Icom iV86 Installation and operating instructions
NOTE: Use these amended pages as one addendum set.
Do not mix them up with the previous master pages.
Definitions
Replacement page The page to replace the original one.
Addendum page The page to be added to the original set.
Amended page The page to be added as change history, including
corrections.
SERVICE MANUAL
ADDENDUM
February 2021
iV86/iV86-T/iG86
[Version List]
Model Version Version
Number
Operable
Frequency
Range
(MHz)
Maximum
transmit
output
power
Installed unit
Remarks
MAIN
MAIN-A
IC-V86 USA-01 #11 136~174 7. 0 W
IC-V86 EXP-01 #12 136~174 7. 0 W
IC-V86 EXP-03 #13 136 ~174 7.0 W
IC-V86 -T THA-01 #31 144~147 5.0 W
IC-G86 EXP-01 # 41 136~174 7. 0 W
Page number information
The number of revisions can be easily understood by the addendum service manual’s page number.
The number of revisions (a, b, c, ...) is added after the page number.
CONTENTS
SECTION 4 ADJUSTMENT PROCEDURE �������� 4-1b~4-7b
SECTION 5 PARTS LIST ���������������� 5-1b~5-6b
SECTION 6 MECHANICAL PARTS ����������� 6-1b~6-2b
SECTION 7 BOARD LAYOUTS �������������� 7-1b~7-2b
SECTION 8 VOLTAGE DIAGRAM ������������ 8-1b~8-6b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
4-1b
SECTION 4 ADJUSTMENT PROCEDURE
4-1 PREPAR ATION
REQUIRED EQUIPMENT
EQUIPMENT GRADE AND RANGE EQUIPMENT GRADE AND RANGE
DC power supply Output voltage: 7.5 V
Current capacity: 3 A or more JIG battery case Modified BP-263.
(See the illustration shown on page 4-2b.)
Frequency counter Range: 0.1~300 MHz
Accuracy: ±1 ppm or better JIG plug
(See the illustration shown on page 4-2b.)
Attenuator Attenuation: 30 dB or 40 dB
Capacity: More than 10 W JIG cable 1 inch) stereo plug.
(See the illustration shown on page 4-2b.)
Audio generator
(AG)
Frequency range: 300~3000 Hz
Output level: 1 ~ 500 mV JIG cable 2
(See the illustration shown on page 4-2b.)
RF power meter
Measuring range: 0.1 ~ 10 W
Frequency range: 100 ~ 300 MHz
SWR: Less than 1.2 : 1
Standard signal
generator (SSG)
Frequency range: 0.1 ~ 300 MHz
AC millivoltmeter Measuring range: 10 mV to 10 V Distortion meter Measuring accuracy: 3% or less at 1 kHz
Input level: 50 mV to 10 V
Modulation analyzer Frequency range: 30 ~ 300 MHz
Measuring range: 0 ~ ±10 kHz External speaker
Capacity: More than 1 W
Spectrum analyzer Measuring range: Up to 3 GHz Ammeter Measuring range: 0 to 10 A
NOTE: For products with early serial numbers
for the adjustment procedures.
[Applicable serial numbers]
Model Name Version Number Serial Numbers Model Name Version Number Serial Numbers
IC-V86 #11 11001001 ~ 11027100 IC-V86 #13 13001001 ~ 13004800
IC-V86 #12 12001001 ~ 12006100 IC-V86-T #31 31001001 ~ 31004700
Standard signal generator
–20 to 90 dBµV
(–127 to –17 dBm)
CAUTION!
NEVER transmit while
the SSG is connected to
the antenna connector.
JIG cable 2: See the illustration shown on page 4-2b.
IC-V86/IC-V86-T/IC-G86
JIG cable 1: See the illustration shown on page 4-2b.
Frequency counter
Loose
coupling
Attenuator
30 dB or 40 dB
Modulation analyzer
30~300 MHz/0 to ±10 kHz
RF power meter
0.1~
Spectrum analyzer
Up to 3 GHz
To [MIC]
To [SP]
JIG battery case: See the illustration shown on page 4-2b.
For receive adjustments For transmit adjustments
CONNECTIONS
4-2b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
JIG
DC power supply
(7.5 V/3 A)
Ammeter
(0 to 10 A)
Red
3 A fuses
Black
BP-263
Make two holes in the back of the case and pass the cables through.
[JIG battery case]
[JIG plug]
(GND)
(REMOTE)
3-conductor 3.5 (d) mm ( plug
(Parts Number: 5610000020)
82 k
[JIG cable 1]
+
AC millivoltmeter
(10 mV to 10 V)
+
Audio generator
(300~3000 Hz/1~500 mV)
(MIC)
(GND)
33 k
4.7 µF
+
PTT
3-conductor 2.5 (d) mm ( plug
[JIG cable 2]
+
(GND)
(SP)
External speaker
(1 W/8 )
+
Distortion meter
(3% or less at 1 kHz/50 mV to 10 V)
3-conductor 3.5 (d) mm ( plug
(Parts Number: 5610000020)
4-3b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
ENTERING THE ADJUST MODE
1. Turn OFF the power.
2. Connect the JIG plug to the [SP] connector.
to [SP]
JIG plug:
See the illustration
shown on page 4-2b.
3. While holding down all [
]/[
] and [VFO/MR/CALL],
turn ON the transceiver power to enter the adjust mode.
[
]
[
]
[VFO/MR/CALL]
[POWER]
4. The adjust mode is displayed.
KEY ASSIGNMENTS FOR THE ADJUST MODE
• Push [
] to select the next adjustment item, push [
] to
select the previous adjustment item.
• Rotate [VOL] to set or modify the adjustment value.
• Push [# ENT]•[ ] to store the adjusted value, or start
automatic adjustment.
• Push [*]•[FUNC] to briefly display the adjustment value.
[VOL]
Adjust the value for
the item
[*]•[FUNC]
Briefly displays
adjusted value
[# ENT]•[ ]
Stores adjusted value,
or starts automatic
adjustment
[
]
Selects the next
adjustment item
[
]
Selects the previous
adjustment item
ADJUST MODE SCREENS
Adjustment frequency
While rotating [VOL],
or when [*]•[FUNC] is pushed
Adjustment item
Adjusted value
4-4b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
4-2 TRANSMIT ADJUSTMENTS
ADJUSTMENT ADJUSTMENT ITEM
DISPL AY SETTING CONDITION OPER ATION
FREQUENCY
-Verification-
1• Connect the RF power meter or
the dummy load to the antenna
connector.
• Loosely couple the frequency
counter to the antenna connector.
• Transmitting
(If out of the specified range,
adjust the frequency by [VOL],
then push [# ENT]•[ ].)
TRANSMIT
OUTPUT POWER
-Adjustment-
(Extra High)
1• Connect the RF power meter to the
antenna connector.
• While transmitting, adjust the
connected DC power supply
voltage to 7.5 V.
• Transmitting
Set the transmit output power to
7.0 W (within ±0.2 W) by [VOL],
then push [# ENT]•[ ].
Note the adjusted value as the
reference value A.
(High) 2Set the transmit output power to
5.5 W (within ±0.2 W) by [VOL],
then push [# ENT]•[ ].
Note the adjusted value as the
reference value B.
(Middle) 3Set the transmit output power to
2.5 W (within ±0.2 W) by [VOL],
then push [# ENT]•[ ].
Note the adjusted value as the
reference value C.
(Low) 4Set the transmit output power to
0.5 W (within ±0.1 W) by [VOL],
then push [# ENT]•[ ].
Note the adjusted value as the
reference value D.
(Extra High) 5• Receiving Set the adjustment value to the
value that add 4 to the reference
value B, then push [# ENT]•[ ].
6
Set the adjustment value to the
value that subtract 5 to the reference
value A, then push [# ENT]•[ ].
7
Set the adjustment value to the
value that subtract 1 to the reference
value B, then push [# ENT]•[ ].
(High) 8Set the adjustment value to the
value that add 4 to the reference
value B, then push [# ENT]•[ ].
Set the adjustment value to the
value that subtract 7 to the reference
value B, then push [# ENT]•[ ].
10
Set the adjustment value to the
value that subtract 1 to the reference
value B, then push [# ENT]•[ ].
(Middle) 11 Set the adjustment value to the
value that add 1 to the reference
value C, then push [# ENT]•[ ].
12
Set the adjustment value to the
value that subtract 3 to the reference
value C, then push [# ENT]•[ ].
13 Set the adjustment value to the
value that add 4 to the reference
value C, then push [# ENT]•[ ].
(Low) 14 Set the adjustment value to the
value that add 1 to the reference
value D, then push [# ENT]•[ ].
15 Set the adjustment value to the
reference value D, then push
[# ENT]•[ ].
16 Set the adjustment value to the
value that add 5 to the reference
value D, then push [# ENT]•[ ].
4-5b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
ADJUSTMENT ADJUSTMENT ITEM
DISPL AY SETTING CONDITION OPER ATION
TRANSMIT
OUTPUT POWER
-Verification-
(Extra High)
1• Connect the RF power meter to the
antenna connector.
• While transmitting, adjust the
connected DC power supply
voltage to 7.5 V.
• Transmitting
4.5~6.5 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[ ].)
26.0~8.0 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[ ].)
34.5~6.5 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[ ].)
(High) 4
5
6
(Middle) 72.0~3.0 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[ ].)
8
(Low) 10 0.25~1.5 W
(If out of the specified range,
adjust the output power by [VOL],
then push [# ENT]•[ ].)
11
12
TRANSMITTING
CURRENT
-Verification-
1• Connect the ammeter between the
JIG battery case and the DC power
supply.
• Transmitting
Less than 2.0 A
2
3
4
SPURIOUS
EMISSION
-Verification-
1• Connect the spectrum analyzer to
the antenna connector through the
attenuator.
• Transmitting
2
3
4
4-2 TRANSMIT ADJUSTMENTS (CONTINUED)
4-6b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
ADJUSTMENT ADJUSTMENT ITEM
DISPL AY SETTING CONDITION OPER ATION
MODULATION
SENSITIVITY
-Verification-
1• Connect the modulation analyzer to
the antenna connector through the
attenuator and set it to:
HPF: OFF
LPF: 20 kHz or 15 kHz
De-emphasis: OFF
• Connect the audio generator and
the AC millivoltmeter to [MIC]
through the JIG cable 1,and set it to:
Frequency: 1 kHz
Waveform: Sine wave
Level: Adjust to the
level so that the
modulation analyzer
shows ±1.50 kHz of
deviation
• Transmitting
10.0~20.0 mV
(Audio generator output level)
TRANSMIT S/N
RATIO
-Verification-
1• Set the modulation analyzer to:
HPF: 50 Hz
LPF: 3 kHz
De-emphasis: ON
• Set the audio generator output level
so that the modulation analyzer
shows ±1.50 kHz of deviation.
• Transmitting
• Toggle the audio generator output
ON and OFF.
More than 34 dB
4-2 TRANSMIT ADJUSTMENTS (CONTINUED)
4-7b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
4-3 RECEIVE ADJUSTMENTS
ADJUSTMENT ADJUSTMENT ITEM
DISPL AY SETTING CONDITION OPER ATION
NOISE SQUELCH
-Adjustment-
1• Connect the standard signal
generator (SSG) to the antenna
connector and set it to:
Frequency: 146.020 MHz
Modulation: 1 kHz
Deviation: ±1.5 kHz
Level*:
• Receiving
Push [# ENT]•[ ].
(Automatic adjustment)
S-METER
-Adjustment-
1• Set the SSG as:
Level*:
• Receiving
Push [# ENT]•[ ].
(Automatic adjustment)
RECEIVE
SENSITIVITY
-Verification-
1• Connect the distortion meter and
the external speaker to [SP] through
the JIG cable 2.
• Set the SSG as:
Frequency: 136.020 MHz
Level:
Set to the level so that
the distortion meter
shows 12 dB SINAD.
• Receiving
*
(SSG output level)
2• Set the SSG as:
Frequency: 155.020 MHz
Level:
Set to the level so that
the distortion meter
shows 12 dB SINAD.
• Receiving
3• Set the SSG as:
Level:
Set to the level so that
the distortion meter
shows 12 dB SINAD.
• Receiving
AUDIO OUTPUT
LEVEL
-Verification-
1• Set the SSG as:
Frequency: 155.020 MHz
Level*
• Receiving
• Adjust the audio output level so that the
distortion meter shows 5% of distortion.
More than 0.45 W
RECEIVE S/N
RATIO
-Verification-
1• Receiving
• Adjust the audio output level so that
the distortion meter shows 1.34 V.
• Toggle the SSG's modulation ON
and O FF.
More than 34 dB
2• Set the SSG as:
Frequency: 136.020 MHz
• Receiving
3• Set the SSG as:
• Receiving
RECEIVING
CURRENT
-Verification-
(Maximum audio)
1
• Connect the ammeter between the JIG
battery case and the DC power supply.
• Set the SSG modulation ON.
• Receiving
• Adjust the audio output to the
maximum level.
Less than 0.6 A
(Stand-by) 2 • No optional unit is connected.
• No RF signal is received.
• Squelch closed.
Less than 80 mA
For only IC-V86
and IC-V86-T:
DEFAULT BATTERY
PACK SETTING
1Select 01 (Ni-MH for [#13]) or 02
(Li-ion for [#11], [#12], and [#31])
by [VOL], then push [# ENT]•[ ].
*The output level of the standard signal generator (SSG) is measured at the load end (PD).
SECTION §SECTION § PARTS LIST
5-1b
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF PART DESCRIPTION M. H/V
NO. NO. LOCATION
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
(Amended page)
The underlined parts have been updated from the previous version of the addendum, or from the original page.
[MAIN UNIT] (for IC-V86 and IC-V86-T)
February 2021
SECTION 5 PARTS LIST
IC1 1110007010 S.IC NJM12904R-TE1 B 34.7/29.4
IC3 1110010000 S.IC AT1846S B 47.4/16.1
IC400 1130019660 S.IC BR24G128NUX-5TR B 92.2/14.0
Eqv. 1130019950 S.IC BR24G128NUX-3ATTR
IC402 1140018490 S.IC STM32L073VBT6 B 81.0/20.5
IC403 1110007780 S.IC NJU7704F3-28A-TE1 B 75.4/8.2
IC701 1110007630 S.IC NJM2783V-TE1 T 39.6/41.5
IC702 1110010010 S.IC U2429G-S08-R B 23.1/36.7
IC706 1110008450 S.IC ISD8102SYI T&R T 22.5/35.4
IC707 6910027810 S.DC TPS561201DDCR B 51.4/41.1
IC817 1110010140 S.IC TLV9002IDGKR B 31.2/36.7
IC818 1180004950 S.REG XC6701B502MR-G T 7.4/29.0
IC819 1110008890 S.IC NJU7056F3-TE2 T 20.2/29.7
IC820 1130007021 S.IC TC7S66FU(TE85LF) B 52.8/32.2
Q2 1590005410 S.TRA DTC014YEBTL B 42.2/31.7
Q4 1590005560 S.TRA DTA014EEBTL B 40.2/31.3
Q6 1530003322 S.TRA 2SC5108-YLF B 37.6/8.0
Q7 1560002420 S.FET RD01MUS2B-T513 B 37.2/15.8
Q8 1530003322 S.TRA 2SC5108-YLF B 38.4/21.4
Q9 1560002460 S.FET RD08MUS2-T512 B 29.6/13.4
Q10 1560002190 S.FET RUM002N02T2L B 39.2/28.0
Q12 1590005410 S.TRA DTC014YEBTL B 27.7/33.8
Q400 1530002851 S.TRA 2SC4116-BL(TE85RF) B 64.2/3.5
Q401 1590005430 S.TRA DTC044TEBTL B 90.2/32.4
Q703 1590004220 S.TRA DRA9123Y0L B 21.6/45.8
Q704 1590005410 S.TRA DTC014YEBTL T 41.5/5.3
Q705 1590005410 S.TRA DTC014YEBTL B 18.1/41.0
Q706 1590004590 S.TRA DMC506010R B 14.5/42.1
Q707 1520001010 S.TRA 2SB1132G-R-AB3-R B 10.1/41.3
Q711 1590005410 S.TRA DTC014YEBTL B 17.2/39.4
Q712 1590005410 S.TRA DTC014YEBTL B 73.1/38.1
Q716 1590005410 S.TRA DTC014YEBTL B 37.4/44.0
Q717 1510001270 S.TRA 2SAR502UBTL B 37.3/39.7
Q718 1590005410 S.TRA DTC014YEBTL T 35.5/36.2
Q720 1510001270 S.TRA 2SAR502UBTL T 31.9/37.1
Q721 1590004230 S.TRA LMUN5213DW1T1G B 40.2/44.1
Q722 1550000590 S.FET UT6401G-AG6-R T 10.9/30.4
Q723 1560002190 S.FET RUM002N02T2L B 13.2/31.4
Q724 1560002190 S.FET RUM002N02T2L T 20.5/31.8
Q725 1560002190 S.FET RUM002N02T2L B 17.9/42.9
D2 1750001810 S.DIO L1SS400T1G B 40.4/25.8
D3 1790001830 S.VAR AVR-M1005C270MTAAB B 25.5/20.1
D4 1720000701 S.VAR 1SV305(TPH3F) B 18.1/24.6
D5 1720000701 S.VAR 1SV305(TPH3F) B 16.3/25.4
D6 1750003940 S.DIO RN142SMT2R B 17.5/14.6
D7 1750003940 S.DIO RN142SMT2R B 15.7/20.4
D8 1750003940 S.DIO RN142SMT2R B 15.7/21.6
D9 1750003830 S.DIO RB751CM-40T2R B 15.0/22.8
D12 1750001810 S.DIO L1SS400T1G B 74.4/5.4
D13 1750003940 S.DIO RN142SMT2R B 17.5/15.8
D400 1750001810 S.DIO L1SS400T1G B 94.7/28.1
D401 1750001810 S.DIO L1SS400T1G B 94.7/25.7
D402 1750001810 S.DIO L1SS400T1G B 94.7/24.5
D404 1750001810 S.DIO L1SS400T1G B 94.7/26.9
D405 1750001810 S.DIO L1SS400T1G [#12] T 57.3/46.9
1750001810 S.DIO L1SS400T1G [#31]
D407 1750001810 S.DIO L1SS400T1G T 59.9/46.9
D408 1750001810 S.DIO L1SS400T1G B 94.7/29.3
D409 1750001810 S.DIO L1SS400T1G B 92.2/26.9
D410 1750001810 S.DIO L1SS400T1G B 92.2/24.5
D411 1750001810 S.DIO L1SS400T1G B 92.2/22.4
D413 1750001820 S.DIO LRB706F-40T1G B 92.8/31.9
D700 1750003390 S.ZEN RCLAMP1521P.TCT T 8.4/34.9
D705 1750001810 S.DIO L1SS400T1G B 36.6/36.8
D706 1750001810 S.DIO L1SS400T1G B 35.9/34.9
D708 1750001810 S.DIO L1SS400T1G T 16.6/39.1
D711 1750003830 S.DIO RB751CM-40T2R B 73.4/40.2
D714 1750003830 S.DIO RB751CM-40T2R B 72.0/39.7
D717 1750001810 S.DIO L1SS400T1G B 10.5/31.0
D719 1750001810 S.DIO L1SS400T1G B 16.0/45.2
X2 6050014880 S.XTA CR-1079 (13 MHz) B 61.9/8.9
X400 6050014200 S.XTA CR-1021 (12.288 MHz) B 82.5/7.3
L3 6200013820 S.COI MLK1005S27NJT B 36.7/9.5
L4 6200013830 S.COI MLK1005S22NJT B 33.3/12.3
L5 6200017370 S.COI SDWL1608CR10GSTF 0.1U B 38.8/23.3
L6 6200012540 S.COI 0.30-1.2-5TR 16.1N B 24.1/15.8
L7 6200013010 S.COI 0.30-0.9-5TL 10.3N B 23.8/13.3
L8 6200017390 S.COI SDWL1608C47NJSTF 47N B 19.6/24.6
L9 6200012390 S.COI 0.30-0.92-3TR 5.8N B 21.3/13.2
L10 6200012470 S.COI 0.30-1.7-7TL 45.3N B 20.5/10.8
L11 6200017560 S.COI NLV25T-R82J-EF T 20.8/16.5
L12 6200017390 S.COI SDWL1608C47NJSTF 47N B 13.7/24.2
L13 6200013820 S.COI MLK1005S27NJT B 21.8/24.2
L15 6200012470 S.COI 0.30-1.7-7TL 45.3N B 11.6/18.7
L16 6200012470 S.COI 0.30-1.7-7TL 45.3N B 17.3/18.1
L17 6200012760 S.COI 0.35-1.6-7TL 37.5N B 7. 5 /1 8 . 2
L18 6200012780 S.COI 0.30-1.4-6TL 27.2N B 9.2/13.7
L19 6200003640 S.COI MLF1608E 100K-T B 43.4/10.6
L22 6200003960 S.COI MLF1608A 1R0K-T B 62.0/11.6
L702 6200017010 S.COI VLS252012CX-100M-1 B 52.2/38.2
L705 6200017010 S.COI VLS252012CX-100M-1 B 46.4/39.7
R1 7510001730 S.THE ERTJ0EP 473J T 22.0/6.6
R2 7030014860 S.RES RGC1/16SC104DTH (100 k) T 21.6/5.3
R4 7030021060 S.RES MCR25JZHFL R150 (0.15) B 29.4/26.9
R8 7030015520 S.RES RMC1/16JPTP B 65.4/9.2
R10 7030016550 S.RES RMC1/16SK154FTH (150 k) B 31.5/26.4
R11 7030016560 S.RES RMC1/16SJPTH B 61.5/10.5
R12 7030016550 S.RES RMC1/16SK154FTH (150 k) B 29.8/30.1
R13 7030017370 S.RES RGC1/16SC183DTH (18 k) B 31.5/28.0
R14 7030015980 S.RES RMC1/16S-333JTH (33 k) B 38.7/31.5
R16 7030016030 S.RES RMC1/16S-154JTH (150 k) B 36.7/31.8
R17 7030015990 S.RES RMC1/16S-683JTH (68 k) B 36.7/32.7
R18 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 76.5/4.4
R19 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 76.5/5.4
R20 7030016740 S.RES RMC1/16SK474DTH (470 k) B 31.6/30.1
R21 7030016740 S.RES RMC1/16SK474DTH (470 k) B 33.0/27.2
R23 7030016360 S.RES RMC1/16S-123JTH (12 k) B 33.0/25.6
R24 7030015900 S.RES RMC1/16S-470JTH (47) B 52.9/17.9
R26 7030016030 S.RES RMC1/16S-154JTH (150 k) B 37.7/30.0
R27 7030016050 S.RES RMC1/16S-102JTH (1 k) B 50.9/14.6
R28 7030017370 S.RES RGC1/16SC183DTH (18 k) B 30.7/30.1
R30 7030016050 S.RES RMC1/16S-102JTH (1 k) B 37.7/28.4
R32 7030016120 S.RES RMC1/16S-682JTH (6.8 k) B 40.9/27.7
R33 7030016110 S.RES RMC1/16S-473JTH (47 k) B 43.2/18.0
R36 7030015910 S.RES RMC1/16S-101JTH (100) B 39.5/9.1
R37 7030016120 S.RES RMC1/16S-682JTH (6.8 k) B 39.0/7.9
R38 7030016150 S.RES RMC1/16S-100JTH (10) B 35.8/7.2
R41 7030016180 S.RES RMC1/16S-680JTH (68) B 38.1/11.1
R42 7030016510 S.RES RMC1/16S-4R7JTH (4.7) B 38.2/12.3
R44 7030016190 S.RES RMC1/16S-273JTH (27 k) B 39.5/11.9
R45 7030016250 S.RES RMC1/16S-220JTH (22) B 38.5/24.6
R46 7030015920 S.RES RMC1/16S-221JTH (220) B 36.7/23.3
R47 7030015910 S.RES RMC1/16S-101JTH (100) B 36.4/21.7
R48 7030016090 S.RES RMC1/16S-223JTH (22 k) B 39.5/12.8
R49 7030016390 S.RES RMC1/16S-184JTH (180 k) B 37.8/19.9
R50 7030016390 S.RES RMC1/16S-184JTH (180 k) B 36.2/19.9
R51 7030016250 S.RES RMC1/16S-220JTH (22) B 32.1/9.3
R52 7030016300 S.RES RMC1/16S-332JTH (3.3 k) B 30.9/7.2
R53 7030016000 S.RES RMC1/16S-823JTH (82 k) B 30.9/8.1
R55 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 17.5/26.4
R56 7030016050 S.RES RMC1/16S-102JTH (1 k) B 17.1/27.6
R57 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 15.9/26.4
R58 7030016370 S.RES RMC1/16S-271JTH (270) T 21.9/19.2
R59 7030016370 S.RES RMC1/16S-271JTH (270) T 21.0/19.2
R60 7030015990 S.RES RMC1/16S-683JTH (68 k) T 14.6/9.0
R67 7030016110 S.RES RMC1/16S-473JTH (47 k) B 40.1/29.4
R400 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 64.6/5.3
R401 7030016440 S.RES RMC1/16S-272JTH (2.7 k) B 66.5/4.9
R402 7030016110 S.RES RMC1/16S-473JTH (47 k) B 92.7/19.8
R403 7030016110 S.RES RMC1/16S-473JTH (47 k) B 92.2/18.6
R404 7030016050 S.RES RMC1/16S-102JTH (1 k) B 92.1/28.0
R405 7030016050 S.RES RMC1/16S-102JTH (1 k) B 91.9/25.7
R406 7030016050 S.RES RMC1/16S-102JTH (1 k) B 92.6/23.5
R407 7030016050 S.RES RMC1/16S-102JTH (1 k) B 92.5/21.4
R409 7030015970 S.RES RMC1/16S-103JTH (10 k) B 90.1/15.8
R410 7030015970 S.RES RMC1/16S-103JTH (10 k) B 72.0/12.3
R411 7030015970 S.RES RMC1/16S-103JTH (10 k) B 72.0/13.3
R412 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 91.5/17.4
R413 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 92.4/17.4
R416 7030015900 S.RES RMC1/16S-470JTH (47) B 79.1/10.0
R417 7030015900 S.RES RMC1/16S-470JTH (47) B 78.2/10.0
R421 7030016060 S.RES RMC1/16S-105JTH (1 M) B 81.3/10.5
R425 7030016110 S.RES RMC1/16S-473JTH (47 k) B 89.4/9.6
R426 7030016330 S.RES RMC1/16S-153JTH (15 k) B 90.8/30.8
R427 7030016830 S.RES RGC1/16SC153DTH (15.0 k) B 92.3/30.0
R428 7030016560 S.RES RMC1/16SJPTH B 69.6/17.9
R429 7030015970 S.RES RMC1/16S-103JTH (10 k) B 73.5/7.9
R430 7030016180 S.RES RMC1/16S-680JTH (68) B 66.0/3.3
R702 7030016500 S.RES RMC1/16S-562JTH (5.6 k) B 29.9/33.9
R703 7030016000 S.RES RMC1/16S-823JTH (82 k) B 31.1/34.4
R704 7030016110 S.RES RMC1/16S-473JTH (47 k) B 33.4/34.5
R705 7030016110 S.RES RMC1/16S-473JTH (47 k) B 34.6/34.8
R706 7030015930 S.RES RMC1/16S-471JTH (470) B 23.1/45.6
R708 7030015980 S.RES RMC1/16S-333JTH (33 k) B 27.7/36.2
R712 7030016190 S.RES RMC1/16S-273JTH (27 k) B 21.4/44.2
R713 7030016110 S.RES RMC1/16S-473JTH (47 k) B 21.4/43.0
R715 7030015980 S.RES RMC1/16S-333JTH (33 k) T 37.9/2.5
R716 7030015970 S.RES RMC1/16S-103JTH (10 k) B 21.2/31.9
R717 7030015970 S.RES RMC1/16S-103JTH (10 k) B 20.2/40.2
R720 7030016050 S.RES RMC1/16S-102JTH (1 k) B 16.6/43.2
R721 7030016110 S.RES RMC1/16S-473JTH (47 k) B 14.5/44.1
R723 7030015970 S.RES RMC1/16S-103JTH (10 k) B 37.3/35.7
R724 7030016020 S.RES RMC1/16S-104JTH (100 k) B 37.7/34.5
R725 7030016340 S.RES RMC1/16S-393JTH (39 k) T 36.3/42.6
R726 7030015980 S.RES RMC1/16S-333JTH (33 k) T 40.9/35.4
R727 7030016350 S.RES RMC1/16S-122JTH (1.2 k) T 40.0/35.9
R728 7030016050 S.RES RMC1/16S-102JTH (1 k) T 40.0/34.3
R729 7030015910 S.RES RMC1/16S-101JTH (100) T 22.6/38.7
R731 7030016050 S.RES RMC1/16S-102JTH (1 k) B 16.5/41.5
R732 7030015970 S.RES RMC1/16S-103JTH (10 k) T 39.6/46.1
5-2b
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
(Amended page)
February 2021
The underlined parts have been updated from the previous version of the addendum, or from the original page.
[MAIN UNIT] (for IC-V86 and IC-V86-T)
R733 7030016030 S.RES RMC1/16S-154JTH (150 k) B 34.8/37.4
R734 7030016340 S.RES RMC1/16S-393JTH (39 k) T 41.3/37.2
R735 7030016050 S.RES RMC1/16S-102JTH (1 k) B 36.1/37.8
R738 7030016050 S.RES RMC1/16S-102JTH (1 k) B 13.9/40.3
R739 7030016330 S.RES RMC1/16S-153JTH (15 k) B 15.5/40.3
R740 7030016910 S.RES RGC1/16SC393DTH (39 k) T 8.7/31.7
R742 7030016330 S.RES RMC1/16S-153JTH (15 k) B 38.8/37.9
R745 7030016430 S.RES RMC1/16S-392JTH (3.9 k) B 15.5/39.4
R746 7030016830 S.RES RGC1/16SC153DTH (15.0 k) T 8.7/33.3
R750 7030016330 S.RES RMC1/16S-153JTH (15 k) B 39.5/36.3
R751 7030016020 S.RES RMC1/16S-104JTH (100 k) T 17.6/37.2
R752 7030016020 S.RES RMC1/16S-104JTH (100 k) T 16.3/38.0
R753 7030016020 S.RES RMC1/16S-104JTH (100 k) B 18.6/38.1
R759 7030015970 S.RES RMC1/16S-103JTH (10 k) B 47.1/42.1
R762 7030016810 S.RES RGC1/16SC392DTH (3.90 k) B 50.9/43.5
R763 7030017510 S.RES RGC1/16SC272DTH (2.7 k) B 52.5/43.5
R765 7030016050 S.RES RMC1/16S-102JTH (1 k) B 25.8/40.8
R767 7030016880 S.RES RGC1/16SC223DTH (22.0 k) B 50.9/44.4
R771 7030016110 S.RES RMC1/16S-473JTH (47 k) B 37.1/41.6
R773 7030016050 S.RES RMC1/16S-102JTH (1 k) B 37.1/42.5
R780 7030016110 S.RES RMC1/16S-473JTH (47 k) T 33.8/37.4
R781 7030016050 S.RES RMC1/16S-102JTH (1 k) T 35.0/37.7
R784 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 42.0/40.0
R785 7030015950 S.RES RMC1/16S-152JTH (1.5 k) B 41.5/42.4
R786 7030016410 S.RES RMC1/16S-561JTH (560) B 41.5/41.5
R787 7030016020 S.RES RMC1/16S-104JTH (100 k) B 41.1/40.0
R788 7030015970 S.RES RMC1/16S-103JTH (10 k) T 36.9/38.3
R789 7030016040 S.RES RMC1/16S-224JTH (220 k) T 37.9/37.1
R790 7030016020 S.RES RMC1/16S-104JTH (100 k) T 13.1/31.0
R791 7030016020 S.RES RMC1/16S-104JTH (100 k) T 14.0/31.0
R795 7030015980 S.RES RMC1/16S-333JTH (33 k) B 23.3/30.4
R796 7030016000 S.RES RMC1/16S-823JTH (82 k) B 21.6/30.0
R797 7030016110 S.RES RMC1/16S-473JTH (47 k) T 20.3/28.0
R798 7030016110 S.RES RMC1/16S-473JTH (47 k) T 21.9/28.0
R799 7030016060 S.RES RMC1/16S-105JTH (1 M) B 11.7/30.0
R800 7030016060 S.RES RMC1/16S-105JTH (1 M) B 11.7/29.1
R801 7030015950 S.RES RMC1/16S-152JTH (1.5 k) B 23.0/47.2
R803 7030015950 S.RES RMC1/16S-152JTH (1.5 k) B 31.1/33.5
R804 7030015990 S.RES RMC1/16S-683JTH (68 k) B 20.4/29.6
R805 7030016020 S.RES RMC1/16S-104JTH (100 k) T 17.9/30.3
R806 7030016060 S.RES RMC1/16S-105JTH (1 M) B 50.0/31.9
R807 7030016060 S.RES RMC1/16S-105JTH (1 M) B 50.9/32.6
R808 7030016110 S.RES RMC1/16S-473JTH (47 k) B 34.3/32.6
R809 7030015910 S.RES RMC1/16S-101JTH (100) T 19.2/32.2
R810 7030016020 S.RES RMC1/16S-104JTH (100 k) T 17.9/32.2
R811 7030016060 S.RES RMC1/16S-105JTH (1 M) B 18.4/44.3
R812 7030016060 S.RES RMC1/16S-105JTH (1 M) B 19.3/42.8
C4 4030022140 S.CER GRM033B31H102KA12D B 28.6/30.1
C19 4030022140 S.CER GRM033B31H102KA12D B 37.8/32.1
C20 4030022100 S.CER GRM0332C1H100JA01D B 32.8/26.4
C22 4030022140 S.CER GRM033B31H102KA12D B 50.2/19.5
C23 4030022160 S.CER GRM033B31A104KE84D B 35.7/27.1
C24 4030022160 S.CER GRM033B31A104KE84D B 50.8/19.5
C25 4030022260 S.CER GRM033R60J105MEA2D T 42.3/8.9
C26 4030022160 S.CER GRM033B31A104KE84D B 38.5/30.1
C28 4030022160 S.CER GRM033B31A104KE84D B 47.0/12.0
C29 4030022140 S.CER GRM033B31H102KA12D B 47.0/12.6
C32 4030022160 S.CER GRM033B31A104KE84D B 47.9/12.3
C33 4030022160 S.CER GRM033B31A104KE84D B 45.1/12.8
C35 4030022140 S.CER GRM033B31H102KA12D B 45.1/12.2
C36 4030022260 S.CER GRM033R60J105MEA2D B 39.3/26.7
C37 4550007520 S.TAN F931A106MAABMA B 44.6/8.9
Eqv. 4550009370 S.TAN 267E1002106MR533
C38 4030022090 S.CER GRM0332C1H330JA01D B 39.9/7.9
C42 4030022140 S.CER GRM033B31H102KA12D B 36.0/8.0
C45 4030022140 S.CER GRM033B31H102KA12D B 36.0/8.6
C46 4030022080 S.CER GRM0332C1H101JA01D B 37.9/9.9
C47 4030022140 S.CER GRM033B31H102KA12D B 39.5/11.1
C49 4030022140 S.CER GRM033B31H102KA12D B 36.6/22.5
C52 4030022120 S.CER GRM0332C1H470JA01D B 39.8/20.2
C53 4030022140 S.CER GRM033B31H102KA12D B 34.3/11.8
C54 4030022140 S.CER GRM033B31H102KA12D B 36.6/20.9
C57 4030026690 S.CER RF15N100G500CT B 34.2/14.8
C58 4030023090 S.CER 0402B102K500CT B 26.1/17.5
C59 4030022920 S.CER 0402N820J500CT B 33.5/13.5
C62 4030022740 S.CER 0402N220J500CT B 20.9/24.2
C64 4030022140 S.CER GRM033B31H102KA12D B 31.1/8.9
C65 4030023450 S.CER 0603N100D500CT B 22.9/10.9
C67 4030023700 S.CER 0603N390J500CT B 24.1/10.9
C68 4030022640 S.CER 0402N101J500CT B 19.1/26.4
C69 4030023500 S.CER 0603N150J500CT B 2 0 .9 / 7. 5
C71 4030022160 S.CER GRM033B31A104KE84D B 16.1/27.9
C73 4030023090 S.CER 0402B102K500CT B 18.8/13.6
C75 4030026740 S.CER RF15N5R0B500CT B 16.8/23.8
C76 4030023520 S.CER 0603N180J500CT B 20.9/8.7
C79 4030022140 S.CER GRM033B31H102KA12D T 22.2/18.1
C81 4030026590 S.CER RF15N180J500CT B 18.8/12.7
C82 4030022640 S.CER 0402N101J500CT B 14.0/26.5
C84 4030023090 S.CER 0402B102K500CT B 14.9/16.8
C86 4030026570 S.CER RF15N120J500CT B 12.8/20.9
C88 4030026700 S.CER RF15N1R0B500CT B 12.4/16.8
C89 4030026590 S.CER RF15N180J500CT B 15.2/18.0
C90 4030026690 S.CER RF15N100G500CT B 15.4/24.1
C92 4030026710 S.CER RF15N2R0B500CT B 10.4/20.9
C93 4030026590 S.CER RF15N180J500CT B 15 .1/19. 3
C94 4030026750 S.CER RF15N7R0C500CT B 9.4/18.4
C95 4030022740 S.CER 0402N220J500CT B 9.4/20.0
C101 4030022740 S.CER 0402N220J500CT B 7.5/15.8
C109 4030022260 S.CER GRM033R60J105MEA2D B 63.6/8.5
C110 4030022260 S.CER GRM033R60J105MEA2D B 64.4/8.5
C113 4030022140 S.CER GRM033B31H102KA12D B 61.2/12.8
C114 4030025320 S.CER GRM0332C1H151JA01D B 61.2/14.0
C115 4030022160 S.CER GRM033B31A104KE84D B 42.6/17.1
C116 4030022140 S.CER GRM033B31H102KA12D B 42.6/16.5
C117 4030022160 S.CER GRM033B31A104KE84D B 52.3/16.3
C118 4030022140 S.CER GRM033B31H102KA12D B 52.3/16.9
C120 4030026710 S.CER RF15N2R0B500CT B 43.5/14.8
C122 4030026710 S.CER RF15N2R0B500CT B 46.0/12.0
C124 4030026710 S.CER RF15N2R0B500CT T 40.7/16.2
C125 4030026690 S.CER RF15N100G500CT B 7.5/14. 9
C126 4030026740 S.CER RF15N5R0B500CT B 7.4 /12 .1
C405 4030022160 S.CER GRM033B31A104KE84D B 71.8/19.6
C408 4030025440 S.CER GRM0332C1E271JA01D B 70.7/17.6
C409 4030022160 S.CER GRM033B31A104KE84D B 70.7/16.6
C410 4030022160 S.CER GRM033B31A104KE84D B 71.8/20.2
C411 4030022160 S.CER GRM033B31A104KE84D B 71.0/22.5
C412 4030022160 S.CER GRM033B31A104KE84D B 71.0/23.2
C413 4030025350 S.CER GRM0332C1H120JA01D B 80.3/7.8
C414 4030022160 S.CER GRM033B31A104KE84D B 70.4/15.1
C415 4030022160 S.CER GRM033B31A104KE84D B 71.0/26.5
C416 4030025350 S.CER GRM0332C1H120JA01D B 81.7/9.5
C417 4030022260 S.CER GRM033R60J105MEA2D B 76.8/9.7
C418 4030022160 S.CER GRM033B31A104KE84D B 76.8/10.3
C420 4030022260 S.CER GRM033R60J105MEA2D B 77.3/10.9
C421 4030022160 S.CER GRM033B31A104KE84D B 77.3/11.5
C425 4030025400 S.CER GRM033R61A273KE84D B 77.1/8.7
C426 4030022160 S.CER GRM033B31A104KE84D B 87.6/29.1
C427 4030022260 S.CER GRM033R60J105MEA2D B 84.8/11.1
C428 4030022160 S.CER GRM033B31A104KE84D B 90.1/14.0
C429 4550007520 S.TAN F931A106MAABMA B 80.5/36.5
Eqv. 4550009370 S.TAN 267E1002106MR533
C430 4030022140 S.CER GRM033B31H102KA12D B 64.6/20.2
C437 4030022140 S.CER GRM033B31H102KA12D B 83.3/11.1
C446 4030022140 S.CER GRM033B31H102KA12D B 84.0/11.1
C451 4030022120 S.CER GRM0332C1H470JA01D B 62.6/17.3
C452 4030022120 S.CER GRM0332C1H470JA01D B 62.0/18.0
C453 4030022120 S.CER GRM0332C1H470JA01D B 71.8/24.5
C454 4030022120 S.CER GRM0332C1H470JA01D B 64.0/15.9
C455 4030022120 S.CER GRM0332C1H470JA01D B 65.0/15.9
C456 4030022120 S.CER GRM0332C1H470JA01D B 87.8/13.1
C457 4030022120 S.CER GRM0332C1H470JA01D B 65.9/17.0
C458 4030022120 S.CER GRM0332C1H470JA01D B 70.2/20.3
C459 4030022120 S.CER GRM0332C1H470JA01D B 64.5/24.1
C460 4030022120 S.CER GRM0332C1H470JA01D B 65.4/24.2
C461 4030022120 S.CER GRM0332C1H470JA01D B 70.0/22.3
C462 4030022120 S.CER GRM0332C1H470JA01D B 69.4/23.4
C463 4030022120 S.CER GRM0332C1H470JA01D B 70.8/24.4
C464 4030022120 S.CER GRM0332C1H470JA01D B 70.2/25.0
C465 4030022120 S.CER GRM0332C1H470JA01D B 72.0/25.8
C466 4030022120 S.CER GRM0332C1H470JA01D B 74.7/29.5
C467 4030022120 S.CER GRM0332C1H470JA01D B 74.6/33.1
C468 4030022120 S.CER GRM0332C1H470JA01D B 60.3/35.3
C469 4030022120 S.CER GRM0332C1H470JA01D B 61.3/35.5
C470 4030022120 S.CER GRM0332C1H470JA01D B 62.2/35.5
C471 4030022120 S.CER GRM0332C1H470JA01D B 63.2/35.5
C472 4030022120 S.CER GRM0332C1H470JA01D B 69.0/35.3
C473 4030022120 S.CER GRM0332C1H470JA01D B 62.7/37.2
C474 4030022120 S.CER GRM0332C1H470JA01D B 62.0/37.8
C475 4030022120 S.CER GRM0332C1H470JA01D B 77.4/36.4
C477 4030022120 S.CER GRM0332C1H470JA01D B 85.5/33.7
C700 4030022260 S.CER GRM033R60J105MEA2D B 24.5/47.1
C702 4030022960 S.CER 0402B333K100CT B 32.0/32.5
C703 4030022260 S.CER GRM033R60J105MEA2D B 32.3/33.7
C707 4030022260 S.CER GRM033R60J105MEA2D B 34.5/34.0
C708 4030023190 S.CER 0402B392K500CT B 26.8/36.2
C710 4030022160 S.CER GRM033B31A104KE84D B 22.2/43.2
C711 4030022260 S.CER GRM033R60J105MEA2D B 26.4/34.8
C724 4030022260 S.CER GRM033R60J105MEA2D T 39.0/2.3
C726 4030022160 S.CER GRM033B31A104KE84D B 20.3/44.2
C731 4030022260 S.CER GRM033R60J105MEA2D B 36.9/34.4
C734 4030022160 S.CER GRM033B31A104KE84D T 38.8/46.0
C735 4030022260 S.CER GRM033R60J105MEA2D B 13.7/43.9
C738 4030022260 S.CER GRM033R60J105MEA2D T 40.4/46.0
C740 4030022260 S.CER GRM033R60J105MEA2D B 34.9/36.2
C741 4030025440 S.CER GRM0332C1E271JA01D T 41.2/36.4
C742 4030022150 S.CER GRM033B31E103KA12D B 14.1/39.5
C744 4030022950 S.CER 0402B273K100CT B 23.3/32.0
C745 4030022260 S.CER GRM033R60J105MEA2D T 39.2/37.3
C747 4030022260 S.CER GRM033R60J105MEA2D T 42.4/37.5
C748 4030022260 S.CER GRM033R60J105MEA2D B 37.5/37.8
C749 4030022260 S.CER GRM033R60J105MEA2D T 18.4/36.6
C750 4030022160 S.CER GRM033B31A104KE84D B 38.7/37.1
C752 4030022160 S.CER GRM033B31A104KE84D B 38.4/36.0
C753 4030022160 S.CER GRM033B31A104KE84D T 17.3/35.6
C755 4030022160 S.CER GRM033B31A104KE84D B 16.8/38.0
C756 4030022160 S.CER GRM033B31A104KE84D B 47.0/41.3
C759 4550008220 S.TAN F931C106MAA B 10.2/44.8
Eqv. 4550009180 S.TAN 267E1602106MR533
C760 4030025550 S.CER CL21A226MAQNNPE B 48.8/41.0
C767 4520000020 S.NIO NOJC227M006RWJV T 28.5/35.2
C768 4030022260 S.CER GRM033R60J105MEA2D T 7.4/26.9
C769 4030022160 S.CER GRM033B31A104KE84D B 50.1/38.7
C772 4030022140 S.CER GRM033B31H102KA12D B 27.2/40.9
C774 4030022120 S.CER GRM0332C1H470JA01D B 26.6/40.9
C777 4030025550 S.CER CL21A226MAQNNPE B 54.8/41.1
C784 4030025440 S.CER GRM0332C1E271JA01D B 38.5/45.7
C792 4030025230 S.CER TMK107BJ105KAHT T 7.0/31.4
Eqv. 4030025510 S.CER CL10B105KA8NNPC
C793 4030025230 S.CER TMK107BJ105KAHT B 45.6/42.1
Eqv. 4030025510 S.CER CL10B105KA8NNPC
C794 4030025230 S.CER TMK107BJ105KAHT T 9.9/27.3
Eqv. 4030025510 S.CER CL10B105KA8NNPC
5-3b
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
(Amended page)
February 2021
The underlined parts have been updated from the previous version of the addendum, or from the original page.
[MAIN UNIT] (for IC-V86 and IC-V86-T)
C798 4030022260 S.CER GRM033R60J105MEA2D B 40.3/40.2
C799 4030022260 S.CER GRM033R60J105MEA2D T 39.0/35.7
C800 4030022160 S.CER GRM033B31A104KE84D B 32.2/7.1
C802 4030022260 S.CER GRM033R60J105MEA2D T 18.4/31.3
C803 4030025320 S.CER GRM0332C1H151JA01D B 20.2/30.5
C804 4030022260 S.CER GRM033R60J105MEA2D T 21.9/29.3
C805 4030025370 S.CER GRM033R61C104KE14D B 12.0/31.3
C806 4030025320 S.CER GRM0332C1H151JA01D T 37.7/36.3
C807 4030022260 S.CER GRM033R60J105MEA2D T 39.0/35.1
C808 4030022260 S.CER GRM033R60J105MEA2D T 41.2/46.0
C809 4030022260 S.CER GRM033R60J105MEA2D T 39.0/36.3
C810 4030022260 S.CER GRM033R60J105MEA2D B 22.1/47.5
C811 4550007520 S.TAN F931A106MAABMA B 25.1/43.8
Eqv. 4550009370 S.TAN 267E1002106MR533
C812 4030022260 S.CER GRM033R60J105MEA2D B 21.5/47.5
C813 4030023110 S.CER 0402B152K500CT B 22.5/29.1
C814 4030022260 S.CER GRM033R60J105MEA2D B 50.9/31.1
C815 4030022160 S.CER GRM033B31A104KE84D B 33.2/32.9
C817 4030022260 S.CER GRM033R60J105MEA2D T 18.4/33.2
C818 4030022260 S.CER GRM033R60J105MEA2D T 17.8/31.3
C819 4030022260 S.CER GRM033R60J105MEA2D T 17.8/33.2
C820 4030022160 S.CER GRM033B31A104KE84D B 16.8/44.3
J700 6450000131 CON HSJ1102-018540
J701 6450002530 CON HSJ4456-010320
DS400 5030004550 LCD GP11538A6
DS401 5040003500 S.LED HT-191 UYG-K828 T 52.8/4.6
DS402 5040003500 S.LED HT-191 UYG-K828 T 48.3/4.6
MC700 7700003280 S.MIC SPU0410HR5H-PB-7 T 36.6/6.6
S400 2250001090 ENC ED08902OFK150S070C-2015
Eqv. 7600000210 ENC TP70N00E20-15F-1903 [#13]
S401 2260003490 S.SWI TAFG-12W-QR B 17.4/1.9
EP1 8930101610 LCD SRCN-4066-SP-N-W (SHJ)
EP3 6910018460 S.BEA MMZ1005Y102C-T B 33.3/9.5
EP4 6910014690 S.BEA MPZ1608S221A-T B 24.5/20.0
EP400 6910021240 S.BEA MMZ1005A152ET B 78.9/38.3
EP700 6910018460 S.BEA MMZ1005Y102C-T B 24.0/45.6
EP701 6910018460 S.BEA MMZ1005Y102C-T B 18.7/45.5
EP702 6910019900 S.BEA MPZ1608S601AT B 26.6/42.1
EP703 6910016330 S.BEA MMZ1005S 601CT-S B 38.3/42.0
EP704 6910018460 S.BEA MMZ1005Y102C-T B 37.0/45.7
5-4b
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
February 2021
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
[MAIN-A UNIT] (for IC-G86)
IC1 1110007010 S.IC NJM12904R-TE1 B 34.7/29.4
IC3 1110010000 S.IC AT1846S B 47.4/16.1
IC400 1130019660 S.IC BR24G128NUX-5TR B 92.2/14.0
IC402 1140018490 S.IC STM32L073VBT6 B 81.0/20.5
IC403 1110007780 S.IC NJU7704F3-28A-TE1 B 75.4/8.2
IC701 1110007630 S.IC NJM2783V-TE1 T 39.6/41.5
IC702 1110010010 S.IC U2429G-S08-R B 23.1/36.7
IC706 1110008450 S.IC ISD8102SYI T&R T 22.5/35.4
IC707 6910027810 S.DC TPS561201DDCR B 51.4/41.1
IC817 1110010140 S.IC TLV9002IDGKR B 31.2/36.7
IC818 1180004950 S.REG XC6701B502MR-G T 7.4/29.0
IC819 1110008890 S.IC NJU7056F3-TE2 T 20.2/29.7
IC820 1130007021 S.IC TC7S66FU(TE85LF) B 52.8/32.2
Q2 1590005410 S.TRA DTC014YEBTL B 42.2/31.7
Q4 1590005560 S.TRA DTA014EEBTL B 40.2/31.3
Q6 1530003322 S.TRA 2SC5108-YLF B 37.6/8.0
Q7 1560002420 S.FET RD01MUS2B-T513 B 37.2/15.8
Q8 1530003322 S.TRA 2SC5108-YLF B 38.4/21.4
Q9 1560002460 S.FET RD08MUS2-T512 B 29.6/13.4
Q10 1560002190 S.FET RUM002N02T2L B 39.2/28.0
Q12 1590005410 S.TRA DTC014YEBTL B 27.7/33.8
Q400 1530002851 S.TRA 2SC4116-BL(TE85RF) B 64.2/3.5
Q401 1590005430 S.TRA DTC044TEBTL B 90.2/32.4
Q703 1590004220 S.TRA DRA9123Y0L B 21.6/45.8
Q704 1590005410 S.TRA DTC014YEBTL T 41.5/5.3
Q705 1590005410 S.TRA DTC014YEBTL B 18.1/41.0
Q706 1590004590 S.TRA DMC506010R B 14.5/42.1
Q707 1520001010 S.TRA 2SB1132G-R-AB3-R B 10.1/41.3
Q711 1590005410 S.TRA DTC014YEBTL B 17.2/39.4
Q712 1590005410 S.TRA DTC014YEBTL B 73.1/38.1
Q716 1590005410 S.TRA DTC014YEBTL B 37.4/44.0
Q717 1510001270 S.TRA 2SAR502UBTL B 37.3/39.7
Q718 1590005410 S.TRA DTC014YEBTL T 35.5/36.2
Q720 1510001270 S.TRA 2SAR502UBTL T 31.9/37.1
Q721 1590004230 S.TRA LMUN5213DW1T1G B 40.2/44.1
Q722 1550000590 S.FET UT6401G-AG6-R T 10.9/30.4
Q723 1560002190 S.FET RUM002N02T2L B 13.2/31.4
Q724 1560002190 S.FET RUM002N02T2L T 20.5/31.8
Q725 1560002190 S.FET RUM002N02T2L B 17.9/42.9
D2 1750001810 S.DIO L1SS400T1G B 40.4/25.8
D3 1790001830 S.VAR AVR-M1005C270MTAAB B 25.5/20.1
D4 1720000701 S.VAR 1SV305(TPH3F) B 18.1/24.6
D5 1720000701 S.VAR 1SV305(TPH3F) B 16.3/25.4
D6 1750003940 S.DIO RN142SMT2R B 17.5/14.6
D7 1750003940 S.DIO RN142SMT2R B 15.7/20.4
D8 1750003940 S.DIO RN142SMT2R B 15.7/21.6
D9 1750003830 S.DIO RB751CM-40T2R B 15.0/22.8
D12 1750001810 S.DIO L1SS400T1G B 74.4/5.4
D13 1750003940 S.DIO RN142SMT2R B 17.5/15.8
D403 1750001810 S.DIO L1SS400T1G B 94.7/23.3
D404 1750001810 S.DIO L1SS400T1G B 94.7/26.9
D408 1750001810 S.DIO L1SS400T1G B 94.7/29.3
D409 1750001810 S.DIO L1SS400T1G B 92.2/26.9
D410 1750001810 S.DIO L1SS400T1G B 92.2/24.5
D411 1750001810 S.DIO L1SS400T1G B 92.2/22.4
D413 1750001820 S.DIO LRB706F-40T1G B 92.8/31.9
D700 1750003390 S.ZEN RCLAMP1521P.TCT T 8.4/34.9
D705 1750001810 S.DIO L1SS400T1G B 36.6/36.8
D706 1750001810 S.DIO L1SS400T1G B 35.9/34.9
D708 1750001810 S.DIO L1SS400T1G T 16.6/39.1
D711 1750003830 S.DIO RB751CM-40T2R B 73.4/40.2
D714 1750003830 S.DIO RB751CM-40T2R B 72.0/39.7
D717 1750001810 S.DIO L1SS400T1G B 10.5/31.0
D719 1750001810 S.DIO L1SS400T1G B 16.0/45.2
X2 6050014880 S.XTA CR-1079 (13 MHz) B 61.9/8.9
X400 6050014200 S.XTA CR-1021 (12.288 MHz) B 82.5/7.3
L3 6200013820 S.COI MLK1005S27NJT B 36.7/9.5
L4 6200013830 S.COI MLK1005S22NJT B 33.3/12.3
L5 6200017370 S.COI SDWL1608CR10GSTF 0.1U B 38.8/23.3
L6 6200012540 S.COI 0.30-1.2-5TR 16.1N B 24.1/15.8
L7 6200013010 S.COI 0.30-0.9-5TL 10.3N B 23.8/13.3
L8 6200017390 S.COI SDWL1608C47NJSTF 47N B 19.6/24.6
L9 6200012390 S.COI 0.30-0.92-3TR 5.8N B 21.3/13.2
L10 6200012470 S.COI 0.30-1.7-7TL 45.3N B 20.5/10.8
L11 6200017560 S.COI NLV25T-R82J-EF T 20.8/16.5
L12 6200017390 S.COI SDWL1608C47NJSTF 47N B 13.7/24.2
L13 6200013820 S.COI MLK1005S27NJT B 21.8/24.2
L15 6200012470 S.COI 0.30-1.7-7TL 45.3N B 11.6/18.7
L16 6200012470 S.COI 0.30-1.7-7TL 45.3N B 17.3/18.1
L17 6200012760 S.COI 0.35-1.6-7TL 37.5N B 7.5/18.2
L18 6200012780 S.COI 0.30-1.4-6TL 27.2N B 9.2/13.7
L19 6200003640 S.COI MLF1608E 100K-T B 43.4/10.6
L22 6200003960 S.COI MLF1608A 1R0K-T B 62.0/11.6
L702 6200017010 S.COI VLS252012CX-100M-1 B 52.2/38.2
L705 6200017010 S.COI VLS252012CX-100M-1 B 46.4/39.7
R1 7510001730 S.THE ERTJ0EP 473J T 22.0/6.6
R2 7030014860 S.RES RGC1/16SC104DTH (100 k) T 21.6/5.3
R4 7030021060 S.RES MCR25JZHFL R150 (0.15) B 29.4/26.9
R8 7030015520 S.RES RMC1/16JPTP B 65.4/9.2
R10 7030016550 S.RES RMC1/16SK154FTH (150 k) B 31.5/26.4
R11 7030016560 S.RES RMC1/16SJPTH B 61.5/10.5
R12 7030016550 S.RES RMC1/16SK154FTH (150 k) B 29.8/30.1
R13 7030017370 S.RES RGC1/16SC183DTH (18 k) B 31.5/28.0
R14 7030015980 S.RES RMC1/16S-333JTH (33 k) B 38.7/31.5
R16 7030016030 S.RES RMC1/16S-154JTH (150 k) B 36.7/31.8
R17 7030015990 S.RES RMC1/16S-683JTH (68 k) B 36.7/32.7
R18 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 76.5/4.4
R19 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 76.5/5.4
R20 7030016740 S.RES RMC1/16SK474DTH (470 k) B 31.6/30.1
R21 7030016740 S.RES RMC1/16SK474DTH (470 k) B 33.0/27.2
R23 7030016360 S.RES RMC1/16S-123JTH (12 k) B 33.0/25.6
R24 7030015900 S.RES RMC1/16S-470JTH (47) B 52.9/17.9
R26 7030016030 S.RES RMC1/16S-154JTH (150 k) B 37.7/30.0
R27 7030016050 S.RES RMC1/16S-102JTH (1 k) B 50.9/14.6
R28 7030017370 S.RES RGC1/16SC183DTH (18 k) B 30.7/30.1
R30 7030016050 S.RES RMC1/16S-102JTH (1 k) B 37.7/28.4
R32 7030016120 S.RES RMC1/16S-682JTH (6.8 k) B 40.9/27.7
R33 7030016110 S.RES RMC1/16S-473JTH (47 k) B 43.2/18.0
R36 7030015910 S.RES RMC1/16S-101JTH (100) B 39.5/9.1
R37 7030016120 S.RES RMC1/16S-682JTH (6.8 k) B 39.0/7.9
R38 7030016150 S.RES RMC1/16S-100JTH (10) B 35.8/7.2
R41 7030016180 S.RES RMC1/16S-680JTH (68) B 38.1/11.1
R42 7030016510 S.RES RMC1/16S-4R7JTH (4.7) B 38.2/12.3
R44 7030016190 S.RES RMC1/16S-273JTH (27 k) B 39.5/11.9
R45 7030016250 S.RES RMC1/16S-220JTH (22) B 38.5/24.6
R46 7030015920 S.RES RMC1/16S-221JTH (220) B 36.7/23.3
R47 7030015910 S.RES RMC1/16S-101JTH (100) B 36.4/21.7
R48 7030016090 S.RES RMC1/16S-223JTH (22 k) B 39.5/12.8
R49 7030016390 S.RES RMC1/16S-184JTH (180 k) B 37.8/19.9
R50 7030016390 S.RES RMC1/16S-184JTH (180 k) B 36.2/19.9
R51 7030016250 S.RES RMC1/16S-220JTH (22) B 32.1/9.3
R52 7030016300 S.RES RMC1/16S-332JTH (3.3 k) B 30.9/7.2
R53 7030016000 S.RES RMC1/16S-823JTH (82 k) B 30.9/8.1
R55 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 17.5/26.4
R56 7030016050 S.RES RMC1/16S-102JTH (1 k) B 17.1/27.6
R57 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 15.9/26.4
R58 7030016370 S.RES RMC1/16S-271JTH (270) T 21.9/19.2
R59 7030016370 S.RES RMC1/16S-271JTH (270) T 21.0/19.2
R60 7030015990 S.RES RMC1/16S-683JTH (68 k) T 14.6/9.0
R67 7030016110 S.RES RMC1/16S-473JTH (47 k) B 40.1/29.4
R400 7030016290 S.RES RMC1/16S-222JTH (2.2 k) B 64.6/5.3
R401 7030016440 S.RES RMC1/16S-272JTH (2.7 k) B 66.5/4.9
R402 7030016110 S.RES RMC1/16S-473JTH (47 k) B 92.7/19.8
R403 7030016110 S.RES RMC1/16S-473JTH (47 k) B 92.2/18.6
R404 7030016050 S.RES RMC1/16S-102JTH (1 k) B 92.1/28.0
R405 7030016050 S.RES RMC1/16S-102JTH (1 k) B 91.9/25.7
R406 7030016050 S.RES RMC1/16S-102JTH (1 k) B 92.6/23.5
R407 7030016050 S.RES RMC1/16S-102JTH (1 k) B 92.5/21.4
R409 7030015970 S.RES RMC1/16S-103JTH (10 k) B 90.1/15.8
R410 7030015970 S.RES RMC1/16S-103JTH (10 k) B 72.0/12.3
R411 7030015970 S.RES RMC1/16S-103JTH (10 k) B 72.0/13.3
R412 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 91.5/17.4
R413 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 92.4/17.4
R416 7030015900 S.RES RMC1/16S-470JTH (47) B 79.1/10.0
R417 7030015900 S.RES RMC1/16S-470JTH (47) B 78.2/10.0
R421 7030016060 S.RES RMC1/16S-105JTH (1 M) B 81.3/10.5
R425 7030016110 S.RES RMC1/16S-473JTH (47 k) B 89.4/9.6
R426 7030016330 S.RES RMC1/16S-153JTH (15 k) B 90.8/30.8
R427 7030016830 S.RES RGC1/16SC153DTH (15.0 k) B 92.3/30.0
R428 7030016560 S.RES RMC1/16SJPTH B 69.6/17.9
R429 7030015970 S.RES RMC1/16S-103JTH (10 k) B 73.5/7.9
R430 7030016180 S.RES RMC1/16S-680JTH (68) B 66.0/3.3
R702 7030016500 S.RES RMC1/16S-562JTH (5.6 k) B 29.9/33.9
R703 7030016000 S.RES RMC1/16S-823JTH (82 k) B 31.1/34.4
R704 7030016110 S.RES RMC1/16S-473JTH (47 k) B 33.4/34.5
R705 7030016110 S.RES RMC1/16S-473JTH (47 k) B 34.6/34.8
R706 7030015930 S.RES RMC1/16S-471JTH (470) B 23.1/45.6
R708 7030015980 S.RES RMC1/16S-333JTH (33 k) B 27.7/36.2
R712 7030016190 S.RES RMC1/16S-273JTH (27 k) B 21.4/44.2
R713 7030016110 S.RES RMC1/16S-473JTH (47 k) B 21.4/43.0
R715 7030015980 S.RES RMC1/16S-333JTH (33 k) T 37.9/2.5
R716 7030015970 S.RES RMC1/16S-103JTH (10 k) B 21.2/31.9
R717 7030015970 S.RES RMC1/16S-103JTH (10 k) B 20.2/40.2
R720 7030016050 S.RES RMC1/16S-102JTH (1 k) B 16.6/43.2
R721 7030016110 S.RES RMC1/16S-473JTH (47 k) B 14.5/44.1
R723 7030015970 S.RES RMC1/16S-103JTH (10 k) B 37.3/35.7
R724 7030016020 S.RES RMC1/16S-104JTH (100 k) B 37.7/34.5
R725 7030016340 S.RES RMC1/16S-393JTH (39 k) T 36.3/42.6
R726 7030015980 S.RES RMC1/16S-333JTH (33 k) T 40.9/35.4
R727 7030016350 S.RES RMC1/16S-122JTH (1.2 k) T 40.0/35.9
R728 7030016050 S.RES RMC1/16S-102JTH (1 k) T 40.0/34.3
R729 7030015910 S.RES RMC1/16S-101JTH (100) T 22.6/38.7
R731 7030016050 S.RES RMC1/16S-102JTH (1 k) B 16.5/41.5
R732 7030015970 S.RES RMC1/16S-103JTH (10 k) T 39.6/46.1
R733 7030016030 S.RES RMC1/16S-154JTH (150 k) B 34.8/37.4
R734 7030016340 S.RES RMC1/16S-393JTH (39 k) T 41.3/37.2
R735 7030016050 S.RES RMC1/16S-102JTH (1 k) B 36.1/37.8
R738 7030016050 S.RES RMC1/16S-102JTH (1 k) B 13.9/40.3
R739 7030016330 S.RES RMC1/16S-153JTH (15 k) B 15.5/40.3
R740 7030016910 S.RES RGC1/16SC393DTH (39 k) T 8.7/31.7
R742 7030016330 S.RES RMC1/16S-153JTH (15 k) B 38.8/37.9
R745 7030016430 S.RES RMC1/16S-392JTH (3.9 k) B 15.5/39.4
R746 7030016830 S.RES RGC1/16SC153DTH (15.0 k) T 8.7/33.3
R750 7030016330 S.RES RMC1/16S-153JTH (15 k) B 39.5/36.3
R751 7030016020 S.RES RMC1/16S-104JTH (100 k) T 17.6/37.2
R752 7030016020 S.RES RMC1/16S-104JTH (100 k) T 16.3/38.0
R753 7030016020 S.RES RMC1/16S-104JTH (100 k) B 18.6/38.1
R759 7030015970 S.RES RMC1/16S-103JTH (10 k) B 47.1/42.1
R762 7030016810 S.RES RGC1/16SC392DTH (3.90 k) B 50.9/43.5
R763 7030017510 S.RES RGC1/16SC272DTH (2.7 k) B 52.5/43.5
R765 7030016050 S.RES RMC1/16S-102JTH (1 k) B 25.8/40.8
R767 7030016880 S.RES RGC1/16SC223DTH (22.0 k) B 50.9/44.4
R771 7030016110 S.RES RMC1/16S-473JTH (47 k) B 37.1/41.6
R773 7030016050 S.RES RMC1/16S-102JTH (1 k) B 37.1/42.5
5-5b
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
February 2021
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
[MAIN-A UNIT] (for IC-G86)
R780 7030016110 S.RES RMC1/16S-473JTH (47 k) T 33.8/37.4
R781 7030016050 S.RES RMC1/16S-102JTH (1 k) T 35.0/37.7
R784 7030015960 S.RES RMC1/16S-472JTH (4.7 k) B 42.0/40.0
R785 7030015950 S.RES RMC1/16S-152JTH (1.5 k) B 41.5/42.4
R786 7030016410 S.RES RMC1/16S-561JTH (560) B 41.5/41.5
R787 7030016020 S.RES RMC1/16S-104JTH (100 k) B 41.1/40.0
R788 7030015970 S.RES RMC1/16S-103JTH (10 k) T 36.9/38.3
R789 7030016040 S.RES RMC1/16S-224JTH (220 k) T 37.9/37.1
R790 7030016020 S.RES RMC1/16S-104JTH (100 k) T 13.1/31.0
R791 7030016020 S.RES RMC1/16S-104JTH (100 k) T 14.0/31.0
R795 7030015980 S.RES RMC1/16S-333JTH (33 k) B 23.3/30.4
R796 7030016000 S.RES RMC1/16S-823JTH (82 k) B 21.6/30.0
R797 7030016110 S.RES RMC1/16S-473JTH (47 k) T 20.3/28.0
R798 7030016110 S.RES RMC1/16S-473JTH (47 k) T 21.9/28.0
R799 7030016060 S.RES RMC1/16S-105JTH (1 M) B 11.7/30.0
R800 7030016060 S.RES RMC1/16S-105JTH (1 M) B 11.7/29.1
R801 7030015950 S.RES RMC1/16S-152JTH (1.5 k) B 23.0/47.2
R803 7030015950 S.RES RMC1/16S-152JTH (1.5 k) B 31.1/33.5
R804 7030015990 S.RES RMC1/16S-683JTH (68 k) B 20.4/29.6
R805 7030016020 S.RES RMC1/16S-104JTH (100 k) T 17.9/30.3
R806 7030016060 S.RES RMC1/16S-105JTH (1 M) B 50.0/31.9
R807 7030016060 S.RES RMC1/16S-105JTH (1 M) B 50.9/32.6
R808 7030016110 S.RES RMC1/16S-473JTH (47 k) B 34.3/32.6
R809 7030015910 S.RES RMC1/16S-101JTH (100) T 19.2/32.2
R810 7030016020 S.RES RMC1/16S-104JTH (100 k) T 17.9/32.2
R811 7030016060 S.RES RMC1/16S-105JTH (1 M) B 18.4/44.3
R812 7030016060 S.RES RMC1/16S-105JTH (1 M) B 19.3/42.8
C4 4030022140 S.CER GRM033B31H102KA12D B 28.6/30.1
C19 4030022140 S.CER GRM033B31H102KA12D B 37.8/32.1
C20 4030022100 S.CER GRM0332C1H100JA01D B 32.8/26.4
C22 4030022140 S.CER GRM033B31H102KA12D B 50.2/19.5
C23 4030022160 S.CER GRM033B31A104KE84D B 35.7/27.1
C24 4030022160 S.CER GRM033B31A104KE84D B 50.8/19.5
C25 4030022260 S.CER GRM033R60J105MEA2D T 42.3/8.9
C26 4030022160 S.CER GRM033B31A104KE84D B 38.5/30.1
C28 4030022160 S.CER GRM033B31A104KE84D B 47.0/12.0
C29 4030022140 S.CER GRM033B31H102KA12D B 47.0/12.6
C32 4030022160 S.CER GRM033B31A104KE84D B 47.9/12.3
C33 4030022160 S.CER GRM033B31A104KE84D B 45.1/12.8
C35 4030022140 S.CER GRM033B31H102KA12D B 45.1/12.2
C36 4030022260 S.CER GRM033R60J105MEA2D B 39.3/26.7
C37 4550007520 S.TAN F931A106MAABMA B 44.6/8.9
Eqv. 4550009370 S.TAN 267E1002106MR533
C38 4030022090 S.CER GRM0332C1H330JA01D B 39.9/7.9
C42 4030022140 S.CER GRM033B31H102KA12D B 36.0/8.0
C45 4030022140 S.CER GRM033B31H102KA12D B 36.0/8.6
C46 4030022080 S.CER GRM0332C1H101JA01D B 37.9/9.9
C47 4030022140 S.CER GRM033B31H102KA12D B 39.5/11.1
C49 4030022140 S.CER GRM033B31H102KA12D B 36.6/22.5
C52 4030022120 S.CER GRM0332C1H470JA01D B 39.8/20.2
C53 4030022140 S.CER GRM033B31H102KA12D B 34.3/11.8
C54 4030022140 S.CER GRM033B31H102KA12D B 36.6/20.9
C57 4030022630 S.CER 0402N100C500CT B 34.2/14.8
C58 4030023090 S.CER 0402B102K500CT B 26.1/17.5
C59 4030022920 S.CER 0402N820J500CT B 33.5/13.5
C62 4030022740 S.CER 0402N220J500CT B 20.9/24.2
C64 4030022140 S.CER GRM033B31H102KA12D B 31.1/8.9
C65 4030023450 S.CER 0603N100D500CT B 22.9/10.9
C67 4030023700 S.CER 0603N390J500CT B 24.1/10.9
C68 4030022640 S.CER 0402N101J500CT B 19.1/26.4
C69 4030023500 S.CER 0603N150J500CT B 20.9/7.5
C71 4030022160 S.CER GRM033B31A104KE84D B 16.1/27.9
C73 4030023090 S.CER 0402B102K500CT B 18.8/13.6
C75 4030022560 S.CER 0402N5R0B500CT B 16.8/23.8
C76 4030023520 S.CER 0603N180J500CT B 20.9/8.7
C79 4030022140 S.CER GRM033B31H102KA12D T 22.2/18.1
C81 4030022700 S.CER 0402N180J500CT B 18.8/12.7
C82 4030022640 S.CER 0402N101J500CT B 14.0/26.5
C84 4030023090 S.CER 0402B102K500CT B 14.9/16.8
C86 4030026570 S.CER RF15N120J500CT B 12.8/20.9
C88 4030022520 S.CER 0402N1R0B500CT B 12.4/16.8
C89 4030022700 S.CER 0402N180J500CT B 15.2/18.0
C90 4030022630 S.CER 0402N100C500CT B 15.4/24.1
C92 4030026710 S.CER RF15N2R0B500CT B 10.4/20.9
C93 4030022700 S.CER 0402N180J500CT B 15.1/19.3
C94 4030022580 S.CER 0402N7R0C500CT B 9.4/18.4
C95 4030022740 S.CER 0402N220J500CT B 9.4/20.0
C101 4030022740 S.CER 0402N220J500CT B 7.5/15.8
C109 4030022260 S.CER GRM033R60J105MEA2D B 63.6/8.5
C110 4030022260 S.CER GRM033R60J105MEA2D B 64.4/8.5
C113 4030022140 S.CER GRM033B31H102KA12D B 61.2/12.8
C114 4030025320 S.CER GRM0332C1H151JA01D B 61.2/14.0
C115 4030022160 S.CER GRM033B31A104KE84D B 42.6/17.1
C116 4030022140 S.CER GRM033B31H102KA12D B 42.6/16.5
C117 4030022160 S.CER GRM033B31A104KE84D B 52.3/16.3
C118 4030022140 S.CER GRM033B31H102KA12D B 52.3/16.9
C120 4030026710 S.CER RF15N2R0B500CT B 43.5/14.8
C122 4030026710 S.CER RF15N2R0B500CT B 46.0/12.0
C124 4030026710 S.CER RF15N2R0B500CT T 40.7/16.2
C125 4030022630 S.CER 0402N100C500CT B 7.5/14.9
C126 4030022560 S.CER 0402N5R0B500CT B 7.4/12.1
C405 4030022160 S.CER GRM033B31A104KE84D B 71.8/19.6
C408 4030025440 S.CER GRM0332C1E271JA01D B 70.7/17.6
C409 4030022160 S.CER GRM033B31A104KE84D B 70.7/16.6
C410 4030022160 S.CER GRM033B31A104KE84D B 71.8/20.2
C411 4030022160 S.CER GRM033B31A104KE84D B 71.0/22.5
C412 4030022160 S.CER GRM033B31A104KE84D B 71.0/23.2
C413 4030025350 S.CER GRM0332C1H120JA01D B 80.3/7.8
C414 4030022160 S.CER GRM033B31A104KE84D B 70.4/15.1
C415 4030022160 S.CER GRM033B31A104KE84D B 71.0/26.5
C416 4030025350 S.CER GRM0332C1H120JA01D B 81.7/9.5
C417 4030022260 S.CER GRM033R60J105MEA2D B 76.8/9.7
C418 4030022160 S.CER GRM033B31A104KE84D B 76.8/10.3
C420 4030022260 S.CER GRM033R60J105MEA2D B 77.3/10.9
C421 4030022160 S.CER GRM033B31A104KE84D B 77.3/11.5
C425 4030025400 S.CER GRM033R61A273KE84D B 77.1/8.7
C426 4030022160 S.CER GRM033B31A104KE84D B 87.6/29.1
C427 4030022260 S.CER GRM033R60J105MEA2D B 84.8/11.1
C428 4030022160 S.CER GRM033B31A104KE84D B 90.1/14.0
C429 4550007520 S.TAN F931A106MAABMA B 80.5/36.5
Eqv. 4550009370 S.TAN 267E1002106MR533
C430 4030022140 S.CER GRM033B31H102KA12D B 64.6/20.2
C437 4030022140 S.CER GRM033B31H102KA12D B 83.3/11.1
C446 4030022140 S.CER GRM033B31H102KA12D B 84.0/11.1
C451 4030022120 S.CER GRM0332C1H470JA01D B 62.6/17.3
C452 4030022120 S.CER GRM0332C1H470JA01D B 62.0/18.0
C453 4030022120 S.CER GRM0332C1H470JA01D B 71.8/24.5
C454 4030022120 S.CER GRM0332C1H470JA01D B 64.0/15.9
C455 4030022120 S.CER GRM0332C1H470JA01D B 65.0/15.9
C456 4030022120 S.CER GRM0332C1H470JA01D B 87.8/13.1
C457 4030022120 S.CER GRM0332C1H470JA01D B 65.9/17.0
C458 4030022120 S.CER GRM0332C1H470JA01D B 70.2/20.3
C459 4030022120 S.CER GRM0332C1H470JA01D B 64.5/24.1
C460 4030022120 S.CER GRM0332C1H470JA01D B 65.4/24.2
C461 4030022120 S.CER GRM0332C1H470JA01D B 70.0/22.3
C462 4030022120 S.CER GRM0332C1H470JA01D B 69.4/23.4
C463 4030022120 S.CER GRM0332C1H470JA01D B 70.8/24.4
C464 4030022120 S.CER GRM0332C1H470JA01D B 70.2/25.0
C465 4030022120 S.CER GRM0332C1H470JA01D B 72.0/25.8
C466 4030022120 S.CER GRM0332C1H470JA01D B 74.7/29.5
C467 4030022120 S.CER GRM0332C1H470JA01D B 74.6/33.1
C468 4030022120 S.CER GRM0332C1H470JA01D B 60.3/35.3
C469 4030022120 S.CER GRM0332C1H470JA01D B 61.3/35.5
C470 4030022120 S.CER GRM0332C1H470JA01D B 62.2/35.5
C471 4030022120 S.CER GRM0332C1H470JA01D B 63.2/35.5
C472 4030022120 S.CER GRM0332C1H470JA01D B 69.0/35.3
C473 4030022120 S.CER GRM0332C1H470JA01D B 62.7/37.2
C474 4030022120 S.CER GRM0332C1H470JA01D B 62.0/37.8
C475 4030022120 S.CER GRM0332C1H470JA01D B 77.4/36.4
C477 4030022120 S.CER GRM0332C1H470JA01D B 85.5/33.7
C700 4030022260 S.CER GRM033R60J105MEA2D B 24.5/47.1
C702 4030022960 S.CER 0402B333K100CT B 32.0/32.5
C703 4030022260 S.CER GRM033R60J105MEA2D B 32.3/33.7
C707 4030022260 S.CER GRM033R60J105MEA2D B 34.5/34.0
C708 4030023190 S.CER 0402B392K500CT B 26.8/36.2
C710 4030022160 S.CER GRM033B31A104KE84D B 22.2/43.2
C711 4030022260 S.CER GRM033R60J105MEA2D B 26.4/34.8
C724 4030022260 S.CER GRM033R60J105MEA2D T 39.0/2.3
C726 4030022160 S.CER GRM033B31A104KE84D B 20.3/44.2
C731 4030022260 S.CER GRM033R60J105MEA2D B 36.9/34.4
C734 4030022160 S.CER GRM033B31A104KE84D T 38.8/46.0
C735 4030022260 S.CER GRM033R60J105MEA2D B 13.7/43.9
C738 4030022260 S.CER GRM033R60J105MEA2D T 40.4/46.0
C740 4030022260 S.CER GRM033R60J105MEA2D B 34.9/36.2
C741 4030025440 S.CER GRM0332C1E271JA01D T 41.2/36.4
C742 4030022150 S.CER GRM033B31E103KA12D B 14.1/39.5
C744 4030022950 S.CER 0402B273K100CT B 23.3/32.0
C745 4030022260 S.CER GRM033R60J105MEA2D T 39.2/37.3
C747 4030022260 S.CER GRM033R60J105MEA2D T 42.4/37.5
C748 4030022260 S.CER GRM033R60J105MEA2D B 37.5/37.8
C749 4030022260 S.CER GRM033R60J105MEA2D T 18.4/36.6
C750 4030022160 S.CER GRM033B31A104KE84D B 38.7/37.1
C752 4030022160 S.CER GRM033B31A104KE84D B 38.4/36.0
C753 4030022160 S.CER GRM033B31A104KE84D T 17.3/35.6
C755 4030022160 S.CER GRM033B31A104KE84D B 16.8/38.0
C756 4030022160 S.CER GRM033B31A104KE84D B 47.0/41.3
C759 4550008220 S.TAN F931C106MAA B 10.2/44.8
Eqv. 4550009180 S.TAN 267E1602106MR533
C760 4030025550 S.CER CL21A226MAQNNPE B 48.8/41.0
C767 4520000020 S.NIO NOJC227M006RWJV T 28.5/35.2
C768 4030022260 S.CER GRM033R60J105MEA2D T 7.4/26.9
C769 4030022160 S.CER GRM033B31A104KE84D B 50.1/38.7
C772 4030022140 S.CER GRM033B31H102KA12D B 27.2/40.9
C774 4030022120 S.CER GRM0332C1H470JA01D B 26.6/40.9
C777 4030025550 S.CER CL21A226MAQNNPE B 54.8/41.1
C784 4030025440 S.CER GRM0332C1E271JA01D B 38.5/45.7
C792 4030025230 S.CER TMK107BJ105KAHT T 7.0/31.4
C793 4030025230 S.CER TMK107BJ105KAHT B 45.6/42.1
C794 4030025230 S.CER TMK107BJ105KAHT T 9.9/27.3
C798 4030022260 S.CER GRM033R60J105MEA2D B 40.3/40.2
C799 4030022260 S.CER GRM033R60J105MEA2D T 39.0/35.7
C800 4030022160 S.CER GRM033B31A104KE84D B 32.2/7.1
C802 4030022260 S.CER GRM033R60J105MEA2D T 18.4/31.3
C803 4030025320 S.CER GRM0332C1H151JA01D B 20.2/30.5
C804 4030022260 S.CER GRM033R60J105MEA2D T 21.9/29.3
C805 4030025370 S.CER GRM033R61C104KE14D B 12.0/31.3
C806 4030025320 S.CER GRM0332C1H151JA01D T 37.7/36.3
C807 4030022260 S.CER GRM033R60J105MEA2D T 39.0/35.1
C808 4030022260 S.CER GRM033R60J105MEA2D T 41.2/46.0
C809 4030022260 S.CER GRM033R60J105MEA2D T 39.0/36.3
C810 4030022260 S.CER GRM033R60J105MEA2D B 22.1/47.5
C811 4550007520 S.TAN F931A106MAABMA B 25.1/43.8
Eqv. 4550009370 S.TAN 267E1002106MR533
C812 4030022260 S.CER GRM033R60J105MEA2D B 21.5/47.5
C813 4030023110 S.CER 0402B152K500CT B 22.5/29.1
C814 4030022260 S.CER GRM033R60J105MEA2D B 50.9/31.1
C815 4030022160 S.CER GRM033B31A104KE84D B 33.2/32.9
C817 4030022260 S.CER GRM033R60J105MEA2D T 18.4/33.2
C818 4030022260 S.CER GRM033R60J105MEA2D T 17.8/31.3
C819 4030022260 S.CER GRM033R60J105MEA2D T 17.8/33.2
C820 4030022160 S.CER GRM033B31A104KE84D B 16.8/44.3
5-6b
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
REF PART DESCRIPTION M. H/V
NO. NO.
LOCATION
(Amended page)
February 2021
The underlined parts have been updated from the previous version of the addendum, or from the original page.
[MAIN-A UNIT] (for IC-G86)
J700 6450000131 CON HSJ1102-018540
J701 6450002530 CON HSJ4456-010320
DS400 5030004550 LCD GP11538A6
DS401 5040003500 S.LED HT-191 UYG-K828 T 52.8/4.6
DS402 5040003500 S.LED HT-191 UYG-K828 T 48.3/4.6
MC700 7700003280 S.MIC SPU0410HR5H-PB-7 T 36.6/6.6
S400 2250001090 ENC ED08902OFK150S070C-2015
S401 2260003490 S.SWI TAFG-12W-QR B 17.4/1.9
EP1 8930101610 LCD SRCN-4066-SP-N-W (SHJ)
EP3 6910018460 S.BEA MMZ1005Y102C-T B 33.3/9.5
EP4 6910014690 S.BEA MPZ1608S221A-T B 24.5/20.0
EP400 6910021240 S.BEA MMZ1005A152ET B 78.9/38.3
EP700 6910018460 S.BEA MMZ1005Y102C-T B 24.0/45.6
EP701 6910018460 S.BEA MMZ1005Y102C-T B 18.7/45.5
EP702 6910019900 S.BEA MPZ1608S601AT B 26.6/42.1
EP703 6910016330 S.BEA MMZ1005S 601CT-S B 38.3/42.0
EP704 6910018460 S.BEA MMZ1005Y102C-T B 37.0/45.7
6-1b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless
SECTION 6 MECHANICAL PARTS
(Amended page)
February 2021
[CHASSIS PARTS]
[MAIN UNIT] (for IC-V86 and IC-V86-T)
[MAIN-A UNIT] (for IC-G86)
[ACCESSORIES]
REF PART DESCRIPTION QTY.
NO. NO.
REF PART DESCRIPTION QTY.
NO. NO.
REF PART DESCRIPTION QTY.
NO. NO.
REF PART DESCRIPTION QTY.
NO. NO.
J1 6510032950 BNC-R4066 1
MP1 8010021713 3285 CHASSIS-3 1
MP2 8930079900 3285 TERMINAL HOLDER 1
MP5 8930104470 4066 MINUS TERMINAL 1
MP9 8830003390 VR NUT (AB) 1
MP10 8610014170 KNOB N-391 1
MP11 8930080280 3254 TOP SEAL 1
MP12 8810009511 PHBT M2 × 4 NI-ZC3 9
MP13 8810009511 PHBT M2 × 4 NI-ZC3 1
MP15 8810008761 PHBT M2 × 8 NI-ZC3 2
MP16 8210034561 4066 FRONT PANEL ASSEMBLY-1 [#11] 1
8210034561 4066 FRONT PANEL ASSEMBLY-1 [#12] 1
8210034561 4066 FRONT PANEL ASSEMBLY-1 [#13] 1
8210034551 4066 FRONT PANEL ASSEMBLY (A)-1 [#31] 1
8210034521 4066 FRONT PANEL (B) ASSEMBLY-1 [#41] 1
MP21 8930103870 3285 A-SIDE SEAL 1
MP22 8930101260 4066 SIDE PLATE 1
MP24 8930101210 THERMAL SHEET DT TC-200CAT-20 (8 × 12) 1
MP26 8830004770 STEP NUT (R) 1
MP28 8850003421 SEALING WASHER (AA)-1 1
MP30 8930104270 3620 MIC RUBBER (A) 1
MP33 8930080020 3253 A-TERMINAL 1
MP34 8930104600 INSULATION SHEET (PF) 1
J700 6450000131 HSJ1102-018540 1
J701 6450002530 HSJ4456-010320 1
DS400 5030004550 GP11538A6 1
MC700* 7700003280 SPU0410HR5H-PB-7 1
S400 2250001090 ED08902OFK150S070C-2015 1
S401* 2260003490 TAFG-12W-QR 1
EP1 8930101610 SRCN-4066-SP-N-W 1
MP1* 8510022740 4066 VCO CASE 1
MP4* 8930101082 3620 SP SPRING-2 1
MP5* 8930100370 4066 ANT SPRING 1
MP6* 8410003170 4066 PA HEATSINK 1
MP7 8210034210 4066 REFLECTOR 1
MP8 8930101200 4066 LCD HOLDER 1
MP9 8930080260 3254 WHITE SHEET 1
MP100* 6910014760 OG-503040 1
J700 6450000131 HSJ1102-018540 1
J701 6450002530 HSJ4456-010320 1
DS400 5030004550 GP11538A6 1
MC700* 7700003280 SPU0410HR5H-PB-7 1
S400 2250001090 ED08902OFK150S070C-2015 1
S401* 2260003490 TAFG-12W-QR 1
EP1 8930101610 SRCN-4066-SP-N-W 1
MP1* 8510022740 4066 VCO CASE 1
MP4* 8930101082 3620 SP SPRING-2 1
MP5* 8930100370 4066 ANT SPRING 1
MP6* 8410003170 4066 PA HEATSINK 1
MP7 8210034210 4066 REFLECTOR 1
MP8 8930101200 4066 LCD HOLDER 1
MP9 8930080260 3254 WHITE SHEET 1
MP100* 6910014760 OG-503040 1
EP1 – FA-B57V†[#11] 1
– FA-B45V†[#12] 1
– FA- B57V†[#13] 1
– FA-B45V†[#31] 1
– FA- B57V†[#41] 1
EP2 – BP-298†[#11] 1
– BP-298†[#12] 1
– BP-264†[#13] 1
– BP-298†[#31] 1
– BP-298†[#41] 1
EP3 – BC-240†[#11] 1
– BC-240†[#12] 1
– BC-192†[#13] 1
– BC-240†[#31] 1
– BC-240†[# 41] 1
EP4 – BC-242†1
MP1 – MB-124†1
MP2 8210025841 3285 JACK PANEL-1 [#11] 1
8210025841 3285 JACK PANEL-1 [#12] 1
8210025841 3285 JACK PANEL-1 [#13] 1
8210025841 3285 JACK PANEL-1 [#31] 1
8210026621 3285 JACK PANEL (B)-1 G [#41] 1
MP3 8810004861 PH M2 × 6 ZK3 2
†Sold as an option.
††The shape may differ depending on the transceiver version.
MP1
MP3 MP2
EP1
EP3
EP4
EP2
6-2b
Apply the glue to the following area ( ).
Used glue: SL320W KONISHI (8950009140)
Apply the grease to the following area.
Grease type: G501 (80G) SHINETSU (8950002750)
MP16 (CHASSIS)
(Refer to the parts list.)
MP16 (CHASSIS)
(Refer to the parts list.)
MP10 (CHASSIS)
(8610014170)
MP26 (CHASSIS)
(8830004770)
MP30 (CHASSIS)
(8930104270)
J1 (CHASSIS)
(6510032950)
J1 (CHASSIS)
(6510032950)
MP1 (CHASSIS)
(8010021713)
MP2 (CHASSIS)
(8930079900)
MP5 (CHASSIS)
(8930104470)
MP9 (CHASSIS)
(8830003390)
MP11 (CHASSIS)
(8930080280)
MP12 (CHASSIS) ×9
(8810009511)
MP13 (CHASSIS)
(8810009511)
MP21 (CHASSIS)
(8930103870)
MP22 (CHASSIS)
(8930101260)
MP24 (CHASSIS)
(8930101210)
MP28 (CHASSIS)
(8850003421)
MP33 (CHASSIS)
(8930080020)
J700 (MAIN/MAIN-A)
(6450000131)
J701 (MAIN/MAIN-A)
(6450002530)
DS400 (MAIN/MAIN-A)
(5030004550)
S400 (MAIN/MAIN-A)
(2250001090)
EP1 (MAIN/MAIN-A)
(8930101610)
MP7 (MAIN/MAIN-A)
(8210034210)
MP8 (MAIN/MAIN-A)
(8930101200)
MP9 (MAIN/MAIN-A)
(8930080260)
MP15 (CHASSIS) ×2
(8810008761)
MP16 (CHASSIS)
(Refer to the parts list.)
MP30 (CHASSIS)
(8930104270)
MP34 (CHASSIS)
(8930104600)
MAIN/MAIN-A UNIT
Torque: 0.3 N·m (±0.05 N·m)
Legend:
Ref.No. Unit Name
MP1 (CHASSIS)
(1234567890)
Parts No.
Tighten with:
ICOM DRIVER (K)-3 (8960000113)
Torque: 0.8N·m (±0.1 N·m)
Tighten with:
ICOM DRIVER (AG)-1 (8960000561)
Torque: 0.7N·m (±0.1 N·m)
Tighten with:
ICOM DRIVER (Y)-1 (8960000461)
Torque: 1.5N·m (±0.15 N·m)
Torque: 0.3 N·m (±0.05 N·m)
Torque: 0.3 N·m (±0.05 N·m)
February 2021 (Amended page) The underlined parts have been updated from the previous version of the addendum, or from the original page.
See the PARTS LIST H/V location on the PARTS LIST for location details.
SECTION 7 BOARD LAYOUTS
7-1b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
NOTE:
Some parts may not be mounted on the PCB.
• MAIN/MAIN-A UNIT (B-9067C: TOP VIEW)
The serial numbers of transceivers that use the PCB (B-9067C).
Model Name Version
Number Serial Numbers
IC-V86 #11 11027101 and above (Plan)
IC-V86 #12 12006101 and above (Plan)
IC-V86 #13 13004801 and above (Plan)
IC-V86-T #31 31004701 and above (Plan)
IC-G86 # 41 41008201 and above
4
3
2
1
J700
J701
B9067C
C819C818
C817
C809
C808
C807
C806
C804
C802
C799
C768
C753
C749
C747
C745
C741
C738
C734
C724
C79
C25
R810
R809
R805
R798R797
R791
R790
R789
R788
R781
R780
R752
R751
R746R740
R734
R732
R729
R728 R727
R726
R725
R715
R60
R59
R58
R2
R1
C124
Q724
Q722
Q720
Q718
Q704
MP6
MP4
MC700
LM1
L11
IC819
IC818
IC706
IC701
DS402 DS401
D708
D700
D407
D406
D405
C794
C792
C767
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80 H85 H90 H95 H100
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50
4
3
2
1
J700
J701
B9067C
C819C818
C817
C809
C808
C807
C806
C804
C802
C799
C768
C753
C749
C747
C745
C741
C738
C734
C724
C79
C25
R810
R809
R805
R798R797
R791
R790
R789
R788
R781
R780
R752
R751
R746R740
R734
R732
R729
R728 R727
R726
R725
R715
R60
R59
R58
R2
R1
C124
Q724
Q722
Q720
Q718
Q704
MP6
MP4
MC700
LM1
L11
IC819
IC818
IC706
IC701
DS402 DS401
D708
D700
D407
D406
D405
C794
C792
C767
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80 H85 H90 H95 H100
V0 V5 V10 V15 V20 V25 V30 V35 V40 V45 V50
[SP][MIC]
DS400
MP8
See the PARTS LIST H/V location on the PARTS LIST for location details.
7-2b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
(Amended page)
February 2021
NOTE:
Some parts may not be mounted on the PCB.
• MAIN/MAIN-A UNIT (B-9067C: BOTTOM VIEW)
S400
C820
C815
C814
C812
C810
C805
C803
C800
C798
C784
C774
C772
C769
C756
C755
C752
C750
C748
C742
C740
C735
C731
C726
C711
C710
C707
C703
C700
C477
C475
C474
C473
C472
C471
C470
C469
C468
C467
C466
C465
C464
C463
C462
C461
C460
C459
C458
C457
C456
C455
C454
C453
C452
C451
C446
C437
C430
C428
C427
C426
C425
C421
C420
C418
C417
C416
C415
C414
C413
C412
C411
C410
C409
C408
C405
C118
C117
C116
C115
C114 C113
C110
C109
C71
C64
C54
C53
C52
C49
C47
C46
C45
C42
C38
C36
C35
C33
C32
C29
C28
C26
C24
C23
C22
C20
C19
C4
D714
D711
D9
R812
R811
R808
R807
R806
R804
R803
R801
R800
R799
R796
R795
R787
R786
R785
R784
R773
R771
R767
R765
R763 R762
R759
R753
R750
R745
R742
R739 R738
R735
R733
R731
R724
R723
R721
R720
R717
R716
R713
R712
R708
R706
R705
R704
R703
R702
R430
R429
R428
R427
R426
R425
R421
R417
R416
R413
R412
R411
R410
R409
R407
R406
R405
R404
R403
R402
R401
R400
R67
R57
R56
R55
R53
R52
R51
R50R49
R48
R47
R46
R45
R44
R42
R41
R38
R37
R36
R33
R32
R30
R28
R27
R26
R24
R23
R21
R20
R19
R18
R17
R16
R14
R13
R12
R11
R10
L13
L4
L3
EP704
EP703
EP701
EP700
EP400
EP3
D3
C813
C744
C708
C702
C126
C125
C122
C120
C101
C95 C94
C93
C92
C90 C89
C88
C86
C84
C82
C81
C75
C73
C68
C62
C59
C58
C57
X400
X2
S401
R8
R4
Q725
Q723
Q721
Q717
Q716
Q712
Q711
Q707
Q706
Q705
Q703
Q401
Q400
Q12
Q10
Q9
Q8
Q7
Q6
Q4
Q2
MP100
MP5
MP1
LM2
L705
L702
L22
L19
L18
L17
L16
L15
L12
L10
L9
L8
L7
L6
L5
IC820
IC817
IC707
IC702
IC403
IC402
IC400
IC3
IC1
EP702
EP4
D719
D717
D706
D705
D413
D411
D410
D409
D408
D404
D403
D402
D401
D400
D13
D12
D8
D7
D6
D5
D4
D2
C811
C793
C777
C760
C759
C429
C76
C69
C67
C65
C37
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80 H85 H90 H95 H100
V0V5
V10
V15V20
V25V30V35V40V45
V50
S400
C820
C815
C814
C812
C810
C805
C803
C800
C798
C784
C774
C772
C769
C756
C755
C752
C750
C748
C742
C740
C735
C731
C726
C711
C710
C707
C703
C700
C477
C475
C474
C473
C472
C471
C470
C469
C468
C467
C466
C465
C464
C463
C462
C461
C460
C459
C458
C457
C456
C455
C454
C453
C452
C451
C446
C437
C430
C428
C427
C426
C425
C421
C420
C418
C417
C416
C415
C414
C413
C412
C411
C410
C409
C408
C405
C118
C117
C116
C115
C114 C113
C110
C109
C71
C64
C54
C53
C52
C49
C47
C46
C45
C42
C38
C36
C35
C33
C32
C29
C28
C26
C24
C23
C22
C20
C19
C4
D714
D711
D9
R812
R811
R808
R807
R806
R804
R803
R801
R800
R799
R796
R795
R787
R786
R785
R784
R773
R771
R767
R765
R763 R762
R759
R753
R750
R745
R742
R739 R738
R735
R733
R731
R724
R723
R721
R720
R717
R716
R713
R712
R708
R706
R705
R704
R703
R702
R430
R429
R428
R427
R426
R425
R421
R417
R416
R413
R412
R411
R410
R409
R407
R406
R405
R404
R403
R402
R401
R400
R67
R57
R56
R55
R53
R52
R51
R50R49
R48
R47
R46
R45
R44
R42
R41
R38
R37
R36
R33
R32
R30
R28
R27
R26
R24
R23
R21
R20
R19
R18
R17
R16
R14
R13
R12
R11
R10
L13
L4
L3
EP704
EP703
EP701
EP700
EP400
EP3
D3
C813
C744
C708
C702
C126
C125
C122
C120
C101
C95 C94
C93
C92
C90 C89
C88
C86
C84
C82
C81
C75
C73
C68
C62
C59
C58
C57
X400
X2
S401
R8
R4
Q725
Q723
Q721
Q717
Q716
Q712
Q711
Q707
Q706
Q705
Q703
Q401
Q400
Q12
Q10
Q9
Q8
Q7
Q6
Q4
Q2
MP100
MP5
MP1
LM2
L705
L702
L22
L19
L18
L17
L16
L15
L12
L10
L9
L8
L7
L6
L5
IC820
IC817
IC707
IC702
IC403
IC402
IC400
IC3
IC1
EP702
EP4
D719
D717
D706
D705
D413
D411
D410
D409
D408
D404
D403
D402
D401
D400
D13
D12
D8
D7
D6
D5
D4
D2
C811
C793
C777
C760
C759
C429
C76
C69
C67
C65
C37
H0 H5 H10 H15 H20 H25 H30 H35 H40 H45 H50 H55 H60 H65 H70 H75 H80 H85 H90 H95 H100
V0V5V10V15V20V25V30V35V40V45V50
[VOL]
J701
J700
[PTT]
[MIC] [SP]
SECTION 8 SCHEMATIC DIAGRAM
8-1b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
February 2021 (Amended page)
• MAIN UNIT (for IC-V86 and IC-V86-T) (1/3)
MAIN UNIT
(2/3)
MAIN UNIT
(3/3)
DRIVER
Pre
DRIVER
13 MHz TCXO
PA
TEMPERATURE
APC
TX MUTE
TX
RX
MPZ1608S221A
EP4
4.7
R42
AVR-M1005C270M
D3
MMZ1005Y102CT
EP3
VCC
RD08MUS2
Q9
2SC5108
Q8
AT1846S
IC3
1AVDD
2SCLK
3SDIO
4AVDD
5XTAL1
6XTAL2
7MODE
8SENB
9AFOUT
10 NC
11 MIC_IN
12 CC
13 AVDD
14 NC
15 RFIN
16 AVDD
17
NC
18
RFOUT
19
NC
20
NC
21
AVDD
22
PABIAS
23
AVDD
24
PDN
25
GPIO7
26
GPIO6
27
GPIO5
28
GPIO4
29
GPIO3
30
GPIO2
31
GPIO1
32
GPIO0
33
GND
CP06S
CP4
RD01MUS2B
Q7
16.1N
L6
L16
45.3N
45.3N
L15
37.5N
L17
T5V
33P
C38 100P
C46
CP06S
CP2
45.3N
L10
L9
5.8N
10.3N
L7
0.82U
L11
S5V
10P
C20
CP06S
CP1
CP06S
CP3
0.001
C84
1SV305
D5
100P
C82
1SV305
D4
100P
C68
1
C36
DTC014YEB
Q2
L1SS400
D2
+3.3V
S5V
T5V
+3.3V
VCC
2SC5108
Q6
0.001
C19
0.001
C22
0.001
C35
0.001
C42
0.001
C45
0.001
C47
0.001
C49
0.001
C53
0.001
C54
0.001
C64
0.001
C79
0.001
C29
1
C25
CP06S
CP6
CP06S
CP5
ERTJ0EP473J
R1
100k
R2
RUM002N02
Q10
0.1
C71
0.1
C24
0.1
C28
0.1
C32
0.1
C33
0.1
C23
0.001
C58
47k
R67
R14
33k
L1SS400
D12
4.7k
R18
4.7k
R19
100
R36
R38
10
1k
R56
22
R51
R44
27k
47k
R33
47
R24
R37
6.8k
68k
R60
68
R41
D9
RB751CM
RN142SM
D8
DTA014EEB
Q4
10U
L19
7P
C94
10P
C125
18P
C93
220
R46
R53
82k
22N
L4
10P
C57
10P
C65
47P
C52
1k
R27
CP06S
CP7
CP06S
CP8
1
C109
1
C110
0.1
C115
0.001
C116
0.1
C117
0.001
C118
0.001
C73
18P
C81
82P
C59
18P
C76
39P
C67
15P
C69
1U
L22
0.001
C113
150P
C114
0
R8
22P
C101
270
R58
270
R59
27N
L3
2P
C120
2P
C122
4066
MP5
MP6
4066
CR-1079
X2
1GND 2
GND
3
OUT
4VCC
0.1U
L5
RN142SM
D6
RN142SM
D13
0
R11
22k
R48
R30
1k
12k
R23
R26
150k
2P
C124
4066
MP1
1
2
3
4
2.2k
R55
2.2k
R57
RN142SM
D7
0.1
C26
100
R47
3.3k
R52
6.8k
R32
R16
150k
R17
68k
10P
C90
5P
C75
180k
R49
180k
R50
47N
L12
47N
L8
22P
C62
12P
C86
10
C37
22
R45
27N
L13
0.15
R4
2
3
1NJM12904R
IC1
V+
8
GND
4
NJM12904R
IC1
NJM12904R
IC1
6
5
7
18P
C89
1P
C88
22P
C95
150k
R10
150k
R12
18.0k
R13
18.0k
R28
470k
R21
470k
R20
RFPWR
TMUT
ATSQ
ATSQ
ATDTMF
ATDTMF
ATCTS
ATCTS
MICIN
AFOATSCK
TEMP
RFPWR
ATDTMF
TMUT
ATSQ
ATCTS
ATSDA
ATSCK
ATSDA
TEMP
RFPWR
MICIN
AFO
APCV
S5V
APCSW
+3.3V
+3.3V
VCC
VCC
T5V
T5V
2P
C92
5P
C126
27.2N
L18
0.001
C4
Q12
DTC014YEB
APCSW
VCC
+3.3V +3.3V +3.3V
S5V
S5V
S5V
S5V
+3.3V
+3.3V+3.3V
+3.3V
+3.3V +3.3V
+3.3V
+3.3V
+3.3V
VCC
VCC
VCC
T5V
S5V
T5V
S5V
T5V
S5V
T5V
T5V T5V
T5V
T5V
T5V
VCC
VCC
8-2b
The underlined parts have been updated from the previous version of the addendum, or from the original page.
February 2021 (Amended page)
• MAIN UNIT (for IC-V86 and IC-V86-T) (2/3)
MAIN UNIT
(3/3)
MAIN UNIT
(1/3)
[MONI][1]•[TONE] [2]•[VOX]
[
]
[
]
[3]•[T.SCAN]
[4]•[DUP]
[VFO/MR/CALL]
[5]•[SCAN] [6]•[SKIP]
[7]•[PRIO] [8]•[SET] [9]•[H/M/L]
[*]•[FUNC] [0]•[DTMF-M] [# ENT]•[ ]
[VOL]
[PTT]
0.027
C425
NJU7704F3
IC403
1CD
2VSS
3MR 4
VOUT
5
VDD
CP06S
CP400
CP06S
CP401
CP06S
CP403
1
C420
STM32L073VBT6
IC402
1
PE2
2
PE3
3
PE4
4
PE5
5
PE6
6
VLCD
7
PC13
8
PC14-OSC32_IN
9
PC15-OSC32_OUT
10
PH9
11
PH10
12
PH0-OSC_IN
13
PH1-OSC_OUT
15
PC0
16
PC1
17
PC2
18
PC3
19
VSSA
20
VREF-
21
VREF+
22
VDDA
23
PA0
24
PA1
25
PA2
26 PA3
27 VSS
28 VDD
29 PA4
30 PA5
31 PA6
32 PA7
33 PC4
34 PC5
35 PB0
36 PB1
37 PB2
38 PE7
39 PE8
40 PE9
41 PE10
42 PE11
43 PE12
44 PE13
45 PE14
46 PE15
47 PB10
48 PB11
49 VSS
50 VDD
51 PB12
52 PB13
53 PB14
54 PB15
55 PD8
56 PD9
57 PD10
58 PD11
59 PD12
60 PD13
61 PD14
62 PD15
63 PC6
64 PC7
65 PC8
66 PC9
67 PA8
68 PA9
69 PA10
70 PA11
71 PA12
72 PA13
73 VDD
74 VSS
75 VDD_USB
76
PA14
77
PA15
78
PC10
79
PC11
80
PC12
81
PD0
82
PD1
83
PD2
84
PD3
85
PD4
86
PD5
87
PD6
88
PD7
89
PB3
90
PB4
91
PB5
92
PB6
93
PB7
94
BOOT0
95
PB8
96
PB9
97
PE0
98
PE1
99
VSS
100
VDD
14
NRST
CR-1021
X400
MMZ1005A152ET
EP400
1
C427
*D400
*D406
*D405
*D404
*D401
*D407
*D403
*D402
VCC
+5V
S5V
T5V
+3.3V
+5V
VCC VCC
+3.3V
T5V
S5V
1
C417
L1SS400
D408
L1SS400
D409
L1SS400
D410
L1SS400
D411
LRB706F
D413
15.0k
R427
12P
C416
CP06S
CP404
DTC044TEB
Q401
2SC4116
Q400
0.1
C405
0.1
C409
0.1
C410
0.1
C411
0.1
C412
0.1
C414
0.1
C415
0.1
C418
0.1
C421
0.1
C426
0.1
C428
12P
C413
CP06S
CP405
CP06S
CP406
R429
10k
R409
10k
R410
10k
R411
10k
15k
R426
1k
R407
1k
R404
1k
R405
1k
R406
R421
1M
2.2k
R400
2.7k
R401
R413
4.7k
R412
4.7k
47k
R425
47k
R403
47
R417
47
R416
KEY
S402
KEY
S403
KEY
S404
KEY
S405
KEY
S406
KEY
S407
KEY
S408
KEY
S409
KEY
S410
KEY
S411
KEY
S412
KEY
S413
KEY
S415
KEY
S416
KEY
S417
HT-191UYG
DS402
HT-191UYG
DS401
BR24G128NUX
IC400
1A0
2A1
3A2
4GND 5
SDA
6
SCL
7
WP
8
VCC
9
KEY
S418
GP11538A6
DS400
2COM2
3COM3
4COM4
5SEG1
6SEG2
7SEG3
8SEG4
9SEG5
10 SEG6
11 SEG7
12 SEG8
13 SEG9
14 SEG10
15 SEG11
16 SEG12
17 SEG13
18 SEG14
19 SEG15
1COM1
20 SEG16
21 SEG17
22 SEG18
23 SEG19
24 SEG20
25 SEG21
26 SEG22
27 SEG23
28 SEG24
29 SEG25
TAFG-12W
S401
CP06S
CP410
CP06S
CP411
CP06S
CP412
CP06S
CP413
CP06S
CP414
270P
C408
0
R428
0.001
C430
0.001
C437
CP06S
CP408
ED08902OFK150S070C
S400
E
UP
DN
10
C429
47P
C451
47P
C452
47P
C453
47P
C454
47P
C455
47P
C456
47P
C457
47P
C458
47P
C459
47P
C460
47P
C461
47P
C462
47P
C463
47P
C464
47P
C465
47P
C466
47P
C467
47P
C468
47P
C469
47P
C470
47P
C471
47P
C472
47P
C473
47P
C474
47P
C475
0.001
C446
47P
C477
47k
R402
68
R430
KR0
KS2
SWCLK
KS1
KS0
SEG2
SEG1
SEG24
SEG25
DIUD
COM4
SEG16
COM2
SEG15
COM1
SEG14
XPTT
SEG13
ESCL
SEG12
ESDAVOXV
SEG11
SEG10
SEG9
SEG8
TEMP
BATV
MDET
ESDA
T5V
ESCL
COM3
FLRXD
FLTXD
S5V
CLI
BOOT0
SWDIO
CSFT
SEG3
SEG7
SEG6
SEG5
SEG4
SEG17
SEG21
SEG19
SEG20
SEG23
SEG22
SEG18
KR1
KR2
KR3
DICK
KS0
KS2
BEEP
RFPWR
MDET
CL
CLI
+5V
IPTT
XPTT
VOXV
BATV
S5C
TXC
VDT
VCL
BEEP
AFON
POSW
CL
PWON
ATSDA
ATSCK
ATCTS
ATSQ
ATDTMF
TMUT
RFPWR
TEMP
FLRXD
ATSCK
BOOT0
LIGT
KS1
KS3
DICK
IPTT
DIUD
CSFT
CPUCLI
ATSQ
ATCTS
ATSDA
CLO
NRST
ISO1
ISO2
MIC2
MIC1
KR1
KR3
KR2
ATX
ATX
MIC1
SWDIO
SWCLK
NRST
MIC2
LIGT
AFON
FLTXD
POSW
ATDTMF
TMUT
TXC
ISO1
ISO2
KS3
CLO
PWON
APCSW
S5C
APCSW
CPUCLO
+3.3V
+3.3V +3.3V
+3.3V
KR0
COM1
COM2
COM3
COM4
SEG1
SEG2
SEG3
SEG4
SEG5
SEG6
SEG7
SEG8
SEG9
SEG10
SEG11
SEG12
SEG13
SEG14
SEG15
SEG16
SEG17
SEG18
SEG19
SEG20
SEG21
SEG22
SEG23
SEG24
SEG25
VDT
VCL
RMUT
RMUT
+3.3V
+3.3V
+3.3V
+3.3V
EEPROM 16 kbyte
CLOCK/CLOCK SHIFT 12.288 MHz
RESET
CLONE
BUFFER
TXFREE
COMEXP
BAND2
BAND1
FREQ2
FREQ1
EXHI
RXFREE
VCC
S5V
+3.3V
+3.3V
+3.3V
+3.3V
+5V
T5V
VCC
S5V
+3.3V
+3.3V+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+3.3V
+5V
T5V
VCC
S5V
+3.3V
+3.3V
+5V
T5V
This manual suits for next models
2
Table of contents
Other Icom Transceiver manuals
