DM&P Vortex86DX3 Panel
PC with 9” TFT LCD
Model:
PDX3-090T-5A / PDX3-090T-8A
PDX3-090T-5A-2G / PDX3-090T-8A-2G
User’s Manual
(Revision 1.1A)

i
Revision
Date Version Description
2016/11/18 Version 1.0 Initial Release
2017/01/10 Version 1.1 Specification correction

ii
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
Copyright
The information in this manual is subject to change without notice for
continuous improvement in the product. All rights are reserved. The manufacturer
assumes no responsibility for any inaccuracies that may be contained in this
document. And makes no commitment to update or to keep current the
information contained in this manual.
No part of this manual may be reproduced, copied, translated or transmitted,
in whole or in part, in any form or by any means without the prior written
permission of the ICOP Technology Inc.
Copyright 2017 ICOP Technology Inc.
Manual No. IUMPDX3090-01 Ver.1.1A Jan, 2017
Trademarks Acknowledgment
Vortex86DX3is the registered trademark of DMP Electronics Inc. Other
brand names or product names appearing in this document are the properties and
registered trademarks of their respective owners. All names mentioned herewith
are served for identification purpose only.
Safety Information
Read these Safety instructions carefully.
Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
Do not expose your Panel PC to rain or moisture, in order to prevent shock
and fire hazard.
Keep PDX3-090T away from humidity.
Do not open the cabinet to avoid electrical shock. Refer to your nearest
dealer for qualified personnel servicing.
Never touch un-insulated terminals or wire unless your power adaptor is
disconnected.
Locate your Panel PC as close as possible to the socket outline for easy access
and to avoid force caused by entangling of your arms with surrounding cables
from the Panel PC.
USB connectors are not supplied with Limited Power Sources.
If the equipment is not used for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
DO NOT ATTEMPT TO OPEN OR TO DISASSEMBLE THE CHASSIS (ENCASING)OF THIS
PRODUCT.PLEASE CONTACT YOUR DEALER FOR SERVICING FROM QUALIFIED TECHNICIAN.

iii
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
Table of Contents
Table of Contents............................................................................................. iii
1.General Information ............................................................................. 1
1.1 Product Description............................................................ 1
1.2 Product Specification ......................................................... 2
1.3 Inspection standard for TFT-LCD Panel .............................. 4
1.4 Product Dimension............................................................. 7
1.5 Panel Mounting Instruction................................................ 8
1.6 Ordering Information ....................................................... 10
1.7 Packing List ....................................................................... 11
2.System Installation ............................................................................. 12
2.1 CPU Board Outline............................................................ 12
2.2 Connector Summary......................................................... 13
2.3 Connector Pin Assignments.............................................. 14
2.4 External I/O Overview ...................................................... 16
2.5 External I/O Pin Assignment............................................. 17
2.6 System Mapping............................................................... 19
2.7 Watchdog Timer............................................................... 22
3.Driver Installation ............................................................................... 23
3.1 PDX3-090T Development Note ........................................ 24
3.2 BIOS Default setting ......................................................... 26
Warranty......................................................................................................... 27

1
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
1.General Information
1.1 Product Description
PDX3-090T is an ultra-compact platform for the present demanding
embedded and productive applications. It has new Vortex86DX3 SoC CPU which
consumes only minimum power requirement when running at 1GHz, and DDR3
memory provides faster data transfer rate. By using 9” TFT LCD, PDX3-090T
becomes the perfect choice for a limited budget. In additional, the integrated
10/100M Ethernet port supplies the communication capability which makes
PDX3-090T can be more widely used when running with Linux, Windows CE,
Windows XP, Windows 7, Windows Embedded environments to become the
perfect solution for system integration.

2
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
1.2 Product Specification
Table 1-1 Product Specification
CPU Board Specifications
CPU DM&P Vortex86DX3 - 1GHz
Cache
L1:16KB I-Cache, 16KB D-Cache
L2: 512KB Cache
BIOS AMI BIOS
Memory 1GB/2GB DDR3 onboard
Watchdog Timer
Software programmable from
30.5u to 512 seconds x 2 sets
LAN Integrated 10/100M Ethernet
Audio HD Audio-Realtek ALC262 CODEC
Internal Drives
Compact Flash Type I / II slot
Micro SD slot (Optional)
1GB or 2GB Flash Memory onboard (Optional)
I/O
RS-232/422/485 x 1
USB ports (Ver2.0) x 2
RJ-45 Port x 1
Mechanical & Environment
Power Requirement
Single Voltage +5VDC ( 5A )
Multi Voltage +8~+35VDC ( 8A )
Power Consumption 20W (Max.)
Operating
Temperature
0 ~ +50℃( 32 ~ +122℉) /
-20~+60℃( -4 ~ +140℉) Optional (-I)
Storage Te mp. -30 ~ +70℃( 14 ~ +158℉)

3
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
Operating Humidity 0% ~ 90% relative humidity, non-condensing
Dimensions 236.6 x 146 x 35mm (9.31 x 5.75 x 1.38 inches)
Weight 790g
Front Panel
Protection
IP 65
Certification CE / FCC / VCCI / Vibration / Shock
LCD Specifications
Display Type 9” TFT LCD
Backlight Unit LED
Display Resolution 1024(W) x 600(H)
Brightness (cd/m2) 300 nits
Contrast Ratio 500 : 1
Display Color 262, 144
Pixel Pitch (mm) 190.5 (H) x 189 (V)
Viewing Angle
Vertical 120o,
Horizontal 140o
Backlight Lifetime 18,000 hrs
Touchscreen
Type Analog Resistive
Resolution Continuous
Transmittance 80%
Controller PS / 2 interface
Software Driver
Linux, Win CE, Win XP, Win 7, Windows Embedded
Standard
Durability 1 million

4
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
1.3 Inspection standard for TFT-LCD Panel
Table 1-2 Inspection Standard
DEFECT TYPE LIMIT Note
VISUAL
DEFECT
INTER
NAL
SPOT
φ＜0.15mm Ignore
Note1
0.15mm≦φ≦0.5mm N≦4
0.5mm＜φN=0
FIBER
0.03mm<W≦0.1mm, L≦
5mm N≦3
Note1
1.0mm＜W, 1.5mm＜L N=0
POLARIZER
BUBBLE
φ＜0.15mm Ignore
Note1
0.15mm≦φ≦0.5mm N≦2
0.5mm＜φN=0
Mura It’ OK if mura is slight visible through 6%ND filter
ELECTRICAL
DEFECT
BRIGHT DOT
A Grade B Grade
C
Area
O
Area Total C Area
O
Area Total Note3
N≦0 N≦2 N≦2 N≦2 N≦3 N≦5 Note2
DARK DOT N≦2 N≦3 N≦3 N≦3 N≦5 N≦8
TOTAL DOT N≦4 N≦5 N≦6 N≦8 Note2
TWO ADJACENT DOT N≦0 N≦1
pair
N≦1
pair
N≦1
pair
N≦1
pair
N≦1
pair Note4
THREE OR MORE
ADJACENT DOT NOT ALLOWED
LINE DEFECT NOT ALLOWED
(1) One pixel consists of 3 sub-pixels, including R, G, and B dot.
(Sub-pixel = Dot)
(2) LITTLE BRIGHT DOT ACCEPTITABLE UNDER 6 % ND-Filter
(3) If require G0 grand (Total dot N≦0), please contact region sales.

5
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
[Note 1] W : Width[mm], L : Length[mm], N : Number, φ: Average Diameter.
1. White / Black Spot
2. Polarizer Bubble
Fig 1-1
Fig 1-2
[Note 2] Bright dot is defined through 6% transmission ND Filter as following.
Fig 1-3

6
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
[Note 3]
C Area: Center of display area
O Area: Outer of display area
[Note 4]
Judge defect dot and adjacent dot as following. Allow below (as A, B, C and D
status) adjacent defect dots, including bright and dart adjacent dot. And they will
be counted 2 defect dots in total quantity.
R
R
G
G
R G
R
R
G
G
R G
R
R
G
G
R G
R
R
G
G
R G
R
R
G
G
RG
R
R
G
G
R G
R
RDefect Dot
Adjacent Dot
A
B
C
D
(1) The defects that are not defined above and considered to be problem shall
be reviewed and discussed by both parties.
Defects on the Black Matrix, out of Display area, are not considered as a defect or
counted.

7
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
1.4 Product Dimension
Fig 1-4 Product Dimension

8
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
1.5 Panel Mounting Instruction
1. Cut a mounting hole in the panel. (Refer to PDX3-090T Dimensions
on page 7) (Note 1)
2. Check and remove the twelve M3 screws in a diagonal pattern as
image below if necessary.
3. Place PDX3-090T face-down on a clean, flat surface.
4. Slide the panel cutout around the back of PDX3-090T, until the panel
rests directly on the gasket. Make sure the screw holes align with the
screw holes on PDX3-090T.
5. The screw size is M3*L (L=wall thickness + 6.0mm) (Note 2)
6. Insert all twelve M3 screws into the screw holes. (Note 2)
7. Finger-tighten the M3 screws. Finish tightening the M3 screws in a
diagonal pattern using an M3 screw driver (see the image as below);
maximum torque 1.18Nm (12 kgf-cm).

9
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
Note 1:
It is strongly recommended that a professional machine shop cut the
mounting hole in the panel.
Note 2:
The length for all twelve M3 screws will be according to the thickness of
mounting panel. For example: The length of standard M3 screws for PDX3-090T
is 6mm. If the thickness of your mounting panel is 3mm and washer thickness is
1mm, you have to use 10mm M3 screw.

10
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
1.6 Ordering Information
Table 1-3 Ordering Information
PART NUMBER DESCRIPTION
PDX3-090T-5A 9” Panel PC w/1GB DDR3
/ 2USB / Line-Out / LAN / COM / CF / MicroSD /
Power Adapter
PDX3-090T-8A 9” Panel PC w/1GB DDR3
/ 2USB / Line-Out / LAN / COM / CF / MicroSD /
8-35 DC Support
PDX3-090T-5A-2G 9” Panel PC w/2GB DDR3
/ 2USB / Line-Out / LAN / COM / CF / MicroSD /
Power Adapter
PDX3-090T-8A-2G 9” Panel PC w/2GB DDR3
/ 2USB / Line-Out / LAN / COM / CF / MicroSD /
8-35 DC Support
PDX3-090T-5A-I9” Panel PC w/1GB DDR3 / Wide Temp.
/ 2USB / Line-Out / LAN / COM / CF / MicroSD /
Power Adapter
PDX3-090T-8A-I9” Panel PC w/1GB DDR3 / Wide Temp.
/ 2USB / Line-Out / LAN / COM / CF / MicroSD /
8-35 DC Support
PDX3-090T-5A-2G-I9” Panel PC w/2GB DDR3 / Wide Temp.
/ 2USB / Line-Out / LAN / COM / CF / MicroSD /
Power Adapter
PDX3-090T-8A-2G-I9” Panel PC w/2GB DDR3 / Wide Temp.
/ 2USB / Line-Out / LAN / COM / CF / MicroSD /
8-35 DC Support

11
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
1.7 Packing List
Table 1-4 Packing List
PART NUMBER PACKAGE
PDX3-090T-5A PDX3-090T-5A Power-20W-3PIN
PDX3-090T-8A PDX3-090T-8A
PDX3-090T-5A-2G PDX3-090T-5A-2G Power-20W-3PIN
PDX3-090T-8A-2G PDX3-090T-8A-2G
PDX3-090T-5A-IPDX3-090T-5A-IPower-20W-3PIN
PDX3-090T-8A-IPDX3-090T-8A-I
PDX3-090T-5A-2G-IPDX3-090T-5A-2G-IPower-20W-3PIN
PDX3-090T-8A-2G-IPDX3-090T-8A-2G-I
WLAN KIT (Optional) USB-WLAN-IPEX-KIT
WIRELESS-ANTENNA-157
WIRELESS-CABLE-150MM

12
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
2.System Installation
2.1 CPU Board Outline
Fig 2-1 PDX3 CPU Board

13
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
2.2 Connector Summary
Table 2-1 Summary Table
Nbr Description Type of Connections Pin nbrs.
J1 CF Master/Slave Switch Slide Switch ON/OFF
J3 USB External USB Connector 6-pin
J4 USB External USB Connector 6-pin
J5 USB (Optional) 2.0mm 5-pin wafer 5-pin
J8 PS/2 Keyboard 2.54mm 5-pin box header 5-pin
J9 PS/2Keyboard External Mini DIN Socket 6-pin
J10 COM1(RS232/422/485) External D-Sub Male Connector 9-pin
J14 VGA 2.0mm 10-pin box header 10-pin
J18 Micro SD Card Socket
(Optional)
Micro SD socket
J23 Audio Line-Out 1.25mm Phone Jack
J24 Audio Mic-In 2.0mm 4-pin wafer 4-pin
J25 COM3 (TX, RX) 1.25mm 3-pin wafer 3-pin
J26 COM4 (TX, RX) 1.25mm 3-pin wafer 3-pin
J30 SOM CPU Board Socket SOM CPU Board Socket 200-pin
J31 4-Wires Touch connector 1.25mm 4-pin wafer 4-pin
J32 USB (WLAN Optional) Internal USB Connector 6-pin
RJ45 Ethernet External RJ45 Connector 8-pin
PWR Power Connector (5A) External Mini DIN Socket 3-pin
PWR Power Connector (8A) External Power Plug 2-pin
CF1 CF Card Socket CF Type I/II Socket

14
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
2.3 Connector Pin Assignments
J1: CF Master/Slave Switch
J3: USB
Pin # Signal Name Pin # Signal Name
1 VCC 2 USBD2-
3 USBD2+ 4 GND
5 GND 6 GND
J4: USB
Pin # Signal Name Pin # Signal Name
1 VCC 2 USBD3-
3 USBD3+ 4 GND
5 GND 6 GND
J5: USB (Optional)
Pin # Signal Name
1 VCC
2 USBD1-
3 USBD1+
4 GND
5 GND
J8: PS/2 Keyboard
Pin # Signal Name Pin # Signal Name
1 KBCLK 2 KBDAT
3 NC 4 GND
5 VCC
J9: PS/2 Keyboard
Pin # Signal Name Pin # Signal Name
1 KBCLK 2 MSCLK
3 GND 4 KBDATA
5 MSDATA 6 VCC
7 GND 8 GND
9 GND
J10: COM1 RS232/422/485
(Change setting by BIOS)
Pin # Signal Name Pin # Signal Name
1
DCD1/
422TX- /
RS485-
2
RXD1 /
422TX+ /
RS485+
3
TXD1 /
422RX+
4
DTR1 /
422RX-
5 GND 6 DSR1
7 RTS1 8 CTS1
9 RI1
Pin # Signal Name
On Master
OFF Slave

15
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
J14: VGA
Pin # Signal Name Pin # Signal Name
1 R OUT 2 GND
3 G OUT 4 GND
5 B OUT 6 GND
7 HSYNC 8 GND
9 VSYNCD 10 GND
J24: MIC-IN
Pin # Signal Name
1 MICVREF
2 GND
3 GND
4 MIC-IN
J25: COM3 (TX, RX)
Pin # Signal Name
1 GND
2 TXD3
3 RXD3
J26: COM4 (TX, RX)
Pin # Signal Name
1 GND
2 TXD4
3 RXD4
J31: 4-Wires Touch connector
Pin # Signal Name
1 Y-
2 X-
3 Y+
4 X+
J32: USB (WLAN Optional)
Pin # Signal Name Pin # Signal Name
1 VCC 2 USBD2-
3 USBD2+ 4 GND
5 GND 6 GND
PWR: Power Connector (5A)
Pin # Signal Name
1 +5V
2 GND
3 NC
4 GND
PWR: Power Connector (8A)
Pin # Signal Name
1 + 8 ~ 35V
2 GND

16
PDX3-090TDM&P Vortex86DX3 Panel PC with 9” WSVGA TFT LCD
2.4 External I/O Overview
{ PDX3-090T-8A / PDX3-090T-8A-2G }
Fig 2-2 PDX3-090T-8A I/O overview
{ PDX3-090T-5A / PDX3-090T-5A-2G }
Fig 2-3 PDX3-090T-5A I/O overview
{Note}
1. WLAN is optional
2. COM1 RS232/422/485 is selected by BIOS setting
3. MicroSD Socket is optional (Either one of CF or Micro SD)
