Hytronik HCD438 User manual

Photocell
Intelligent
Tri-level dimming control based upon occupancy (also known as corridor function)
TM
HC438V HCD438
Detached Linear Version with Remote Control
Tri-level Control Sensor
Applications
Occupancy detector with tri-level dimming control suitable for indoor use:
Ofce / Commercial Lighting
Classroom
Meeting Room
Use for new luminaire designs and installations
Features
Technical Data
Input Characteristics
Optional 1-10V or DALI dimming control method
Sensor Data
5-year warranty
Zero crossing detection circuit reduces in-rush current and prolongs relay life (HC438V)
Ambient daylight
threshold One-touch daylight learning via remote control
Loop-in and loop-out terminal for efcient installation (HC438V)
Loop in
Loop out
Safety and EMC
Tc: +75
O
C
Operation temperature
Case temperature (Max.)
Ta: -20
O
C~ +55
O
C
Environment
IP20
IP rating
Stand-by power
Model No.
120~277VAC 50/60Hz
Mains voltage
Load ratings:
HC438V
HCD438
<0.5W
Capacitive:
200VA~120V / 400VA~277V
Resistive:
500W~120V / 1200W~277V
30mA, 16VDC (max. 15 devices)
20s
Warming-up
HC438V HCD438
24 hour daylight monitoring dawn/dusk sensor
Lux off function, daylight threshold prior to motion detection
Daylight
Monitoring
Special photocell to measure and differentiate natural light from LED light
Photocell Advance
Model No.
30O~ 150O
<0.2mW
5.8GHz +/- 75MHz
High Frequency (microwave)
PIR Detection
Sensor principle:
Operation frequency
Transmission power
Detection range:
Detection angle
SAM7 SAM7/I
HIR02 HIR04 HIR19
SAM7
HIR02 HIR04
SAM7 SAM7/I HIR02 HIR04
HIR09/S HIR09/F HIR09/C HIR09/AA
Max installation height
Max Detection range 12m (Diameter)
6m
Max installation height
Max Detection range 6m (Diameter)
3m
HIR09 & HIR19
Max installation height
Max Detection range (Ø) 24m (forklift)
20m (single person)
15m (forklift)
12m (single person)
SAM7 SAM7/I
HIR19/S HIR19/F HIR19/C
Safety standard
FCC standard FCC Part 15C
Certicate UL, CUL, FCC
UL773A , CSA-C22.2 No. 284
Class 2
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 1/11
HIR09/AA
Installation height
Max Detection range 15m (Diameter)
3m

35.2
43.3
52.5
30
35
39.5
4.2
19.3 28.5 31.2
30
2.5
1.5
16
23.3
25.8
13.5
16
Model SAM7
Model SAM7/I
HF sensorDIMTM
1-10V-
RJ12 connector
RJ12 connector Push
L’
N
L
N
L
N
DALI
Push
1-10V+ 120
30
21
4.5
110.5
4.5
PIR Sensor Head
Model HIR02
PIR Sensor Head
Model HIR04
Lens
RJ12 connector
Installation hole
Sensor Main Body
HC438V (1-10V output)
HCD438 (DALI output)
There are ten different sensor antenna modules to choose from:
LENS
RJ12 connector
40.9
44.5
16.4
19.3
17.8
15.9
12.9
Ø13.8
17
Antenna module
Daylight sensor
Installation hole
Cable entry
Infrared remote receiver
LED indication
Antenna module
Daylight sensor
Installation hole
Cable entry
Infrared remote receiver
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 2/11

Photocell Advance
TM
A
E
B
F
GH
PIR Sensor Head
11 sensor antennas and 2 control units offer 22 combinations in total:
CD
IJ
KL
MN
Loop in
Loop out
Ambient daylight
threshold
Daylight
Monitoring
Photocell
Intelligent
6
0
6
Detection Pattern
One-Key
Commissioning
Note:We recommend the mounting distance between sensor to sensor should be more than 2m to prevent sensors from false-triggering.
HIR09/C & HIR19/C
Screw to the luminaire by conduit
For highbay application
IP65 (facia/lens part)
The cable length is around 30cm.
Lens Accessories
RJ12 connector
25
33.9
M13
12
Ø 40.5
25
42.7
63
HIR09/F & HIR19/F
Flush mounting
For highbay application
IP65 (facia/lens part)
The cable length is around 30cm.
Ø 48
30.4
21.5 1.2
Lens Accessories
RJ12 connector
32.6
23.2
20
Ø 36.3
Lens Housing
RJ12 connector
Lug
HIR09/S & HIR19/S
Surface mounting
For highbay application
IP65 (facia/lens part)
The cable length is around 30cm.
Ø14
Ø41
Installation hole
Installation hole
Installation hole
17
Ø17.5
Ø3.5
P
QR
S
U V
T
Accessories
1.2
RJ12
Lens
HIR09/AA
PIR sensor head
Adjustable angle
IP65 (facia/lens part)
The cable length is around 30cm.
90
21.5
30.4
Microwave antenna SAM7 + DALI control HCD438 Microwave antenna SAM7 + 1-10V control HC438V
Microwave antenna SAM7/I + DALI control HCD438 Microwave antenna SAM7/I + 1-10V control HC438V
PIR antenna HIR02 + DALI control HCD438 PIR antenna HIR02 + 1-10V control HC438V
PIR antenna HIR04 + DALI control HCD438 PIR antenna HIR04 + 1-10V control HC438V
PIR antenna HIR09/S + DALI control HCD438 PIR antenna HIR09/S + 1-10V control HC438V
PIR antenna HIR09/F + DALI control HCD438 PIR antenna HIR09/F + 1-10V control HC438V
PIR antenna HIR09/C + DALI control HCD438 PIR antenna HIR09/C + 1-10V control HC438V
O
PIR antenna HIR19/S + DALI control HCD438 PIR antenna HIR19/S + 1-10V control HC438V
PIR antenna HIR19/F + DALI control HCD438 PIR antenna HIR19/F + 1-10V control HC438V
PIR antenna HIR19/C + DALI control HCD438 PIR antenna HIR19/C + 1-10V control HC438V
PIR antenna HIR09/AA + DALI control HCD438 PIR antenna HIR09/AA + 1-10V control HC438V
O
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 3/11

Functions and Features
Tri-level Control (Corridor Function)
1
Hytronik builds this function inside the motion sensor to achieve tri-level control, for some areas which require a light change notice
before switch-off. The sensor offers 3 levels of light: 100%-->dimmed light (natural light is insufcient) -->off; and 2 periods of
selectable waiting time: motion hold-time and stand-by period; Selectable daylight threshold and freedom of detection area.
With sufcient natural light, the
light does not switch on when
presence is detected.
With insufcient natural light,
the sensor switches on the light
automatically when presence is
detected.
After hold-time, the light dims to
stand-by level if the surrounding
natural light is below the
daylight threshold.
Light switches off automatically
after the stand-by period
elapses.
24h Daylight Monitoring Function (SAM7)
2
The light turns off
completely when natural
light lux exceeds daylight
threshold pre-set.
100% on when movement
detected, and dims to 10%
in long absence.
1 3
goes in cycle
at night
...
4
08:10
The light dims to stand-by
level after the hold-time.
The light switches on at
100% when there is
movement detected.
1
21:00
The light remains in dimming
level at night.
3
21:40
The light automatically turns
on at 10% when natural light
is insufcient (no motion).
5
17:40
2
21:10
Settings on this demonstration:
Hold-time: 10min
Daylight threshold: 50lux
Stand-by dimming level: 10%
Stand-by period: +∞
Our innovative and patented software enables our antenna with built-in daylight sensor to provide a “smart photocell” function. This
function is activated when stand-by period is set to “+∞ ”.
Photocell AdvanceTM Function (SAM7/I, HIR04)
3
It’s well known that LED lights have a totally different spectrum to natural light. Hytronik uses this principle and comes up with special
photocell and sophisticated software algorithm to measure and differentiate natural light from LED light, so that this photocell can
ignore the LED light and only respond to the natural light.
Our technology has no infringement to the existing patents in the market.
Lux Off Function (SAM7/I, HIR02, HIR04)
4
The light turns off automatically whenever surrounding natural light lux level exceeds the daylight threshold for more than 5min, even
there is motion detected. For HIR02 and HIR04,please pay attention that if the stand-by period is pre-set to innity “+∞”, the xture
never switches off but stays at dimming level, even when natural light is sufcient .
100% On
Hold-time ends
Every 30min
Check
Dim
Off
motion
No motion
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 4/11

Manual Override
5
* Short Push (<1s): on/off function;
On →Off: the light turns off immediately and cannot be triggered ON by motion until the expiration of pre-set hold-time. After this
period, the sensor goes back to normal sensor mode.
Off →On: the light turns on and goes to sensor mode, no matter if ambient Lux level exceeds the daylight threshold or not.
* Long Push (>1s): adjust the hold-time brightness level between10% and 100%.
Note: if end-user do not want this manual override function, just leave the “push” terminal unconnected to any wire.
This sensor reserves the access of manual override function for end-user to switch on/off, or adjust the brightness by push-switch,
which makes the product more user-friendly and offers more options to t some extra-ordinary demands:
Semi-auto Mode (Absence Detection)
6
It is easy to forget to switch off the light, in ofce, corridor, even at home. And in many other cases, people do not want to have a
sensor to switch on the light automatically, for example, when people just quickly pass-by, there is no need to have the light on. The
solution is to apply this “absence detector”: motion sensor is employed, but only activated on the maunal press of the push switch, the
light keeps being ON in the presence, and dims down in the absence, and eventually switches off in the long absence.
This is a good combination of sensor automation and maunal override control, to have the maximum energy saving, and at the same
time, to keep efcient and comfortable lighting.
Note: end-user can choose either function or function for application. Default function is manual override.
56
The light turns on full, and the sensor stays in
sensor mode.
The light does not switch on when there is
presence being detected.
Short push to activate the sensor
and switch on the light
People left, the light dims to stand-by level
after the hold-time.
The light switches off automatically after the
stand-by period elapses.
The light keeps being ON during the presence.
zero-cross point
Alternating current
Zero-cross Relay Operation (HC438V)
Designed in the software, sensor switches on/off the
load right at the zero-cross point, to ensure that the
in-rush current is minimised, enabling the maximum
lifetime of the relay.
7
Double L N terminal makes it easy for wire loop-in and loop-out, and saves the cost of terminal block and assembly time.
Loop-in and Loop-out Terminal (HC438V)
8
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 5/11

Wiring Diagram
LED Driver
LED Driver
N
L
1-10V+
1-10V
-
N
L
1-10V+
1-10V
-
HC438V
1-10V+
1-10V
P
L’
N
N
L
-
L
N
DALI Driver
DALI Driver
DALI
DALI
L
N
DALI
DALI
L
N
HCD438
DALI
DALI
Push
N
L
L
N
Detection Pattern (Ceiling mounted)
Model SAM7 & SAM7/I
Ceiling mounted height(m)
6
0
6
10%
30%
75%
50%
Model HIR02 & HIR04
walking towards
walking across
tangential movement 6m
radial movement 3.2m
3m
1. 200 metres (total) max. for 1mm² CSA (Ta = 50℃)
2. 300 metres (total) max. for 1.5mm² CSA (Ta = 50℃)
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 6/11

Installation height 6m：
Installation height 3m：
6m
max. 8m
max. 10m
360°
The installation data conduct by following testing conditions:
1. Environmental humidity: 80.5%;
2. Single person walking;
3. Sensor not connected to any driver that may have soft-on period;
4. Testing temperature Ta = 31.5°C;
5. The testing is conducted in an open and spacious indoor eld, without noticeable obstacles or infuences that may affect PIR performances.
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 7/11
8
16
10
13
7
14
8
10
6
12
5
5
6
3
Height (m) 100% 75% 50%
Sensitivity
Detection range (m)
Angle
90
70
10%
4
8
4
6
Application
Ceiling-mounted
3m
max. 6m
max. 10m
360°
6
3
Note: The unit of 90 degree detection data is diameter.
Model HIR09/AA

Settings (Remote Control HRC-11, for SAM7/I , HIR04 , HIR09 and HIR19)
Permanent ON/OFF function
Press button “ON/OFF” to select permanent ON or permanent OFF mode.
* Press button “AUTO”, “RESET” or “Ambient” to quit this mode.
The mode will change to AUTO Mode after power failure.
ON/
OFF
Press button “RESET”, all settings go back to default values.
Reset Settings
Press button “Shift”, the LED on the top left corner is on to indicate mode selection.
All values / settings in RED are valid for 20 seconds.
Shift Button
HIR09 & HIR19 (High-bay)
Tangential: max. 20m
h = max.12m
A
Radial: max. 3m
h = max.12m
B
Radial (B)
Tangential (A)
10m
Mount height
14m
15m
13m
12m
11m max 452m2 (Ø = 24m)
max 380m2 (Ø = 22m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 452m2 (Ø = 24m)
max 201m2 (Ø = 16m)
max 201m2 (Ø = 16m)
max 201m2 (Ø = 16m)
max 177m2 (Ø = 15m)
max 133m2 (Ø = 13m)
max 113m2 (Ø = 12m)
A: Tangential movement
Tangential: max. 24m
h = max.15m
A
B: Radial movement
Radial: max. 16m
h = max.15m
B
HIR09 & HIR19: High-bay lens detection pattern for forklift @ Ta = 20℃
(Recommended installation height 10m-15m)
Radial (B)
Tangential (A)
2.5m
Mount height
11m
12m
10m
8m
6m max 104m2 (Ø = 11.5m)
max 50m2 (Ø = 8m)
max 154m2 (Ø = 14m)
max 227m2 (Ø = 17m)
max 269m2 (Ø = 18.5m)
max 314m2 (Ø = 20m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
max 7m2 (Ø = 3m)
A: Tangential movement B: Radial movement
HIR09 & HIR19: High-bay lens detection pattern for single person @ Ta = 20℃
(Recommended installation height 2.5m-12m)
insensitive sensitive insensitive sensitive
insensitive sensitive insensitive sensitive
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 8/11

1. Press button “Shift”, the red LED starts to ash.
2. Press button “Ambient”, the surrounding lux level is sampled and set as the new daylight threshold.
Ambient daylight threshold
Hold-time
Press buttons in zone “hold-time” to set the hold-time at 2s / 30s / 1min / 5min / 10min / 15min / 20min / 30min.
Note: 1. To set hold-time at 30s / 5min / 15min / 30min, press “Shift” button rst.
2. 2s is for testing purpose only, stand-by period and daylight sensor settings are disabled in this mode.
*To exit from Test mode, press button “RESET” or any button in “Hold-time”.
AUTO mode
Press button “AUTO” to initiate automatic mode. The sensor starts working and all
settings remain as before the light is switched ON/OFF.
1. Press button “Shift”, the red LED ashes for indication.
2. Press button “SEMI-AUTO/AUTO” to initiate semi-auto mode. The xture is
manually turned on by pressing the push-switch, and goes off automatically after
stand-by time. (Absence detection mode)
SEMI-AUTO mode
Press the buttons to select light output at 80% (at initial 10,000 hours) or 100%.
Note: “Sensor off” and “Twilight” functions are disabled.
Power output
Press these two buttons to adjust the light output brightness during hold-time.
Brightness +/-
Scene program - 1-key commissioning
1. Press button “Start” to program.
2. Select the buttons in “Detection range”, “Daylight threshold”, “Hold-time”, “Stand-by time”, “Stand-by dimming level” to set all
parameters.
3. Press button “Memory” to save all the settings programmed in the remote control.
4. Press button “Apply” to set the settings to each sensor unit(s).
For example, to set detection range 100%, daylight threshold Disable, hold-time 5min, stand-by time +∞, stand-by dimming level 30%, the steps should be:
Press button “Start”, button ”100%”, “Disable”, “Shift”, “5min”, “Shift”, “+∞”, “30%”, “Memory”. By pointing to the sensor unit(s) and pressing “Apply”, all
settings are passed on the sensor(s).
Detection range
All buttons in this zone are disabled for HIR04.
Press buttons in zone “ Daylight threshold” to set daylight sensor at 2Lux/ 10Lux / 50Lux / 100Lux / 300Lux / 500Lux / Disable.
Note: To set daylight sensor at 100Lux / 300Lux / 500Lux, press “Shift” button rst.
Daylight threshold
HRC-11
&
A
4 hh
4
h
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 9/11

Power output
Power
80%
Power
100%
By pressing these two buttons, the output shifts between 80% (at initial 10,000 hours) and 100%, for energy saving purpose.
Settings (Remote Control HRC-05, for SAM7 & HIR02)
Press “RESET” button, all settings go back to default settings.
Reset function
RESET
Permanent ON/OFF function
Sensor mode
Press “Auto Mode” button, the sensor starts to function and all settings remain the same
as the latest status before the light is switched on/off.
Press the “ON/OFF” button, the light goes to permanent on or permanent off mode, and
the sensor is disabled.
* Press “Auto Mode”, “RESET” or “Scene mode” buttons to quit this mode.
The mode will change to AUTO Mode after power failure.
Test mode
HRC-05
ON/
OFF
Auto Mode
Stand-by dimming level
Detection range
ON/
OFFAuto ModeReset
Power
80%
Test
2s
10%20%
30s 1min
100%
30min10min5min
0s 10s1min
30%
SC1SC2
SC3
Scene mode
10min
50%10%
30min
Hold-time
Stand-by period
5min
Lux
Disable
2Lux
10Lux
50Lux
Daylight Sensor
SC4
Power
100% +
-
Dim
M/A
+
-
Note: the buzzer beeps one time
when RC receives signal
successfully.
Dim +/
This button is for testing purpose only. The sensor goes to test mode (hold-time is 2s)
after commissoning, meanwhile the stand-by period and daylight sensor are disabled.
* This mode can be ended by pressing “reset”, or any button of “scene mode” and
“hold-time”. The sensor settings are changed accordingly.
Long press “Dim +” or “Dim ” to adjust the light brightness during hold-time. “ + ”
means dimming up, “ ” means dimming down.
Dual tech & RF mode
Stand-by dimming level
Stand-by time (corridor function)
Press buttons in zone “stand-by time” to set the stand-by period at 0s / 10s / 1min / 5min / 10min / 30min / 1h / +∞.
Note: “0s” means on/off control; “+∞” means the stand-by time is innite and the xture never switches off.
Press the button in zone “stand-by dimming level” to set the stand-by dimming level at 10% / 20% / 30% / 50%.
All buttons in this zone are disabled.
Auto-conguration function
All buttons in this zone are disabled.
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 10/11

Press this button, the latest surrounding lux value overwrites the previous lux value learned, and it is set as the daylight threshold. This
feature enables the xture to function well in any real application circumstances.
Ambient daylight threshold
Lux
Disable
Manual override / Semi-auto mode (absence detection)
M/A
Lux disable
Press this button, the built-in daylight sensor stops working, and all motion detected could turn on the lighting xture, no matter how
bright the natural light is.
By pressing this button, the sensor goes to manual override or Semi-auto mode (absence detection) function.
* The buzzer beeps twice if it’s manual override function, and beeps once if it shifts to Semi-auto mode (absence detection).
Detection range
Press the buttons of “detection range” to set detection range at 10% /50% /100%.
Note: these buttons are invalid for antenna module HIR02.
Press the buttons of “hold-time” to set hold-time at 30s / 1min / 5min / 10min / 30min.
Hold-time
Daylight sensor
Press the buttons of “daylight sensor” to set daylight threshold at 2Lux / 10Lux / 50Lux.
Stand-by dimming level
Stand-by period (corridor function)
Press the buttons of “stand-by period” to set stand-by period at 0s / 10s / 1min / 10min / 30min / +∞.
* “0s” means on/off control; “+∞” means bi-level dimming control, the xture never switches off when daylight sensor is disabled.
Press the buttons of “stand-by dimming level” to set the stand-by dimming level at 10% / 20% / 30%.
4
Scene mode
There are 4 scene modes xed program built in the remote control to choose for different applications:
Scene options Detection range Hold-time Stand-by period Stand-by dimming level Daylight sensor
SC1 100% 1min 10min 10% 2Lux
SC2 100% 5min 10min 10% 2Lux
SC3 100% 10min 30min 10% 10Lux
SC4 100% 10min 10% 50Lux
* End-user can adjust the settings by pressing buttons of detection range/hold-time/stand-by period/stand-by dimming
level/daylight sensor. The last setting stays in validity.
Additional Information / Documents
1. For full explanation of Hytronik Photocell AdvanceTM technology, please kindly refer to
www.hytronik.com/download ->knowledge ->Introduction of Photocell Advance
2. Regarding precautions for microwave sensor installation and operation, please kindly refer to
www.hytronik.com/download ->knowledge ->Microwave Sensors - Precautions for Product Installation and Operation
3. Regarding precautions for PIR sensor installation and operation, please kindly refer to
www.hytronik.com/download ->knowledge ->PIR Sensors - Precautions for Product Installation and Operation
4. Data sheet is subject to change without notice. Please always refer to the most recent release on
www.hytronik.com/products/Motion Sensors ->Built-in HF Sensor
5. Regarding Hytronik standard guarantee policy, please refer to
www.hytronik.com/download ->knowledge ->Hytronik Standard Guarantee Policy
Subject to change without notice. Edition: 12 Oct. 2023 Ver. A0 Page 11/11
