Hydac OLSW 20 Series User manual

OLSW 20…
OffLine Separator
Water
Installation and Maintenance Instructions
English (translation of original instructions)
Document No.: 3587900a
Keep for future reference.

Imprint
OLSW en(us) Page 2 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Imprint
Publisher and responsible for the content:
HYDAC FILTER SYSTEMS GMBH
Postfach 1251
66273 Sulzbach / Saarland
Germany
Phone:
[phone]
Fax:
[phone]
E-mail:
[e-mail]
Homepage:
www.hydac.com
Court of Registration:
Saarbrücken, HRB 17216
Executive director:
Mathias Dieter,
Dipl.Kfm. Wolfgang Haering
Documentation Representative
Mr. Günter Harge
c/o HYDAC International GmbH, Industriegebiet, 66280 Sulzbach / Saar
Phone:
[phone]
Fax:
[phone]
E-mail:
[e-mail]
© HYDAC FILTER SYSTEMS GMBH
All rights reserved. No part of this work may be reproduced in any form (print,
photocopy or by other means) or processed, duplicated or distributed using
electronic systems without the written consent of the publisher.
These documents have been created and inspected with the greatest care.
However, errors cannot be ruled out completely.

Content
OLSW en(us) Page 3 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Content
Imprint............................................................................................................2
Documentation Representative...................................................................2
Content ..........................................................................................................3
Preface...........................................................................................................5
Technical Support........................................................................................5
Modifications to the Product........................................................................5
Warranty......................................................................................................5
Using the documentation.............................................................................6
General Safety Information..........................................................................7
Signal words and their meaning in the general safety information...............7
Structure of the general safety information..................................................8
Warning signs used.....................................................................................8
Others used symbols...................................................................................9
Signs used for the required specialist personnel.........................................9
Specialist personnel – Mechanical...........................................................9
Specialist personnel – Electricity..............................................................9
Proper/designated use...............................................................................10
Improper Use.............................................................................................10
Informal Safety Precautions.......................................................................10
Safety Measures to Be Followed during Normal Operation.......................10
Hazards Posed by Stored Residual Energy...............................................11
Qualifications of personnel / target group..................................................12
Transporting the OLSW..............................................................................14
Storing the OLSW.......................................................................................14
Storage conditions.....................................................................................14
Checking the scope of delivery.................................................................15
OLSW Features...........................................................................................16
Restrictions Pertaining...............................................................................17
OLSW components ...................................................................................18
OLSW dimensions.....................................................................................20
Hydraulic diagram......................................................................................22
Installing the OLSW....................................................................................23
Notes on pipes and hoses.........................................................................24
Water inlet / outlet......................................................................................25
Installing the oil drain.................................................................................25
Setting Up the Electrical Connection.........................................................26
Commissioning the OLSW.........................................................................28

Content
OLSW en(us) Page 4 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Performing maintenance............................................................................28
Breather maintenance...............................................................................29
Check breather functionality...................................................................30
Cleaning breather / Replacing parts.......................................................31
Help with errors on the breather..........................................................32
Changing the coalescing elements............................................................33
Decommissioning the OLSW.....................................................................35
Disposing of the OLSW..............................................................................35
Spare parts list............................................................................................36
Accessories.................................................................................................37
Technical Data.............................................................................................37
Attachment..................................................................................................38
Finding a Customer Service team .............................................................38
Glossary ....................................................................................................38
Model code................................................................................................39
Index..........................................................................................................40

Preface
OLSW en(us) Page 5 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Preface
This operating manual was made to the best of our knowledge. Nevertheless
and despite the greatest care, it cannot be excluded that mistakes could have
crept in. Therefore please understand that in the absence of any provisions
to the contrary hereinafter our warranty and liability – for any legal reasons
whatsoever – are excluded in respect of the information in these operating
instructions. In particular, we shall not be liable for lost profit or other financial
loss. This exclusion of liability does not apply in cases of intent and gross
negligence. Moreover, it does not apply to defects which have been
deceitfully concealed or whose absence has been guaranteed, nor in cases
of culpable harm to life, physical injury and damage to health. If we
negligently breach any material contractual obligation, our liability shall be
limited to foreseeable damage. Claims due to Product Liability shall remain
unaffected.
Technical Support
Contact our technical sales department if you have any questions on our
product. When contacting us, please always include the model code, serial
no. and part no. of the product:
Fax:
+49 6897 / 509 - 9046
E-mail:
[e-mail]
Modifications to the Product
We would like to point out that changes to the product (e.g., purchasing
options, etc.) may result in the information in the operating instructions no
longer being completely accurate or sufficient.
After modification or repair work that affects the safety of the product has
been carried out on components, the product may not be returned to
operation until it has been checked and released by a HYDAC technician.
Please notify us immediately of any modifications made to the product
whether by you or a third party.
Warranty
For the warranty provided by us, please refer to the terms of delivery of
HYDAC FILTER SYSTEMS GMBH.
You will find these under www.hydac.com -> Legal information.

General Safety Information
OLSW en(us) Page 6 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Using the documentation
Note that the method described for locating specific information
does not release you from your responsibility of carefully reading
these instructions prior to starting the unit up for the first time and
at regular intervals in the future.
What do I want to know?
I determine which topic I am looking for.
Where can I find the information I’m looking for?
The documentation has a table of contents at the beginning. There, I select
the chapter I'm looking for and the corresponding page number.
de
HYDACFiltertechnikGmbH
BeWa123456ade
Seite x
Produkt/Kapitel
200x-xx-xx
The documentation number with its index enables you to order another copy
of the operating and maintenance instructions. The index is incremented
every time the manual is revised or changed.
Chapter description
Page number
Edition date
Document language
Documentation no.
with index/
file name

General Safety Information
OLSW en(us) Page 7 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
General Safety Information
The filter housing was built according to the statutory provisions valid at the
time of delivery and satisfies current safety requirements.
Any residual hazards are indicated by safety information and instructions and
are described in the operating instructions.
Observe all safety and warning instructions attached to the filter housing.
They must always be complete and legible.
Do not operate the filter housing unless all the safety devices are present.
Secure the hazardous areas which may arise between the filter housing and
other equipment.
Maintain the unit inspection intervals prescribed by law.
Document the results in an inspection certificate and keep it until the next
inspection.
Signal words and their meaning in the general safety information
In these instructions you will find the following signal words:
DANGER
DANGER – The signal word indicates a hazardous situation with a high level
of risk, which, if not avoided, will result lethal or serious injury.
WARNING
WARNING – The signal word indicates a hazardous situation with a medium
level of risk, which, if not avoided, can result lethal or serious injury.
CAUTION
CAUTION – The signal word indicates a hazardous situation with a low level
of risk, which, if not avoided, can result in minor or moderate injury.
NOTICE
NOTICE – The signal word indicates a hazardous situation with a high level
of risk, which, if not avoided, will result in damage to property.

General Safety Information
OLSW en(us) Page 8 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Structure of the general safety information
All warning instructions in this manual are highlighted with pictograms and
signal words. The pictogram and the signal word indicate the severity of the
danger.
Warning instructions listed before an activity are laid out as follows:
HAZARD SYMBOL
SIGNAL WORD
Type and source of danger
Consequence of the danger
►Measures to avert danger
Warning signs used
These signs are listed for all safety information and instructions in these
operating instructions which indicate particular hazards to persons, property
or the environment.
Danger point warning
Dangerous electrical voltage warning
Warning about operating pressure

General Safety Information
OLSW en(us) Page 9 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Others used symbols
The following symbols found you in this operation instructions.
Tip for handling the product
Required tools
Signs used for the required specialist personnel
These symbols show the required training/knowledge for installation work
and/or maintenance work.
Specialist personnel – Mechanical
Only specialist personnel with training as mechanics and
the following knowledge:
•Safe handling/use of tools
•Fitting and connection of hydraulic tubes and
connections
•Product-specific knowledge
•Knowledge about how to handle operating media.
Specialist personnel – Electricity
Only specialist personnel with training as electricians and
the following knowledge:
•Safe handling/use of tools
•Fitting and connection of electrical lines, electrical
machinery, sockets, etc.
•Checking the phase sequence
•Product-specific knowledge
•Knowledge about how to handle operating media.

General Safety Information
OLSW en(us) Page 10 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Proper/designated use
The OLSW is a stationary filter housing which is used to separate oil from
watery fluids.
Any other uses shall be deemed to be improper and not in keeping with the
product's designated use.
The manufacturer will not assume any liability for any damage resulting from
such use.
Proper or designated use of the product extends to the following:
•Observing all the notes contained in these operating instructions
•Performing requisite inspection and maintenance work.
Improper Use
Improper use can result in hazards.
Improper use includes, for example, using the OLSW with a non-authorized
fluid.
Informal Safety Precautions
Make sure to always keep the operating instructions in the vicinity of the filter
housing.
In addition to the operating instructions, the general and local regulations on
accident prevention and environmental protection are to be made available
and observed.
All safety guidelines and hazard warnings on the machine must be
maintained in legible condition and replaced as required.
Check the hoses and connection fittings for leakage daily (visual check). The
electrical components of the OLSW must also be checked regularly (visual
check once a month). Replace any loose connections or damaged cables
immediately.
Safety Measures to Be Followed during Normal Operation
The OLSW may be operated only if all of the safety devices function properly.
The filter housing is to be checked once a day for external damage and the
proper functioning of the safety devices.

General Safety Information
OLSW en(us) Page 11 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Hazards Posed by Stored Residual Energy
Note that the filter housing may pose a hazard as the result of possible
residual stored mechanical and electrical energy. Take the proper
precautions when instructing personnel on the use of the unit. Detailed
information is provided in the respective chapters of this manual.
WARNING
Operating pressure
Danger of bodily injury
►The hydraulic system must be depressurized
before performing any work on the hydraulic
system.

General Safety Information
OLSW en(us) Page 12 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Qualifications of personnel / target group
Staff who work with the filter housing must be aware of the dangers involved,
must be over the age of 14 and must be without any physical impediments
with regard to the industrial environment.
These operating instructions are intended for:
Auxiliary personnel:
Auxiliary personnel: such persons have been instructed about the product
and informed about potential hazards that can result from improper use.
Operating personnel:
Such persons have been instructed about the filter housing and informed
about potential hazards that can result from improper use.
Specialist personnel:
Such persons have corresponding specialist training and several years'
work experience. They are able to assess and perform the work assigned to
them, they are also able to recognize potential hazards.

General Safety Information
OLSW en(us) Page 13 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Activity
Person
Knowledge
Transport / storage
Forwarding
agent
Specialist
personnel
•Proof of knowledge of
cargo securing
instructions
•Safe handling/operation
of hoisting and lifting
equipment
Hydraulic / electrical
installation,
First commissioning,
Maintenance,
Troubleshooting,
Repair,
Decommissioning,
Disassembly
Specialist
personnel •Safe handling/use of
tools
•Fitting and connection of
hydraulic tubes and
connections
•Fitting and connection of
electrical lines, electrical
machinery, sockets, etc.
•Product-specific
knowledge
Operation
Operations control
Specialist
personnel •Product-specific
knowledge
•Knowledge about how to
handle operating media.
•Knowledge about
contamination due to
solids and water
Disposal
Specialist
personnel •Proper and
environmentally-friendly
disposal of materials and
substances
•Decontamination of
contaminants
•
Knowledge about reuse

Transporting the OLSW
OLSW en(us) Page 14 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Transporting the OLSW
Transport the OLSW in a horizontal position on a pallet.
When transporting using a crane, use a sling as follows:
Storing the OLSW
Completely drain the OLSW and remove all filter elements before putting into
storage. Store the OLSW in a horizontal position on a pallet.
Storage conditions
Storage
temperature:
+5°C to +40°C
Humidity:
Maximum 80% relative humidity
Air:
Clean, salt-free air, not near oxidizing substances (rust
film).
Storage duration:
Indefinite.
Before the unit is started up again after being stored for
more than two years, all seals must be replaced.

Checking the scope of delivery
OLSW en(us) Page 15 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Checking the scope of delivery
Upon receiving the OLSW check it for any damage in transit. Do not put the
OLSW into operation unless it is in perfect condition.
The following items are supplied:
Qty Description
1 OLSW coalescing housing
1 Installation and Maintenance Instructions (this document)
1 Drain line hose for automatic breather
1 Cable and plug for drainage valve
1 Phase boundary sensor cable

OLSW Features
OLSW en(us) Page 16 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
OLSW Features
The OffLine Separator Water OLSW is used to remove oil from water-based
washing liquids, which are contaminated with mineral oils (density < 900
kg/m³).
Coalescing procedure
The dewatering works according to the coalescence principle, during which
the oil collects on the fibers of the coalescing element and is conveyed
deeper into the coalescing element by the fluid flow. Smaller drops unite to
form larger ones at the fiber nodes during this process. Large oil drops climb
upwards and can be removed from the system by opening a valve.
The application is used in the bypass flow. The use of a micro-filtration
system is expedient to ensure the maximum possible service life of the
coalescing elements.
Limits of the coalescing procedure
The filter housing is unsuitable for the separation of oils whose density is
higher than 900 kg/m3, such as ester-based liquids and polyglycols.

OLSW Features
OLSW en(us) Page 17 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
The coalescing elements must be protected from contaminant particles by a
pre-filter so that the transport of oil drops is not obstructed by contaminant
particles.
HYDAC recommends the use of a WombatFilter WBF as pre-
filter. For details, see www.hydac.com.
Restrictions Pertaining
NOTICE
Impermissible operating media
The filter housing will be damaged
►The OLSW may be used only in combination with watery fluids that
contain small amounts of mineral oil (water with mineral oil <10% by
volume).
►Aggressive or explosive fluids must not be conveyed.

OLSW Features
OLSW en(us) Page 18 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
OLSW components

OLSW Features
OLSW en(us) Page 19 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
Item
Designation
(A)
INLET WATER
(B)
OUTLET WATER
(C)
DRAIN OIL
(D)
VENT
(E)
DRAIN
(F)
Clogging indicator
(G)
Sight glass / connection for bypass level display accessories
(H)
Phase boundary sensor
(I)
Drain line hose for breather
(J)
Flow restrictor

OLSW Features
OLSW en(us) Page 20 / 44
MoWa OLSW 3587900a en-us 2018-08-17.docx
2018-08-17
OLSW dimensions
