HydraMaster Steamatic 8800 TMU User manual

MAN-44210 Rev. 0, July16, 2010
(182-880)
No part of this manual may be reproduced or used in any form or by any means (i.e. graphic, electronic, photocopying
or electronic retrieval systems) without the express written permission of Steamatic, Inc.
All rights reserved. © 2010 Steamatic, Inc.
Steamatic 8800 TMU
Owner’s Manual

i - Steamatic 8800 TMU Owner’s Manual
Steamatic 8800 TMU
Table of Contents
GENERAL INFORMATION........................................................................... SECTION 1
System Concept......................................................................................1-3
Contact Information.................................................................................1-4
Warnings, Cautions and Notices.............................................................1-5
Responsibilities.......................................................................................1-9
Machine Specications ...........................................................................1-12
Spare Parts.............................................................................................1-14
High Altitude Operation...........................................................................1-16
Local Water Precautions.........................................................................1-16
INSTALLATION INFORMATION...................................................................SECTION 2
Operating the Steamatic 8800 TMU in Hot Weather...............................2-2
Setting Up the Steamatic 8800 TMU.......................................................2-5
Orientation of Fuel Pump........................................................................2-6
CLEANING INFORMATION.........................................................................SECTION 3
Precautions.............................................................................................3-2
Preparing the Carpet for Extraction.........................................................3-2
Rinse and Recover..................................................................................3-3
Overwetting.............................................................................................3-3
Streaking.................................................................................................3-3
Cleaning Tool Tips...................................................................................3-4
OPERATING INSTRUCTIONS.....................................................................SECTION 4
Setting the Temperature..........................................................................4-3
Start-up Procedure..................................................................................4-4
Setting the Pressure................................................................................4-4
Shut Down Procedure.............................................................................4-6
MACHINE MAINTENANCE..........................................................................SECTION 5
Operational Maintenance........................................................................5-2
Overall Machine Maintenance.................................................................5-4
Engine Maintenance ............................................................................... 5-5
High Pressure Pump Maintenance ......................................................... 5-8
Vacuum System Maintenance ................................................................5-17
Descaling Procedure (Required).............................................................5-18
Freeze Guarding.....................................................................................5-19

Steamatic 8800 TMU Owner’s Manual - ii
Steamatic 8800 TMU
WATER AND CHEMICAL SYSTEM .............................................................SECTION 6
ELECTRICAL SYSTEM................................................................................SECTION 7
SYSTEMS TROUBLESHOOTING............................................................... SECTION 8
Heating System.......................................................................................8-2
Chemical System....................................................................................8-3
Engine.....................................................................................................8-4
High Pressure System ............................................................................8-7
Vacuum System......................................................................................8-9
ASSEMBLIES AND PARTS LISTS...............................................................SECTION 9
Machine Assembly Parts List ................................................................. 9-2
Frame Assembly Parts List ....................................................................9-8
Electrical Panel Assembly Parts List ......................................................9-11
Engine Assembly Parts List.....................................................................9-17
Blower Assembly Parts List..................................................................... 9-20
Pump and Silencer Assembly Parts List ................................................. 9-21
Pump Assembly Parts List ...................................................................... 9-24
Water Box Assembly Parts List...............................................................9-26
Upper Dash Assembly Parts List............................................................. 9-28
Lower Dash Assembly Parts List............................................................. 9-31
Top Cover Assembly Parts List ............................................................... 9-32
Side Cover Assembly Parts List.............................................................. 9-33
Blower Heat Exchanger Assembly Parts List.......................................... 9-35
Coolant Heat Exchanger Assembly Parts List......................................... 9-36
Exhaust Assembly Parts List................................................................... 9-37
Diverter Valve Box Assembly Parts List.................................................. 9-38
By-Pass Valve Assembly Parts List.........................................................9-39
3 Way ValveAssembly Parts List............................................................9-40
Flywheel Plate Assembly Parts List ........................................................ 9-42
Actuator Valve Assembly Parts List.........................................................9-43
Hi Pressure Manifold Assembly Parts List .............................................. 9-44
Magnaclean Assembly Parts List............................................................ 9-45
100 Gallon Universal Recovery TankAssembly Parts List......................9-48
Recovery Tank Cover with 2 1/2” Port KitAssembly Parts List............... 9-50
110 Gallon Fresh Water TankAssembly Parts List .................................9-52

iii - Steamatic 8800 TMU Owner’s Manual
Steamatic 8800 TMU
HOW TO ORDER PARTS............................................................................ SECTION 10
Warranty Parts Orders ............................................................................10-1
Parts Orders............................................................................................10-1
Emergencies...........................................................................................10-1
WARRANTY INFORMATION....................................................................... SECTION 11
Blower ....................................................................................................11-1
High Pressure Water Pump ...................................................................11-1
Vacuum Tank .......................................................................................... 11-1
Chemical System....................................................................................11-1
Control Panel .........................................................................................11-1
Vacuum and Solution Hoses .................................................................. 11-2
Cleaning Wand and Tool.........................................................................11-2
Water Heating System ............................................................................11-2
Hard Water Deposits...............................................................................11-2
Warranty Procedure................................................................................11-2

Steamatic 8800 TMU Owner’s Manual - iv
Steamatic 8800 TMU
List of Figures
Figure 1-1. Hard Water Map of Mainland United States .....................................1-17
Figure 2-1. Location of Roof Vents in Vehicle ......................................................2-1
Figure 2-2. Recommended Location of Steamatic 8800 TMU in Van...................2-3
Figure 2-3. Install Fuel Pump, Outlet Side Up.......................................................2-6
Figure 2-4. Fuel Pump Must Be in Vertical Position..............................................2-6
Figure 4-1. Steamatic 8800 TMU Upper Dash Assembly .....................................4-1
Figure 4-2. Steamatic 8800 TMU Lower Dash Assembly .....................................4-2
Figure 4-3. Heat Selector Valve............................................................................4-3
Figure 4-4. Thermostat Dial ..................................................................................4-3
Figure 4-5. Throttle Switch....................................................................................4-3
Figure 4-6. Location of Water Pressure Selector Valve .......................................4-4
Figure 4-7. Location of Chemical System Switches..............................................4-5
Figure 5-1. Remove Valve Cap and Valve Assembly............................................5-9
Figure 5-2. Inspect Manifold and Old Valves ........................................................5-9
Figure 5-3. Replace Center Inlet Check Valve
with Modied Check Valve ..............................................................5-10
Figure 5-4. Apply Grease and Install Valves.......................................................5-10
Figure 5-5. Replace Valve Cap and Torque to 95 ft. lbs. (13 m kgs)...................5-10
Figure 5-6. Separate Manifold from Crankcase.................................................. 5-11
Figure 5-7. Seal Assemblies May Come Off with Manifold................................. 5-11
Figure 5-8. Examine Ceramic Plungers.............................................................. 5-11
Figure 5-9. Remove Stainless Steel Plunger Bolt and Ceramic Plunger............5-12
Figure 5-10. Install O-ring, Apply Sealant and Slide Plunger
over Plunger Guide.........................................................................5-12
Figure 5-11. Extract Retainers and Seals ...........................................................5-13
Figure 5-12. Seal Kit and Insertion Tool for Seal Installation ..............................5-14
Figure 5-13. Install Seal Assembly Using O-Ring Grease ..................................5-14
Figure 5-14. Install Retainers into Cavities .........................................................5-15
Figure 5-15. Press Low Pressure Seal Assembly into Cavity.............................5-15
Figure 5-16. Re-install Manifold and Torque Fasteners......................................5-16
Figure 5-17. Torque Sequence in “X” Pattern .....................................................5-16
Figure 5-18. Torque Bolts to 22 ft. lbs (3 m kgs).................................................5-16
Figure 5-19. Recirculation Fitting........................................................................5-18

v - Steamatic 8800 TMU Owner’s Manual
Steamatic 8800 TMU
Figure 6-1. Annotated Water, Chemical and
Solution Flow Diagram - View 1 of 3..................................................6-3
Figure 6-2. Annotated Water, Chemical and
Solution Flow Diagram - View 2 of 3..................................................6-4
Figure 6-3. Annotated Water, Chemical and
Solution Flow Diagram - View 3 of 3..................................................6-5
Figure 6-4. Water, Chemical and Solution Flow Diagram - Larger View...............6-6
Figure 6-5. Chemical Flow Diagram - Larger View...............................................6-7
Figure 6-6. Exhaust Flow Diagram........................................................................6-8
Figure 7-1. Electrical Schematic ...........................................................................7-2
Figure 7-2. Wiring Diagram - View 1 of 3..............................................................7-3
Figure 7-3. Wiring Diagram - View 2 of 3..............................................................7-4
Figure 7-4. Wiring Diagram - View 3 of 3..............................................................7-5
Figure 9-1. Machine Assembly..............................................................................9-2
Figure 9-2. Frame Assembly - View 1 of 5............................................................9-3
Figure 9-3. Frame Assembly - View 2 of 5............................................................9-4
Figure 9-4. Frame Assembly - View 3 of 5............................................................9-5
Figure 9-5. Frame Assembly - View 4 of 5............................................................9-6
Figure 9-6. Frame Assembly - View 5 of 5............................................................9-7
Figure 9-7. Electrical Panel Assembly - View 1 of 2..............................................9-9
Figure 9-8. Electrical Panel Assembly - View 2 of 2............................................9-10
Figure 9-9. Engine Assembly - View 1 of 5.........................................................9-12
Figure 9-10. Engine Assembly - View 2 of 5.......................................................9-13
Figure 9-11. Engine Assembly - View 3 of 5 .......................................................9-14
Figure 9-12. Engine Assembly - View 4 of 5.......................................................9-15
Figure 9-13. Engine Assembly - View 5 of 5.......................................................9-16
Figure 9-14. Blower Assembly ............................................................................9-19
Figure 9-15. Pump and Silencer Assembly.........................................................9-21
Figure 9-16. Pump Assembly - View 1 of 2.........................................................9-22
Figure 9-17. Pump Assembly - View 2 of 2.........................................................9-23
Figure 9-18. Water Box Assembly.......................................................................9-25
Figure 9-19. Upper Dash Assembly....................................................................9-27

Steamatic 8800 TMU Owner’s Manual - vi
Steamatic 8800 TMU
Figure 9-20. Lower Dash Assembly - View 1 of 2...............................................9-29
Figure 9-21. Lower Dash Assembly - View 2 of 2...............................................9-30
Figure 9-22. Top CoverAssembly.......................................................................9-32
Figure 9-23. Side Cover - Machine Assembly.....................................................9-33
Figure 9-24. Blower Heat Exchanger Assembly .................................................9-34
Figure 9-25. Coolant Heat Exchanger Assembly................................................9-36
Figure 9-26. Exhaust Assembly ..........................................................................9-37
Figure 9-27. Diverter Valve Assembly.................................................................9-38
Figure 9-28. By-Pass Valve Assembly................................................................9-39
Figure 9-29. 3 Way Valve Assembly....................................................................9-40
Figure 9-30. Flywheel Plate Assembly................................................................9-41
Figure 9-31. Actuator Valve Assembly ................................................................9-43
Figure 9-32. Hi Pressure Manifold Assembly......................................................9-44
Figure 9-33. Magnaclean Assembly....................................................................9-45
Figure 9-34. 100 Gallon Universal Recovery Tank Assembly - View 1 of 2........9-46
Figure 9-35. 100 Gallon Universal Recovery Tank Assembly - View 2 of 2........9-47
Figure 9-36. Recovery Tank Cover with 2 1/2” Port Kit Assembly .....................9-49
Figure 9-37. 110 Gallon Fresh Water Tank Assembly.........................................9-51

1-1 - General Information
Steamatic 8800 TMU
The compact but powerful Steamatic 8800 TMU is a carefully engineered truckmount
carpet cleaning machine.
A950G Daihatsu engine powers the Steamatic 8800 TMU’s Tuthill 4007 Tri-Lobe vacuum
blower and the high pressure water pump, rated at 4 gpm (15 litres/minute).
The Steamatic 8800 TMU’s innovative design features a blower/engine exhaust diverter
which allows for a non-recirculating or “dump-less” subsystem. This dump-less system,
a rst in the carpet cleaning industry, reduces the need to rell the fresh water tank or
empty the recovery tank.
Other features of the Steamatic 8800 TMU include:
Dual oil bath and sight glasses for enhanced blower reliability• 0 - 1,200 psi (0 - 8,274 kPa) heated for carpet and tile cleaning• Dual tool/wand capable• A.D.C temperature control with instant heat up to 265° F (129.4° C)• Dura FlowAutomatic Pump Out (APO)• 110 gallon Fresh Water Tank•
1- General Information

General Information - 1-2
Steamatic 8800 TMU
This Owner’s Manual contains installation and operation instructions as well
as information required for proper maintenance, adjustment and repair of the
Steamatic 8800 TMU. Component troubleshooting guides have also been included for
your convenience.
It is the purpose of this manual to help you properly understand, maintain and service
your Steamatic 8800 TMU. Follow the directions carefully and you will be rewarded with
years of protable, trouble-free operation.
It is imperative that no section of this manual be overlooked when preparing for operation
of the Steamatic 8800 TMU. Please read the manual to familiarize yourself with the
operation of your machine, paying special attention to all Warnings and Cautions.
This section of the manual contains the following information:
Contact Information

Warnings, Cautions and Notices

Machine Specications

Responsibilities

Local Water Precautions

1-3 - General Information
Steamatic 8800 TMU
SYSTEM CONCEPT
This is how the Steamatic 8800 TMU works:
Incoming water enters the water box and is pressurized by the high pressure water1. pump. The water is heated by engine coolant in the tube and shell heat exchanger
and then by the engine and blower exhaust in the cross ow heat exchanger.
Cleaning solution is then injected into the pressurized water stream and the heated
2. solution is delivered to the cleaning tool.
The solution is recovered by the vacuum generated by the vacuum pump and is
3. collected in the recovery tank for proper disposal.
Photographs and illustrations included in this document can represent optional
equipment as well as standard equipment.
Water Box
Water Pump
Heat
Exchangers
Silencer
Engine
Vacuum Blower

General Information - 1-4
Steamatic 8800 TMU
CONTACT INFORMATION
If you have any questions regarding the operation, maintenance or repair of this machine,
please contact your local distributor.
To nd a local distributor, please visit our website at http://www.hydramaster.com/owners/
locate/index.asp.
If your question cannot be resolved by your distributor or by the information within this
manual, you may contact HydraMaster Customer Service direct using the following phone
numbers.
Hours Telephone Numbers E-mail Addresses
Monday-Friday [phone] Service Tech Support:
[e-mail]
7:00 a.m. to 5:00 p.m. [phone] Parts Parts Support:
[e-mail]
Pacic Standard Time [phone] Parts /
Service FAX
When calling your distributor, be sure to reference the serial number and date of
purchase.
FOR YOUR REFERENCE:
Serial No. ____________________________________________________
Date of Purchase: _____________________________________________
Purchased From (Distributor): ____________________________________

1-5 - General Information
Steamatic 8800 TMU
WARNINGS, CAUTIONS AND NOTICES
The manufacturer uses this WARNING symbol throughout the manual to warn of
possible injury or death.
This CAUTION symbol is used to warn of possible equipment damage.
This NOTICE symbol indicates that federal or state regulatory laws may apply,
and also emphasizes supplemental information.

General Information - 1-6
Steamatic 8800 TMU
Warnings and Cautions specic to the Steamatic 8800 TMU include the following:
During the operation of the truckmount many components are in motion. Never
touch any part of the truckmount that is in motion. Serious injury may result.
During the operation of the truckmount many surfaces will become extremely hot.
Never touch hot surfaces. Serious injury may result.
The operation of this truckmount can produce noise levels exceeding 85 decibels
to a distance of 10 ft (3.05 m). The Occupational Safety and HealthAdministration
(OSHA) recommends the use of hearing protective equipment if a person is
exposed to an average of 85 decibels over an 8-hour period. Check with local
and state agencies concerning hearing conservation rules.
During the operation of the truckmount carbon monoxide and other toxic fumes
are produced. Position the vehicle so that any fumes produced will be directed
away from inhabited areas and any points of building entry (doors, windows, air
conditioning units, fans, etc.). Do not occupy the vehicle while the truckmount is
in operation. Serious injury may result.
Duringthe operation of thetruckmount, chemicals known tothe State of California
to cause cancer, birth defects and other reproductive harm are produced by the
engine exhaust.
Never operate the truckmount with a portable gas container inside the vehicle.
Doing so will increase the risk of re and explosion. Serious injury or death may
result.
Transportingaventedfuelcontainerthatpresentlycontains,orhasevercontained
in the past, a ammable liquid is strictly forbidden by The manufacturer and by
federal and state regulations. Doing so will increase the risk of re and explosion.
Serious injury or death may result.

1-7 - General Information
Steamatic 8800 TMU
Never smoke in or around the truckmount. Doing so will increase the risk of re
and explosion. Serious injury or death may result.
During the operation of the truckmount the exhaust system will become extremely
hot. Keep all ammable materials away from the truckmount exhaust system.
Failure to do so will increase the risk of re and explosion. Serious property
damage may result.
Never operate the truckmount when the vehicle is tilted more than 10 degrees in
anydirection.Doingsowillresultinimproperlubricationoftheinternalcomponents,
and will increase the risk of serious component or engine damage.
Never perform cleaning operations when the truckmount engine is running at the
IDLE throttle position. Failure to do so will increase the risk of serious component
or engine damage.
Never operate the truckmount with the vehicle doors closed. Doing so results in
extremelyhigh temperaturesinside thevehicle andwill leadto seriouscomponent
or engine damage.
Neveruseconcentratedacidsorsolvents(includingd-limonene)inthetruckmount
water system or chemical system. Use of these products will cause serious
component damage.
Neveroperatethetruckmountwithawaterhardnessreadingmeasuring3.0grains
per gallon (3.79 litres) or higher. Using reading than 3.0 grains per gallon (3.79
litres) will cause scale to build up inside the truckmount water system. Scale build
up causes serious component damage. Test all water prior to use and use water
softening equipment if necessary.

General Information - 1-8
Steamatic 8800 TMU
Never allow water to freeze inside the truckmount. Serious component damage
will occur. Perform all freeze guarding procedures outlined in this digital Owner’s
Manual.
Many vehicles have critical components mounted directly below the oor that
can easily be damaged. Before drilling holes in the oor of the vehicle inspect
the underside of the vehicle for critical components. Failure to do so may result
in damage to the vehicle.

1-9 - General Information
Steamatic 8800 TMU
RESPONSIBILITIES
Purchaser’s Responsibilities
Prior to purchasing a van, ensure that the payload is suitable for all of the equipment• thatwillbeinstalledand transported.Thisincludesand isnotlimitedto:thetruckmount,
recovery tanks, fresh water tanks, on-board water, hose reels, hoses, cleaning tools,
chemicals and drying equipment. Payload capacity information is available through
the auto dealer, the manufacturer’s web site, and is also located on the door pillar of
the driver’s side door.
Purchase a heavy duty Group 24 (500+ CC Amps) battery for this truckmount. This is
• normally available from the installation dealer.
Prior to dropping your van off at the distributor for the truckmount to be installed, have
•
a spray-on bed liner applied to the oor such as Rhino Lining® or Line-X®.
Plywood and carpet are not recommended.
Prior to operating the truckmount, read this manual in its entirety and familiarize• yourself with the information contained here. Special attention should be paid to all
Warnings and Cautions.
The distributor is responsible for the correct installation of the truckmount. The
• distributor is also responsible to train you in the correct and proper operation and
maintenance of the truckmount.
Any modication of the truckmount may void the warranty.

General Information - 1-10
Steamatic 8800 TMU
Distributor’s Responsibility
Acceptance of Shipment
Before accepting the truckmount, check the following:
The truckmount should be free from any damage during shipping. Do not sign the1. delivery receipt until you have closely inspected the truckmount and noted any
damageonthedeliveryreceipt.Hiddendamagemaybepresenteveniftheboxlooks
okay. It is recommended that the box be opened before you sign for the shipment.
Check the packing list and verify that all items are accounted for.
2.
Installation Responsibilities
Ensure proper payload capacity. It is the distributor’s responsibility to verify that the• equipment package does not exceed the vehicle capacity.
Ensure installation of a safe fuel tap system and through-oor ttings as provided by
• The manufacturer.
Ensure proper placement of the truckmount, recovery tank, fresh water tank, and• accessories in the vehicle, and check that they are secured with bolts and back up
plates. The distributor should verify that the owner is in agreement with the layout.
Ensure proper connection of the fuel lines.• Ensure proper connection and installation of the battery. Verify that the battery is in• accordance with The manufacturer’s recommendation.
Check the pump, vacuum blower and engine oil levels prior to starting the
• truckmount.
Start and run the truckmount and check that all systems function properly.
• Test all hoses, wands and other accessories for correct operation.• Ensure timely return of the document package.•

1-11 - General Information
Steamatic 8800 TMU
Training
The distributor should provide a thorough review of the operation manual with the
purchaser along with instruction and familiarization in:
How all the truckmount’s systems function.
1. All safety precautions and their importance.2. How to correctly start and shut down the truckmount.3. How to correctly clean with the truckmount.4. Where and how often to check and change component oil levels.5. Freezing damage and how to avoid it. This includes explaining proper freeze6. guarding procedures.
How to do basic troubleshooting of the truckmount.
7. Hard water damage and how to avoid it. This includes how to determine if hard8. water exists in your area and the installation and use of water softening systems.
The truckmount’s warranty and warranty procedures.
9.

General Information - 1-12
Steamatic 8800 TMU
MACHINE SPECIFICATIONS
Frame Dimensions 26.0" W x 45" D x 39" H
(66 cm x 114 cm x 99 cm)
Weight 900 lbs (408 kg)
Engine - Daihatsu 950G Oil Type 5W-30 Synthetic
Capacity 3.2 quarts (3.02 litres)
when changing oil and lter
Engine rpm High - 3,000 rpm
Mid - 2,650 rpm
Idle - 1,500 rpm
Fuel Consumption High - 1.4 gph (5.3 litres/hr)
Mid - 1.2 gph (4.6 litres/hr)
Ignition Keyless
Vacuum Blower - Tuthill
4007 Competitor (Dual
Splash Lubrication)
Oil Type
Max. Vac. 12” Hg PneuLube or other ISO 100 rating
Gear End Capacity Approx. 5.8 oz. (171.5 ml)
Drive End Capacity Approx. 4.7 oz. (139 ml)
Blower rpm 3,000 rpm
Water Pump- General
Pump Oil Type 15W-40
Capacity 14 oz (414 ml).
Pump Rate 4.0 gpm (15 litres/minute)
Pump rpm 1,700 rpm
Operating Pressure 0 - 1,200 psi (heated)
(0 - 8,274 kPa) 0 - 2,000 (no heat) (0 - 13,790 kPa)
Chemical System Last Step Chemical
Injection
