IDK FDX-S Series User manual

Modular Matrix Switcher
FDX-S Series
FDX- S16U / S32U
FDX- S16 / S32
<User Guide>
Ver.1.0.0
⚫Thank you for choosing our product.
⚫To ensure the best performance of this product, please read this user guide fully and carefully before
using it and keep this manual together with the product for future reference as needed.
IDK Corporation

FDX-S Series User Guide
2
Trademarks
⚫Blu-ray Disc and Blu-ray are trademarks of Blu-ray Disc Association.
⚫ETHERNET is a registered trademark of Fuji Xerox Co., Ltd.
⚫Javascript®is a trademark or registered trademark of Oracle Corporation, its subsidiaries, and affiliated
companies in the United States and other countries.
⚫HDBaseT™ and the HDBaseT Alliance Logo are trademarks of the HDBaseT Alliance.
⚫The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
⚫Microsoft, Windows, Internet Explorer are either registered trademarks or trademarks of the Microsoft
Corporation in the United States and other countries.
⚫The terms Mozilla and Firefox, and their logos are registered trademarks or trademarks of Mozilla
Foundation in the United States and other countries.
⚫Oracle and Java are trademarks of Oracle Corporation its subsidiaries, and affiliated companies in the
United States and other countries.
⚫The terms Anti-snow and Connection Reset are registered trademarks of IDK Corporation in Japan.
⚫All other company and product names mentioned in this manual are either registered trademarks or
trademarks of their respective owners. In this manual, the “®” or “™” marks may not be specified.

FDX-S Series User Guide
3
Before reading this manual
⚫All rights reserved.
⚫Some information contained in this User guide such as exact product appearance, diagrams, menu
operations, and so on may differ depending on the product version.
⚫This User guide is subject to change without notice. You can download the latest version from IDK’s
website at: http://www.idkav.com
The reference manual consists of the following two volumes:
■User guide (this document):
Provides explanations and procedures for operations, installation, connections among devices,
I/O adjustment and settings.
■Command guide: Please download the command guide from the website above.
Provides explanations and procedures for external control using RS-232C and LAN communications.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in accordance with the instruction
manual, may cause harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference, in which case the user will be required to correct the
interference at his own expense.
CE MARKING
This equipment complies with the essential requirements of the relevant European health, safety and
environmental protection legislation.
WEEE MARKING
Waste Electrical and Electronic Equipment (WEEE), Directive 2002/96/EC
(This directive is only valid in the EU.)
This equipment complies with the WEEE Directive (2002/96/EC) marking requirement.
The left marking indicates that you must not discard this electrical/electronic equipment in
domestic household waste.

FDX-S Series User Guide
4
Safety Instructions
Read and understand all safety and operating instructions before using this product. Follow all instructions
and heed all warnings/cautions.
Enforcement Symbol
Description
Indicates the presence of a hazard that may result in death or serious
personal injury if the warning is ignored or the product is handled
incorrectly.
Indicates the presence of a hazard that may cause minor personal
injury or property damage if the caution is ignored or the product is
handled incorrectly.
Symbol
Description
Example
Caution
This symbol is intended to alert the user. (Warning and caution)
Electrical
Hazard
Prohibited
This symbol is intended to prohibit the user from specified actions.
Do not
disassemble
Instruction
This symbol is intended to instruct the user.
Unplug
Warning
Caution

FDX-S Series User Guide
5
■For lifting heavy products:
Instruction
●Lifting must be done by two or more personnel.
To avoid injury: When lifting the product, bend your knees, keep your back straight and get close to it with two
or more persons.
■For installing and connecting products:
Prohibited
●Do not place the product upon a surface that may give way or that may become
unstable.
Install the product in a secure and stable place to prevent it from falling and possibly causing injury.
●Secure the product if installing in locations prone to vibration or movement.
Otherwise, it may move unexpectedly or it may fall and lead to injury.
Instruction
●Installation work must be performed by professionals.
The product is intended to be installed by skilled technicians. For installation, please contact a system integrator
or IDK. Improper installation may lead to the risk of fire, electric shock, injury, or property damage.
●Insert the power plug into an outlet that is unobstructed.
Unobstructed access to the plug enables unplugging the product in case of any extraordinary failure, abnormal
situation or for easy disconnection during extended periods of non-use.
●Insert the power plug into an appropriate outlet completely.
If the plug is partially inserted, arching may cause the connection to overheat, increasing the risk of electrical
shock or fire. Do not use a damaged plug or connect to a damaged outlet.
●Unplug the product from the AC power source during installation or service.
When connecting peripheral devices to this product, unplug all involved devices from outlets. Ground potential
differences may cause fire or other difficulties.
■For operating products:
Prohibited
●Keep out any foreign objects.
To avoid fire or electric shock, do not permit foreign objects, such as metal and paper, to enter the product from
vent holes or other apertures.
●For power cable/ plug:
・Do not scratch, heat, or modify, including splicing or lengthening them.
・Do not pull, place heavy objects on them, or pinch them.
・Do not bend, twist, tie or clamp them together forcefully.
Misuse of the power cable and plug may cause fire or electric shock. If power cables/plugs become damaged,
contact your IDK representative.
Do not
disassemble
●Do not repair, modify or disassemble.
Since the product includes circuitry that uses potentially lethal, high voltage levels, disassembly by
unauthorized personnel may lead to the risk of fire or electric shock. For internal inspection or repair, contact
your IDK representative.
Do not touch
●Do not touch the product and connected cables during electrical storms.
Contact may cause electric shock
Instruction
●Clean the power plug regularly.
If the plug is covered in dust, it may increase the risk of firer.
Warning

FDX-S Series User Guide
6
■If the following problem occurs:
Unplug
●Unplug immediately if the product smokes, makes unusual noise, or produces a
burning odor.
If you continue to use the product under these conditions, it may cause electric shock or fire.
●Unplug immediately if the product is damaged by falling or having been dropped.
If you continue to use the product under these conditions, it may increase the risk of electrical shock or fire. For
maintenance and repair, contact your IDK representative.
●Unplug immediately if water or other objects are directed inside.
If you continue to use the product under these conditions, it may increase the risk of electrical shock or fire. For
maintenance and repair, contact your IDK representative.
Warning

FDX-S Series User Guide
7
■For installing and connecting products:
Prohibited
●Do not place the product in a location where it will be subjected to high
temperatures.
If the product is subjected to direct sunlight or high temperatures while under operation, it may affect the
product’s performance and reliability and may increase the risk of fire.
●Do not store or operate the product in dusty, oil smoke filled, or humid place.
If the product is placed near humidifiers or in a dusty area, it may increase the risk of fire or electric shock.
●Do not block the vent holes.
If ventilation slots are blocked, it may cause the product to overheat, affecting performance and reliability and
may increase the risk of fire.
●Do not place or stack heavy items on the product.
Failure to observe this precaution may result in damage to the product and other property and may lead to the
risk of personal injury.
●Do not exceed ratings of outlet and wiring devices.
Exceeding the rating of an outlet may increase the risk of fire and electric shock.
No wet hands
●Do not handle power plug with wet hands.
Failure to observe this precaution may increase the risk of electrical shock.
Instruction
●Use and store the product within the specified temperature/humidity range.
If the product is used outside the specified range for temperature and humidity continuously, it may increase the
risk of fire or electric shock.
●Do not place the product at elevations of 1.24 mi. (2,000 m) or higher above sea
level.
Failure to do so may shorten the life of the internal parts and result in malfunctions.
●When mounting the product into the rack, provide sufficient cooling space.
Mount the product in a rack meeting EIA standards, and maintain spaces above and below for air circulation.
For your safety as required, attach an L-shaped bracket in addition to the panel mount bracket kit to improve
mechanical stability.
●Never insert screws without the rubber feet into the threaded holes on the
bottom of the product.
Never insert screws without the rubber feet into the threaded holes on the bottom of the product. Doing so may
lead to damage when the screws contact electrical circuitry or components inside the product.
Reinstall the originally supplied rubber feet using only the originally supplied screws.
■For operating products:
Prohibited
●Use only the supplied power cable and AC adapter.
●Do not use the supplied power cable and AC adapter with other products.
If non-compliant adapter or power cables are used, it may increase the risk of fire or electrical shock.
Unplug
●If the product won’t be used for an extended period of time, unplug it.
Failure to observe this precaution may increase the risk of fire.
●Unplug the product before cleaning.
To prevent electric shock.
Instruction
●If cooling fan stops, power off the product and contact us.
Failure to do so may rise internal temperature and increase the risk of malfunction, fire, or electric shock.
●Clean the vent holes regularly.
If the vent holes of the cooling fan is covered in dust, internal temperature rises and it may increase the risk of
malfunction, fire, or electric shock.
Caution

FDX-S Series User Guide
8
Table of Contents
1 About this Guide ........................................................................................................................................... 12
2 Included items............................................................................................................................................... 13
3 About FDX-S Module Matrix Switchers ........................................................................................................ 14
4 Features........................................................................................................................................................ 15
5 Panels........................................................................................................................................................... 17
5.1 Frame..................................................................................................................................................... 17
5.1.1 FDX-S16U/S16................................................................................................................................ 17
5.1.2 FDX-S32U/S32................................................................................................................................ 19
5.2 I/O boards .............................................................................................................................................. 21
5.3 Redundant power supply unit ................................................................................................................ 22
6 System Configuration Example .................................................................................................................... 23
7 Installation..................................................................................................................................................... 24
7.1 Precautions ............................................................................................................................................ 24
7.2 Rack mounting brackets ........................................................................................................................ 24
8 Connection Details........................................................................................................................................ 25
8.1 Precautions ............................................................................................................................................ 25
8.2 Connecting video devices...................................................................................................................... 25
8.2.1 Securing HDMI cable ...................................................................................................................... 26
8.2.2 HDBaseT input and output connectors ........................................................................................... 26
8.2.3 Category cable ................................................................................................................................ 27
8.2.4 Coaxial cable................................................................................................................................... 28
8.3 Connecting control devices.................................................................................................................... 29
8.3.1 RS-232C communication ................................................................................................................ 30
8.3.2 LAN communication ........................................................................................................................ 30
8.3.3 Alarm............................................................................................................................................... 31
8.4 Connecting power cord.......................................................................................................................... 31
9 Operation...................................................................................................................................................... 32
9.1 Powering on/off...................................................................................................................................... 32
9.2 Front panel operations........................................................................................................................... 33
9.2.1 Selecting menu................................................................................................................................ 33
9.2.2 Video switching ............................................................................................................................... 34
9.2.3 Recalling crosspoint ........................................................................................................................ 38
9.2.4 Front panel security lockout ............................................................................................................ 39
9.2.5 Initialization...................................................................................................................................... 40
9.3 WEB browser operations ....................................................................................................................... 41
9.3.1 Starting WEB browser..................................................................................................................... 41
9.3.2 Normal/Advanced menu.................................................................................................................. 42
9.3.3 Editing crosspoint name.................................................................................................................. 42
9.3.4 Registering bitmap .......................................................................................................................... 43
9.3.5 Automatic reload ............................................................................................................................. 44
9.3.6 Saving/Restoring settings................................................................................................................ 44
9.3.7 Initialization...................................................................................................................................... 45
10 Configuration and Control........................................................................................................................... 46
10.1 Menu .................................................................................................................................................... 46
10.1.1 Normal setting menu ..................................................................................................................... 47
10.1.2 Advanced setting menu................................................................................................................. 48
10.2 Displaying crosspoint........................................................................................................................... 51

FDX-S Series User Guide
9
10.3 Output position, size, and masking...................................................................................................... 51
10.3.1 Output resolution........................................................................................................................... 51
10.3.2 Aspect ratio for sink device ........................................................................................................... 52
10.3.3 Image position............................................................................................................................... 52
10.3.4 Image size..................................................................................................................................... 52
10.3.5 Background color .......................................................................................................................... 53
10.3.6 Test pattern ................................................................................................................................... 53
10.3.7 Videowall configuration ................................................................................................................. 54
10.3.8 Videowall position.......................................................................................................................... 54
10.3.9 Frame delay................................................................................................................................... 55
10.3.10 Synchronization mode................................................................................................................. 55
10.3.11 Video synchronization ................................................................................................................. 56
10.4 Output .................................................................................................................................................. 57
10.4.1 Disabling synchronous signal output when no video signal is input ............................................. 57
10.4.2 Presence of output signal for when no video signal is input ......................................................... 57
10.4.3 HDCP output ................................................................................................................................. 57
10.4.4 Output equalizer............................................................................................................................ 58
10.4.5 Output format................................................................................................................................. 58
10.4.6 HDBaseT output long reach mode................................................................................................ 59
10.4.7 Deep Color output ......................................................................................................................... 59
10.4.8 Window transition effect ................................................................................................................ 59
10.4.9 Sink device EDID check................................................................................................................ 60
10.4.10 Hot plug ignoring duration........................................................................................................... 60
10.4.11 Presence of output signal for when no signal is input (No scan conversion).............................. 61
10.5 Input position, size, and cropping ........................................................................................................ 61
10.5.1 Aspect ratio.................................................................................................................................... 61
10.6 Input ..................................................................................................................................................... 62
10.6.1 No-signal input monitoring............................................................................................................. 62
10.6.2 HDCP input.................................................................................................................................... 63
10.6.3 HDBaseT input long reach mode.................................................................................................. 64
10.6.4 SDI input audio group.................................................................................................................... 64
10.6.5 3G-SDI Dual Stream input video................................................................................................... 64
10.7 Input timing........................................................................................................................................... 65
10.7.1 Horizontal start position................................................................................................................. 65
10.7.2 Horizontal active area.................................................................................................................... 66
10.7.3 Vertical start position..................................................................................................................... 66
10.7.4 Vertical active area........................................................................................................................ 66
10.8 Picture controls .................................................................................................................................... 67
10.8.1 Output brightness.......................................................................................................................... 67
10.8.2 Output contrast.............................................................................................................................. 67
10.8.3 Output gamma............................................................................................................................... 67
10.8.4 Output video correction initialization ............................................................................................. 68
10.8.5 Input sharpness............................................................................................................................. 68
10.8.6 Input brightness............................................................................................................................. 68
10.8.7 Input contrast................................................................................................................................. 68
10.8.8 Input hue........................................................................................................................................ 69
10.8.9 Input saturation.............................................................................................................................. 69
10.8.10 Input video correction initialization .............................................................................................. 69
10.9 Output audio......................................................................................................................................... 70
10.9.1 Mute............................................................................................................................................... 70

FDX-S Series User Guide
10
10.9.2 Output Lip Sync............................................................................................................................. 70
10.10 Input audio ......................................................................................................................................... 70
10.10.1 Stable input audio wait ................................................................................................................ 70
10.11 EDID................................................................................................................................................... 71
10.11.1 External EDID.............................................................................................................................. 71
10.11.2 Resolution.................................................................................................................................... 72
10.11.3 Copying EDID.............................................................................................................................. 75
10.11.4 HDMI/DVI .................................................................................................................................... 75
10.11.5 Frame rate................................................................................................................................... 75
10.11.6 Deep Color .................................................................................................................................. 76
10.11.7 LPCM audio................................................................................................................................. 76
10.11.8 AAC audio ................................................................................................................................... 77
10.11.9 Dolby Digital audio ...................................................................................................................... 77
10.11.10 Dolby Digital Plus audio ............................................................................................................ 77
10.11.11 Dolby TrueHD audio.................................................................................................................. 78
10.11.12 DTS audio.................................................................................................................................. 78
10.11.13 DTS-HD audio........................................................................................................................... 78
10.11.14 Speaker configuration ............................................................................................................... 79
10.12 RS-232C ............................................................................................................................................ 80
10.12.1 RS-232C communication ............................................................................................................ 80
10.13 LAN .................................................................................................................................................... 80
10.13.1 IP address ................................................................................................................................... 80
10.13.2 Subnet mask ............................................................................................................................... 80
10.13.3 MAC address............................................................................................................................... 81
10.13.4 TCP port number......................................................................................................................... 81
10.13.5 HDBaseT Output LAN................................................................................................................. 81
10.13.6 HDBaseT Input LAN.................................................................................................................... 81
10.14 Preset memory................................................................................................................................... 82
10.14.1 Recalling crosspoint .................................................................................................................... 82
10.14.2 Saving crosspoint........................................................................................................................ 82
10.14.3 Editing crosspoint........................................................................................................................ 83
10.14.4 Recalling preset memory............................................................................................................. 84
10.14.5 Saving preset memory ................................................................................................................ 84
10.14.6 Start-up setting............................................................................................................................ 85
10.15 Bitmap................................................................................................................................................ 86
10.15.1 Bitmap image output ................................................................................................................... 87
10.15.2 Background color ........................................................................................................................ 87
10.15.3 Aspect ratio.................................................................................................................................. 87
10.15.4 Image position............................................................................................................................. 88
10.15.5 Start-up bitmap output................................................................................................................. 88
10.16 Configuring FDX-S............................................................................................................................. 89
10.16.1 Grouping front panel security lockout.......................................................................................... 89
10.16.2 Beep............................................................................................................................................ 89
10.16.3 Alarm........................................................................................................................................... 90
10.16.4 Displaying advanced menu......................................................................................................... 91
10.16.5 Power saving............................................................................................................................... 91
10.16.6 Top page ..................................................................................................................................... 92
10.16.7 Channel selection mode.............................................................................................................. 94
10.17 Status indication................................................................................................................................. 95
10.17.1 Sink device status ....................................................................................................................... 95

FDX-S Series User Guide
11
10.17.2 Viewing sink device EDID ........................................................................................................... 95
10.17.3 Input signal status ....................................................................................................................... 95
10.17.4 System status.............................................................................................................................. 96
10.17.5 Viewing board status................................................................................................................... 97
10.17.6 Fan status.................................................................................................................................... 98
10.17.7 Power supply voltage status........................................................................................................ 98
10.17.8 Device information....................................................................................................................... 98
10.18 Factory default list.............................................................................................................................. 99
11 Product specification................................................................................................................................. 102
11.1 FDX-S16U.......................................................................................................................................... 102
11.2 FDX-S16 ............................................................................................................................................ 103
11.3 FDX-S32U.......................................................................................................................................... 104
11.4 FDX-S32 ............................................................................................................................................ 105
11.5 FDX-SIV4H ........................................................................................................................................ 106
11.6 FDX-SIV4T......................................................................................................................................... 106
11.7 FDX-SIV4S......................................................................................................................................... 107
11.8 FDX-SIV4UH...................................................................................................................................... 107
11.9 FDX-SIV4UT...................................................................................................................................... 108
11.10 FDX-SOV4H..................................................................................................................................... 108
11.11 FDX-SOV4T..................................................................................................................................... 109
11.12 FDX-SOV4HS .................................................................................................................................. 109
11.13 FDX-SOV4TS................................................................................................................................... 110
11.14 FDX-SOV4UH.................................................................................................................................. 110
11.15 FDX-SOV4UT .................................................................................................................................. 111
11.16 FDX-SRP16 ..................................................................................................................................... 111
11.17 FDX-SRP32 ..................................................................................................................................... 111
12 Troubleshooting........................................................................................................................................ 112

FDX-S Series User Guide
12
1 About this Guide
This guide contains installation, setting, and operating information for the FDX-S series Modular Matrix
Switchers (hereafter referred to as “FDX-S”).
The FDX-S consists of the modular matrix switcher, redundant power supply unit, and Input/Output boards.
[Table 1.1] FDX-S series
Model
Item
FDX
S16U
S32U
S16
S32
Max. resolution
4K@60 (4:4:4)
4K@30
HDCP
1.4/2.2
1.4
Input
16
32
16
32
Output
16
32
16
32
Redundant power supply (Optional)
(FDX-SRP16/SRP32)
✓
(SRP16)
✓
(SRP32)
✓
(SRP16)
✓
(SRP32)
I/O boards (4 I/Os per board)
Input
4K@30 HDMI/DVI
(FDX-SIV4H)
✓
✓
✓
✓
4K@30 HDBaseT
(FDX-SIV4T)
✓
✓
✓
✓
3G-SDI/HD-SDI/SD-SDI
(FDX-SIV4S)
✓
✓
✓
✓
4K@60 HDMI/DVI
(FDX-SIV4UH)
✓
✓
N/A
N/A
4K@60 HDBaseT
(FDX-SIV4UT)
✓
✓
N/A
N/A
Output
4K@30 HDMI/DVI
(FDX-SOV4H)
✓
✓
✓
✓
4K@30 HDBaseT
(FDX-SOV4T)
✓
✓
✓
✓
HDMI/DVI scan conversion
(FDX-SOV4HS)
✓
✓
✓
✓
HDBaseT scan conversion
(FDX-SOV4TS)
✓
✓
✓
✓
4K@60 HDMI/DVI
(FDX-SOV4UH)
✓
✓
N/A
N/A
4K@60 HDBaseT
(FDX-SOV4UT)
✓
✓
N/A
N/A

FDX-S Series User Guide
13
2 Included items
Ensure that all items illustrated below are included in the package.
If any items are missing or damaged, please contact IDK.
One (1) frame (Example: FDX-S16U)
3-pin captive screw connector
2-pin captive screw connector
Rack mounting brackets
(For FDX-S16U/S16)
Rack mounting brackets
(For FDX-S32U/S32)
M4 screw
Cable clamp
One (1) power cord, 6 ft. (1.8 m)
[Table 2.1] Included items
Item
FDX
S16U
S32U
S16
S32
Frame
1
1
1
1
3-pin captive screw connector
1
1
1
1
2-pin captive screw connector
1
1
1
1
Rack mounting brackets/M4 screw
Two (2) brackets/
6 screws
Two (2) brackets/
8 screws
Two (2) brackets/
6 screws
Two (2) brackets/
8 screws
Cable clamp for I/O boards
Depends on the number of HDMI connectors
Power cord, 6 ft. (1.8 m) for frame
1
1
1
1
Power cord, 6 ft. (1.8 m) for
redundant power supply unit
1
1
1
1

FDX-S Series User Guide
14
3 About FDX-S Module Matrix Switchers
The FDX-S is an HDCP-compliant modular digital matrix switcher that supports resolutions up to 4K@60. It
provides up to 32 inputs and 32 outputs. Video and embedded audio can be switched simultaneously.
The FDX-S features RS-232C/LAN ports for remote control, redundant power supply, and system check that
outputs an alarm in case an abnormality is detected in power supply voltage, fans, internal temperature, or
board.
The redundant power supply ensures constant availability and minimizes the chance of a failure even for
mission-critical environments.
FDX-S16U
inputs/1 board
4FDX-SIV4T outputs/1 board
FDX-SOV4T
4Digital video/audio/
communication
for extension
HDBaseT
Digital video/audio/
communication
for extension
HDBaseT
EDID emulator
Up to outputs/4 boards
16
Up to inputs/4 boards
16
- Input board can expand in 4-input unit.
- Output board can expand in 4-output unit.
inputs/1 board
4FDX-SIV4H
Digital video/audio
HDMI DVI EDID emulator
outputs/1 board
FDX-SOV4H
4Digital video/audio
HDMI DVI
*1 Up to 328 ft. (100 m) : 4K@60 (FDX-SIV4UT/FDX-SOV4UT)
4K@30 (FDX-SIV4T/FDX-SOV4T)
QWXGA, 1080p (FDX-SOV4TS)
Up to 492 ft. (150 m) : 1080p (24bit) in Long reach mode
For long reach mode, video signals up to 1080p (24 bit) can be transmitted to 492 ft. (150 m) at maximum
if using with IDKs HDBaseT products supporting 328 ft. (100 m) transmission.
*2 Up to 98 ft. (30 m): 1080p@60
Up to 39 ft. (12m) : 4K@60 (when cable supporting 18 Gbps transmission is used)
Up to 98 ft.
(30 m)
inputs/1 board
4FDX-SIV4S
SDI video/audio
3G-SDI
HD-SDI
SD-SDI
Cable driver
Receiver
Loop-through
Transmitter
outputs/1 board
FDX-SOV4HS
4Scan converter
outputs/1 board
FDX-SOV4TS
4Scan converter
Digital video/audio
HDMI DVI
Digital video/audio/
communication
for extension
HDBaseT
Output EQ
Transmitter
Transmitter
Receiver
Receiver
RS-232C1Port
LAN 1Port HUB
CPU
Lip Sync
Lip Sync
inputs/1 board
4FDX-SIV4UH
Digital video/audio
HDMI DVI EDID emulator
Receiver
inputs/1 board
4FDX-SIV4UT
Digital video/audio/
communication
for extension
HDBaseT
EDID emulator
Receiver
outputs/1 board
FDX-SOV4UH
4Digital video/audio
HDMI DVI
Transmitter
outputs/1 board
FDX-SOV4UT
4Digital video/audio/
communication
for extension
HDBaseT
Transmitter
Video/audio
matrix
switcher
16IN-
16OUT
Transmitter
SDI video/audio
3G-SDI
HD-SDI
SD-SDI
Up to 98 ft.
(30 m)*2
Up to 98 ft.
(30 m)
Up to 98 ft.
(30 m)*2
Up to 131 ft.
(40 m)
Up to 328 ft.
(100 m)*1
Up to 328 ft.
(100 m)*1 Up to 328 ft.
(100 m)*1
Up to 328 ft.
(100 m)*1
Up to 328 ft.
(100 m)*1
(A)
(A) SD-SDI : Up to 1312 ft. (400 m)/
HD-SDI: Up to 787 ft. (240 m)/
3G-SDI : Up to 459 ft. (140 m)
over 1694A (BELDEN RG-6) cable
[Fig. 3.1] Diagram (Example: FDX-S16U)

FDX-S Series User Guide
15
4 Features
[1/2]
Features
Frame
Remarks
S16U
S32U
S16
S32
Video
Maximum resolution
4K@60
(4:4:4)
4K@30
HDCP
1.4/2.2
1.4
HDR
✓
N/A
FDX-SIV4UH,
FDX-SIV4UT,
FDX-SOV4UH,
FDX-SOV4UT
3D
✓
N/A
x.v.Color
✓
N/A
3G-SDI/HD-SDI/SD-SDI input
✓
✓
FDX-SIV4S
Automatic signal equalization
Output 131 ft. (40 m)
✓
✓
FDX-SOV4HS
Up to 984 ft. (300 m) over coaxial cable
✓
✓
FDX-SIV4S
Motion adaptive interlaced/progressive
conversion
✓
✓
FDX-SOV4HS,
FDX-SOV4TS
Aspect ratio control
✓
✓
Seamless switching with one black
frame
✓
✓
Anti-snow
✓
✓
Scaling
✓
✓
FDX-SOV4HS,
FDX-SOV4TS
SDI Loop-through output connector
✓
✓
FDX-SIV4S
Videowall output
✓
✓
FDX-SOV4HS,
FDX-SOV4TS
Up to 492 ft. (150 m) over Cat6 cable in
Long reach mode*2
✓
✓
FDX-SIV4T,
FDX-SIV4UT*1,
FDX-SOV4T,
FDX-SOV4TS,
FDX-SOV4UT*1
Audio
Lip Sync
✓
✓
FDX-SOV4HS,
FDX-SOV4TS
Control
input
RS-232C
✓
✓
LAN
✓
✓

FDX-S Series User Guide
16
[2/2]
Features
Frame
I/O boards
S16U
S32U
S16
S32
Others
EDID emulation
✓
✓
I/O board, CPU board, fan unit, and
power unit can be replaced without
removing from rack
✓
✓
Alarm output (Monitoring power supply
voltage, fans, internal temperature, and
board status)
✓
✓
Preset memory
✓
✓
Last memory
✓
✓
Connection Reset
✓
✓
Button security lockout
✓
✓
System check
✓
✓
WEB browser control
✓
✓
Redundant power supply (Optional)
✓
✓
LAN and RS-232C transmission
✓
✓
FDX-SIV4T,
FDX-SIV4UT*1,
FDX-SOV4T,
FDX-SOV4TS,
FDX-SOV4UT*1
Status notification
✓
✓
HDBaseT status display
✓
✓
*1: For FDX-S16U/S32U only.
*2: For long reach mode, video signals up to 1080p (24 bit) can be transmitted to 492 ft. (150 m) at maximum
if using with IDK's HDBaseT products supporting 328 ft. (100 m) transmission.

FDX-S Series User Guide
17
5 Panels
5.1 Frame
5.1.1 FDX-S16U/S16
󳔤Front panel
󳏀
󳏁
󳏃󳏄
󳏅
󳏂
󳏆
󳏇
󳏈󳏉󳏊
󳏋󳏌
󳏍󳏎
󳏏 󳏑󳏐 󳏒 󳏓
㉑
󳔤Rear panels
㉒㉓
㉔㉔
With redundant power supply
[Fig. 5.1] Drawings

FDX-S Series User Guide
18
[Table 5.1] Features
#
Feature
Description
Front panel
①
INPUT SELECT button
Selects an input.
Loads the crosspoint number (in loading crosspoint mode).
②
OUTPUT SELECT button
Selects an output.
③
PRESET LOAD button
Enables preset memory load mode.
④
MENU/ENTER button
Selects menus, edits, controls, and saves settings.
⑤
Navigation buttons
Navigates menu or changes values of adjustable features.
⑥
BACK button
Available only in menu page. Goes back to the previous page.
⑦
Front display
Displays menus and settings.
Rear panel
⑧
Main power switch
(POWER)
Controls the main power.
⑨
HDMI input connectors
Input connectors for HDMI and DVI signals to interface source
devices, such as Blu-ray players
⑩
HDMI cable fixing holes
Retain HDMI cables by inserting cable clamps.
⑪
HDBaseT input connector
Input connector for HDBaseT signals
Connects to a transmitter over a category cable.
⑫
SDI input connector
Input connector for 3G-SDI/HD-SDI/SD-SDI signals
⑬
SDI loop-through output
connector
If the FDX is powered on, the input SDI signals can be output from the
SDI loop-through output connectors.
⑭
HDMI output connectors
Output connectors for HDMI and DVI signals, interfaces sink devices
such as LC monitors and projectors
⑮
HDBaseT output
connectors
Output connector for HDBaseT signal
Connects to a receiver over a category cable.
⑯
RS-232C connector
3-pin captive screw connector for RS-232C serial control
⑰
LAN connector
For external control by communication commands or web browsers
⑱
ALARM connector
Outputs an alert for abnormalities of power supply unit, cooling fan,
internal temperature, and board.
⑲
Power supply connector
For use with supplied power cable
⑳
Frame ground
Use for bonding chassis to local ground.
An M4 screw is used.
㉑
Fan unit
Replaceable fan unit
㉒
Power supply unit
(Primary)
Primary power supply unit for redundant power supply
㉓
Power supply unit
(Secondary)
Secondary power supply unit for redundant power supply
Side panel
㉔
Ventilation holes
Prevents internal temperature raise. Do not block ventilation holes.

FDX-S Series User Guide
19
5.1.2 FDX-S32U/S32
󳏀󳏁
󳏃
󳏂
󳏄󳏅
󳏆
󳏇󳏈󳏉󳏌󳏍
󳏎 󳏐󳏏 󳏑 󳏒
󳏊󳏋
󳏓
With redundant power supply
㉑㉒
㉓
㉓
󳔤Rear panels
󳔤Front panel
[Fig. 5.2] Drawings

FDX-S Series User Guide
20
[Table 5.2] Features
[1/2]
#
Feature
Description
Front panel
①
I/O channel selection
buttons
Buttons
Description
Numeric buttons
(0 to 9)
Enters number.
SET
Applies the setting.
INPUT
Moves the cursor to the INPUT side.
OFF
Does not output video.
OUTPUT
Moves the cursor to the OUTPUT side.
ALL
Selects all output channels.
②
PRESET LOAD button
Enables preset memory load mode.
③
MENU/ENTER button
Selects menus, edits, controls, and saves settings.
④
Navigation buttons
Navigates menu or changes values of adjustable features.
⑤
BACK button
Available only in menu page. Goes back to the previous page.
⑥
Front display
Displays menus and settings.
Rear panels
⑦
Main power switch
(POWER)
Controls the main power.
⑧
HDMI input connectors
Input connectors for HDMI and DVI signals to interface source
devices, such as Blu-ray players
⑨
HDMI cable fixing holes
Retain HDMI cables by inserting cable clamps.
⑩
HDBaseT input connector
Input connector for HDBaseT signals
Connects to a transmitter over a category cable.
⑪
SDI input connector
Input connector for 3G-SDI/HD-SDI/SD-SDI signals.
⑫
SDI loop-through output
connector
If the FDX is powered on, the input SDI signals can be output from the
SDI loop-through output connectors.
⑬
HDMI output connectors
Output connectors for HDMI and DVI signals, interfaces sink devices
such as LC monitors and projectors
⑭
HDBaseT output
connectors
Output connector for HDBaseT signal
Connects to a receiver over a category cable.
⑮
RS-232C connector
3-pin captive screw connector for RS-232C serial control
⑯
LAN connector
For external control by communication commands or web browsers
⑰
ALARM connector
Outputs an alert for abnormalities of power supply unit, cooling fan,
internal temperature, and board.
⑱
Power supply connector
For use with supplied power cable
⑲
Frame ground
Use for bonding chassis to local ground.
An M4 screw is used.
