Hytronik HC005S/BT Quick guide

Installation and Instruction Manual
3. Installation
Mechanical Structure & Dimensions
HC005S/BT
Built-in Microwave Motion Sensor with 5.0 SIG Mesh
2. Download the App
Free App for set-up and commissioning
HBHC25-20200302-A0
1. Technical Specifications
ON/OFF CONTROL
Protocol
4 dBm
2.4 GHz - 2.483 GHz
Operation frequency
Transmission power
Range (Typical indoor)
10~30m
Stand-by power
Operating voltage
< 1W
220~240VAC 50/60Hz
Load ratings
20sWarming-up
300VA(capacitive),400W(resistive)
EMC standard (EMC)
Safety standard (LVD)
Certification
EN55015, EN61000, EN61547
Semko,CB, CE , EMC, RED, RCM,UKCA
EN60669-1/-2-1
AS/NZS60669-1/-2-1
RED EN300328, EN301489-1/-17,EN62479,
30°~150°
Ta:-20
OC~+50OC
Sensor principle
Detection range (Max.)*
Detection angle
Operation temperature
IP20IP rating
5.0 SIG Mesh
Max installation height: 6m
Max detection range：10m (diameter)
High Frequency (microwave)
Tc:+75°Case temperature(MAX.)
4.2
36.5
65
71.7
80.5
26
12.1
23.8 24.9
Bluetooth module
Antenna module
Photocell AdvanceTM
Daylight sensor
Power supply
220-240V out control
26
23.8
50
43.8
36.5
65
4.2
Bluetooth module
Antenna module
Photocell AdvanceTM
Daylight sensor
Power supply
220-240V out control
5.0 SIG mesh
Web app/platform: www.iot.koolmesh.com
Koolmesh Pro app for iPad
Smartphone app for both iOS & Android platform
for iOS for Android
for iPad
for Web
Web
iOS
Android

HBHC25-20200302-A0
Subject to change without notice.
5. Additional Information / Documents
4. Detection Pattern
Wiring Diagram
Control gear
Control gear
Control gear
Wire Preparation
0.75 - 1.5mm
8mm
To make or release the wire from the terminal,
use a screwdriver to push down the button.
For some special Applications, customers may need a larger Bluetooth transmission for both smartphone to device and device to device. Thanks to the reinforced Bluetooth antenna,
with it being added to the sensor, the transmission distance(smartphone to device) enlarges to 20m, the distance of device to device is around 50m.
Optional accessory: Reinforced Bluetooth antenna
Ceiling mounted detection pattern (m)
Ceiling mounted height(m)
50
6
10%
30%
75%
50%
Wall mounted height (m)
Wall mounted detection pattern (m)
9
4
0
10%
30%
75%
50%
1. For full explanation of Hytronik Photocell AdvanceTM technology, please kindly refer to www.hytronik.com/download ->knowledge ->Introduction of Photocell Advance
2. To learn more about detailed product features/functions, please refer to www.hytronik.com/download ->knowledge ->Introduction of App Scenes and Product Functions
3. Regarding precautions for Bluetooth product installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->Bluetooth Products - Precautions for Product Installation and Operation
4. Regarding precautions for microwave sensor installation and operation, please kindly refer to www.hytronik.com/download ->knowledge ->Microwave Sensors - Precautions for Product Installation and Operation
5. Data sheet is subject to change without notice. Please always refer to the most recent release on www.hytronik.com/products/bluetooth technology ->Bluetooth Sensors
6. Regarding Hytronik standard guarantee policy, please refer to www.hytronik.com/download ->knowledge ->Hytronik Standard Guarantee Policy
HA01BHA01W
12.7 9.5
31.2
48.7
Installation hole 6.5mm Bluetooth antenna
Gasket Metallic Spacer M6.5 Nut
