IBM ServeRAID
User’s Reference, Version 5.10
SC33-P263-60


Note: Before using this information and the product it supports, be sure to read the general information in
Appendix B, “Warranty information” on page 183 and Appendix C, “Notices” on page 195.
Fifth Edition (July 2002)
© Copyright International Business Machines Corporation 2002. All rights reserved.
US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract
with IBM Corp.

Safety
Before installing this product, read the Safety Information book.
Antes de instalar este produto, leia o Manual de Informações sobre Segurança.
Před instalací tohoto produktu si přečtěte příručku bezpečnostních instrukcí.
Læs hæftet med sikkerhedsforskrifter, før du installerer dette produkt.
Lue Safety Information -kirjanen, ennen kuin asennat tämän tuotteen.
Avant de procéder à l’installation de ce produit, lisez le manuel Safety Information.
Vor Beginn der Installation die Broschüre mit Sicherheitshinweisen lesen.
Przed zainstalowaniem tego produktu należy przeczytać broszurę Informacje Dotyczące
Bezpieczeństwa.
Prima di installare questo prodotto, leggere l’opuscolo contenente le informazioni
sulla sicurezza.
Lees voordat u dit product installeert eerst het boekje met veiligheidsvoorschriften.
Les heftet om sikkerhetsinformasjon (Safety Information) før du installerer dette
produktet.
Antes de instalar este produto, leia o folheto Informações sobre Segurança.
Перед установкой продукта прочтите брошюру по технике безопасности
(Safety Information).
© Copyright IBM Corp. 2002 iii

Pred inštaláciou tohto produktu si pre ítajte Informa nú brožúrku o bezpe nosti.
Preden namestite ta izdelek, preberite knjižico Varnostne informacije.
Antes de instalar este producto, lea la Información de Seguridad.
Läs säkerhetsinformationen innan du installerar den här produkten.
iv IBM ServeRAID: User’s Reference, Version 5.10

Statement 1
Danger
Electrical current from power, telephone, and communication cables is hazardous.
To avoid a shock hazard:
vDo not connect or disconnect any cables or perform installation, maintenance, or
reconfiguration of this product during an electrical storm.
vConnect all power cords to a properly wired and grounded electrical outlet.
vConnect to properly wired outlets any equipment that will be attached to this
product.
vWhen possible, use one hand only to connect or disconnect signal cables.
vNever turn on any equipment when there is evidence of fire, water, or structural
damage.
vDisconnect the attached power cords, telecommunications systems, networks, and
modems before you open the device covers, unless instructed otherwise in the
installation and configuration procedures.
vConnect and disconnect cables as described in the following table when installing,
moving, or opening covers on this product or attached devices.
To connect:
1. Turn everything OFF.
2. First, attach all cables to devices.
3. Attach signal cables to connectors.
4. Attach power cords to outlet.
5. Turn device ON.
To disconnect:
1. Turn everything OFF.
2. First, remove power cords from outlet.
3. Remove signal cables from connectors.
4. Remove all cables from devices.
Statement 2
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has a
module containing a lithium battery, replace it only with the same module type made
by the same manufacturer. The battery contains lithium and can explode if not
properly used, handled, or disposed of.
Do not:
vThrow or immerse into water.
vHeat to more than 100° C (212° F)
vRepair or disassemble
Dispose of the battery as required by local ordinances or regulations.
Safety v

Statement 5
CAUTION:
The power control button on the device and the power switch on the power supply do
not turn off the electrical current supplied to the device. The device also might have
more than one power cord. To remove all electrical current from the device, ensure
that all power cords are disconnected from the power source.
1
2
vi IBM ServeRAID: User’s Reference, Version 5.10

Contents
Safety ............................iii
Preface ............................xi
How this book is organized.....................xi
Notices that are used in this book ..................xii
IBM ServeRAID Support CD ....................xiii
Supported operating systems....................xv
Part 1. Installation and configuration......................1
Chapter 1. Product information ..................3
Option package contents......................3
Controller features ........................3
Connector locations .......................4
Chapter 2. Installing and cabling a ServeRAID controller ........11
Using a ServeRAID controller in a server with Active PCI features ......11
Installing the ServeRAID-4 controller .................12
Installing the ServeRAID-5i controller.................16
Chapter 3. Understanding RAID technology .............21
Stripe-unit size .........................21
Selecting a RAID level and tuning performance .............22
Supported RAID levels ......................22
Drive-state descriptions ......................32
Chapter 4. Configuring ServeRAID controllers ............35
Obtaining ServeRAID updates ...................35
Updating BIOS and firmware code..................35
Configuring the ServeRAID controller.................36
Viewing your configuration.....................44
Getting assistance .......................45
Chapter 5. Installing ServeRAID device drivers ............49
Chapter 6. Configuring two ServeRAID controllers in a failover
environment.........................51
Hardware requirements ......................51
Installation guidelines and restrictions ................51
Preparing the active controller ...................52
Preparing the passive controller...................61
Completing the failover environment installation .............63
Part 2. Utility programs ...........................65
Chapter 7. Using the ServeRAID Mini-Configuration program ......67
Accessing the Mini-Configuration program ...............67
Viewing the controller status ....................67
Viewing the configuration .....................68
Using the advanced configuration functions ..............68
Chapter 8. Installing and using the IPSSEND command-line program ...71
© Copyright IBM Corp. 2002 vii

Installing the IPSSEND command-line program .............71
Starting the IPSSEND command-line program .............77
Using the IPSSEND command-line program ..............77
Chapter 9. Using the IPSMON command-line program (NetWare only) ...91
Installing the IPSMON command-line program .............91
Using the IPSMON command-line program ..............91
Chapter 10. Installing and starting the ServeRAID Manager program ...93
Installing the ServeRAID Manager program ..............93
Starting the ServeRAID Manager program ...............97
Part 3. Installing the IBM ServeRAID Cluster Solution.............101
Chapter 11. Introduction to the IBM ServeRAID Cluster Solution.....103
Chapter 12. Preparing to install or change a cluster solution ......107
Terms and definitions ......................107
ServeRAID considerations ....................108
Chapter 13. Configuring ServeRAID controllers for clustering ......111
Configuring the controller for Microsoft Cluster Server using Windows 2000 or
Windows NT 4.0 .......................111
Configuring a controller for clustering ................112
Configuring ServeRAID arrays and a logical drive............113
Chapter 14. Installing the Microsoft Cluster Server software ......119
Installing the Microsoft Cluster Server software on Windows NT 4.0 .....119
Installing the Microsoft Cluster Server software on Windows 2000 .....126
Chapter 15. Monitoring and updating an IBM ServeRAID Cluster Solution 135
Checking the ownership of a physical drive ..............135
Adding logical drives to a cluster ..................136
Validating a cluster .......................137
Viewing merge-group numbers and other cluster information .......138
Part 4. Maintenance and troubleshooting ..................139
Chapter 16. Obtaining ServeRAID updates .............141
Downloadable files from the World Wide Web .............141
Updating the ServeRAID BIOS, firmware, and software code for clustering 141
Chapter 17. Upgrading a ServeRAID controller ...........143
Updating device drivers, BIOS and firmware code, and utility programs....143
Replacing the old controller ....................143
Chapter 18. Solving ServeRAID problems .............145
IBM ServeRAID Support CD warning message while starting .......145
ServeRAID controller messages ..................145
ServeRAID startup (POST) messages ................150
Recovering from problems starting the ServeRAID Manager ........155
Recovering from an incomplete format of a physical drive.........156
Rebuilding a defunct drive ....................157
Recovering from multiple physical drive failures (Windows only) ......159
Locating the startup device (SCO OpenServer only) ...........164
viii IBM ServeRAID: User’s Reference, Version 5.10

Solving problems in a failover environment ..............164
Troubleshooting an IBM ServeRAID Cluster Solution ..........166
Chapter 19. Getting help and technical assistance ..........175
Before you call ........................175
Using the documentation .....................175
Getting help and information from the World Wide Web .........175
Software service and support ...................176
Hardware service and support ...................176
Part 5. Appendixes .............................177
Appendix A. Creating ServeRAID diskettes .............179
Creating diskettes on Windows ..................180
Creating diskettes on IBM OS/2 ..................180
Creating diskettes on Linux or UNIX ................180
Appendix B. Warranty information ................183
Warranty period ........................183
IBM Statement of Limited Warranty Z125-4753-06 8/2000 ........186
Appendix C. Notices ......................195
Edition notice .........................195
Trademarks..........................196
Important notes ........................196
Electronic emission notices ....................197
Glossary ..........................199
Index ............................205
Contents ix

xIBM ServeRAID: User’s Reference, Version 5.10

Preface
This book provides information for configuring an IBM
®
ServeRAID
™
controller,
installing device drivers, and installing and using the ServeRAID utility programs
and the IBM ServeRAID Cluster Solution.
Note: The IBM ServeRAID product can be either a controller on an adapter, such
as the one in this option package, or a controller on the system board of
your server. For consistency in this manual, the ServeRAID product is
referred to as a ServeRAID controller, unless it is specifically noted
otherwise.
To install device drivers and utility programs for a RAID controller that comes
as a standard feature on an IBM server system board, see the Installation
Guide and CDs provided with your server for instructions.
How this book is organized
Chapter 1, “Product information” on page 3 contains introductory information and
specifications for the IBM ServeRAID-4H, ServeRAID-4Mx, ServeRAID-4Lx, and
ServeRAID-5i controllers.
Chapter 2, “Installing and cabling a ServeRAID controller” on page 11 explains how
to install and cable a ServeRAID-4 and ServeRAID-5i controller.
Chapter 3, “Understanding RAID technology” on page 21 contains general
information about RAID technology.
Chapter 4, “Configuring ServeRAID controllers” on page 35 explains the ServeRAID
configuration process. You can refer to the information when configuring one or
more devices attached to a ServeRAID controller.
Chapter 5, “Installing ServeRAID device drivers” on page 49 contains information
about installing and updating the ServeRAID device drivers.
Chapter 6, “Configuring two ServeRAID controllers in a failover environment” on
page 51 contains instructions for configuring two ServeRAID controllers in a failover
environment. These instructions are for Microsoft
®
Windows NT
®
4.0 and Microsoft
Windows
®
2000 only.
Chapter 7, “Using the ServeRAID Mini-Configuration program” on page 67,
Chapter 8, “Installing and using the IPSSEND command-line program” on page 71,
and Chapter 9, “Using the IPSMON command-line program (NetWare only)” on
page 91 contain instructions for installing, starting, and using the Mini-Configuration,
IPSSEND, and IPSMON programs. You can use these operating-system-specific
programs to maintain and monitor your ServeRAID subsystem.
Chapter 10, “Installing and starting the ServeRAID Manager program” on page 93
contains instructions for installing and starting the ServeRAID Manager program.
You can use this program to maintain and monitor your ServeRAID subsystem.
Chapter 11, “Introduction to the IBM ServeRAID Cluster Solution” on page 103 and
Chapter 12, “Preparing to install or change a cluster solution” on page 107 provide
general information about the IBM ServeRAID Cluster Solution, including terms,
definitions, and considerations.
© Copyright IBM Corp. 2002 xi

Chapter 13, “Configuring ServeRAID controllers for clustering” on page 111 explains
the procedure for configuring ServeRAID controllers for clustering when using
Microsoft Cluster Server (MSCS).
Chapter 14, “Installing the Microsoft Cluster Server software” on page 119 provides
the procedure for installing Microsoft Cluster Server on Windows 2000 and
Windows NT 4.0.
Chapter 15, “Monitoring and updating an IBM ServeRAID Cluster Solution” on
page 135 contains information for monitoring and updating an IBM ServeRAID
Cluster Solution.
Chapter 16, “Obtaining ServeRAID updates” on page 141 provides information for
obtaining IBM ServeRAID and IBM ServeRAID Cluster Solution updates from the
World Wide Web.
Chapter 17, “Upgrading a ServeRAID controller” on page 143 contains instructions
for upgrading your ServeRAID controller.
Chapter 18, “Solving ServeRAID problems” on page 145 describes the ServeRAID
POST error codes and startup messages. This chapter also includes some basic
information about rebuilding a defunct drive and troubleshooting failover and cluster
problems.
Chapter 19, “Getting help and technical assistance” on page 175 provides
information about accessing the IBM World Wide Web sites to obtain future code
and information updates for the ServeRAID controller.
Appendix A, “Creating ServeRAID diskettes” on page 179 contains instructions for
creating the IBM ServeRAID Support diskettes, which contain device drivers and
the IPSSEND utility program.
Appendix B, “Warranty information” on page 183 contains warranty information.
Appendix C, “Notices” on page 195 contains product notices and trademarks.
Notices that are used in this book
This book contains the following notices designed to highlight key information:
vNotes: These notices provide important tips, guidance, or advice.
vImportant: These notices provide information or advice that might help you avoid
inconvenient or difficult situations.
vAttention: These notices indicate possible damage to programs, devices, or
data. An attention notice is placed just before the instruction or situation in which
damage could occur.
vCaution: These statements indicate situations that can be potentially hazardous
to you. A caution statement is placed just before the description of a potentially
hazardous procedure step or situation.
vDanger: These statements indicate situations that can be potentially lethal or
extremely hazardous to you. A danger statement is placed just before the
description of a potentially lethal or extremely hazardous procedure step or
situation.
xii IBM ServeRAID: User’s Reference, Version 5.10

IBM ServeRAID Support CD
The IBM ServeRAID Support CD contains the following:
vServeRAID ROM Update Wizard
vDevice drivers
vServeRAID Manager program
vIPSSEND command-line program
vDiskette images
vServeRAID files needed to install Microsoft Cluster Server (MSCS)
vServeRAID publications
ServeRAID ROM Update Wizard
The IBM ServeRAID ROM (read-only memory) Update Wizard is a program
designed to automatically identify and scan each ServeRAID controller installed in
your server. If the BIOS and firmware code need updating, the wizard will give you
the opportunity to do so.
Device drivers
The device drivers are located in the following directory on the IBM ServeRAID
Support CD:
e:/operatingsystem/DRIVER
where eis the CD-ROM drive and operatingsystem is the specific operating system
used in the ServeRAID installation.
The device drivers are also located on the operating-system-specific IBM
ServeRAID Support diskettes.
ServeRAID Manager program
Use this program to configure arrays and logical drives using ServeRAID
controllers. ServeRAID Manager operates in two ways: in startable-CD mode and
as an installed program. In startable-CD mode, you can configure your ServeRAID
adapter before you install an operating system.
This program is available in the following directory:
e:/operatingsystem/MANAGER
where eis the CD-ROM drive and operatingsystem is the specific operating system
used in the ServeRAID installation.
IPSSEND command-line program
Use this program to configure and manage your ServeRAID controllers. This
program is available on both the IBM ServeRAID Support CD and the
operating-system-specific IBM ServeRAID Support diskettes.
Preface xiii

Diskette images
Use these images to create the ServeRAID diskettes. These diskettes include the
following:
vIBM ServeRAID BIOS and Firmware Update (1 of 3) diskette
vIBM ServeRAID BIOS and Firmware Update (2 of 3) diskette
vIBM ServeRAID BIOS and Firmware Update (3 of 3) diskette
vIBM ServeRAID Failover Support for Windows NT 4.0 and Windows 2000
diskette
vIBM ServeRAID Cluster Solution for Windows NT 4.0 and Windows 2000 diskette
vIBM ServeRAID Support for Windows 2000 Server diskette
vIBM ServeRAID Support for Windows (Professional Editions) diskette
vIBM ServeRAID Support for Windows NT 4.0 diskette
vIBM ServeRAID Support for IBM OS/2 diskette
vIBM ServeRAID Support for Novell NetWare diskette
vIBM ServeRAID Support for Caldera UnixWare and Open UNIX diskette
vIBM ServeRAID Support for SCO OpenServer diskette
vIBM ServeRAID Support for Red Hat Linux (1 of 2) diskette
vIBM ServeRAID Support for Red Hat Linux (2 of 2) diskette
vIBM ServeRAID Support for Caldera OpenLinux (1 of 2) diskette
vIBM ServeRAID Support for Caldera OpenLinux (2 of 2) diskette
vIBM ServeRAID Support for SuSE Linux diskette
vIBM ServeRAID Support for Turbolinux diskette
vIBM ServeRAID Support for DOS diskette
These files are available in the e:/DISKETTE directory, where eis the CD-ROM
drive.
For instructions on creating the diskettes, see Appendix A, “Creating ServeRAID
diskettes” on page 179.
ServeRAID files needed to install Microsoft Cluster Server (MSCS)
Note: The IBM ServeRAID Cluster Solution requires either Windows 2000 or
Windows NT 4.0.
These files are available in the following directory:
e:/operatingsystem/CLUSTER
where eis the CD-ROM drive and operatingsystem is the specific operating system
used in the ServeRAID installation.
ServeRAID publications
The following books are available in Portable Document Format (PDF) on the IBM
ServeRAID Support CD in the /BOOKS directory:
vIBM ServeRAID User’s Reference, Version 5.10 (SRAID51.PDF)
vIBM ServeRAID Device Driver Installation Instructions (DEVDRV51.PDF)
xiv IBM ServeRAID: User’s Reference, Version 5.10

The following booklets are extracted from the IBM ServeRAID User’s Reference,
Version 5.10 and are available on the IBM ServeRAID Support CD in the /BOOKS
directory:
vIBM ServeRAID-4 Ultra160 and ServeRAID-5i Ultra320 SCSI Controllers
Installation Guide (INSTAL51.PDF)
vConfiguring IBM ServeRAID Controllers for Failover (FAILOV51.PDF)
vInstalling the IBM ServeRAID Cluster Solution (CLUSTE51.PDF)
vUnderstanding IBM ServeRAID Technology (TECHNO51.PDF)
Note: Use Adobe Acrobat Reader to view these files. The IBM ServeRAID Support
CD contains the Acrobat Readers for Microsoft Windows, IBM OS/2
®
, and
Linux
®
in the /BOOKS/READERS directory.
If you are installing the IBM ServeRAID Cluster Solution, you might need to refer to
the IBM Shared Disk Clustering Hardware Reference. This book provides general
information about planning and configuring a shared-disk cluster using IBM server
products. It contains illustrations, descriptions, and parts listings for various
high-availability, shared-disk cluster examples.
Note: You can obtain this publication from the IBM Support Web site. See
“Downloadable files from the World Wide Web” on page 141 for additional
information.
In addition, the following IBM Redbooks
™
might be of interest:
vImplementing Netfinity Disk Subsystems: ServeRAID SCSI, Fibre Channel, and
SSA
vTuning Netfinity Servers for Performance: Getting the most out of Windows 2000
and Windows NT 4.0
vNetfinity Director: Integration and Tools
vNetfinity Clustering Planning Guide
You can download these books from the IBM Web site at
http://www.ibm.com/redbooks/.
Supported operating systems
The following operating systems are supported with ServeRAID-4 and ServeRAID-5i
controllers:
vMicrosoft XP Professional (ServeRAID-4Lx controller only)
vMicrosoft Windows 2000 Advanced Server, Datacenter, and Server
vMicrosoft Windows 2000 Professional (ServeRAID-4Lx controller only)
vMicrosoft Windows NT 4.0 Enterprise Edition and Server
vNovell NetWare (versions 5.x and 6.0)
vIBM OS/2 WARP
®
Server for e-business
vRed Hat Linux (versions 6.2, 7.0, 7.1, 7.2, and 7.3)
vSuSE Linux (versions 7.1, 7.2, 7.3, and 8.0)
vCaldera OpenLinux (versions 3.1 and 3.1.1)
vTurbolinux (versions 6.5 and 7.0)
vSCO OpenServer 5.0.6a
vCaldera UnixWare 7.1.1
vCaldera Open UNIX 8.0
Preface xv

xvi IBM ServeRAID: User’s Reference, Version 5.10

Part 1. Installation and configuration
© Copyright IBM Corp. 2002 1

2IBM ServeRAID: User’s Reference, Version 5.10

Chapter 1. Product information
This book provides the information needed to install and configure the following:
vIBM ServeRAID-4H Ultra160 SCSI controller
vIBM ServeRAID-4Mx Ultra160 SCSI controller
vIBM ServeRAID-4Lx Ultra160 SCSI controller
vIBM ServeRAID-5i Ultra320 SCSI controller
Hereafter, these controllers are referred to as ServeRAID controllers. These
high-performance, redundant array of independent disk (RAID) controllers are
ideally suited for data-storage environments that require superior performance,
flexibility, and reliable data storage. (See “Controller features” for more information.)
You also can use the IBM ServeRAID Manager program with an IBM xSeries
™
server that contains an integrated SCSI controller with RAID capabilities. Hereafter,
these controllers are referred to as integrated RAID controllers.
Option package contents
In addition to this book, the ServeRAID option package contains:
vIBM ServeRAID Support CD
See “IBM ServeRAID Support CD” on page xiii for more detailed information.
vOne of the following:
– IBM ServeRAID-4H Ultra160 SCSI controller
– IBM ServeRAID-4Mx Ultra160 SCSI controller
– IBM ServeRAID-4Lx Ultra160 SCSI controller
– IBM ServeRAID-5i Ultra320 SCSI controller
Attention: Do not open the static-protective package containing the controller
until you are instructed to do so.
Contact your place of purchase if any items are missing or damaged.
Controller features
The standard features of the ServeRAID controllers are as follows.
Feature ServeRAID-5i ServeRAID-4H ServeRAID-4Mx ServeRAID-4Lx
Arrays (max.) 8 8 8 8
Battery-backup cache Yes Yes Yes No
Cache memory 128 MB 128 MB 64 MB 32 MB
Hard disk drives (max.) 30 60 30 15
Logical drives (max.) 8 8 8 8
Microprocessor 100 MHz 266 MHz 100 MHz 100 MHz
SCSI channels 0 4 2 1
SCSI transfer speed (max.) 320 MB per sec. 160 MB per sec. 160 MB per sec. 160 MB per sec.
© Copyright IBM Corp. 2002 3

Feature ServeRAID-5i ServeRAID-4H ServeRAID-4Mx ServeRAID-4Lx
Supported RAID levels 0, 1, 5, Enhanced-1
(1E), 00, 10, 1E0,
50
0, 1, 5, Enhanced-1
(1E), and
Enhanced-5 (5E),
00, 10, 1E0, 50
0, 1, 5, Enhanced-1
(1E), and Enhanced-5
(5E), 00, 10, 1E0, 50
0, 1, 5, Enhanced-1
(1E), and
Enhanced-5 (5E),
00, 10, 1E0, 50
System PCI data bus 64 bit at 66 MHz 64 bit at 33 MHz 64 bit at 33 to 66
MHz
64 bit at 33 to 66
MHz
The ServeRAID controllers support the following features of ServeRAID software
and utility programs.
ServeRAID features ServeRAID-5i ServeRAID-4H ServeRAID-4Mx ServeRAID-4Lx
ServeRAID ROM Update
Wizard
Yes Yes Yes Yes
ServeRAID Manager Yes Yes Yes Yes
ServeRAID
Mini-Configuration program
Yes Yes Yes Yes
IPSSEND Yes Yes Yes Yes
IPSSEND FlashCopy
®
function (Windows XP
Professional, Windows
2000, and Windows NT
only)
No Yes Yes Yes
IPSMON (NetWare only) Yes Yes Yes Yes
Clustering (Windows NT
and Windows 2000 only)
No Yes Yes Yes
Failover (Windows NT and
Windows 2000 only)
No Yes Yes Yes
Connector locations
This section provides illustrations of the SCSI channel connectors and cable
connectors for the ServeRAID-4H, ServeRAID-4Mx, ServeRAID-4Lx, and
ServeRAID-5i controllers.
The light-emitting diodes (LEDs) on the controllers indicate activity on the SCSI
channels and provide diagnostic information for trained service technicians.
ServeRAID-4H controller
The ServeRAID-4H controller has four independent SCSI channel connectors:
Channel 1, Channel 2, Channel 3, and Channel 4. Each of these SCSI channels
supports up to 15 physical devices.
Note: In the event of a power outage or failure, the battery-backup cache protects
the data stored in the ServeRAID cache memory when using the write-back
setting of the write-cache mode.
4IBM ServeRAID: User’s Reference, Version 5.10
