IBM 3745 21A User manual

IBML Installation Instructions
Field Feature Bill of Material (FFBM)
PN 17G5534
CONVERT an IBM 3745 Model 21A to 31A
Written by: J. Michaut
Checked by: J. Combes
Approved by: A. Badino
Reviewed by: B. Smith
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 1 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
Copyright IBM Corp. 1997 1

IBML Installation Instructions
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 2 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
2

IBML Installation Instructions
As instructions are divided in two procedures, 2 CEs may be used for the installation.
An additional person may be called to move the enclosure unit.
┌───────────────────────────────────┐
│ CE A and CE B │
├───────────────────────────────────┤
│ Step 1.0 - 8.0 │
│ Preliminary Set Up and Power Off │
││
└───────────────────────────────────┘
││
││
┌────────────┘ └────────────┐

┌─────────────────────────┐ ┌─────────────────────────┐
│CEA││CEB│
├─────────────────────────┤ ├─────────────────────────┤
││││
│ From the REAR frame │ │ From the FRONT frame │
│ ------------------- │ │ -------------------- │
│ Step 10.2.1 │ │ Step 10.3.1 │
│ (Power supplies) │ │ (AMD, Power cords) │
│ Step 10.2.2 │ │ Step 10.3.2 │
│ (Tri lead, MAC card)│ │ (Flat cables) │
││││
└─────────────────────────┘ └─────────────────────────┘
││
││
└────────────┐ ┌────────────┘

┌───────────────────────────────────┐
│ Both CEs A and B │
├───────────────────────────────────┤
││
│ Step 10.4 │
│ (CCU enclosure exchange) │
││
└───────────────────────────────────┘
││
││
┌────────────┘ └────────────┐

┌─────────────────────────┐ ┌─────────────────────────┐
│CEA││CEB│
├─────────────────────────┤ ├─────────────────────────┤
│ Step 10.5.1 │ │ Step 10.6.1 │
│ (Flat cables) │ │ (Flat cables) │
│ Step 10.5.2 │ │ Step 10.6.2 │
│ (PSTY1B Install) │ │ (Mechanical changes)│
│ Step 10.5.3 │ │ Step 11.5 │
│ (Mechanical) │ │ (TCM removal and │
│ Step 11.0 │ │ re-packing) │
│ (Test procedures) │ │ │
└─────────────────────────┘ └─────────────────────────┘
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 3 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 3

IBML Installation Instructions
Before Installation (steps 1-8)
VERY IMPORTANT
MES should be installed without delay, after
receipt, to avoid multiple MCLs needed for
the microcode.
Net Priced Feature
All parts removed from this machine are IBM
property and must be returned to IBM.
1.0 Machines Affected
3745 Model 21A.
This feature should only be applied on the
machine serial for which it is specified.
2.0 Related BMs and ECs
None.
3.0 BMs to be Installed
FFBM 17G5537 - Convert a 3745 21A into a 31A
(4MB memory size)
or 17G5538 - Convert a 3745 21A into a 31A
(8MB memory size)
or 17G5539 - Convert a 3745 21A into a 31A
(16MB memory size)
17G5534 - Installation Instructions
4.0 Preparation
1. Familiarize yourself with the purpose and
details of the installation instruction before
negotiating machine time with the customer.
2. Check all items listed on the BM(s) to deter-
mine that all parts have been received.
3. The installation must be performed off-line.
4. Ensure that RETAIN search has been per-
formed and all prerequisites have been
installed. Perform a search using
3745CCUPGRADE as SAS keyword.
5. To check if a new MCLs level is necessary,
perform a RETAIN search using
3745UPGRADE CODE LEVEL for the TDR
which gives the most recent level of micro-
code available for this machine (model).
To install the last level of MCLs, the most
efficient way is with the LIC upgrade proce-
dure. Use the RETAIN search, 3745ECA134
COF, for the TDR which explains the proce-
dure for ordering the latest level microcode
from COF.
Third party can get the latest level of code
through their normal microcode ordering
procedures.
MCLs can be obtained from RETAIN (If if the
customer provide an RSF link), or by
ordering the 3746 optical disk MCL via CCSS.
6. Follow the instructions attached to the case
to unpack the MES material.
Do not damage the packing boxes, they will
be used for repacking.
7. Before starting Model conversion ensure that
the complete 3745 is available.
Additional Information:
•All parts to be removed should be handled
carefully. Returnable parts must be received
at the factory in good working order.
•To save installation time and machine down
time, some tasks will be performed after the
General IPL section.
•When hardware installation is complete, and
before starting the test procedure, each CE
should check the others CE′s work.
5.0 Programming
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 4 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
4

IBML Installation Instructions
5.1 Diagnostic Programs
To reflect this change, CDF will be upgraded in
Step 11.0. This is essential to allow the internal
diagnostics to be run properly.
5.2 System Programs
The customer must update the control program
to implement this change.
6.0 Purpose and Description
6.1 Purpose
Convert a 3745 Model 21A to a 3745 Model 31A.
6.2 Description
•Remove the TCM CCU enclosure, PSTY1, air
moving device, and associated cabling.
•Install a new CCU enclosure with FAN, new
PSTY1B, and associated cabling.
Logic cards will not be re-used.
7.0 Installation Time
Tobe reported as MES
8.0 Tools/Materials Required
•ESD kit (PN 6428316)
•TCM tool kit (PN 69X7667)
•Isopropyl alcohol.
FFBM Machine
hours System Hours Nbr of CEs
17G5537
or 17G5538
or 17G5539 2.0 0.0 2
Test Time 1.15 0.0
Total Time 3.15 0.0
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 5 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 5

IBML Installation Instructions
Installation (steps 9-11)
9.0 Safety
•Review the Safety Notices and the Service
Inspection Procedures located at the begin-
ning of the
3745 Maintenance Information
Procedure (MIP)
manual, SY33-2054.
* Steps 10.0 to 10.1.4.
10.0 Details of Installation
Before the installation of this MES ask the cus-
tomer:
•To set all lines and channel addresses
offline for this controller and associated
machines.
•To provide the maintenance password.
•To logoff the Service Processor if not already
done.
10.1 Checking, Diagnostics
10.1.1 MOSS IML
From the control panel:
1. Check that the Power Control indicator
displays 3. If it does not, record the
value __. Then, set the Power Control
indicator to 3.
Press the Validate key.
2. Set the Function indicator to 1.
Press the Validate key.
3. Set the Service Mode indicator to 2.
Press the Validate key.
The MOSS IML is completed when F0E is dis-
played on the control panel.
10.1.2 Logon
From the Service Processor:
1. In MOSS-E View window, click on
Program.
2. Click on LOG ON MOSS-E.
3. Enter the maintenance password, press
Enter.
Administrator Maintenance Mode is displayed on
the lower line of the window.
10.1.3 Open MOSS/MOSS-E Session
1. On the MOSS-E View window, double
click on the ICON of the identified 3745.
2. On the 3745 Menu window, double click
on MOSS Console.
Wait for Function Selection Rules screen.
10.1.4 Disable Channels Adapters
1. Enter CID, press Enter.
2. On the CA Interface Display screen,
record the Enable Channel Adapters, then
Disable all the Channel Adapters.
Note: If 3746 A11 is installed, press F8 to
display channels 8 through 16.
3. Wait for Interface Status Disabled for all
channels.
4. Press F1.
5. If CCU running, enter RST to reset the
CCU.
MOSS goes in MOSS ALONE state.
10.1.5 Verify the CDF
1. Enter CDF, press Enter.
2. Enter 4(VERIFY), press Enter.
The value from the CDF DATA and
MACHINE DATA should be identical.
If there is a discrepancy, verify the fea-
tures. If correct, update the CDF with the
machine values, enter 2, press Enter.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 6 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
6

IBML Installation Instructions
3. When CDF VERIFY COMPLETED is dis-
played, press F1.
10.1.6 Run the Diagnostics
1. Enter ODG, press Enter.
2. Enter 3(IOCB), press Enter.
•If NO ERROR FOUND is displayed,
press F1.
•Otherwise, see the
MIP , Chapter 1.
10.1.7 Power OFF
Note
Remove all electrical power from the
machine and associated machines before the
hardware installation.
1. From the control panel, press the Power
OFF key.
2. Open the front system cover, then switch
OFF CB1.
Follow flow chart on page 3 for 2 CE/FE activity.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 7 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 7

IBML Installation Instructions
10.2 CE ′A′ Tasks
Warning: Follow the existing ESD procedures
when handling logic parts.
10.2.1 Power Supplies
Open the rear system doors. Disconnect the
ground wire(s) (if present) from the right door,
and remove the door.
Note: To provide clearance for easier door
removal, you may have to loosen two screws
securing the end cover.
1. From the rear, remove the shield 1
over the CCU cards, if present.
2. Locate the PSTY1 in location 01Q and
remove the plastic cover from the power
TB 2.
Disconnect all FDS cables from the TB.
Tape the FDS cable ends to the enclo-
sure (use tape provided for repacking).
3. From the top of PSTY1, unplug the power
control bus cable from connector J2 and
the Power On Reset cable from J1 3.
Warning
Secure the power bus cable in its
raceway to prevent damage during
CCU enclosure exchange.
4. Remove the 3 screws 4. Then, remove
the PSTY1 from the 3745 (the power cord
has been routed back by CE ′B′).
5. Disconnect the FDS ground cable
attached to the frame 5
Save screws.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 8 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
8

IBML Installation Instructions
10.2.2 Tri Lead Cables, MAC Card
Exchange
1. Locate the MOSS board in 01A, and the
tri lead cables connected in 01A-Y0D4/D5
and E4/E5 1.
Note
To prevent damages to cables and
board, use the tool (PN 71F9877) to
unlock the connector as shown in the
figure below.
Gently insert the blade, then pull on
the cable housing to remove the
cable.
2. Unplug the cables and route them back
to the CCU enclosure.
Secure the tri lead cables in the right
side of the CCU cage 2.
3. In the MOSS board, locate the MAC card
in 01A-X0H2, and remove the cable con-
nected to the MAC card 3.
Route the cable back to the CCU enclo-
sure, and secure it in the right side of the
CCU cage 2.
4. Remove the spring clips securing the
locks of the MAC card.
5. Remove the MAC card.
6. Install the new MAC card provided by the
FFBM in the same position.
7. Reinstall the spring clips on the MAC
card, then take ′H′ label off the old card
and put it on the new card.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 9 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 9

IBML Installation Instructions
10.3 CE ′B′ Tasks
Warning: Follow the existing ESD procedures
when handling logic parts.
10.3.1 AMD, Power Cords
1. From the front of the 3745, remove the
shield 1(four screws) over the AMD
(Air Moving Device). It will not be
re-used.
2. Unplug the AMD power cable from the
primary power box connector J1 2.
3. Remove the AMD (four screws) 4.
Note: Swing out the bottom of the AMD
to disengage the top leg.
4. Unplug the PSTY1 power cable from the
connector J4, and route it to the rear of
the 3745 3.
5. Remove the dummy AMD bracket placed
over the empty CCUB TCM location.
10.3.2 Flat Cables
1. Open the control panel gate.
Note
To prevent damages to cables and
board, use the tool (PN 71F9877) to
unlock the connector as shown in the
figure on previous page.
Gently insert the blade, then pull on
the cable.
2. Check that all cables connected to the
SACU board are correctly labelled.
Rewrite the plug location on the cables if
not readable.
3. Unplug the flat cables from the SACU
board.
Warning
Secure the cables in the raceway to
prevent damage during the CCU
enclosure exchange.
4. Attach the handhold (PN 76F9077) 2
with 2 screws as shown on figure on the
next page (view A), on the 2 top holes of
the AMD asm.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 10 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
10

IBML Installation Instructions
10.4 CCU Enclosure Exchange
CAUTION:
The CCU enclosure can weight up to 37 kg (81.5
lb).
An additional person may be needed because of
the weight of the enclosure unit.
The first person is placed on the right side of the
enclosure, the second on the left side, and the
third, if needed, at the front of the enclosure
using the provided handhold.
Note: Ensure that all flat cables are protected
from damage during the CCU enclosure
exchange.
10.4.1 TCM Enclosure Removal
1. Remove the 4 screws 1securing the
CCU enclosure.
2. Pull the complete enclosure partially out
of the 3745 (approximately 15 cm).
3. From the rear of the 3745, attach the
handhold (PN 76F9076) 3to the enclo-
sure as shown on the figure below. This
will allow the third person involvement.
The handhold is clipped to the right and
left sides of the CCU enclosure (see view
B). Secure the handhold with the
attached pins.
4. Two persons grasp the enclosure
assembly by the handhold 2and at the
SACL board. The third person, if
needed, grasps the front handhold 3.
Slide the assembly out of the 3745.
5. Put the enclosure in a safe place.
6. Install 3 clamps (PN 34F1295) as follows:
Remove the clamp 4, and stick a
clamp 9 cm (3.5 in.) to the left.
Remove the clamp 5and stick a clamp
3 cm (1.1 in.) to the right.
Remove the clamp 6and stick a clamp
1 cm (0.4 in.) to the right.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 11 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 11

IBML Installation Instructions
10.4.2 New CCU Enclosure
Installation
1. Move the new CCU enclosure, still sitting
on its shipping pallet assembly, close to
the machine.
2. If a third person is needed, remove the
handhold (PN 76F9076) from the TCM
CCU enclosure and attach it to the new
CCU enclosure (need to tilt the enclosure
on the shipping pallet).
3. Lift the enclosure from the shipping
pallet using the enclosure top bar, and
put the part of the enclosure marked A
on the slides Bin 3745 (refer to figure
on previous page).
Slide the enclosure partially in the 3745.
Note
When the enclosure is put on its
slides in the 3745, check from the
front of the 3745 that there is no risk
of damaging flat cables, FDS cables,
and FAN power cords.
4. Remove the handhold and slide the
enclosure in place.
10.4.3 Card Locking
1. Remove the red bracket 3(four screws)
and place it on a table.
2. Remove the plate 1which is shipped
attached to the Red Bracket.
Save screws and plate for re-use.
3. Secure the enclosure with the screws
provided in the bag attached to the red
bracket 2.
Save the red bracket for the reinstalla-
tion.
4. On each card, move levers 4inwards
simultaneously.
Note: To improve contact, operate the
levers 3 times.
5. Position the plate 1to lock STER cards
and block card locations which are used
for CCU B cards.
Secure with 4 screws saved in previous
Steps 1 and/or 2.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 12 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
12

IBML Installation Instructions
10.5 CE ′A′ Tasks
10.5.1 Flat Cables
1. Place the template (PN 76F8595) 1as
shown on figure. Template should be
positioned as far up and left as permitted
by the frame.
Note: Remove existing cable clamps
which interfere with the correct place-
ment of the template.
2. Attach 4 clamps (PN 34F1295) in the
windows of the template 2.
Note: Place the clamps as shown on the
template.
3. Remove the template.
4. Install the pre-folded flat cables (PN
76F8591) in the clamps.
5. Plug the flat cables, one at a time, on the
MOSS board 3in the following
sequence:
•Y0E4, Y0D4, Y0E5, and Y0D5.
6. Route the flat cables 4through the
machine to CE ′B′.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 13 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 13

IBML Installation Instructions
10.5.2 PSTY1B installation
1. Install the PSTY1B support asm (PN
71F9950) 1and secure it at the bottom
and at the top left with 3 screws provided
in the bag attached to it.
Do not tighten the screws.
2. Install the PSTY1B (PN 26F1733) 2with
3 screws (PN 2665528) provided in the
bag attached to the support bracket.
3. Tighten the bottom screws of the power
supply bracket.
Feed the PSTY1B power cable to the
front of the machine.
4. Loosen the screw securing the bracket
3that secures the air filter and install
the air filter (PN 58X9295) under the CCU
enclosure.
Note the arrow direction for the air flow.
Tighten the screw.
5. Connect the FDS ground cable 4to the
frame. Secure it with the screws saved
in Step 10.2.1.
6. Connect the FDS cables 5to the
PSTY1B with screws (PN 61F4511) pro-
vided in a bag attached to the power
supply.
Connect the cables on TB1/TB2 first.
7. Connect the power control bus cable to
the connector J2 of the power supply 6.
8. Locate the Power On Reset cable (PN
61F4448) connected in the SACL
01B-A1Z2-D. Route the cable to PSTY1B
and connect it to connector J1 7.
9. On PSTY1B, check that the switch 1 is
set to A (CCUA) 8.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 14 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
14

IBML Installation Instructions
10.5.3 Mechanical
1. Re-install the shield over the CCU board
(if used).
2. Re-install the rear door removed in Step
10.2.1, “Power Supplies” on page 8.
Note: Tighten end cover screws if they
were loosened.
3. Re-connect the ground wires, if present.
4. Affix the label (PN 71F9997) over the
existing label on the door 1.
Close the door.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 15 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 15

IBML Installation Instructions
10.6 CE ′B′ Tasks
10.6.1 Flat Cables
1. Reconnect flat cables to the SACU board
1.
Refer to the template on the SACU
board.
2. Route and connect to the SACU board
the flat cable group (PN 76F8591) which
was prepared by CE ′A′ 2.
10.6.2 Diskette Storage Box
•Install the new diskette storage box supplied
on the top of the PS6 4.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 16 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
16

IBML Installation Instructions
10.6.3 Mechanical Changes
1. Install the air filter (PN 58X9296) 1on
the CCU enclosure. Note the arrow
direction for the air flow. Secure it with
the bottom bracket.
2. Plug the power cords in the primary
power box 2as follows:
a. PSTY1B 01Q Connector J4.
b. FAN CCU Connector J1.
3. Affix the label (PN 71F9996) over existing
labels in the front door 3.
4. Remove the name plate from the front
system cover(s), and clean any adhesive
residue from the recessed area with
Isopropyl alcohol.
Remove the paper from the back of the
new name plate (PN 17G5603) and affix
the plate.
5. Strike out the model number on the S/N
label, only the nameplate will identify the
model type from now on.
11.0 Test Procedures
Note: Ensure that each CE has verified the
other′s work before powering on the 3745.
11.1 Power ON
•Switch CB1 ON and close the system
cover(s).
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 17 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 17

IBML Installation Instructions
From the control panel:
1. Set the Function indicator to 1.
Press the Validate key.
2. Set the Service Mode indicator to 2.
Press the Validate key.
3. Press the Power On Reset key.
The MOSS IML is completed when F0E is dis-
played on the control panel.
11.2 Open MOSS/MOSS-E
Session
From the Service Processor, wait until the ICON
of the identified 3745 becomes purple.
1. On the 3745 Menu window, double click
on MOSS Console.
Wait for Function Selection Rules screen.
11.2.1 Update the CDF
1. Enter CDF, press Enter.
2. Enter 4(VERIFY), press Enter.
The value from the CDF DATA and the
MACHINE DATA should be identical
except for the new hardware installed.
3. To update the CDF with machine values,
enter 2, press Enter.
4. When CDF VERIFY COMPLETED is dis-
played, press F1.
11.2.2 Record the 3745 Model
From the Service Processor:
1. On the Service Processor menu, double
click on Manage 3745/3746-900 Installa-
tion.
2. Click on the line of the 3745 you have
just converted.
3. Click on Change.
4. On Controller Model Change message,
click on Yes.
From the 3745 control panel:
5. Press the Power OFF key.
6. Set the Service Mode indicator to 2.
Press the Validate key.
7. Set the Function indicator to 1.
Press the Validate key.
8. Press the Power On Reset key.
The MOSS IML is completed when F0E is
displayed on the control panel.
From the Service Processor:
9. Click on OK.
The 3745 Model number is being
recorded.
10. When the operation is completed, click
on OK.
11. Click on Cancel.
12. On the 3745 Menu window, double click
on MOSS Console.
Wait for Function Selection Rules screen.
11.2.3 Run the Diagnostics
1. Enter ODG, press Enter.
2. Enter 2(CCU), press Enter.
•If NO ERROR FOUND is displayed,
press F1.
•Otherwise, see the
MIP , Chapter 1.
3. Enter 3(IOCB), press Enter.
•If NO ERROR FOUND is displayed,
press F1.
•Otherwise, see the
MIP , Chapter 1.
4. If no HSS/ELA feature installed, press F1
and go to next Step.
If HSS/ELA feature is installed in your
3745, run HSS/ELA diags on at least one
HSS or ELA on each DMA bus (Adp 1-4
and 5-8) with HSS/ELA adapter.
•If NO ERROR FOUND is displayed, press F1.
•Otherwise, see the
MIP , Chapter 1.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 18 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
18

IBML Installation Instructions
11.2.4 Air Filter Acknowledge
1. Check all frame filters. replace if needed.
2. Enter POS, press Enter.
3. Select option A, press Enter.
4. Select option F(Acknowledge Air Filter
change), press Enter.
5. Enter a Yto confirm, press Enter. When
completed, press F1.
11.3 Close MOSS/MOSS-E
Session
1. Enter CID, press Enter.
2. Re-enable all channel Adapters disabled
in step 10.1.4, “Disable Channels
Adapters” on page 6.
3. When CA are enabled, press F1.
4. Enter OFF, press Enter.
5. On 3745 Menu, click on Function. Then,
click on Exit.
The MOSS-E View window is displayed.
11.4 General IPL
From the control panel:
1. Set the Power Control indicator to its
original value, as per step 10.1.1, “MOSS
IML” on page 6
2. Set the Service Mode indicator to 0
Press the Validate key.
3. Set the Function indicator to 0.
(General IPL).
Press the Validate key.
The General IPL starts.
•If FF4 code is displayed on control panel,
ask customer to load the control program.
•If the control program is loaded from hard
disk, 000 will be displayed when IPL suc-
cessful.
Note: The control program load can fail if a
mismatch exists between control program
and hardware configuration.
11.5 Disk Save
When the customer network is restarted, save
the contents of the hard disk on the BACKUP set
of diskettes.
11.5.1 Open MOSS/MOSS-E Session
From the Service Processor:
1. On the MOSS-E View window, double
click on the ICON of the identified 3745.
2. On the 3745 Menu window, double click
on MOSS Console.
Wait for Function selection rules screen.
11.5.2 Save Disk Contents onto
Diskettes
1. If NCP is restarted and MOSS ONLINE,
set the MOSS OFF LINE, enter MOF,
press Enter.
2. Select DIF, press Enter.
3. Select 2.
4. Enter the save-ID and press Enter.
5. Follow prompts on console.
6. When the function is completed, press
F1.
11.6 Install Latest MLCs.
Prior to returning the 3745 to the customer, you
must install the latest MCLs.
1. If you have an RSF link:
Refer to the
SP Installation and Mainte-
nance
Manual. Follow the procedure
Reporting problem to retain in Chapter 3
and, when requested enter Converting a
Model A and testing the RSF link as
short description of the problem. The
latest MCLs are automatically
dowloaded. Then go to :Handling Micro-
code Change level in Chapter 3. When
the RSF link is completed and the MCLs
are installed, go to 11.7, “Close
MOSS/MOSS-E Session” on page 20.
2. If you use the LIC Upgrade kit:
Refer to the
SP Installation and Mainte-
nance
Manual. Follow the procedure
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 19 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97 19

IBML Installation Instructions
Installing a new version of the Licensed
Internal Code in Chapter 3. When done
go to 11.7, “Close MOSS/MOSS-E
Session” on page 20.
3. If you use the 3746 Optical Disk MCLs:
Refer to the
SP Installation and Mainte-
nance
Manual. Follow the procedure
Handling Microcode Change Level in
Chapter 3. When done go to 11.7, “Close
MOSS/MOSS-E Session.”
11.7 Close MOSS/MOSS-E
Session
1. Enter OFF, press Enter.
2. On 3745 Menu, click on Function. Then,
click on Exit.
The MOSS-E View window is displayed.
11.8 Logging OFF from SP
1. On MOSS-E View window, click on
Program.
2. Click on LOG OFF MOSS-E.
3745 PN 17G5534 EC C38405 EC C38405A EC D55799 EC D55883 EC E27926
FFBM 20 of 22 06APR93 17JUN93 16SEP94 11MAY95 14MAR97
20
