ICON Health & Fitness NordicTrack Elite 1400 User manual

nordictrack.com
Model No. NTL14020.0
Serial No.
Write the serial number in the space
above for reference.
USER'S MANUAL
CAUTION
Read all precautions and
instructions in this manual before
using this equipment. Keep this
manual for future reference.
To register your product and
activate your warranty today,
go to my.nordictrack.com.
For service at any time, go to
nordictrackservice.com.
Or call 1-866-362-4490
Mon.–Fri. 6 a.m.–6 p.m. MT
Sat. 8 a.m.–12 p.m. MT
Please do not contact the store.
REGISTER YOUR
PRODUCT
CUSTOMER CARE
Serial
Number
Decal

2
WARNING DECAL PLACEMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
IMPORTANT PRECAUTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
BEFORE YOU BEGIN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
PART IDENTIFICATION CHART. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
ASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
HOW TO USE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
HOW TO FOLD AND MOVE THE TREADMILL . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
MAINTENANCE AND TROUBLESHOOTING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
EXERCISE GUIDELINES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
PART LIST. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
EXPLODED DRAWING. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
ORDERING REPLACEMENT PARTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
LIMITED WARRANTY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Back Cover
This drawing shows the locations of the warning
decals. If a decal is missing or illegible, call the
telephone number on the front cover of this
manual and request a free replacement decal.
Apply the decal in the location shown. Note: The
decals may not be shown at actual size.
WARNING DECAL PLACEMENT
TABLE OF CONTENTS
NORDICTRACK and IFIT are registered trademarks of ICON Health & Fitness, Inc. Google Maps is a trademark
of Google LLC. The Bluetooth®word mark and logos are registered trademarks of Bluetooth SIG, Inc. and are
used under license. Wi-Fi is a registered trademark of Wi-Fi Alliance. WPA and WPA2 are trademarks of Wi-Fi
Alliance.

3
1. It is the responsibility of the owner to ensure
that all users of this treadmill are adequately
informed of all warnings and precautions.
2. Before beginning any exercise program,
consult your physician. This is especially
important for persons over age 35 or persons
with pre-existing health problems.
3. The treadmill is not intended for use by
persons with reduced physical, sensory, or
mental capabilities or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use
of the treadmill by someone responsible for
their safety.
4. Use the treadmill only as described in this
manual.
5. The treadmill is intended for home use only.
Do not use the treadmill in any commercial,
rental, or institutional setting.
6. Keep the treadmill indoors, away from mois-
ture and dust. Do not put the treadmill in a
garage or covered patio, or near water.
7. Place the treadmill on a level surface, with
at least 8 ft. (2.4 m) of clearance behind it
and 2 ft. (0.6 m) on each side. Do not place
the treadmill on any surface that blocks air
openings. To protect the floor or carpet from
damage, place a mat under the treadmill.
8. Do not operate the treadmill where aerosol
products are used or where oxygen is being
administered.
9. Keep children under age 16 and pets away
from the treadmill at all times.
10. The treadmill should be used only by per-
sons weighing 350 lbs. (159 kg) or less.
11. Never allow more than one person on the
treadmill at a time.
12. Wear appropriate exercise clothes while
using the treadmill. Do not wear loose
clothes that could become caught in the
treadmill. Athletic support clothes are recom-
mended for both men and women. Always
wear athletic shoes. Never use the treadmill
with bare feet, wearing only stockings, or in
sandals.
13. Plug the power cord into a surge sup-
pressor (not included), and plug the surge
suppressor into an appropriate outlet (see
page 19). To avoid overloading the circuit,
do not plug other electrical devices, except
for low-power devices such as cell phone
chargers, into the surge suppressor or into
an outlet on the same circuit.
14. Use only a surge suppressor that meets all
of the specifications described on page 19.
To purchase a surge suppressor, see your
local NORDICTRACK dealer, call the tele-
phone number on the front cover of this
manual, or see your local electronics store.
15. Failure to use a properly functioning surge
suppressor could result in damage to the
control system of the treadmill. If the control
system is damaged, the walking belt may
slow, accelerate, or stop unexpectedly, which
may result in a fall and serious injury.
16. Keep the power cord and the surge suppres-
sor away from heated surfaces.
17. Never move the walking belt while the power
is turned off. Do not operate the treadmill
if the power cord or plug is damaged, or if
the treadmill is not working properly. (See
MAINTENANCE AND TROUBLESHOOTING
on page 32 if the treadmill is not working
properly.)
18. Read, understand, and test the emergency
stop procedure before using the treadmill
(see HOW TO TURN ON THE POWER on
page 21). Always wear the clip while using the
treadmill.
WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read
all important precautions and instructions in this manual and all warnings on your treadmill before
using your treadmill. ICON assumes no responsibility for personal injury or property damage sus-
tained by or through the use of this product.
IMPORTANT PRECAUTIONS

4
19. Always stand on the foot rails when starting
or stopping the walking belt. Always hold the
handrails while using the treadmill.
20. When a person is walking on the treadmill,
the noise level of the treadmill will increase.
21. Keep fingers, hair, and clothing away from
the moving walking belt.
22. The treadmill is capable of high speeds.
Adjust the speed in small increments to
avoid sudden jumps in speed.
23. The heart rate monitor is not a medical
device. Various factors, including the user’s
movement, may affect the accuracy of heart
rate readings. The heart rate monitor is
intended only as an exercise aid in determin-
ing heart rate trends in general.
24. Never leave the treadmill unattended while it
is running. Always remove the key, press the
power switch into the off position (see the
drawing on page 6 for the location of the
power switch), and unplug the power cord
when the treadmill is not in use.
25. Do not attempt to move the treadmill until it
is properly assembled. (See ASSEMBLY on
page 8 and HOW TO FOLD AND MOVE
THE TREADMILL on page 31.) You must be
able to safely lift 45 lbs. (20 kg) to move the
treadmill.
26. When folding or moving the treadmill, make
sure that the storage latch is holding the
frame securely in the storage position. Do
not operate the treadmill while it is folded.
27. Do not change the incline of the treadmill by
placing objects under the treadmill.
28. Never insert any object into any opening on
the treadmill.
29. Inspect and properly tighten all parts each
time the treadmill is used.
30. DANGER: Always unplug the power
cord immediately after use, before clean-
ing the treadmill, and before performing the
maintenance and adjustment procedures
described in this manual. Never remove the
motor hood unless instructed to do so by an
authorized service representative. Servicing
other than the procedures in this manual
should be performed by an authorized ser-
vice representative only.
31. Over exercising may result in serious injury
or death. If you feel faint, if you become short
of breath, or if you experience pain while
exercising, stop immediately and cool down.
SAVE THESE INSTRUCTIONS

5
all
STANDARD SERVICE PLANS

6
Thank you for selecting the new NORDICTRACK®
ELITE 1400 treadmill. The ELITE 1400 treadmill
provides an impressive selection of features designed
to make your workouts at home more effective and
enjoyable.
For your benefit, read this manual carefully before
you use the treadmill. If you have questions after
reading this manual, please see the front cover of this
manual. To help us assist you, note the product model
number and serial number before contacting us. The
model number and the location of the serial number
decal are shown on the front cover of this manual.
Before reading further, please familiarize yourself with
the parts that are labeled in the drawing below.
BEFORE YOU BEGIN
Handrail
Heart Rate Monitor
Console
Key/Clip
Accessory Tray
Power Switch
Walking Belt
Motor Hood
Wheel
Foot Rail
Idler Roller Screws
Platform Cushions
Length: 6 ft. 7 in. (201 cm)
Width: 3 ft. (91 cm)
Power Cord

7
PART IDENTIFICATION CHART
Use the drawings below to identify small parts used for assembly. The number in parentheses below each draw-
ing is the key number of the part, from the PART LIST near the end of this manual. The number following the key
number is the quantity used for assembly. Note: If a part is not in the hardware kit, check to see whether it is
preattached. Extra parts may be included.
5/16" x 3/4"
Screw (8)–2
#8 x 3/4"
Screw (2)–6
#8 x 1"
Screw (14)–2
3/8" Star
Washer (13)–8
5/16" Star
Washer (11)–12
#8 x 1/2"
Ground Screw
(10)–1
#8 x 1/2"
Screw (1)–8
#10 Star
Washer (5)–4
5/16" x 2 1/2" Screw (28)–4
5/16" x 1 3/4"
Screw (12)–2
3/8" x 2 1/4" Screw (7)–4
3/8" x 1 3/4" Screw (62)–2
3/8" x 1 1/4"
Screw (63)–2
#10 x 3/4"
Screw (9)–4

8
• Assembly requires two persons.
• Place all parts in a cleared area and remove the
packing materials. Do not dispose of the packing
materials until you finish all assembly steps.
• After shipping, there may be an oily substance
on the exterior of the treadmill. This is normal. If
there is an oily substance on the treadmill, wipe
it off with a soft cloth and a mild, non-abrasive
cleaner.
• To identify small parts, see page 7.
• Left parts are marked “L” or “Left” and right parts
are marked “R” or “Right.”
• Assembly requires the following tools:
the included hex keys
one Phillips screwdriver
one adjustable wrench
To avoid damaging parts, do not use power tools.
ASSEMBLY
1. To use the assembly steps in this manual, first see the helpful tips below.

9
3. Lay the Right Upright (90) near the Base (94).
Press the Grommet (77) into the square hole (B)
in the Right Upright. Make sure not to pinch
the ground wire (C).
If there is a screw (D) preattached to the Right
Upright (90), remove and discard it.
Then, attach the ground wire (C) to the Right
Upright (90) with a #8 x 1/2" Ground Screw (10). 94
90
10
90
A
281
77
CB
D
2. Make sure that the power cord is unplugged.
Remove the tie securing the Upright Wire (81) to
the front of the Base (94).
Next, identify the Right Upright (90). Have a
second person hold the Right Upright near the
Base (94).
See the inset drawing. Tie the wire tie (A) in
the Right Upright (90) securely around the end
of the Upright Wire (81). Then, insert the Upright
Wire into the lower end of the Right Upright as
you pull the other end of the wire tie through the
Right Upright.
94
90
81
A
3
81

10
4
63
62
101
94
13
13
90
7
13
5. Remove and save the four 5/16" x 3/4" Patch
Screws (4).
Identify the Left and Right Base Covers (82, 83).
Slide the Left Base Cover onto the Left Upright
(89), and slide the Right Base Cover onto the
Right Upright (90). Do not press the Base
Covers into place yet.
82
90
83
5
89
81
4. Hold the Right Upright (90) against the Base
(94). Make sure not to pinch the Upright
Wire (81).
Attach the Right Upright (90) and a Wheel (101)
with two 3/8" x 2 1/4" Screws (7), a 3/8" x 1 1/4"
Screw (63), a 3/8" x 1 3/4" Screw (62), and four
3/8" Star Washers (13) as shown; do not fully
tighten the Screws yet.
Attach the Left Upright (not shown) and the
other Wheel (not shown) in the same way.
Note: There are no wires on the left side.
4
4

11
6. See the left drawing. Insert the tab (E) on one
of the Cover Brackets (18) into the slot (F) in the
Left Upright (89), and attach the Cover Bracket
with two #8 x 1/2" Screws (1).
See the right drawing. Attach the other
Cover Bracket (18) to the Right Upright (90) as
described above. Note: On the Right Upright,
the slot (F) is below the two small holes. The
Cover Bracket will need to be rotated 180º
compared to the Cover Bracket on the left
side.
Position the Upright Wire (81) to the left side of
the Right Upright (90) as shown.
E
E
81
89
90
81
90
6
7
18
18
G
F
F
1
1
90
8
H
H
7. With the help of a second person, set the
console base assembly (G) on the Right Upright
(90) and the Left Upright (not shown). See the
inset drawing. Position the Upright Wire (81) so
that it is on the inside of the Upright as shown.
Do not pinch the Upright Wire.
Partially tighten a 5/16" x 3/4" Screw (8) into the
center hole (H) on each side of the console
base assembly (G) and into the top of the Right
Upright (90) and the Left Upright (not shown);
do not fully tighten the Screws. Note: The
Screws are used only to hold the console
base assembly in place during assembly. 81

12
28
11
J
86
8
9
I
93
I
K
18
K
G
9
5
93
8. Identify the right handrail assembly (I). Remove
and discard the two indicated screws (J).
Next, carefully raise the Pulse Crossbar (93)
enough to allow you to slide the Handrail (86)
onto the console base assembly (G). See the
inset drawing. The Cover Bracket (18) should
slide into the indicated space (K) in the hand-
rail assembly.
Attach the right handrail assembly (I) with two
5/16" x 2 1/2" Screws (28) and two 5/16" Star
Washers (11); do not fully tighten the Screws
yet. Tip: You may need to adjust the position
of the right handrail assembly to align the
Screws properly.
Attach the left handrail assembly (not shown)
to the left side as described above.
9. IMPORTANT: To avoid damaging the Pulse
Crossbar (93), do not use power tools and do
not overtighten the #10 x 3/4" Screws (9).
Attach the Pulse Crossbar (93) to the right hand-
rail assembly (I) and the left handrail assembly
(not shown) with four #10 x 3/4" Screws (9)
and four #10 Star Washers (5) (only one side
is shown); start all of the Screws, and then
tighten them.

13
11
G
N
M
O, 81
L
10. With the help of a second person, hold the
console assembly (L) near the console base
assembly (G).
See the inset drawing. Connect the wire (M)
from the console base assembly (G) to the
wire (N) from the console assembly (L). The
connectors should slide together easily
and snap into place. If they do not, turn one
connector and try again. IF YOU DO NOT
CONNECT THE CONNECTORS PROPERLY,
THE CONSOLE MAY BECOME DAMAGED
WHEN YOU TURN ON THE POWER.
Next, locate the console wire (O) in the console
assembly (L). Connect the console wire to the
Upright Wire (81).
Then, insert the wires (M, N) into the hole in the
Console Base (64). Insert the wires (O, 81) into
the console assembly (L), and position the wires
on the decal.
M
N
G
L
81
64
O
10
11
12
11. Set the console assembly (L) on the brackets on
the console base assembly (G). Do not pinch
any wires. Make sure that the wires (O, 81) are
inserted into the console assembly.
Attach the console assembly (L) with two
5/16" x 1 3/4" Screws (12) and two 5/16" Star
Washers (11); start both Screws, and then
tighten them. Note: Only one side is shown.

14
12. Attach the Small Console Cover (27) with two
#8 x 3/4" Screws (2); do not overtighten the
Screws. Note: Use the outer two holes in the
underside of the console base assembly (G).
12
27
2
P
I
13
2
2
2
8
8
G
13. Tighten the two 5/16" x 3/4" Screws (8).
Then, tighten four #8 x 3/4" Screws (2) into
the right and left handrail assemblies (I, P) in
the locations shown; do not overtighten the
Screws.

15
15
15. Orient the Upright Crossbar (105) as shown.
Carefully slide the Upright Crossbar (105)
between the Left and Right Uprights (89, 90).
Attach the Upright Crossbar (105) with the four
5/16" x 3/4" Patch Screws (4) that you removed
in step 5 and four 5/16" Star Washers (11); start
all four Patch Screws, and then tighten them.
11 411
90 89
105 4
I
14
14
26
R
28
Q
L
14. Firmly tighten the two 5/16" x 2 1/2" Screws (28)
on each side of the handrail assembly (only one
side is shown).
Next, identify the Right Handrail Cover (26).
Insert the tab (Q) on the Right Handrail Cover
into the right handrail assembly (I) in the loca-
tion shown. Then, press the Right Handrail
Cover onto the console assembly (L). The Right
Handrail Cover should snap into the indicated
hole (R).
Then, attach the Right Handrail Cover (26) with
a #8 x 1" Screw (14); do not overtighten the
Screw.
Attach the Left Handrail Cover (not shown)
as described above.

16
17
56
41 S
T
T
4
4
11
11
16
1
105
1
31
16. Insert the Tray (31) from the front of the treadmill
and set it on the Upright Crossbar (105) as
shown.
Attach the Tray (31) to the Upright Crossbar
(105) with four #8 x 1/2" Screws (1); start all
four Screws, and then tighten them.
17. Note: If the treadmill is assembled on a
smooth surface, it may roll forward in this
step.
Remove the two 5/16" x 3/4" Patch Screws (4)
from the Latch Crossbar (41).
Raise the Frame (56) to the upright position.
Have a second person hold the Frame until
step 19 is completed.
Orient the Latch Crossbar (41) as shown.
Make sure that the “This side toward belt”
sticker (S) is facing the treadmill. Attach
the Latch Crossbar to the brackets (T) on the
Frame (56) with the two 5/16" x 3/4" Patch
Screws (4) that you just removed and two 5/16"
Star Washers (11).

17
94
53
6
34
18
18. Remove the 5/16" Nut (34) and the 5/16" x 1 3/4"
Bolt (6) from the bracket on the Base (94).
Next, orient the Storage Latch (53) as shown.
Attach the lower end of the Storage Latch (53)
to the bracket on the Base (94) with the 5/16" x
1 3/4" Bolt (6) and the 5/16" Nut (34) as shown.
Then, raise the Storage Latch (53) to a vertical
position, and remove the tie (U).
U
41
3
56
34
53
19
V
19. Remove the 5/16" Nut (34) and the
5/16" x 2 1/4" Bolt (3) from the bracket on the
Latch Crossbar (41).
Align the upper end of the Storage Latch (53)
with the bracket on the Latch Crossbar (41),
and insert the 5/16" x 2 1/4" Bolt (3) through the
bracket and the Storage Latch. This will push a
spacer (V) out of the Storage Latch; discard
the spacer.
Next, tighten the 5/16" Nut (34) onto the
5/16" x 2 1/4" Bolt (3). Do not overtighten the
Nut; the Storage Latch (53) must be able to
pivot.
Then, lower the Frame (56) (see HOW TO
LOWER THE TREADMILL FOR USE on
page 31).

18
21. Make sure that all parts are properly tightened before you use the treadmill. If there are sheets of plastic
on the treadmill decals, remove the plastic. To protect the floor or carpet, place a mat under the treadmill. To
avoid damage to the console, keep the treadmill out of direct sunlight. Keep the included hex key in a secure
place; the hex key is used to adjust the walking belt (see page 33). Note: Extra hardware may be included.
99
83
82
62
89
7
7
63
62
100
63
20
90 101
101
20. Firmly tighten the four 3/8" x 2 1/4" Screws
(7) and the two 3/8" x 1 1/4" Screws (63).
Next, tighten the two 3/8" x 1 3/4" Screws
(62); the Wheels (101) must turn freely.
Next, set the Left Inner Base Cover (99) onto the
lower end of the Left Upright (89). Slide the Left
Base Cover (82) downward and press it onto the
Left Inner Base Cover.
Then, set the Right Inner Base Cover (100) onto
the lower end of the Right Upright (90). Slide the
Right Base Cover (83) downward and press it
onto the Right Inner Base Cover.
To register your product and activate your
warranty today, go to my.nordictrack.com.

19
HOW TO USE THE TREADMILL
HOW TO CONNECT THE POWER CORD
Use a Surge Suppressor
Your treadmill, like other electronic equipment, can be
damaged by sudden voltage changes in your home’s
power. Voltage surges, spikes, and noise interfer-
ence can result from weather conditions or from other
appliances being turned on or off. To decrease the
risk of damaging the treadmill, always use a surge
suppressor with the treadmill. To purchase a surge
suppressor, see precaution 14 on page 3.
Use only a surge suppressor that is UL 1449 listed as a
transient voltage surge suppressor (TVSS). The surge
suppressor must have a UL suppressed voltage rating
of 400 volts or less and a minimum surge dissipation of
450 joules. The surge suppressor must also be electri-
cally rated for 120 volts AC and 15 amps. There must
be a monitoring light on the surge suppressor to indi-
cate whether it is functioning properly. Failure to use a
properly functioning surge suppressor could result
in damage to the control system of the treadmill
and serious injury to users.
Plug in the Power Cord
The treadmill must be grounded. If it should malfunc-
tion or break down, grounding provides a path of least
resistance for electric current to reduce the risk of elec-
tric shock. The treadmill power cord has a plug with a
grounding pin (see drawing 1 on this page).
Plug the power cord into a surge suppressor, and plug
the surge suppressor into an appropriate outlet that is
properly installed and grounded in accordance with all
local codes and ordinances. The outlet must be on a
nominal 120-volt circuit capable of carrying 15 or
more amps. To avoid overloading the circuit, do
not plug other electrical devices, except for low-
power devices such as cell phone chargers, into
the surge suppressor or into an outlet on the same
circuit. IMPORTANT: If the treadmill is connected to
an AFCI-equipped outlet and your circuit breaker
trips repeatedly when the treadmill is used, see the
front cover of this manual to purchase an arc filter.
A temporary
adapter may
be used to
connect the
surge sup-
pressor to
a 2-pole
receptacle
if a properly
grounded
outlet is not
available.
The lug or wire extending from the adapter must
be connected with a metal screw to a permanent
ground such as a properly grounded outlet box cover.
Some 2-pole receptacle outlet box covers are not
grounded. Before using an adapter, contact a quali-
fied electrician to determine whether the outlet box
cover is grounded. The temporary adapter should
be used only until a properly grounded outlet can
be installed by a qualified electrician.
2
Adapter
2-pole Receptacle
Lug
Metal
Screw
DANGER: Improper connection
of the power cord increases the risk of elec-
tric shock. Do not modify the plug—if it will
not fit an outlet, have a proper outlet installed
by a qualified electrician. If you are unsure
whether the treadmill is properly grounded,
contact a qualified electrician.
1
Surge
Suppressor
Grounding Pin
Grounded Outlet
Grounding Pin

20
CONSOLE DIAGRAM
FEATURES OF THE CONSOLE
The advanced treadmill console offers a selection of
features designed to make your workouts more effec-
tive and enjoyable.
The console features wireless technology that enables
the console to connect to iFit. With iFit, you can access
a large and varied workout library, create your own
workouts, track your workout results, and access many
other features.
When you use the manual mode, you can change
the speed and incline of the treadmill with the touch
of a button. As you exercise, the console will display
instant exercise feedback. You can even measure
your heart rate using the handgrip heart rate monitor.
See page 30 for information about purchasing an
optional chest heart rate monitor.
In addition, the console features a selection of work-
outs. Each workout automatically controls the speed
and incline of the treadmill as it guides you through an
effective exercise session.
You can even listen to your favorite workout music or
audio books with the console’s sound system while you
exercise.
To turn on the power, see page 17. To learn how
to use the touch screen, see page 17. To set up
the console, see page 18.
