IBM WebSphere DataPower XI50B User manual

IBM WebSphere DataPower Integration Blade XI50B
Type 4195
Installation and User's Guide


IBM WebSphere DataPower Integration Blade XI50B
Type 4195
Installation and User's Guide


Note
Before using this information and the product it supports, read the general information in
“Notices” on page 39, the Warranty Information document, and the IBM Safety Information and the
Environmental Notices and User Guide documents on the IBM Documentation CD.
The most recent version of this document is available at http://www.ibm.com/supportportal.
Fourth Edition (May 2013)
This edition applies to Type 4195-4BX and to Type 2426-4BX appliances until otherwise indicated in new editions.
© Copyright IBM Corporation 2011, 2013.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Contents
Safety ...............v
Safety statements ............vii
Chapter 1. Introduction ........1
Related documentation ...........3
The IBM Documentation CD .........4
Hardware and software requirements .....4
Using the Documentation Browser ......4
Notices and statements in this document .....5
Features and specifications..........6
Major components of the blade appliance.....7
Input/output connectors and devices ......7
Chapter 2. Power, controls, and
indicators ..............9
Blade appliance controls and LEDs .......9
Control panel controls and LEDs ......9
Storage drive controls and LEDs ......11
Expansion unit controls and LEDs ......11
Turning on the blade appliance ........12
Turning off the blade appliance........12
Chapter 3. Installing and removing the
blade appliance ...........13
Installation guidelines ...........13
System reliability guidelines ........14
Handling static-sensitive devices ......14
Installing the blade appliance ........15
Installing the expansion unit........15
Installing the blade appliance in a BladeCenter
unit ................16
Updating the blade appliance configuration . . 18
Removing the blade appliance from the BladeCenter
unit .................18
Removing the expansion unit ........19
Chapter 4. Setting up the initial
firmware configuration ........21
Configuration requirements .........21
Connection requirements .........21
Information requirements.........21
Password for administration account .....22
Considerations for operational modes .....22
Initializing the blade appliance ........23
Verifying the configuration with the WebGUI . . . 24
Completing the configuration ........25
Defining the base configuration manually ....25
Downloading the firmware image .......25
Chapter 5. Solving problems .....27
Solving installation problems ........27
Solving operational problems ........27
IBM WebSphere DataPower Integration Blade XI50B
unique information ............28
Diagnostic tools overview .........28
Error logs ...............29
Working with event logs during system startup 30
Viewing event logs without restarting the blade
appliance ..............30
Chapter 6. Parts listing, Type 4195 . . . 31
Appendix. Getting help and technical
assistance .............35
Before you call .............35
Using the documentation ..........36
Getting help and information from the World Wide
Web.................36
How to send DSA data to IBM ........36
Creating a personalized support web page ....37
Software service and support ........37
Hardware service and support ........37
IBM Taiwan product service .........37
Notices ..............39
Trademarks ..............40
Important notes .............40
Particulate contamination..........41
Documentation format...........42
Telecommunication regulatory statement ....42
Electronic emission notices .........43
Federal Communications Commission (FCC)
statement ..............43
Industry Canada Class A emission compliance
statement ..............43
Avis de conformité à la réglementation
d'Industrie Canada ...........43
Australia and New Zealand Class A statement . 43
European Union EMC Directive conformance
statement ..............44
Germany Class A statement ........44
Japan VCCI Class A statement .......45
Korea Communications Commission (KCC)
statement ..............46
Russia Electromagnetic Interference (EMI) Class
A statement .............46
People's Republic of China Class A electronic
emission statement ...........46
Taiwan Class A compliance statement ....46
Index ...............47
© Copyright IBM Corp. 2011, 2013 iii

iv IBM WebSphere DataPower Integration Blade XI50B Type 4195: Installation and User's Guide

Safety
Before installing this product, read the Safety Information.
Antes de instalar este produto, leia as Informações de Segurança.
Læs sikkerhedsforskrifterne, før du installerer dette produkt.
Lees voordat u dit product installeert eerst de veiligheidsvoorschriften.
Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information.
Avant d'installer ce produit, lisez les consignes de sécurité.
Vor der Installation dieses Produkts die Sicherheitshinweise lesen.
Prima di installare questo prodotto, leggere le Informazioni sulla Sicurezza.
© Copyright IBM Corp. 2011, 2013 v

Les sikkerhetsinformasjonen (Safety Information) før du installerer dette produktet.
Antes de instalar este produto, leia as Informações sobre Segurança.
Antes de instalar este producto, lea la información de seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
Bu ürünü kurmadan önce güvenlik bilgilerini okuyun.
vi IBM WebSphere DataPower Integration Blade XI50B Type 4195: Installation and User's Guide

Safety statements
Review all safety statements before installing this product.
Important:
Each caution and danger statement in this document is labeled with a number.
This number is used to cross reference an English-language caution or danger
statement with translated versions of the caution or danger statement in the Safety
Information document.
For example, if a caution statement is labeled "Statement 1", translations for that
caution statement are in the Safety Information book under "Statement 1".
Be sure to read all caution and danger statements in this document before you
perform the procedures. Read any additional safety information that comes with
the server or optional device before you install the device.
This device is intended for use with UL listed IBM BladeCenters.
Statement 1
Safety vii

DANGER
Electrical current from power, telephone, and communication cables is
hazardous.
To avoid a shock hazard:
vDo not connect or disconnect any cables or perform installation,
maintenance, or reconfiguration of this product during an electrical storm.
vConnect all power cords to a properly wired and grounded electrical outlet.
vConnect to properly wired outlets any equipment that will be attached to
this product.
vWhen possible, use one hand only to connect or disconnect signal cables.
vNever turn on any equipment when there is evidence of fire, water, or
structural damage.
vDisconnect the attached power cords, telecommunications systems,
networks, and modems before you open the device covers, unless
instructed otherwise in the installation and configuration procedures.
vConnect and disconnect cables as described in the following table when
installing, moving, or opening covers on this product or attached devices.
To Connect: To Disconnect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
viii IBM WebSphere DataPower Integration Blade XI50B Type 4195: Installation and User's Guide

Statement 2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has a
module containing a lithium battery, replace it only with the same module type
made by the same manufacturer. The battery contains lithium and can explode if
not properly used, handled, or disposed of.
Do not:
vThrow or immerse into water
vHeat to more than 100°C (212°F)
vRepair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Statement 21
CAUTION:
Hazardous energy is present when the blade is connected to the power source.
Always replace the blade cover before installing the blade.
Safety ix

xIBM WebSphere DataPower Integration Blade XI50B Type 4195: Installation and User's Guide

Chapter 1. Introduction
The IBM®WebSphere®DataPower®Integration Blade XI50B, Type 4195 is
compatible with IBM BladeCenter®H and HT units and with IBM BladeCenter E
units that have an advanced management module installed. The appliance is a
double-wide configuration that installs in two adjacent blade bays of the
BladeCenter unit.
Important: If the IBM WebSphere DataPower Integration Blade XI50B is purchased
through Passport Advantage, the machine type is Type 2426-4BX. This document
applies to Type 4195-4BX and to Type 2426-4BX appliances until otherwise
indicated in new editions.
Note: Unless otherwise stated, references to the BladeCenter unit apply to all
supported BladeCenter unit types.
This Installation and User's Guide provides information about:
vSetting up the blade appliance
vStarting and configuring the blade appliance
vPerforming basic troubleshooting of the blade appliance
vReplacement parts for the blade appliance
Packaged with this document are resource CDs that help you to configure
hardware and system software.
The blade appliance comes with a limited warranty. For information about the
terms of the warranty and getting service and assistance, see the Warranty
Information document for your blade appliance on the IBM Documentation CD.
The blade appliance might have features that are not described in the
documentation that comes with the blade appliance, and the documentation might
be updated occasionally to include information about those features, or technical
updates might be available to provide additional information that is not included
in the blade appliance documentation.
To download the latest blade appliance firmware, see “Downloading the firmware
image” on page 25.
© Copyright IBM Corp. 2011, 2013 1

To check for updated documentation, go to http://www.ibm.com/software/
integration/datapower/library/documentation/. You can obtain other up-to-date
information about the blade appliance at http://www.ibm.com/systems/
bladecenter/.
You can subscribe to information updates specific to your blade appliance at
http://www.ibm.com/support/mynotifications.
The model number and serial number are on the ID label on the side of the control
panel on the front of the blade appliance, and on a label on the side of the blade
appliance that is visible when the blade appliance is not in the BladeCenter unit.
Note: The illustrations in this document might differ slightly from the hardware.
Release
handle
Release
buttons
Release
handle
Expansion unit
A set of blank labels comes with the BladeCenter unit. When you install the blade
appliance in the BladeCenter unit, write identifying information on a label and
place the label on the BladeCenter unit bezel. See the documentation for your
BladeCenter unit for recommended label placement.
Important: Do not place the label on the blade appliance itself or in any way block
the ventilation holes on the blade appliance.
2IBM WebSphere DataPower Integration Blade XI50B Type 4195: Installation and User's Guide

Related documentation
This Installation and User's Guide contains general information about the blade
appliance. The following documentation is in PDF on an IBM Documentation CD
that comes with the blade appliance:
vProblem Determination and Service Guide
This document is for the HS22 blade server that is the blade appliance system
board assembly. It is referenced by this Installation and User's Guide and contains
additional information to help you solve problems yourself, and it contains
information for service technicians. The HS22 blade server Problem Determination
and Service Guide should be used in addition to the blade appliance specific
information contained in this Installation and User's Guide.
vSafety Information
This document contains translated caution and danger statements. Each caution
and danger statement that appears in the documentation has a number that you
can use to locate the corresponding statement in your language in the Safety
Information document.
vSafety Information Labels
This document provides the Simplified Chinese, Mongolian, Tibetan, Uygur, and
Zhuang translated versions of the product safety labels.
vWarranty Information
This document contains information about the terms of the warranty and getting
service and assistance.
vEnvironmental Notices and User Guide
This document contains translated environmental notices.
The following documentation is available at http://www.ibm.com/software/
integration/datapower/library/documentation/:
vIBM WebSphere DataPower SOA Appliances: Administrators Guide
This document describes the concepts and tasks to configure the blade
appliance.
vIBM WebSphere DataPower: Command Reference
This document describes the commands used to configure the blade appliance.
Depending on your BladeCenter product, additional documents might be included
on an IBM Documentation CD. In addition to the documentation in this library, be
sure to review the Planning and Installation Guide for your BladeCenter unit for
information to help you prepare for system installation and configuration. To check
for updated documentation and technical updates, go to http://www.ibm.com/
software/integration/datapower/library/documentation/.
Chapter 1. Introduction 3

The IBM Documentation CD
Use the IBM Documentation CD to access the blade appliance documentation in
PDF format.
You can run the IBM Documentation CD on any personal computer that meets the
hardware and software requirements.
The IBM Documentation CD contains documentation for your blade appliance in
Portable Document Format (PDF) and includes the IBM Documentation Browser to
help you find information quickly.
Hardware and software requirements
The IBM Documentation CD requires the following minimum hardware and
software:
vMicrosoft Windows XP, Windows 2000, or Red Hat Enterprise Linux 5 Server
v100 MHz microprocessor
v32 MB of RAM
vAdobe Acrobat Reader 3.0 (or later) or xpdf, which comes with Linux operating
systems
Using the Documentation Browser
Use these instructions to start the Documentation Browser.
Use the Documentation Browser to browse the contents of the CD, read brief
descriptions of the documents, and view documents, using Adobe Acrobat Reader
or xpdf. The Documentation Browser automatically detects the regional settings in
use in your system and displays the documents in the language for that region (if
available). If a document is not available in the language for that region, the
English-language version is displayed.
Use one of the following procedures to start the Documentation Browser:
vIf Autostart is enabled, insert the CD into the CD drive. The Documentation
Browser starts automatically.
vIf Autostart is disabled or is not enabled for all users, use one of the following
procedures:
– If you are using a Windows operating system, insert the CD into the CD or
DVD drive and click Start →Run.IntheOpen field, type
e:\win32.bat
where eis the drive letter of the CD or DVD drive, and click OK.
– If you are using Red Hat Linux, insert the CD into the CD or DVD drive;
then, run the following command from the /mnt/cdrom directory:
sh runlinux.sh
Select your blade appliance from the Product menu. The Available Topics list
displays all the documents for your blade appliance. Some documents might be in
folders. A plus sign (+) indicates each folder or document that has additional
documents under it. Click the plus sign to display the additional documents.
When you select a document, a description of the document is displayed under
Topic Description. To select more than one document, press and hold the Ctrl key
while you select the documents. Click View Book to view the selected document
4IBM WebSphere DataPower Integration Blade XI50B Type 4195: Installation and User's Guide

or documents in Acrobat Reader or xpdf. If you selected more than one document,
all the selected documents are opened in Acrobat Reader or xpdf.
To search all the documents, type a word or word string in the Search field and
click Search. The documents in which the word or word string appears are listed
in order of the most occurrences. Click a document to view it, and press Crtl+F to
use the Acrobat search function, or press Alt+F to use the xpdf search function
within the document.
Click Help for detailed information about using the Documentation Browser.
Notices and statements in this document
Use this information to understand the most common documentation notices and
statements and how they are used.
The caution and danger statements in this document are also in the multilingual
Safety Information document, which is on the IBM Documentation CD. Each
statement is numbered for reference to the corresponding statement in the Safety
Information document.
The following notices and statements are used in this document:
vNote: These notices provide important tips, guidance, or advice.
vImportant: These notices provide information or advice that might help you
avoid inconvenient or problem situations.
vAttention: These notices indicate possible damage to programs, devices, or data.
An attention notice is placed just before the instruction or situation in which
damage might occur.
vCaution: These statements indicate situations that can be potentially hazardous
to you. A caution statement is placed just before the description of a potentially
hazardous procedure step or situation.
vDanger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
Chapter 1. Introduction 5

Features and specifications
Use this table to view specific information about the blade appliance, such as blade
appliance hardware features and the dimensions of the blade appliance.
Notes: Power, cooling, removable-media drives, external ports, and advanced
system management are provided by the BladeCenter unit.
The following table is a summary of the features and specifications of the blade
appliance.
Table 1. Features and specifications
Microprocessor: Supports two
multi-core Intel Xeon microprocessors
Memory:
v12 dual inline memory module
(DIMM) connectors
vType: Very Low Profile (VLP)
double-data rate (DDR3) DRAM.
Supports six 2 GB DIMMs on the
system board
Drives: Two hot-swap, small form
factor (SFF) Serial Attached SCSI
(SAS) storage drives
Integrated functions:
vLocal service processor: Integrated
Management Module (IMM) with
Intelligent Platform Management
Interface (IPMI) firmware
vIntegrated Matrox G200eV video
controller
vLSI 1064E SAS controller
vBroadcom BCM5709S dual-port
Gigabit Ethernet controller
vBroadcom BCM57711 dual-port 10
Gigabit Ethernet controller
Note: The blade appliance
high-speed Ethernet interfaces are
available only when the blade
appliance is installed in
BladeCenter unit that is
high-speed-switch capable. A
high-speed 10GbE I/O module
must also be installed in the
BladeCenter unit that is set up for
operation with the blade appliance.
(continued)
Integrated functions: (continued)
vIntegrated keyboard/video/
mouse (cKVM) controller through
IMM
vLight path diagnostics
vRS-485 interface for
communication with the
management module
vAutomatic server restart (ASR)
vUSB 2.0 for communication with
cKVM and removable media
drives
vSerial over LAN (SOL)
vRedundant buses for
communication with keyboard,
mouse, and removable media
drives
Predictive Failure Analysis (PFA)
alerts:
vMicroprocessors
vMemory
vStorage drives
Electrical input: 12Vdc
Size:
vHeight: 24.5 cm (9.7 inches) (6U)
vDepth: 44.6 cm (17.6 inches)
vWidth: 5.9 cm (2.32 inches)
vMaximum weight: 7.4 kg (16.3 lb)
Environment:
vAir temperature:
– Blade server on: 10°C to 35°C
(50°F to 95°F). Altitude:0mto
914.4 m (0 ft to 3000 ft)
– Blade server on: 10°C to 32°C
(50°F to 89.6°F). Altitude: 914.4 m
to 2133.6 m (3000 ft to 7000 ft)
– Blade server off: 10°C to 43°C
(50°F to 109.4°F). Altitude: 914.4
m to 2133.6 m (3000 ft to 7000 ft)
– Blade server shipping: -40°C to
60°C (-40°F to 140°F)
vHumidity:
– Blade server on: 8% to 80%
– Blade server off: 8% to 80%
– Blade server storage: 5% to 80%
– Blade server shipment: 5% to
100%
vParticulate contamination:
Attention: Airborne particulates
and reactive gases acting alone or in
combination with other
environmental factors such as
humidity or temperature might pose
a risk to the server. For information
about the limits for particulates and
gases, see “Particulate
contamination” on page 41.
6IBM WebSphere DataPower Integration Blade XI50B Type 4195: Installation and User's Guide

Major components of the blade appliance
Use this information to locate the major components on the blade appliance.
The following illustration shows the major components of the blade appliance.
Hot-swap
storage drive
Expansion unit
Input/output connectors and devices
The input/output connectors that are available to the blade appliance are supplied
by the BladeCenter unit. See the documentation that comes with the BladeCenter
unit for information about the input/output connectors.
The blade appliance has two selection buttons on the control panel: the media tray
select button and the keyboard/video/mouse select button. See “Blade appliance
controls and LEDs” on page 9 for information about these buttons and their
functions.
The Ethernet controllers on the blade appliance communicate with the network
through the Ethernet-compatible I/O modules in the BladeCenter unit. Network
signals to and from the blade appliance or any expansion cards are automatically
routed to a same-network-interface I/O module through circuitry in the
BladeCenter unit.
Chapter 1. Introduction 7

8IBM WebSphere DataPower Integration Blade XI50B Type 4195: Installation and User's Guide
