IBM

5110

System

Maintenance Analysis Procedures

Third Edition (January 1979)

This

a

major

revision

of,

and obsoletes,

SY31-0553-1.

Because the changes

and

additions

are extensive,

this

publication

should

be reviewed in

its

entirety.

Changes

are

periodically

made

to

the

information

herein; changes

will

be

reported

in

technical

newsletters

or

in

new

editions

of

this

publication.

Use

this

publication

only

as an aid in servicing

the

IBM

5110

System.

Publications

are

not

stocked

at

the

address

below.

Requests

for

copies

of

IBM

publications

and

for

technical

information

about

the

system

should

be

made

to

your

IBM

representative

or

to

the

branch

office

serving

your

locality.

This

publication

could

contain

technical

inaccuracies

or

typographical

errors. Use

the

Reader's

Comment

Form

at

the

back

of

this

publication

to

make

comments

about

this

publication.

If

the

form

has been removed,

address

your

comments

to

IBM

Corporation,

Publications,

Department

245, Rochester,

Minnesota

55901.

IBM

may

use

and

distribute

any

of

the

information

you

supply

in any

way

it

believes

appropriate

without

incurring

any

obligation

whatever.

You may,

of

course,

continue

to

use

the

information

you

supply.

©

Copyright

International

Business

Machines

Corporation

1978,

1979

o

o.

W·

o

I

Contents I

(

Logic Card Part Numbers

...........

.050-1

I

Logic Card Jumpers. . . . . . . . . . .

....

.050-5

(

USING

THE

IBM

5110

COMPUTER

MAPs.

0100-1

II

MAPs

........

0100-1

MAP

Organization 0100-2

Using the

MAPs.

0100-3

MAP

Examples

..

0100-4

I

Start

MAP

.....

0200-1

,.

Cable Checkout

MAP.

. 0210-1

(--

Tape Read

MAP

....

0300-1

Di~.kette

Read

MAP

..

0310-1

Bring Up

MAP

.....

0400-1 I

Process Check

MAP

..

0420-1

Display

MAP

......

0500-1

TV

Monitor

MAP

..

0510-1

Keyboard

MAP

. . . . 0600-1 I

Power

MAP

......

0700-1

5103

Printer

MAP

...

0810-1

Communications, Serial

I/O,

and Parallel

I/O

. 0830-1

Transmit/Receive Level Checkout

MAP

. 0831-1

Local CBS Coupler

(Auto

Answer)

MAP

I

for

38LS

Integrated Modem

.......

0832-1

Manual Call

to

a Manual Answer Station

Using a

CDT

Type

Coupler 0833-1

Digital

Network

Remote Wrap I

Test Procedure

.......

0834-1

(:-/

BSC

Network

and BSCA

Intermittent

Problem

MAP

0835-1

Automatic

Answer

MAP

for

38LS

with

World Trade Line

Box

....

0836-1 I

Manual Call

MAP

for

World Trade

38LS

.................

0837-1

Manual Answer

MAP

for

38LS

with

World

Trade Line

Box

......

0838-1

II

Auxiliary

Tape

MAP

........

0850-1

5114

Diskette

Unit

Entry

MAP

..

0880-1

Machine

Checkout

MAP

......

0900-1

II

('~-'

II

I

1

-;

..

-

iii

I

"\

This

page

intentionally left blank.

iv

LOGIC CARD PART NUMBERS I

Card

Name

Location

Model

Part

Number

(,e,

~"

I/O

cable

driver

A2

4360292

Async

comm-serial

I/O

D2

1607138

APL

ROS

E4

AXX

or

CXX

4360442

('"

4834732

~h,

.,

..-/

A1X2

4360434

Common

and

language

F2

ROS

4834796

48347641

(:~/

B1X2

4834714

4834722

4834796

48347641

C1X

2 4834712

4834724

4834796

48347641

A2X

3 4834716

4834726

4834754

(~1'

48347661

,/

B2X

3 4834718

4834728

4834798

48347681

C2X

3 4834720

4834730

4834800

48347701

Display

G2

4360476

4360450

("'h

(Katakana 4834708

feature only)

-L

•.

./

Base

I/O

H2

X1X

4360496

4834746

(~~

X2X

4834700

4834794

,./'

Processor

J2 1607136

I

The

Katakana feature requires

one

of

these cards

Parallel

I/O

K2

4360430

to

be included.

C~

2

The

cards in model

C1

X may be

substituted

for

the

/ cards

in

models A1X

and

B1

X.

Feature

ROS

K4

4834964

3

The

cards

in

model C2X may be

substituted

for

the

(diskette sort) 4834972

cards

in

models A2X

and

B2X.

MAP

050·1

Card Name Location Model Part Number

Executable

ROS

L2

A1X

or

C1X6 4834734

,/

,Jr

4360478 :

..

~

48347841

B1X6 4834736

4360480

48347861

,~,

A2X

or C2X7 4834738

4360482

4360478

48347841

,..

B2X7 4834740

,Iii

4360484

48347881

Read/write M2-N4 8238223

Print adapter 5103 16071422

1607154

1607152

(Katakana 4834706

feature only)

Tape

adapter 5106 16071342

1607144

1607146

Tape

control 5106 or 8527645

internal tape

Diskette adapter 5114 4834710

4834960

48349783

48349623

Diskette control 5114 8528195

4178068

4178065

VFO 5114 16072174

BSCA

2 A4 48347922

4834780

BSCA 1

B2

16071765

IThe

Katakana feature requires

one

of

these cards

to

be installed.

200

not

replace with

the

same

part

number.

3

The

VFO

card

is

incorporated

in

this

card.

4Not

used

with

diskette

adapter

card 4834710

or

4834960.

5

The

microprocessor

module

on

this card

is

part

5615702.

j'."

6

The

cards

in

models A1X

or

C2X may be

substituted

for

the

cards

in

the

5110

model

B1

X.

7The

cards in models

A2X

or

C2X may be

substituted

for

the

cards

in

the

MAP 050-2

5110 model

B2X.

I

Communication Location Model Part Number

(:'

Communication

C2

facility

EJA

Used

with 5864363

external modems 5864660

(~'".~

DDSA

Used

with 8527032

digital network

..

38LS

U.S.

switched network 1756001

with auto answer 8564508

38LS

U.S.

non-switched 1756003

(

...

'"

network with SNBU 8564509

38LS

U.S.

non-switched 1756005

network

without

SNBU 8454510

38LS World Trade non- 1756011

switched network 8564481

38LS World Trade 1756007

switched network 8564479

c

MAP 050-3

"

This page

intentionally

left

blank.

MAP 050-4

(

.(

.......

~-~

c

LOGIC CARD JUMPERS

Printer Adapter Card!

\

I

~

\

\\\

\

\\

\

Country Jumper Positions!

.-

-.

Austria/Germany

§WiB

• _.

-.

.-.

Belgium .--.

-.

Brazil

lilliE.

_.

.-.-

Denmark/Norway

.-

-.

_.

.-

EBCDIC (U.S.) 1 -. .

-

.-

.

~

Finland/Sweden

--

.

_.

--

. .

--

France •

MmII

...

-.

.-

French/Canada • iU!lllII .-

.-.-

International

....

.-

-.

.-

Italy

-.

.--.

Japan 1 .-

...

.-

-.

Portugal

-.

.-

-.

...

Spain .-.

...

-.

Spanish Speaking

-.

.-

..-- .-

United Kingdom .-.-

.-

-.

Unassigned

.-

_.

Display Card

4360476

\

,

Jumper Positions2

.-.-

.-

-.

.-.-

-..

.

.-

.-.

.-

-.

.-

-.

.

.-

-.

.

-.

...

-.

.-

-.

.-

_.

.

--

_.

...

.-

_.

-.

.-

_. -.

.-

..

.

•

IIIBl

-.

_.

..

•

...

.-

.-.-

_.

.-

.--.

-. .-

-..-

_. .-

-.

_.

...

.-

• -

• -• -

Display Card

4360450

I

Jumper

Positions2

1-- -

-III

-;

--

I-II

II- -

-

-II

--I -

II-I

IIII

----

a-I-

-I- I

-II-

I --I

-III

1-- -

I-II

.1

--

III-

---I

-. -I

III-

I- -I

.I I -

.I -I

I -I -

II-I

-

-I

-

--II

II- -

--- -

IIII

Iprinter

adapter

card used

with

Katakana

feature

should

have

either

EBCDIC (U.S.)

jumpers

or

none

at

all.

2There

is

no

display

jumpering

for

the

Katakana

feature. '

MAP

050-5

Diskette

Adapter

Card

Auxiliary

Tape

Unit

Adapter Card ,

,

'-.e._

e

Jumper Position

for

All

Machines

........................

........

.....

I

I I

d:!3

----------

,

DDDDDD

~

Processor

Card(J2)

Jumper Position

for

5100

Jumper Position

for

5110

Executable

ROS

Card (L2) Jumper Position

for

5110-X1 X

Jumper Position

for

5110-X2X

IIII

II:

:

III:

I;::

Feature

ROS

Card (K4)

Jumper on

for

All

Machines

Jumper Position

for

5100

Jumper Position

for

5110

Jumper Position

for

5100

~

Jumper Position

for

5110

MAP 050-6

c

USING

THE

IBM 5110 SYSTEM MAPS

MAPs

The

MAPs

guide

you

through

the

service call using step-by-

step

procedures

that

require

you

to

follow

trace

lines

when

responding

to

questions

or

when

leaving

or

entering

a page.

The

MAPs use a logical

approach

for

isolating

the

possible

causes

of

machine

problems

and

point

you

to

that

part

of

the

5110

that

requires

adjustment

or

replacement.

Two

types

of

MAPs are used

in

the

5110

maintenance

library. First,

there

are

the

hard-copy

(printed)

MAPs

within

the

MLM

binder.

These

MAPs are

contained

in

a

separate

removable

binder.

The

second

type

of

MAP

is

the

MOl (MAP

diagnostic

integration).

These MAPs

are

located

on

the

diagnostic

tape/diskette

and

are

shown

on

the

display

screen.

The

system

automatically

pages

through

the

MAPs

when

you

respond

to

the

questions

on

the

display.

I

MAP 0100-1

MAP

ORGANIZATION

START

Start

MAP 200

Record

the

Error Code Displayed

Indicator

Lights-Use

MAP

200

Other

Reported

Fail ures

-------f..----------------------1~O-~L-

__________________________

~

NoSymptoms---------------+---------------,

Begin each call

with

Start

MAP 200. This MAP ensures

that

the

system

is

operating

sufficiently

to

use

other

MAPs

or

MDls.

Start

MAP 200 asks

you

to

record

the

status

bytes,

error

logs,

and

history

logs because this

information

is

lost

on

power

down

or

RESTART.

The

Start

MAP

either

fixes

or

directs

you

to

a MAP

that

tells you

how

to

fix

any

of

the

following problems:

Indi

cator

lights

Bring

up

failures

Process

checks

Display failures

For

other

failures,

the

Start

MAP directs

you

to

the

correct

MAP

through

an

error

code.

If

you

are

certain

the

failure

is

not

covered

in

the

Start

MAP,

you

can go

directly

to

the

other

MAPs

indicated

by

the

®

in

the

chart.

All

MDls have a MAP

as

an

entry.

For

example,

MAP

810-5103

is

an

entry

for

MOl 800

through

805. These

MAPs provide

the

setup

instructions

for

running

the

MDls.

The

MDls are a

combination

of

MAPs

and

diagnostics.

The

MD

Is

call

in

and

run

the

appropriate

diagnostics

and

answer

most

of

the

MAP questions

automatically.

The

procedures

for

diagnosing

intermittent

failures

contain

a

more

detailed

description

of

what

part

of

the

system

each MOl checks.

(.~.\

C·

"

/

CI

USING THE MAPS

When

using the MAPs, you must:

READ

CAREFULLY.

The MAPs

can

help you find the

problem only

if

you

follow

instructions

and

answer

questions accurately.

FOLLOW THE SEQUENCE.

Proceed

step-by-step at all

times.

At

times, the MAP instructions might

seem

irrele-

-vant. However, they

can

be

important in determining the

correct error indications.

FOLLOW INSTRUCTIONS. Instructions must

be

carried

out

exactly in the order given. Questions

are

based

on

instructions immediately preceding the questions. Do

not

change

the conditions established by the instructions

before answering the questions. Do

not

press

the

RESTART switch

until

you

are

told

to

do

so

in the MAPs.

When

you

are

asked

to

probe a line in the MAPs, the line

name

and

its active level

are

given. For example:

-Probe H2-G06

(-

machine check).

The -(minus) in

front

of

machine check indicates that this

line

is

active at adown level.

I

MAP 0100-3

MAP EXAMPLE

__

-----

MAP name and number

PROCESS CHECK

MAP

0420

----------~En:t~ry::a~nd~exit

points-show

all

entry

and

exit

points

to

PAGE 1 OF

75

ENTRY

POINTS

and

from

this MAP.

FROM

ENTER

THIS

MAP

EXIT

THIS

MAP

TO

PAGE

STEP

MAP

ENTRY

MAP

NUMBER

ENTRY

POINT

PAGE

NUMBER

STEP

NUMBER

NUMBER NUMBER

POINT

0200

0300

0600

0810

0830

0850

0900

830C

A

001

5

18

75

001

--------------------------------------

(Entry

Point

A)

________________

_

Is

the

PROCESS

CH

ECK

light

on

'7

Y

N----------------------

002

Can

you

create

the

PROCESS CHECK?

Y N

003

The

MAPs

depend on having the PROCESS

CHECK on

the

machine

or

being able

to

create the PROCESS CHECK. Gather and

record all available information pertaining

to

the

PROCESS CHECK. Advise the

customer

that

if

the PROCESS CHECK

appears again,

to

leave

the

machine in the

failing

condition

until you arrive.

004

Is

the

PROCESS

CHECK

intermittent?

Y N

222

ABC

044 0400 A

218 0400 A

828 0500 A

Step number

Entry

point-indicates

a possible starting

point

in this

MAP.

It

is

usually referenced

from

a step

within

a

MAP.

Y=yes, N=no

Off-page reference-identifies the

page

and trace on

which this MAP

leg

continues. The 2 indicates

that

this

leg

continues on

page

2.

The C indicates

that

th

is

leg

continues at trace

C.

MAP 0100-4

'l

.,:,/

('\,

(

.""'\

•

0'

c

c"

CI

MAP

EXAMPLE (continued)

ABC

PROCESS CHECK

MAP

1 1

1-

PAGE

2 OF

75

005

Create

the

PROCESS CHECK.

Did the PROCESS CHECK come on

as

a

result of pressing RESTART or powering

on the 5110?

Y N

006

We

will

assume

that

the

PROCESS

CHECK

comes

on

as

a result of running

a job.

-On-page reference-indicates the trace and page from

which this

MAP

leg

came. The 1 indicates

that

this

leg

came from page

1.

The C indicates

that

this

leg

came from trace

C.

Go

to

Step

010,

--------------Internal

exit

point-indicates

the page, step, and entry

Entry

Point

H.

point

to

go

to

within this

MAP.

007

We

will

use

the

RESTART condition

to

create

the

PROCESS CHECK.

Go To Map 0400, Entry Point

A.

---------

External exit

point-indicates

the

MAP

and entry

point

to

go

to.

008

Create the PROCESS CHECK

-----------Instruction-establishes

conditions for answering the

Go to the INTERMITTENT

FAI

LURE CHART next question.

in

the 5110 SERVICE AIDS.

009

Is

the

PROCESS

CHECK

intermittent7---------0uestion-answer

either yes or no. Continue from

Y N your answer

to

the next question or instruction.

010

(Entry

Point

H)

Bad

RESTART switch.

--------------

Action-possible fixes for the failure. Replace, repair,

Check/replace Z3 (display and control panel) or adjust

in

the order given. (Check/replace means

to

cable

(see

MAP

0210 and

MIM

210, 241). check first, then replace

if

defective.)

Is

the

display

blank

or

dark

7

Y N

011

Reference

number-refers

to

a location graphic,

Are there

~ny

devices attached

to

th~

maintenance procedure, chart, or other pertinent

5110

I/O mterface port? (see

MIM

information

in

the maintenance section.

271)

Y N

7 7 1

558

o E F

G-

1-10

_ On-page reference-indicates the trace on this page

from which this

leg

of

the

MAP

continues.

MAP

0100-5

I

MAP 0100·6

This page intentionally left blank.

MAP 0100·6

START

MAP

0200

('.'"

PAGE

1

OF

5

ENTRY

POINTS

('"

',,",

FROM

ENTER

THIS

MAP

.

_/

MAP

ENTRY

PAGE

STEP

NUMBER

POINT

NUMBER NUMBER

..

('

0300 A 2

001

0900 A 2

001

_/

C

MAP 0200, ENTRY POINT A

IS

ON

PAGE 2

c

MAP

0200-1

EXIT

POINTS

EXIT

THIS

MAP

TO

PAGE

STEP

MAP

ENTRY

NUMBER

NUMBER NUMBER

POINT

4 020 0300 B

4 020 0310 A

3 014 0400 A

3 018 0400 D

5 030 0420 A

4 020 0420 A

4

021

0420 A

4 026 0420 A

5 027 0500 A

3 012 0500 A

4 025 0500 A

3 015 0500 A

4 020 0500 A

4 024 0500 A

4 020 0510 A

4 020 0600 A

4 020 0810 A

4 020 0830 A

4 020 0850 A

4 020 0880 A

4 020 0900 A

4 020 0900 C

4 020 0900 D

4 020 0900 F

01JAN79

EC

836600

PEC

835541

MAP

0200-1

I

START

MAP

PAGE 2

OF

5

001

(Entry

Point

A)

When

the

MAP

leads

to

a bad card, measure the

voltages at the card location before replacing the

card (see

MIM

274,

DC

VOLTAGE

DISTRIBUTION).

If

any voltages are

out

of

tolerance Go To

Map

0700, Entry Point A.

Any

reference numbers in the MAPs, such

as

(see

MIM

241), will be

for

the

5110

MIM,

unless

stated otherwise.

-Record customer supplied information including

error codes,

if

any.

-Record the status bytes

to

aid in diagnosing

intermittent

I/O

problems (see STATUS BYTES

and DISPLAY REGISTERS in the Diagnostic

Aids section

of

the

MIM).

-Switch

the

L32-64-R32

switch

to

64.

-Press the

bottom

of

the

REVERSE

DISPLAY

switch.

-Switch

the DISPLAY REGISTERS switch

to

NORMAL.

-Check

that the RUN switch (under the covers) is

set

to

run,

if

the

covers are

off

(see

MIM

201).

Is

the

PROCESS

CHECK

light

on

1

Y N

002

-Power

on the 5110

or

press RESTART.

Does

the

IN PROCESS

light

stay

on?

Y N

003

Is

the

5110

display

dark

for

all

positions

of

the

BRIGHTNESS

control?

Y N

555

ABC

D

o

MAP

0200-2

004

To

test

the indicator lights:

-Press and hold the RESTART switch.

Are

both

the

PROCESS

CHECK

light

and

the

IN PROCESS

light

on?

V N

005

Bad

L2

(exec

ROS)

card (see

MAP

050

for

jumpering).

Bad PROCESS CHECK light.

Bad IN PROCESS light.

Bad RESTART switch.

Check/

replace Z3 (display and control panel)

cable (see

MAP

0210

and

MIM

248,249).

006

-Release the RESTART switch.

seconds.

Is

the

PROCESS

CHECK

light

on1

V N

007

Wait

25

-Adjust

the BRIGHTNESS control so that

if

there are any characters on the display they

are well defined.

The 5110 display is grossly distorted

if

it

has a

black rather than a

white

background,

or

is

greatly reduced

in

size.

Is

the

5110

display

grossly

distorted?

V N

008

Is

the

5110

display

rolling?

V N

444

3

E F G H

01JAN79

EC

836600

PEC

835541

MAP

0200-2

,

jI'

..

("'"

(

'~'"

/

. "

c'

c

H

START

MAP

2

PAGE 3

OF

5

009

Does

the

5110

display

contain

wide

horizontal

bars

similar

to

a

TV

set

with

the

horizontal

hold

out

of

adjustment?

Y N

4

010

No more than 25 seconds

after

RESTART is

pressed, the

following

events should occur:

1.

ABCDEFGH appears on the

top

line

of

the

5110

display.

2.

ABCDEFGHJKLMNP appears on the

top

line.

3. The

top

line is cleared and either LOADO

or

CLEAR

WS

appears once on one and

only one

iine

of

the

5110

display.

-Press RESTART.

Do

all

three

events

occur

before

25

seconds,

in

sequence,

after

RESTART

is

pressed?

Y N

011

-Switch

the

RUN

switch

under the covers

to

NOT RUN (see

MIM

201).

-Switch

the

DISPLAY REGISTERS

switch

to

DISPLAY REGISTERS.

(See DISPLAY

REG

ISTERS in

the

Diagnostic

Aids

section in the

MIM).

Do

all

1024

positions

contain

legible,

well-formed

characters,

with

no

blank

spaces?

Y N

012

-Switch

the

DISPLAY REGISTERS

switch

to

NORMAL.

-Switch

the RUN

switch

under

the

covers

to

RUN.

Go

To

Map

0500,

Entry

Point

A.

J K L

KL

MAP

0200-3

013

-Switch

the RUN switch under

the

covers

to

RUN.

-ObseNe

the IN PROCESS light.

-Hold

down

the

CMD

key and press

the

4 key

on

the

Alphameric Keyboard.

-Release

the

keys.

-Press EXECUTE.

Does

the

IN PROCESS

light

turn

on

or

flash?

Y N

014

-Switch

the

DISPLAY REGISTERS

switch

to

NORMAL.

Go

To

Map

0400,

Entry

Point

A.

015

Bringup is OK.

-Switch

the

DISPLAY REGISTERS

switch

to

NORMAL.

-Press A

TIN

to

reset

the

error condition.

Go

To

Map

0500,

Entry

Point

A.

016

Does

an

error

code

appear

on

the

display

after

REST

ART

is

pressed?

Y N

017

Are

the

top

13

lines

of

the

display

entirely

blank

(there

are

16

lines

total

for

the

display)?

Y N

018

Go

To

Map

0400,

Entry

Point

D.

019

Is

the

PROCESS

CHECK

light

on?

Y N

444

M N P

01JAN79

EC

836600

PEC

835541

MAP

0200-3

I

P

3

020

(Entry Point

E)

START

MAP

PAGE 4

OF

5

-Use the customer information recorded earlier

and the customer error code charts

to

determine

the

probable failure area.

-Record the status bytes

to

aid in diagnosing

intermittent

I/O

problems (see STATUS BYTES

and DISPLAY REGISTERS in

the

Diagnostic

Aids

section

of

the

MIM).

Exit

to

the appropriate

MAP

:

-INTERNAL

TAPE

UNIT

Go

To

Map

0300, Entry Point

B.

-5114

DRIVE 1 (only use this

Map

if

the

5110

does NOT have

an

internal tape drive)

Go To

Map

0310, Entry Point A.

-DISPLAY

Go To

Map

0500, Entry Point A.

-TV

MONITOR

Go

To

Map

0510, Entry Point A.

-KEYBOARD

Go

To

Map

0600, Entry Point A.

-PRINTER

Go

To

Map

0810, Entry Point A.

-BSCA,

ASYNC

COMM-SERIAL

I/O,

PARALLEL

I/O

Go To

Map

0830, Entry Point A.

-AUXILIARY

TAPE

UNIT

Go

To

Map

0850, Entry Point A.

-DISKETTE DRIVE

Go

To

Map

0880, Entry Point A.

-PROCESS CHECK

Go

To

Map

0420, Entry Point

A.

(Step

020

continues)

E F GJ MN

2 2 2 3 3 3

MAP

0200-4

(Step

020

continued)

-ALARM

Go To

Map

0900,

Entry Point D.

-5110

SWITCH CHECKOUT

Go

To

Map

0900,

Entry Point

F.

-MACHINE

CHECKOUT

Go To

Map

0900,

Entry Point A.

-If

the failing area can

not

be

identified

from

the list above:

Go To

Map

0900,

Entry Point

C.

021

Go

To

Map

0420, Entry Point A.

022

Go

to

Step

020,

Entry Point

E.

023

Bad display assembly (see

MIM

204).

024

The vertical frequency may be

out

of

adjustment (see

MIM

247

for

adjustment).

*************

* CAUTION *

*************

High voltage is present.

If

this adjustment has no

effect

Go

To

Map

0500, Entry Point A.

025

Go To

Map

0500, Entry Point A.

026

Go To

Map

0420, Entry Point A.

01JAN79

EC

836600

PEe 835541

MAP

0200-4

,t'

""',

"",_

,.lIto'

IBM 5110 Manual

Popular Desktop manuals by other brands
