IBASE Technology BYTEM-W071-PC User manual

The information contained in this document has been carefully researched and is, to the best
of our knowledge, accurate. However, we assume no liability for any product failures or
damages, immediate or consequential, resulting from the use of the information provided
herein. Our products are not intended for use in systems in which failures of product could
result in personal injury. All trademarks mentioned herein are property of their respective
owners. All specifications are subject to change without notice.
Manual
BYTEM-W071-PC
BYTEM-101-PC
BYTEM-121-PC
iBASE
Our company network supports you worldwide with offices in Germany, Austria,
Switzerland, Great Britain and the USA. For more information please contact:
FORTEC Elektronik AG
Hauptniederlassung
Lechwiesenstr. 9
86899 Landsberg am Lech
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Internet: www.fortecag.de
FORTEC Elektronik AG
Büro West
Hohenstaufenring 55
50674 Köln
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Internet: www.fortecag.de
FORTEC Elektronik AG
Büro Wien
Nuschinggasse 12
A-1230 Wien
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Internet: www.fortec.at
ALTRAC AG
(Tochter der FORTEC):
Bahnhofstraße 3
CH-5436 Würenlos
Telefon: [phone]
Telefax: [phone]
E-Mail: [email protected]
Internet: www.altrac.ch

www.ibase.com.tw
IBASE Technology Inc.
BYTEM-xx1-PC
User Manual

Copyright © 2013 IBASE Technology Inc. All Rights Reserved. 2
2
BYTEM-xx1-PC User Manual
Revision
Release Date
V1.0
2015/08/11

i
BYTEM-xx1-PC User Manual
Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
No part of this manual, including the products and software described in it, may be
reproduced, transmitted, transcribed, stored in a retrieval system, or translated into
any language in any form or by any means, except documentation kept by the
purchaser for backup purposes, without the express written permission of IBASE
Technology INC. (“IBASE”).
Products and corporate names mentioned in this manual may or may not be
registered trademarks or copyrights of their respective companies, and are used for
identification purposes only. All trademarks are the property of their respective
owners.
Every effort has been made to ensure that the contents of this manual are correct and
up to date. However, the manufacturer makes no guarantee regarding the accuracy of
its contents, and reserves the right to make changes without prior notice.

ii
BYTEM-xx1-PC User Manual
Table of Contents
Safety Information ..................................................................................................iii
Setting up your system ....................................................................................................... iii
Care during use...................................................................................................................iv
Acknowledgments ............................................................................................................... v
CHAPTER 1 INTRODUCTION .................................................................................... 1
1.1 General Description .......................................................................................................1
1.2 System Specification ......................................................................................................2
1.2.1 Hardware Specifications .............................................................................................2
1.2.2 Dimensions .................................................................................................................3
1.2.3 I/O View......................................................................................................................6
1.3 Accessory List.................................................................................................................6
1.4 Installation .....................................................................................................................7
CHAPTER 2 MOTHERBOARD INTRODUCTION .......................................................... 8
2.1 Introduction...................................................................................................................8
2.2 Installing the Memory .................................................................................................11
2.3 Setting Jumpers............................................................................................................12
CHAPTER 3 BIOS SETUP .........................................................................................28
CHAPTER 4 DRIVERS INSTALLATION .......................................................................42
4.1 Intel Chipset Software Installation Utility ...................................................................42
4.2 VGA Drivers Installation...............................................................................................43
4.3 Realtek High Definition Audio Driver Installation .......................................................44
4.4 Intel Trusted Execution Engine Installation .................................................................48
Appendix...............................................................................................................53

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
iii
IBASE Technology Inc.
Safety Information
Your BYTEM product is designed and tested to meet the latest standards of safety for
information technology equipment. However, to ensure your safety, it is important that
you read the following safety instructions
Setting up your system
Read and follow all instructions in the documentation before you operate your
system.
Do not use this product near water.
Set up the system on a stable surface. Do not secure the system on any unstable
plane.
Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
Slots and openings on the chassis are for ventilation. Do not block or cover these
openings. Make sure you leave plenty of space around the system for ventilation.
Never insert objects of any kind into the ventilation openings.
This system should be operated from the type of power indicated on the marking
label. If you are not sure of the type of power available, consult your dealer or
local power company.
Use this product in environments with ambient temperatures between 0˚C and
50˚C.
If you use an extension cord, make sure that the total ampere rating of the
devices plugged into the extension cord does not exceed its ampere rating.
DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C OR ABOVE 60° C. THIS
COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT SHOULD BE IN A
CONTROLLED ENVIRONMENT.

iv
BYTEM-xx1-PC User Manual
Care during use
Do not walk on the power cord or allow anything to rest on it.
Do not spill water or any other liquids on your system.
When the system is turned off, a small amount of electrical current still flows.
Always unplug all power, and network cables from the power outlets before
cleaning the system.
If you encounter the following technical problems with the product, unplug the
power cord and contact a qualified service technician or your retailer.
The power cord or plug is damaged.
Liquid has been spilled into the system.
The system does not function properly even if you follow the operating
instructions.
The system was dropped or the cabinet is damaged.
Lithium-Ion Battery Warning
CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with
the same or equivalent type recommended by the manufacturer. Dispose of used
batteries according to the manufacturer’s instructions.
NO DISASSEMBLY
The warranty does not apply to the products that have been disassembled by users.
WARNING
HAZARDOUS MOVING PARTS
KEEP FINGERS AND OTHER BODY PARTS AWAY

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
v
IBASE Technology Inc.
Acknowledgments
AMI is a registered trademark of AMI Software International, Inc.
AMD and ATI are registered trademarks of AMD Corporation.
Microsoft Windows is a registered trademark of Microsoft Corporation.
FINTEK is a registered trademark of FINTEK Electronics Corporation.
REALTEK is a registered trademark of REALTEK Electronics Corporation.
All other product names or trademarks are properties of their respective owners.

1
BYTEM-xx1-PC User Manual
CHAPTER 1 INTRODUCTION
1.1 General Description
BYTEM, an ALL in ONE Panel PC, utilizes an Intel®Atom™ processor that provides
high computing performance with low power consumption. It is available in 7-inch,
10.1-inch and 12.1-inch sizes.
The fanless BYTEM series operates silently and reliably in harsh environments. It
comes with two SODIMM slots to accommodate up to 8GB of DDR3L 1333MHz
system memory for 10.1-inch, 12.1-inch models and one 2.5” SATA HDD for data
storage. It features two Gigabit Ethernet and one RS-232/422/485 port. (The 7-inch
model supports two COM ports.) The unit is equipped with a front bezel that has
IP65-rated protection.
The BYTEM series supports a wide-range 9V~30V DC power input for 10.1-inch
and 12.1-inch models, using an 84W power adaptor, and 12V DC power input for
7-inch unit with a 60W power adaptor which makes it ideal for factory automation or
any other industrial applications.
BYTEM-W071-PC overview
BYTEM-101/121-PC overview

2
BYTEM-xx1-PC User Manual
1.2 System Specification
1.2.1 Hardware Specifications
Model Name
BYTEM-W071-PC
BYTEM-101-PC
BYTEM-121-PC
System Mainboard
IB897
CPU
Intel®Atom E3815
(Single-Core @ 1.46 GHz)
Intel®Atom E3845 (Quad-Core @ 1.91 GHz)
Chipset
Integrated in Intel® AtomTM SoC
Memory
2x DDR3L-1333 SO-DIMM, up to 4GB, Default 2GB(2GBx1) for BYTEM-W071-PC
2x DDR3L-1333 SO-DIMM, up to 8GB, Default 4GB(4GBx1) for BYTEM-101/121-PC
I/O Interface
1 x USB 3.0 flag type blue color
1 x USB 2.0 Type A flag type
1 x D-SUB9 RS-232/422/485 COM1
1 x COM2 for BYTEM-W071-PC only
1 x DP port
2 x Gigabit LAN (RJ45)
1 x 3-pin DC power connector (1 x DC power jack for BYTEM-W071-PC)
1 x Power on/off switch, power on LED / HDD LED
Storage
1 x 2.5” half-size SATA HDD with easy accessibility; Default 32G SSD for
BYTEM-W071-PC
1 x 2.5” SATA HDD with easy accessibility; Default 32G SSD
Expansion Slots
None
Power Supply
12V DC input
9~30V wide range DC input
LCD Size
7” TFT LCD
10.1” TFT LCD
12.1” TFT LCD
LCD Color
16.7M
262K
16.7M
LCD Resolution
1024 x 600
1280 x 800
1024 x 768
LCD Brightness
500
350
LCD View Angle
(H°/V°)
150/150
170/170
160/160
LCD Contrast
800:1
Backlight MTBF
50,000 hrs
12,000 hrs
30,000 hrs
Touch Screen
Projected capacitive touch
Construction
Aluminum front bezel and white steel back cover with aluminum heat-sink
Mounting
Panel Mount
VESA 50x50/75x75 mm
VESA 75X75 mm
Dimensions
(W)x(D)x(H) mm
211.5 x 143.5 x 52
285 x 204 x 59.6
317 x 255 x 59.6
Operating
Temperature
-10°C~ 50°C
0°C~ 50°C(With SSD) / 0°C~ 40°C(with HDD)
Storage
Temperature
-30°C ~ 70°C
-20°C ~ 60°C
Relative Humidity
10%~90% (non-condensing)
Protection Class
IP65 front bezel
Certification
CE/FCC Class B
Operating System
Support
Windows 8 32/64bit, Windows 7 Pro for Embedded 64bit, WES7 64bit
‧ This specification is subject to change without prior notice.

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
3
IBASE Technology Inc.
1.2.2 Dimensions
BYTEM-W071-PC

4
BYTEM-xx1-PC User Manual
BYTEM-101-PC

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
5
IBASE Technology Inc.
BYTEM-121-PC

6
BYTEM-xx1-PC User Manual
1.2.3 I/O View
BYTEM-W071-PC I/O side
BYTEM-101/121-PC I/O side
1.3 Accessory List
Part No.
Description
Quantity
1
3-pin terminal block for DC in for
BYTEM-101/121-PC
1 pc
2
DVD
1 pc
3
60W Adaptor for BYTEM-W071-PC only
84W Adaptor and power cord (option)
1 pc

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
7
IBASE Technology Inc.
1.4 Installation
1.4.1 Installing HDD/SSD
1. Loosen the two screws as shown in the picture.
2. Pull out the HDD/SSD bracket and replace the HDD/SSD module.

8
BYTEM-xx1-PC User Manual
CHAPTER 2 MOTHERBOARD INTRODUCTION
2.1 Introduction
IB897 is a 3.5-inch single board computer based on the Intel® AtomTM E3800
series processor. It supports two DDR3L (1.35V) SODIMM sockets for a maximum
memory capacity of 8GB.
IB897 features Intel's 7th generation (Gen 7) graphics engine and has both CRT
and DisplayPort video display interface, as well as 24-bit LVDS dual channel interface
with the use of the NXP PTN3460 device.
Onboard connectivity available includes two SATA II ports, two COM ports, one
USB 3.0 port, four USB2.0 ports, audio, two Mini PCI-e(x1) slots, and Micro SD.
Power input is provided by a +9~+30V DC in connector.
Product Name
IB897
Form Factor
3.5”disk size SBC
SoC Type/Speed
Intel® AtomTM QC E3845 /2MB cache/1.91GHz (IB897-I45&I45P)
Intel® AtomTM DC E3827 /1MB cache/1.75 GHz (IB897-I27&I27P)
Intel® AtomTM SC E3815 /512KB cache/1.46 GHz (IB897-I15& I15P)
Package = FCBGA1170, 25mmx27mm, 22nm,Tj= -40 ﾟC to +110 ﾟC
BIOS
AMI BIOS
Memory
Intel® AtomTM SoC integrated memory controller
Supports DDR3L (1.35V only), Non-ECC memory only
2 x DDR3 SO-DIMM socket [IB897-I45_P/IB897-I27_P], 8GB max.
1 x DDR3 SO-DIMM socket [IB897-I15_P], 4GB max.
VGA
Intel® Gen7 w/4 EUs graphics engines
DisplayPort x 1 [Supports up to 2560x1200@60Hz]
CRT x 1 via pin header [Supports up to 1920x1080@60Hz]
LVDS
24-bit dual channel via NXP PTN3460 thru eDP
(Supports up to1920x1200 @ 60 Hz)
LAN
Intel® I210IT PCIe Gigabit LAN x 2
USB
Intel® AtomTM SoC built-in USB host controller
Supports USB 2.0 x 4 ports; USB 3.0 x 1 port,
extra USB 2.0 x4 ports (Thru SMSC HUB USB2514)

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
9
IBASE Technology Inc.
Serial ATA
Intel® AtomTM SoC built-in SATA II controller, supports 2 ports
Audio
Intel®AtomTM SoC built-in HD audio controller + Realtek ALC269QHD
Codec w/ class-D speaker amplifier (2.3W per channel @ 5V power supply)
[7mm x 7mm @ 48-QFN]; support 2-channel audio out + amp
LPC I/O
Nuvoton NCT5523D [64-pin LQFP, 7x7x1.4mm]
-COM #1 (RS232/422/485) [EXAR SP339EER1 x 1 for jumper-less]
-COM #2 (RS-232 only)
[Hardware Monitor]: 2x thermal inputs; 2x voltage monitoring
Digital IO
4 in & 4 out
Expansion Slots
Mini PCI-e socket x2(1xFull-sized+1xHalf-sized,)
**Full length MiniPCIe (1x) supports mSATA**
Edge Connector
DB9 for COM1, DisplayPort, RJ45 x 2 for LAN 1 & 2
USB 2.0 vertical connector x 1, USB 3.0 vertical connector x 1
LED indicators (red+green) x1 for power and HDD status &
power button x 1(IB897-I45/I27/I15)
4-pin header for LED indicator & 2-pin header for power button via cable
(IB897-I45P/I27P/I15P)
Onboard
Header/
Connector
2x8 pin header for CRT; 2x4 pin header for 2x USB 2.0
DF20 socket connector x2 for 24-bit dual channel LVDS
4-pin box header for backlight/brightness control (PWM)
2x6 pin box header for Audio, 4-pin header for speaker
2x5 pin box header for COM2
2x5 pin headers for LPC (80-port card debugging purpose)
Mini PCI-e(1x) connector x2, 5 pins box header for smart battery
SATA connector x2for SATA device
4-pin power connector (JST type, for SATA device)
2-pin connector for power input, Micro SD slot (type 3.3V)
Watchdog
Yes (256 segments, 0, 1, 2…255 sec/min)
Power Connector
9V ~ 30V DC-in thru onboard 2-pin connector
Others
iSMART 2.0 [Auto-scheduler / Power resume]
OS Support
Windows 8.1 / Embedded; Windows 7 / Embedded, Linux
RoHS / REACH/
CE / FCC
Yes / Yes / Yes / Class B
Operating Temp.
-40 ﾟC to +85 ﾟC
Board Size
102mm x 147mm

10
BYTEM-xx1-PC User Manual
Board Dimensions for [IB897-I45/I27/I15]

Copyright © 2013 IBASE Technology Inc. All Rights Reserved.
11
IBASE Technology Inc.
2.2 Installing the Memory
The IB897 board supports two DDR3L memory sockets for a maximum of 8GB.
Installing and Removing Memory Modules
To install the DDR3 modules, locate the memory slot on the board and perform the
following steps:
1. Hold the DDR3 module so that the key of the DDR3 module aligned with that on
the memory slot.
2. Gently push the DDR3 module in an upright position until the clips of the slot
close to hold the DDR3 module in place when the DDR3 module touches the
bottom of the slot.
3. To remove the DDR3 module, press the clips with both hands.
** Channel-A slot must be installed with memory module for booting up**
