Icop PMX-090T-5A User manual

i
DM&P Vortex86MX+
Panel PC with 9” TFT LCD
Model:
PMX-090T-5A / PMX-090T-8A
PMX-090T-5A-512 / PMX-090T-8A-512
(Revision 1.0A)

i
Revision
Date Version Description
2012/11/20 Version 1.0 Initial Release

ii
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
Copyright
The information in this manual is subject to change without notice for
continuous improvement in the product. All rights are reserved. The manufacturer
assumes no responsibility for any inaccuracies that may be contained in this
document. And makes no commitment to update or to keep current the
information contained in this manual.
No part of this manual may be reproduced, copied, translated or transmitted,
in whole or in part, in any form or by any means without the prior written
permission of the ICOP Technology Inc.
Copyright 2012 ICOP Technology Inc.
Manual No. IUMPMX090-01 Ver. 1.0A Nov, 2012
Trademarks Acknowledgmen
Vortex86MXis the registered trademark of ICOP Technology Inc. Other
brand names or product names appearing in this document are the properties and
registered trademarks of their respective owners. All names mentioned herewith
are served for identification purpose only.
Safety Information
Read these Safety instructions carefully.
Make sure the voltage of the power source is correct before connecting the
equipment to the power outlet.
Do not expose your Panel PC to rain or moisture, in order to prevent shock
and fire hazard.
Keep PMX-090T away from humidity.
Do not open the cabinet to avoid electrical shock. Refer to your nearest
dealer for qualified personnel servicing.
Never touch un-insulated terminals or wire unless your power adaptor is
disconnected.
Locate your Panel PC as close as possible to the socket outline for easy access
and to avoid force caused by entangling of your arms with surrounding cables
from the Panel PC.
USB connectors are not supplied with Limited Power Sources.
If the equipment is not used for a long time, disconnect it from the power
source to avoid damage by transient overvoltage.
DO NOT ATTEMPT TO OPEN OR TO DISASSEMBLE THE CHASSIS (ENCASING)OF THIS
PRODUCT.PLEASE CONTACT YOUR DEALER FOR SERVICING FROM QUALIFIED TECHNICIAN.

iii
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
Table of Contents
1 General Information .............................................................................. 3
1.1 Product Description...................................................... 1
1.2 Product Specification ................................................... 2
1.3 Inspection standard for TFT-LCD Panel ........................ 4
1.4 Product Dimension....................................................... 7
1.5 Ordering Information ................................................... 8
1.6 Packing List ................................................................... 8
2System Installation ................................................................................ 9
2.1 CPU Board Outline........................................................ 9
2.2 Connector Summary .................................................. 10
2.3 Connector Pin Assignments........................................ 11
2.4 External I/O Overview ................................................ 13
2.5 External I/O Pin Assignment....................................... 14
2.6 System Mapping......................................................... 16
2.7 Watchdog Timer ......................................................... 20
3Driver Installation ................................................................................ 21
3.1 PMX-090T Development Note ................................... 22
3.2 BIOS Default setting ................................................... 24
Warranty......................................................................................................... 25

1
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
1.General Information
1.1 Product Description
PMX-090T is an ultra-compact platform for the present demanding
embedded and productive applications. It has new Vortex86MX SoC CPU which
consumes only minimum power requirement when running at 1GHz, and DDR2
memory provides faster data transfer rate. By using 9” TFT LCD, PMX-090T
becomes the perfect choice for a limited budget. In additional, the integrated
10/100M Ethernet port supplies the communication capability which makes
PMX-090T can be more widely used when running with Linux, Windows CE, and
Windows XP environment to become the perfect solution for system integration.

2
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
1.2 Product Specification
Table 1-1 Product Specification
CPU Board Specifications
CPU DM&P Vortex86MX+ 1GHz
Cache
L1:16KB I-Cache, 16KB D-Cache
L2: 256KB Cache
BIOS AMI BIOS
Memory 512MB/1GB DDR2 onboard
Watchdog Timer
Software programmable from
30.5u to 512 seconds x 2 sets
LAN Integrated 10/100M Ethernet
Audio HD Audio-Realtek ALC262 CODEC
Internal Drives
Compact Flash Type I / II slot
Micro SD slot
1GB or 2GB Flash Memory onboard (Optional)
I/O
RS-232/422/485 x 1
USB ports (Ver2.0) x 2
RJ-45 Port x 1
Mechanical & Environment
Power Requirement
Single Voltage +5VDC ( 5A )
Multi Voltage +8~+35VDC ( 8A )
Power Consumption 1.5A@5VDC
Operating
Temperature 0 ~ +50℃( 32 ~ +122℉)
Storage
Temperature -10 ~ +60℃( 14 ~ +140℉)

3
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
Operating Humidity 0% ~ 90% relative humidity, non-condensing
Dimensions 236.6 x 146 x 35mm (9.31 x 5.75 x 1.38 inches)
Weight 468g
Front Panel
Protection
IP 65
Certification CE / FCC / VCCI / Vibration
LCD Specifications
Display Type 9” TFT LCD
Backlight Unit LED
Display Resolution 1024(W) x 600(H)
Brightness (cd/m2) 300 nits
Contrast Ratio 500 : 1
Display Color 262, 144
Pixel Pitch (mm) 190.5 (H) x 189 (V)
Viewing Angle
Vertical 120o,
Horizontal 140o
Backlight Lifetime 25,000 hrs
Touchscreen
Type Analog Resistive
Resolution Continuous
Transmittance 80%
Controller PS / 2 interface
Software Driver DOS / Linux / WinCE / WinXP
Durability 1 million

4
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
1.3 Inspection standard for TFT-LCD Panel
Table 1-2 Inspection Standard
DEFECT TYPE LIMIT Note
VISUAL
DEFECT
INTER
NAL
SPOT
φ＜0.15mm Ignore
Note1
0.15mm≦φ≦0.5mm N≦4
0.5mm＜φN=0
FIBER
0.03mm<W≦0.1mm, L≦
5mm N≦3
Note1
1.0mm＜W, 1.5mm＜L N=0
POLARIZER
BUBBLE
φ＜0.15mm Ignore
Note1
0.15mm≦φ≦0.5mm N≦2
0.5mm＜φN=0
Mura It’ OK if mura is slight visible through 6%ND filter
ELECTRICAL
DEFECT
BRIGHT DOT
A Grade B Grade
C
Area
O
Area Total C Area
O
Area Total Note3
N≦0 N≦2 N≦2 N≦2 N≦3 N≦5 Note2
DARK DOT N≦2 N≦3 N≦3 N≦3 N≦5 N≦8
TOTAL DOT N≦4 N≦5 N≦6 N≦8 Note2
TWO ADJACENT DOT N≦0 N≦1
pair
N≦1
pair
N≦1
pair
N≦1
pair
N≦1
pair Note4
THREE OR MORE
ADJACENT DOT NOT ALLOWED
LINE DEFECT NOT ALLOWED
(1) One pixel consists of 3 sub-pixels, including R, G, and B dot.
(Sub-pixel = Dot)
(2) LITTLE BRIGHT DOT ACCEPTITABLE UNDER 6 % ND-Filter
(3) If require G0 grand (Total dot N
≦
0), please contact region sales.

5
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
[Note 1] W : Width[mm], L : Length[mm], N : Number, φ: Average Diameter.
1. White / Black Spot
2. Polarizer Bubble
Fig 1-1
Fig 1-2
[Note 2] Bright dot is defined through 6% transmission ND Filter as following.
Fig 1-3

6
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
[Note 3]
C Area: Center of display area
O Area: Outer of display area
[Note 4]
Judge defect dot and adjacent dot as following. Allow below (as A, B, C and D
status) adjacent defect dots, including bright and dart adjacent dot. And they will
be counted 2 defect dots in total quantity.
R
R
G
G
Ｂ
Ｂ
R GＢ
R
R
G
G
Ｂ
Ｂ
RGＢ
R
R
G
G
Ｂ
Ｂ
R GＢ
R
R
G
G
Ｂ
Ｂ
RGＢ
R
R
G
G
Ｂ
Ｂ
R GＢ
R
R
G
G
Ｂ
Ｂ
RGＢ
R
RDefect Dot
Adjacent Dot
A
B
C
D
(1) The defects that are not defined above and considered to be problem shall
be reviewed and discussed by both parties.
Defects on the Black Matrix, out of Display area, are not considered as a defect or
counted.

7
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
1.4 Product Dimension
Fig 1-4 Product Dimension

8
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
1.5 Ordering Information
Table 1-3 Ordering Information
PART NUMBER DESCRIPTION
PMX-090T-5A 9” Panel PC w/1GB
DDR2 / 2USB / Line-Out / LAN / COM / CF / MicroSD /
Power Adapter
PMX-090T-8A 9” Panel PC w/1GB
DDR2 / 2USB / Line-Out / LAN / COM / CF / MicroSD /
8-35 DC Support
PMX-090T-5A-512 9” Panel PC w/512MB
DDR2 / 2USB / Line-Out / LAN / COM / CF / MicroSD /
Power Adapter
PMX-090T-8A-512 9” Panel PC w/512MB
DDR2 / 2USB / Line-Out / LAN / COM / CF / MicroSD /
8-35 DC Support
1.6 Packing List
Table 1-4 Packing List
PART NUMBER PACKAGE
PMX-090T-5A PMX-090T-5A Power-20W-3PIN
PMX-090T-8A PMX-090T-8A
PMX-090T-5A-512 PMX-090T-5A-512 Power-20W-3PIN
PMX-090T-8A-512 PMX-090T-8A-512
WLAN KIT (Optional) USB-WLAN-IPEX-KIT WIRELESS-
ANTENNA-157
WIRELESS-
CABLE-150MM

9
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.System Installation
2.1 CPU Board Outline
Fig 2-1 PMX CPU Board

10
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.2 Connector Summary
Table 2-1 Summary Table
Nbr Description Type of Connections Pin nbrs.
J1 CF Master/Slave Switch Slide Switch ON/OFF
J3 USB External USB Connector 6-pin
J4 USB External USB Connector 6-pin
J5 USB (Optional) 2.0mm 5-pin wafer 5-pin
J8 PS/2 Keyboard 2.54mm 5-pin box header 5-pin
J9 PS/2Keyboard External Mini DIN Socket 6-pin
J10 COM2(RS232/422/485) External D-Sub Male Connector 9-pin
J14 VGA 2.0mm 10-pin box header 10-pin
J18 Micro SD Card Socket Micro SD socket
J23 Audio Line-Out 1.25mm Phone Jack
J24 Audio Mic-In 2.0mm 4-pin wafer 4-pin
J25 COM3 (TX, RX) 1.25mm 3-pin wafer 3-pin
J26 COM4 (TX, RX 1.25mm 3-pin wafer 3-pin
J30 SOM CPU Board Socket SOM CPU Board Socket 200-pin
J31 4-Wires Touch connector 1.25mm 4-pin wafer 4-pin
J32 USB (Wi-Fi Optional) Internal USB Connector 6-pin
RJ45 Ethernet External RJ45 Connector 8-pin
PWR Power Connector (5A) External Mini DIN Socket 3-pin
PWR Power Connector (8A) External Power Plug 2-pin
CF1 CF Card Socket CF Type I/II Socket

11
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.3 Connector Pin Assignments
J1: CF Master/Slave Switch
J3: USB
Pin #
Signal Name Pin #
Signal Name
1 VCC 2 USBD2-
3 USBD2+ 4 GND
5 GND 6 GND
J4: USB
Pin #
Signal Name Pin #
Signal Name
1 VCC 2 USBD3-
3 USBD3+ 4 GND
5 GND 6 GND
J5: USB (Optional)
Pin # Signal Name
1 VCC
2 USBD1-
3 USBD1+
4 GND
5 GND
J8: PS/2 Keyboard
Pin # Signal Name Pin # Signal Name
1 KBCLK 2 KBDAT
3 NC 4 GND
5 VCC
J9: PS/2 Keyboard/Mouse
Pin # Signal Name Pin # Signal Name
1 KBCLK 2 MSCLK
3 GND 4 KBDATA
5 MSDATA 6 VCC
7 GND 8 GND
9 GND
J10: COM1 RS232/422/485
(Change setting by BIOS)
Pin # Signal Name Pin # Signal Name
1
DCD1/
422TX- /
RS485-
2
RXD1 /
422TX+ /
RS485+
3
TXD1 /
422RX+
4
DTR1 /
422RX-
5 GND 6 DSR1
7 RTS1 8 CTS1
9 RI1
Pin # Signal Name
On Master
OFF Slave

12
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
J14: VGA
Pin # Signal Name Pin # Signal Name
1 R OUT 2 GND
3 G OUT 4 GND
5 B OUT 6 GND
7 HSYNC 8 GND
9 VSYNCD 10 GND
J24: MIC-IN
Pin # Signal Name
1 MICVREF
2 GND
3 GND
4 MIC-IN
J25: COM3 (TX, RX)
Pin # Signal Name
1 GND
2 TXD3
3 RXD3
J26: COM4 (TX, RX)
Pin # Signal Name
1 GND
2 TXD4
3 RXD4
J31: 4-Wires Touch connector
Pin # Signal Name
1 Y-
2 X-
3 Y+
4 X+
J32: USB (WiFi Optional)
Pin # Signal Name
Pin # Signal Name
1 VCC 2 USBD2-
3 USBD2+ 4 GND
5 GND 6 GND
PWR: Power Connector (5A)
Pin # Signal Name
1 +5V
2 GND
3 NC
4 GND
PWR: Power Connector (8A)
Pin # Signal Name
1 + 8 ~ 35V
2 GND

13
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.4 External I/O Overview
{ PMX-090T-8A / PMX-090T-8A-512 }
Fig 2-2 PMX-090T-8A I/O overview
{ PMX-090T-5A / PMX-090T-5A-512 }
Fig 2-3 PMX-090T-5A I/O overview
{Note}
1. Wireless is optional
2. COM1 RS232/422/485 is selected by BIOS setting)

14
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.5 External I/O Pin Assignment
Power Switch
Pin # Status
| ON
O OFF
Power Connector (5A)
Pin # Signal Name
1 +5V
2 GND
3 NC
Power Connector (8A)
Pin # Signal Name
1 +8 ~ 35V
2 GND
Audio Line-Out
Pin # Signal Name
1 GND
2 LOUTL
3 Open Touch
4 Open Touch
5 VREFOUT
USB
Pin # Signal Name
1 VCC
2 USB0-
3 USB0+
4 GND
5 GGND
6 GGND
PS/2 Keyboard/Mouse
Pin # Signal Name
1 KBCLK
2 PMCLK
3 GND
4 KBDAT
5 PMDAT
6 SB5V

15
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
J10: COM1 RS232/422/485 (Change setting by BIOS)
Pin # Signal Name Pin # Signal Name
1 DCD1/422TX-/RS485-
2 RXD1/422TX+/RS485+
3 TXD1 / 422RX+ 4 DTR1 / 422RX-
5 GND 6 DSR1
7 RTS1 8 CTS1
9 RI1
RJ45
Pin # Signal Name Pin # Signal Name
1 FTXD+ 2 FTXD-
3 FRXIN+ 4 NC
5 NC 6 FRXIN-
7 NC 8 NC

16
PMX-090TDM&P Vortex86MX+ Panel PC with 9” WSVGA TFT LCD
2.6 System Mapping
Table 2-2 Technical Data Sheet
Technical Data Sheet
Product Name PMX-090T-8A DM171CDoc.No. QMT1000014R00
Product
Description
9”
Vortex86MX Panel PC with 1GB
DDR2 / 2USB / Line-out
/ LAN / 1COM / CF / MicroSD
Doc. Category Confidential
Issued Date 10-08-2012
System Mapping
Memory Mapping
Address Description Usage
00000000-0009FFFF System RAM *
000A0000-000AFFFF EGA/VGA Video Memory *
000B0000-000B7FFF MDA RAM, Hercules Graphics
Display RAM
*
000B8000-000BFFFF CGA Display RAM *
000C0000-000C7FFF EGA/VGA BIOS ROM *
000C8000-000CFFFF Boot ROM Enable
000CC000-000CFFFF Console Redirection Enable
000D0000-000D7FFF Expansion ROM Space
000D8000-000DBFFF
SPI FLASH Emulation Floppy A
Enable
000DC000-000DFFFF Expansion ROM Space
000E0000-000EFFFF USB Legacy SCSI ROM Space
000F0000-000FFFFF Motherboard BIOS *
FEBD9000-FEBD90FF Standard Open
HCD USB Host
Controller
*
FEBDA000-FEBDA0FF Standard Open
HCD USB Host
Controller
*
FEBDB400-FEBDB4FF On board Ethernet Adapter *
