Icop PDX-057T-D5A User manual

PDX-057T-D5A / PDX-057T-D5A-512
PDX-057T-D8A / PDX-057T-D8A-512
DM&P Vortex86DX Panel PC
with 5.7” VGA TFT LCD
User’s Manual
(Revision 1.1A)

ii
Copyright
The information in this manual is subject to change without notice for continuous improvement in
the product. All rights are reserved. The manufacturer assumes no responsibility for any
inaccuracies that may be contained in this document. And makes no commitment to update or to
keep current the information contained in this manual.
No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part,
in any form or by any means without the prior written permission of the ICOP Technology Inc.
Copyright 2011 ICOPTechnology Inc.
Manual No. IUMPDX057-01 Ver.1.1A July, 2011
Trademarks Acknowledgment
Vortex86DXis the registered trademark of ICOP Technology Inc. Other brand names or
product names appearing in this document are the properties and registered trademarks of their
respective owners.All names mentioned herewith are served for identification purpose only.

iii
Safety Information
Read these Safety instructions carefully.
Make sure the voltage of the power source is correct before connecting the equipment to
the power outlet.
Do not expose your Panel PC to rain or moisture, in order to prevent shock and fire
hazard.
Keep PDX-057T away from humidity.
Do not open the cabinet to avoid electrical shock. Refer to your nearest dealer for
qualified personnel servicing.
Never touch un-insulated terminals or wire unless your power adaptor is disconnected.
Locate your Panel PC as close as possible to the socket outline for easy access and to
avoid force caused by entangling of your arms with surrounding cables from the Panel
PC.
USB connectors are not supplied with Limited Power Sources.
If the equipment is not used for a long time, disconnect it from the power source to avoid
damage by transient overvoltage.
DO NOTATTEMPT TO OPEN OR TO DISASSEMBLE THE CHASSIS
(ENCASING)OF THIS PRODUCT.PLEASE CONTACT YOUR DEALER FOR
SERVICING FROM QUALIFIED TECHNICIAN.

T a b l e o f C o n t e n t s
T ab l e o f C o n t e nt s.............................................................iv
C h a p t e r 1 General Information..…………………………………1
1.1 Product Description................................................1
1.2 Product Specifications............................................2
1.3 Product Dimension..........................................4
1.4 Ordering Information..............................................5
1.5 Packing List............................................................5
C h a p t e r 2 System Installation.................................................6
2.1 CPU Board Outline.................................................6
2.2 Connector Summary..............................................8
2.3 Connector PinAssignments...................................9
2.4 External I/O Overview..........................................12
2.5 External I/O PinAssignment.................................13
2.6 System Mapping...................................................15
2.7 Watchdog Timver.................................................18
C h a p t e r 3 Driver Installation…..………………………………..19
3.1 PDX-057T Development Note..............................20
3.2 BIOS Defaul Setting.............................................23
Warranty............................................................................................24

v
This page is blank

PDX-057T DM&PVortex86DXPanel PC with 5.7” VGA TFT LCD
1
C h a p t e r 1
General Information
1.1 Product Description
PDX-057T is an ultra compact platform for the present demanding embedded and productive
applications. It has new Vortex86DX SoC CPU which consumes only minimum power
requirement when running at 1GHz, and DDR2 memory provides faster data transfer rate. By
using 5.7” TFT LCD, PDX-057T becomes the perfect choice for a limited budget. In additional,
the integrated 10/100M Ethernet port supplies the communication capability which makes
PDX-057T can be more widely used when running with DOS, Linux, Windows CE, and Windows
XP environment to become the perfect solution for system integration.
5.7” VGATFT LCD
4-Wire Resistive Touch Panel
DM&P Vortex86DX SoC 1GHz
256/512MB DDR2 system memory
AMI BIOS
2 watchdog timer
Compact FlashType I/II / Micro SD
10/100Mbps Ethernet
2 USB 2.0 (host)
1 RS-232/485/422 ports
Mini-PCI Socket (Wi-Fi Optional)
AudioOut
Single voltage +5V DC(5AVersion)
Multi voltage +8~+35V DC(8AVersion)
Fanless Design
Operating temperature range of -20°C
to +60°

PDX-057T DM&PVortex86DXPanel PC with 5.7” VGA TFT LCD 2
1.2 Product Specification
CPU Board Specifications
CPU DM&P Vortex86DX 1GHz
Cache L1:16KB I-Cache, 16KB D-Cache
L2: 128KB Cache
BIOS AMI BIOS
Memory 256/512MB DDR2 onboard
Watchdog Timer Software programmable from 30.5u to 512 seconds x 2 sets
LAN Integrated 10/100M Ethernet
Audio CM119 Line-Out
Internal Drives Compact FlashType I/II slot
Micro SD slot
I/O
RS-232/422/485 x 1
USB ports (Ver2.0) x 2
RJ-45 Port x 1
Expansion Slot Mini-PCI socket x 1 (Internal)
Mechanical & Environment
Power Requirement Single Voltage +5VDC ( 5A)
Multi Voltage +8~+35VDC ( 8A)
Power Consumption 1.3A@5VDC
Operating Temperature
-20 ~ +60 ℃(-4 ~ +140 ℉)
Storage Temperature -30 ~ +70 ℃(-22 ~ +158 ℉)
Dimensions 152 x 112 x 33mm (5.98 x 4.41 x 1.3 inches)
Weight 374g
Certification CE, FCC, VCCI, Vibration

PDX-057T DM&PVortex86DXPanel PC with 5.7” VGA TFT LCD 3
LCD Specifications
Display Type 5.7” TFT LCD
Backlight Unit LED
Display Resolution 640(W) x 480(H)
Brightness (cd/m2) 500 nits
Contrast Ratio 300:1
Display Color 262,144
Dot Pitch (mm) 0.06 x 0.18
Viewing Angle Vertical 100o,
Horizontal 140o
Backlight Lifetime 25,000 hrs
Touchscreen
Type Analog Resistive
Resolution Continuous
Transmittance 80%
Controller USB interface
Software Driver Linux/WinCE/WinXP
Durability 1 million

PDX-057T DM&PVortex86DXPanel PC with 5.7” VGA TFT LCD 4
1.3 Product Dimension

PDX-057T DM&PVortex86DXPanel PC with 5.7” VGA TFT LCD 5
1.4 Ordering Information
Part Number Description
PDX-057T-D5A-512 5.7” Panel PC w/512MB
DDR2/2USB/Line-Out/LAN/COM/CF/MicroSD/PowerAdapter
PDX-057T-D8A-512 5.7” Panel PC w/512MB
DDR2/2USB/Line-Out/LAN/COM/CF/MicroSD/8-35 DC support
PDX-057T-D5A 5.7” Panel PC w/256MB
DDR2/2USB/Line-Out/LAN/COM/CF/MicroSD/PowerAdapter
PDX-057T-D8A 5.7” Panel PC w/256MB
DDR2/2USB/Line-Out/LAN/COM/CF/MicroSD/8-35VDC support
1.5 Packing List
Part Number Package
PDX-057T-D5A-512 PDX-057T-D5A-512
Power-20W-3PIN
PDX-057T-D8A-512 PDX-057T-D8A-512
PDX-057T-D5A PDX-057T-D5A
Power-20W-3PIN
PDX-057T-D8A PDX-057T-D8A
WLAN KIT (Optional) MINI-PCI-WLAN-CARD
WIRELESS-ANTENNA-157
WIRELESS-CABLE-90MM
