
(3) Compliance symbols
(4) Company name and country of manufacture
The nameplate figure is for reference only.

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
6
Table 2-2 Compliance symbols
Symbol
Name
Meaning
Environmentally friendly
use period (EFUP) mark
The product does not
pollute the environment
during the specified
period.
EU waste electrical and
electronic equipment
(WEEE) mark
Do not dispose of the
product as household
garbage.
2.2 Product Introduction
Function
The SUN2000 is a grid-tied PV string inverter that converts the DC power generated by PV
strings into AC power and feeds the power into the power grid.
Features
Intelligent
Six independent maximum power point tracking (MPPT) circuits and 12 PV string inputs:
Supports the flexible configuration of 2+2+2+2+2+2 strings.
12 routes of high-precision smart PV string monitoring: Help identify and rectify
exceptions timely.
Smart I-V curve diagnosis: Implements I-V scanning and health diagnosis for PV strings.
In this way, potential risks and faults can be detected in time, improving the plant
operation & maintenance (O&M) quality.
Safe
Embedded DC and AC SPDs: all-dimensional surge protection
Embedded residual current monitoring unit: Immediately disconnects from the power
grid upon detecting that the residual current exceeds the threshold.
Reliable
Natural cooling
Free fuse design
Protected to IP65.
Effective design against ground subsidence: The AC terminal block can be pulled down
by up to 50 mm due to the pulling force.
Network Application
The SUN2000 applies to distributed grid-tied commercial PV systems and large-scale
grid-tied PV plants. Typically, a grid-tied PV system consists of the PV string, SUN2000, AC
combiner box, and step-up transformer.

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
7
Figure 2-4 Network application
(A) PV string
(B) SUN2000
(C) AC combiner box
(D) Step-up transformer
(E) Power grid
Supported Power Grid
The SUN2000 supports the IT power grid.
Figure 2-5 Supported power grid

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
8
2.3 Product Appearance
2.3.1 Appearance
Front View
Figure 2-6 Front view
(1) Maintenance compartment door
(2) Host panel
Rear View
Figure 2-7 Rear view
(1) Mounting plate
(2) Heat sink

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
9
Bottom View
Figure 2-8 Bottom view
No.
Component
Silk Screen
Description
1
Cable glands
COM1, COM2,
COM3
Inner diameter: 14–18 mm
2
USB port
USB
Use the USB port only during
maintenance (such as power-on
setting, upgrade, and data export).
Ensure that the USB cover is
tightened when maintenance is not
performed.
3
Handler
N/A
N/A
4
DC input terminals
+/–
Controlled by DC SWITCH 1
5
DC input terminals
+/–
Controlled by DC SWITCH 2
6
Cable gland
AC OUTPUT
Inner diameter: 24–57 mm
7
Cable gland
RESERVE
Inner diameter: 14–18 mm
8
DC switch 1
DC SWITCH 1
N/A
9
DC switch 2
DC SWITCH 2
N/A

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
10
Dimensions
Figure 2-9 Dimensions
Figure 2-10 Mounting bracket dimensions
Figure 2-11 Dimensions of reserved holes on the rear

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
11
Four M5 screw holes are reserved on the rear of the SUN2000 for installing an awning.
Wiring Area
Figure 2-12 Wiring ports
(1) RS485 port (RJ45
network port)
(2) RS485 port (terminal
block)
(3) AC terminal block (OT/DT
terminal)
(4) Spot-check terminal
(5) DC input terminal
To see theAC terminal block and spot-check terminal, remove the protective cover.
2.3.2 Indicator Status
Figure 2-13 Indicators

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
12
No.
Indicator
Status
Meaning
1
PV connection indicator
Steady green
At least one PV string is
properly connected, and the
DC input voltage of the
corresponding MPPT circuit
is higher than or equal to 600
V.
Off
The SUN2000 disconnects
from all PV strings, or the
DC input voltage of each
MPPT circuit is less than 600
V.
2
Grid-tied indicator
Steady green
The SUN2000 is in grid-tied
mode.
Off
The SUN2000 is not in
grid-tied mode.
3
Communication indicator
Blinking green
The SUN2000 is receiving
data over RS485.
Off
The SUN2000 has not
received data over RS485 for
10 seconds.
4
Alarm/Maintenance
indicator
Alarm state
Blinking red at
long intervals
(on for 1s and
then off for 4s)
A warning alarm is
generated.
Blinking red at
short intervals
(on for 0.5s and
then off for 0.5s)
A minor alarm is generated.
Steady red
A major alarm is generated.
Local maintenance
state
Blinking green at
long intervals
(on for 1s and
then off for 1s)
Local maintenance is in
progress.
Blinking green at
short intervals
(on for 0.125s
and then off for
0.125s)
Local maintenance fails.
Steady green
Local maintenance succeeds.

SUN2000-63KTL-JPH0
User Manual
2 Overview
Issue 04 (2019-06-30)
Copyright © Huawei Technologies Co., Ltd.
13
Local maintenance refers to operations performed after a USB flash drive, a WLAN module, a
Bluetooth module, or a USB data cable is inserted into the USB port of the solar inverter. For
example, localmaintenance includes data import and export using a USB flash drive, and connecting
to the SUN2000 app over a WLAN module, a Bluetooth module, or a USB data cable.
If the alarming and the local maintenancehappen concurrently, the alarm/maintenance indicator
shows the local maintenance state first. After the USB flash drive, WLAN module, Bluetooth
module, or USB data cable is removed, the indicator shows the alarm state.
2.3.3 Label Description
Label
Name
Meaning
Running
warning
Potential hazards exist after
the SUN2000 is powered on.
Take protective measures
when operating the
SUN2000.
Burn warning
Do not touch a running
SUN2000, as the shell
becomes hot during
operation.
Delayed
discharge
High voltage exists after
the SUN2000 is powered
on. Only qualified and
trained electrical
technicians are allowed to
perform operations on the
SUN2000.
Residual voltage exists
after the SUN2000 is
powered off. It takes 15
minutes for the SUN2000
to discharge to the safe
voltage.
Refer to
documentation
Reminds operators to refer to
the documents shipped with
the SUN2000.
Grounding
Indicates the position for
connecting the protective
earthing (PE) cable.
Operation
warning
Do not remove the DC input
connector when the
SUN2000 is running.
High voltage
warning
High voltage exists after the
SUN2000 is powered on.
Read this document carefully
before operating the
SUN2000.
