Hytera PD40X User manual

DIGITAL PORTABLE RADIO
OWNER’S MANUAL

Preface
Thanks for your favor in our product. This manual is helpful for you to quickly
know how to use the product. To avoid body injury or property loss caused by
misoperation, please read the Safety Information Booklet carefully before use.
This manual is applicable to the following product:
PD40X Digital Portable Radio (X may represent 2, 5, 6 or 8)
DIGITAL PORTABLE RADIO

2
Icon Conventions
: Indicates functions that are available on digital channel only.
: Indicates functions that are available on analog channel only.
Functions marked with no icon are available on both analog and digital
channels.
Disclaimer
Hytera Communications Corporation Limited (the Company) endeavors to
achieve the accuracy and completeness of this manual, but no warranty
of accuracy or reliability is given. All the specifications and designs
are subject to change without notice due to continuous technology
development. No part of this manual may be copied, modified, translated,
or distributed in any manner without the express written permission of us.
We do not guarantee, for any particular purpose, the accuracy, validity,
timeliness, legitimacy or completeness of the Third Party products and
contents involved in this manual.
If you have any suggestions or would like to learn more details, please visit
our website at: http://www.hytera.com.
RF Radiation Information
This product must be restricted to operations in an occupational/controlled
RF exposure environment. Users must be fully aware of the hazards of the
exposure and able to exercise control over their RF exposure to qualify for
the higher exposure limits.
RF Radiation Prole
Radio Frequency (RF) is a frequency of electromagnetic radiation in the
range at which radio signals are transmitted. RF technology is widely
used in communication, medicine, food processing and other fields. It may
generate radiation during use.
RF Radiation Safety
In order to ensure user health, experts from relevant industries including
science, engineering, medicine and health work with international
organizations to develop standards for safe exposure to RF radiation.
These standards consist of:
●United States Federal Communications Commission, Code of Federal
Regulations; 47CFR part 2 sub-part J;
●American National Standards Institute (ANSI)/Institute of Electrical and
Electronic Engineers (IEEE) C95. 1-1992;
●Institute of Electrical and Electronic Engineers (IEEE) C95.1-1999;
●International Commission on Non-Ionizing Radiation Protection
(ICNIRP) 1998;
FCC Regulations
Federal Communication Commission (FCC) requires that all radio
communication products should meet the requirements set forth in
the above standards before they can be marketed in the U.S, and the
manufacturer shall post a RF label on the product to inform users of
operational instructions, so as to enhance their occupational health against
exposure to RF energy.
Operational Instructions and Training Guidelines
To ensure optimal performance and compliance with the occupational/
controlled environment RF energy exposure limits in the above standards
and guidelines, users should transmit not more than 50% of the time and
always adhere to the following procedures:
●RF energy will be generated only when the radio is transmitting.
●The radio must be at least 2.5 centimeters away from human body
when transmitting.

3
Contents
Items in the Package----------------------------------------1
Product Overview --------------------------------------------2
Product Controls ---------------------------------------------------2
Programmable Keys ----------------------------------------------3
Before Use------------------------------------------------------3
Attaching the Battery----------------------------------------------3
Attaching the Antenna --------------------------------------------3
Attaching the Belt Clip --------------------------------------------4
Attaching the Accessories ---------------------------------------4
Charging the Battery ---------------------------------------------4
Checking the Battery Power ------------------------------------5
Status Indication ---------------------------------------------5
LED Indicator -------------------------------------------------------5
Basic Operation-----------------------------------------------6
Turning the Radio On/Off ----------------------------------------6
Adjusting the Volume ---------------------------------------------6
Selecting a Zone ---------------------------------------------------6
Selecting a Channel ----------------------------------------------6
Call Services---------------------------------------------------7
Call on Digital Channel --------------------------------------7
Call on Analog Channel -------------------------------------7
Features and Operations ----------------------------------8
Power Level ---------------------------------------------------------8
Covert Mode --------------------------------------------------------8
Time-out Timer (TOT)---------------------------------------------8
Busy Channel Lockout -------------------------------------------8
Scan-------------------------------------------------------------------8
Talk Around----------------------------------------------------------9
One Touch Call ------------------------------------------------9
Squelch Level Adjustment ---------------------------------10
Monitor ----------------------------------------------------------10
CTCSS/ CDCSS ----------------------------------------------10
Squelch Off ----------------------------------------------------10
TDMA Direct Mode -------------------------------------------11
VOX -------------------------------------------------------------------11
Auto Mode Switch --------------------------------------------11
Troubleshooting ----------------------------------------------12
Care and Cleaning -------------------------------------------13
Optional Accessories ---------------------------------------14

1
Items in the Package
Please unpack carefully and check if all items listed below are received.
If any item is missing or damaged, please contact your dealer.
The frequency band is marked on the label of antenna; if
not, please refer to the label on the radio for frequency band
information.
Note
All pictures in this manual are for reference only.
Note

2
Product Overview
Product Controls

3
Programmable Keys
For enhanced convenience, you may request your dealer to program the
SK1 and SK2 keys as shortcuts to certain feature.
Product Overview Before Use
Attaching the Battery
To attach the battery, do as follows.
To remove the battery, please turn off the radio first. Then
slide the battery latch upwards to unlock the battery.
Attaching the Antenna
Do not hold the radio by its antenna, otherwise the
performance and lifespan of the antenna will be reduced.
12
“ click ”
“ click ”
Assemble Disassemble
Note
Assemble Disassemble
Caution

4
123
12
Before Use
Attaching the Belt Clip
Attaching the Accessories
Remove the screws Assemble the Belt Clip
Caution
Charging the Battery
Charging the Radio Charging the Battery
LED Indication Current Status
The LED Indicator flashes red slowly Standby (no load)
The LED Indicator glows red Charging
The LED Indicator glows orange 90 %90% charged
The LED Indicator glows green 100 %Fully charged
The LED Indicator flashes red rapidly Charging error
●Make sure the radio is powered off before charging.
Read the Safety Information Booklet in advance to
get necessary safety information.
●Charge a new battery for at least 5 hours before initial
use for best performance.

5
Before Use
LED
LED
Checking the Battery Power
You may check the current battery power by holding down the
programmed Battery Power Indicator key preset by your dealer. And
release the key to exit. Battery power indications are listed below:
LED Indication Battery Power
The LED indicator glows green High
The LED indicator glows orange Medium
The LED indicator glows red Low
The LED indicator glows red and
low battery alert sounds
Under the low battery
threshold. Charge or replace
the battery for proper radio
operation
LED Indication Product Status
The LED indicator flashes green Powering on
The LED indicator glows green Receiving
The LED indicator glows red Transmitting
The LED indicator flashes orange slowly Scanning
The LED indicator glows orange
Call hung period.
No voice is being
transmitted or received
on the traffic channel
during a call. Within
such period, you can
hold down the PTT
key to talk to the other
party.
Status Indication
LED Indicator

6
- +
Basic Operation
Turning the Radio On/Off
Adjusting the Volume
Selecting a Zone
A zone is a group of channels with the same property, which can facilitate
convenient management over the channels. The radio supports three
zones, each of which consists of up to 16 channels. You can switch to the
appropriate zone by pressing the programmed Zone Up or Zone Down
key preset by your dealer.
If the Zone Notify feature is enabled by your dealer, the radio will
announce the zone number when selecting zone.
Selecting a Channel
After the radio is powered on, you can rotate the Channel Selector
Knob to select an appropriate channel.
If the Channel Notify feature is enabled by your dealer, the radio will
announce the channel number upon channel switching.
Selecting a Zone Selecting a Channel

7
2.5~5.0CM
Call Services
After the radio is powered on, you can make and receive calls. To ensure
optimal volume of the receiving radio, keep the microphone about 2.5 to
5 centimeters away from your mouth when transmitting.
●Private call: It is a voice call between one individual user and another
individual user.
●Group call: It is a voice call between one individual user and a
predefined group of users. All parties in the group can communicate
with each other.
●All call: It is a one-way voice call from any user to all users on a
channel.
Call on Digital Channel
You can initiate a private call, group call or all call (your radio must be
programmed to allow you to use the all call service) through the same
operations on digital channel. When calling back, the radio will make a
call to the calling party in private call; but in group call, the radio will make
a call to all parties involved when calling back. And you cannot call back
in an all call.
Here takes the private call between Radio A and Radio B for example:
1. Radio A and B select the same digital channel.
You may preset a regular private call/group call/all call contact for
each digital channel via your dealer.
2. Radio A holds down the PTT key to initiate a call.
3. Radio A can talk to the microphone when the LED indicator on the
radio glows red and release the PTT key to finish talking.
4. Radio B can receive the call without any operation.When receiving,
the LED indicator glows green.
5. Radio B can hold down the PTT key to talk when the LED indicator on
the radio is glowing orange.
6. Radio A can receive the call without any operation. When receiving,
the LED indicator glows green.
7. Radio A can hold down the PTT key to talk when the LED indicator on
the radio is glowing orange.
Call on Analog Channel
The calling operations on the analog channel are the same as that on the
digital channel. The difference is that the called parties are all the users
on the channel, rather than the preset contact for the channel.

8
Features and Operations
Power Level
Description
Power Level allows you to set the TX power level. High power can extend
the signal coverage, enabling you to communicate with farther radios.
Generally, we recommend you to adopt low power for battery saving.
Operation
Press the programmed Adjust Power Level key to toggle the power
level between high and low. When you switch to high power, a high-
pitched tone sounds; when you switch to low power, a low-pitched tone
follows.
Covert Mode
Description
Covert Mode allows you to disable all the visible or audible indications
programmed by your dealer, such as the LED indicator, vibration and
tones, for communication in covert situations. This feature is mainly used
in special missions.
If an audio accessory is connected to the radio, the
radio will output the voice and alert tones via the audio
accessory when the Covert Mode is enabled.
Operation
Press the programmed Covert Mode key to enable or disable this
feature.
Note
Time-out Timer (TOT)
Description
This feature is to prevent any user from occupying a channel for an
extended period and to avoid radio damages due to overheat.
Operation
If the TX time (60s preset by dealer) expires, the radio will automatically
terminate transmission and keep beeping. To stop beeping, please
release the PTT key. You must wait for a certain time period (preset by
your dealer) before you can hold down the PTT key to transmit again.
Busy Channel Lockout
Description
Busy Channel Lockout can prevent radio user from interfering other
transmitting radio users on the same channel.
Operation
When the channel is busy, the radio will beep when you hold down the
PTT key to transmit, indicating the channel is busy. You can hold down
the PTT key to transmit when the channel is free.
Scan
Description
Scan allows you to search for channels with ongoing activities and listen

9
Features and Operations
to communication activities on other channels so that you can keep a
close track of your team members.
Operation
Press the programmed Scan key to enable the Scan feature (a high-
pitched tone sounds). Or switch to a channel on which the Auto Scan
feature is enabled via the CPS to enable the Scan feature.
After the feature is enabled, the radio will scan all the channels in the
scan list set for the channel on which scanning starts. The scanning
process is as follows:
1. During scanning, the LED indicator flashes orange slowly.
2. When activities are detected on a channel, the radio will stay on the
channel to receive current activities, and the LED indicator will glow
green.
3. If you want to continue listening to the activities on the channel, press
the programmed Monitor or Squelch Off Momentary key during
scan stay.
4. If you want to stop scanning, press the programmed Scan key again (a
low-pitched tone sounds).
The radio cannot scan analog channel and digital channel
at the same time.
Talk Around
Description
Talk Around allows you to continue to communicate in DMO by pressing
Note
the programmed Talk Around key when the repeater malfunctions, or
when the radio is out of the repeater’s coverage but still within the
coverage of the other radio.
Operation
Press the programmed Talk Around key to enable the feature (a high-
pitched tone sounds); press this key again to disable the feature (a low-
pitched tone sounds).
One Touch Call
Description
This feature allows you to make calls or send messages to the predefined
contact easily. By pressing the programmed One Touch Call key, you
can make the following services:
●To initiate group calls or send text messages to the group contact.
●To initiate private calls or send messages to the private contact.
Operation
Service Operation
To initiate private calls or group
calls on the digital channel.
Press the One Touch Call key and
then hold down the PTT key.
To send text messages Press the programmed One Touch
Call key.

10
Features and Operations
Squelch Level Adjustment
Description
Squelch Level Adjustment allows you to adjust the squelch threshold
required for the radio to be unmuted.
Generally, the higher squelch level requires stronger signal. If the squelch
level is set to “Open”(squelch level: 0), the speaker will keep unmuted
irrespective of the decoding conditions.
Operation
Press the programmed Adjust Squelch Level key to switch the level
among “Tight”, ”Normal”and ”Open”. When switching from
“Tight“to “Open“, a low-pitched tone sounds followed by the
background noise; from “Open“to “Normal“, a high-pitched tone
sounds with the background noise fading; from “Normal“to “Tight“,
a high-pitched tone sounds.
Monitor
Description
Monitor allows you to set whether the radio can receive the weak signals
in order to monitor the radio.
Operation
Press the programmed Monitor key to enable the feature (a high-pitched
tone sounds); press this key again to disable the feature (a low-pitched
tone sounds).
CTCSS/ CDCSS
Description
CTCSS/CDCSS allows the radio to add signaling with a frequency lower
than that of the audio to the carrier. The speaker can be unmuted only
when the CTCSS/CDCSS received by the receiving party is matched
with that transmitted by the transmitting party.
Operation
Enable or disable this feature via CPS by your dealer.
Squelch Off
Description
Squelch Off allows the speaker of the radio to keep unmuted no matter
whether carrier is present.
Operation
●Press the programmed Squelch Off key to enable the feature (a high-
pitched tone sounds) and sounds background noise. Press this key
again to disable the feature (a low-pitched tone sounds).
●Press the programmed Squelch Off Momentary key to enable
the feature (a high-pitched tone sounds) and sounds background
noise. Press this key again to disable the feature (a low-pitched tone
sounds).

11
TDMA Direct Mode
Description
TDMA Direct Mode allows the radio to divide the 12.5 kHz channel into
two alternative slots in direct mode. If the radio operates on a channel
with this feature enabled and one time slot is already occupied, it can
transmit and receive in the other free time slot.
Operation
With this feature enabled, you can manually switch to a digital channel in
TDMA Direct Mode or enter the TDMA Direct Mode by powering on the
radio on a digital channel in TDMA Direct Mode.
VOX
Description
VOX allows you to trigger the voice transmission by speaking directly
without holding down the PTT key. When the voice detected by the
microphone (either external or internal microphone) reaches the volume
to trigger the transmission, it will be transmitted automatically.
Follow the instructions below when using the VOX
feature:
●To use the VOX feature with an external microphone,
make sure the PTT/VOX switch is switched to “VOX”
before the radio is powered on and the VOX feature is
enabled.
Features and Operations
●The VOX feature will be enabled for all the channels.
●The VOX feature settings will not remain unchanged when
the radio is powered on and off.
●After the VOX feature is enabled, switching the PTT/
VOX switch to “PTT” will disable the feature. In such case,
switching the PTT/VOX switch to “VOX” will keep the radio
transmitting. To make the radio function properly, reattach the
earpiece to enable the feature again.
Operation
Switch the PTT/VOX switch to “VOX”and attach the earpiece to the
radio. Press the programmed VOX key to enable this feature.
Auto Mode Switch
Description
Auto Mode Switch allows the channel with this feature to be configured
with digital and analog parameters at the same time, to receive digital
or analog voice calls, and to call back after switching to digital or analog
mode automatically.
Operation
To enable Auto Mode Switch feature, switch to the mixed channel
manually or turn on the radio on the mixed channel.
Caution

12
Troubleshooting
Phenomena Analysis Solution
The radio cannot
be powered on.
The battery may be improperly installed. Remove the battery and reattach it.
The battery power may run out. Recharge or replace the battery.
The battery may suffer from poor contact caused by dirtied
or damaged battery contacts.
Clean the battery contacts. If the problem cannot be solved, contact your
dealer or authorized service center for inspection and repair.
During receiving,
the voice is weak,
discontinuous or
totally inactive.
The battery voltage may be low. Recharge or replace the battery.
The volume level may be low. Increase the volume.
The antenna may get loose or may be improperly installed. Power off the radio, and reattach the antenna.
The speaker may be blocked or damaged. Clean the surface of the speaker. If the problem cannot be solved,
contact your dealer or authorized service center for inspection and repair.
You cannot
communicate with
other members.
The frequency or signaling may be inconsistent with that of
other members.
Set your TX/RX frequency and signaling to the same as that of other
members.
The channel type (digital and analog) may be set
inconsistently. Make sure all members are on the same digital/analog channel.
You may be too far away from the group members. Move towards other members.
Irrelevant
communication or
noise is heard on
the channel.
You may be interrupted by radios using the same frequency. Change the frequency, or adjust the squelch level.
The radio may be set without signaling. Set signaling for all member radios to avoid interference at the same
frequency.
The noise is too
loud.
You may be too far away from other members. Move towards other members.
You may locate in an unfavorable position. For example,
your communication may be blocked by high buildings or
frustrated in the underground areas.
Move to an open and flat area, and restart the radio.
You may suffer from external disturbance (such as
electromagnetic interference). Stay away from equipment that may cause interference.
If the above solutions cannot fix your problems, or you may have some other queries, please contact us or your local dealer for more technical support.

13
Care and Cleaning
To guarantee optimal performance as well as a long service life of the
product, please follow the tips below.
Product Care
Do not pierce or scrape the product.
Keep the product far away from substances that can
corrode the circuit.
Do not hold the product by its antenna directly.
Do not hold the product by its earpiece cable directly.
Attach the accessory connector cover when the
accessory is not in use.
HNO 2
HNO 3
H2FeO4
HMNO4
HMNO 4
HNO3
H2FeO4
H2TIO3
Product Cleaning
Turn off the product and remove the battery before
cleaning.
�
●Clean up the dust and fine particles on the product surface and
charging piece with a clean and dry lint-free cloth or a brush regularly.
●Use neutral cleanser and a non-woven fabric to clean the keys and
front case after long-time use. Do not use chemical preparations such
as stain removers, alcohol, sprays or oil preparations, so as to avoid
surface case damage.
●Make sure the product is completely dry before use.
Caution

14
Optional Accessories
The following items are the main optional accessories for the product,
and please consult your local dealer for more other accessories.
Use the accessories specified by the Company only. If
not, the Company shall not be liable for any losses or
damages arising out of use of unauthorized accessories.
Caution
Audio:
MCA08 MCU Multi-unit Rapid-rate Charger (for Li-
Ion/Ni-MH batteries),
CH10A06 Dual-Pocket MCU Charger Kit (for Li-
Ion/Ni-MH battery, including Dual-Pocket Charger
and Switching Power),
PS7501 AC/DC Adaptor,
MCA05 Battery Optimizing System,
BL2010 2000mAh Li-Ion battery
Power Supply:
EAM13 3-wire Surveillance Earpiece with VOX &
Transparent Acoustic Tube (Black),
ESM14 Remote Earbud,
EAM17 Remote Earpiece with Transparent
Acoustic Tube,
EHM20 Remote Swivel Earset,
EHM19 Remote C-Earset,
SM26M1 Remote Speaker Microphone,
SM13M1 Remote Speaker Microphone (IP55)
Carrying
Accessories:
Cable: PC76 Programming & Download Cable
NCN011 Nylon Carrying Case (Half-folded)(Non-
swivel)(Black),
LCBN13 Universal Chest Pack (Nylon)(Black)

8 1 1 PD4 0 0 0 0 0 0 0
2015
C10524 L07157
Hytera Communications Corporation Limited.
Hytera Communications Corporation Limited.
