IDK MSD-701UHD Operating manual

4K@60 and HDCP 2.2 supported Digital Multi Switcher
MSD-701UHD / 702UHD
MSD-801UHD / 802UHD
<Command Reference Guide>
Ver.1.0.0
Thank you for choosing this IDK product.
To ensure the best performance of this product, please read this User’s Guide fully and carefully
before using it and keep this manual beside this product.
IDK Corporation

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
2
Trademarks
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing Administrator, Inc. in the United States and other countries.
PJLink is a trademark in Japan, the United States, and other countries/regions.
All other company and product names mentioned in this manual are either registered trademarks or
trademarks of their respective owners. In this manual, the “®” or “™” marks may not be specified.

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
3
Before reading this manual
●All rights reserved.
●Some of the contents in this command guide such as product appearance in diagrams, menu operations,
communication commands, and so on may differ from one NJR-CTB model to another.
●This command guide is subject to change without notice. You can download the latest version from IDK’s
website at:http://www.idkav.com
The reference manual for the NJR-T01UHD/NJR-R01UHD consists of the two following volumes:
■User’s guide: Please download from the website above.
■Command guide (this document): Please download from the website above.

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
4
Table of Contents
1About this Guide................................................................................................................................... 5
2Communication configuration and Specifications .................................................................................. 6
2.1 RS-232C communication................................................................................................................. 6
2.1.1 RS-232C connector specification.............................................................................................. 6
2.1.2 RS-232C communication specification...................................................................................... 6
2.1.3 Setting up RS-232C communication......................................................................................... 7
2.2 LAN communication ........................................................................................................................ 8
2.2.1 LAN connector specification..................................................................................................... 8
2.2.2 LAN communication specification............................................................................................. 8
2.2.3 Setting up LAN communication................................................................................................. 9
2.2.4 The number of TCP-IP connections.........................................................................................10
3Command ...........................................................................................................................................11
3.1 Command outline ...........................................................................................................................11
3.2 Command list .................................................................................................................................12
3.3 Detailed descriptions ......................................................................................................................17
3.3.1 Error status.............................................................................................................................17
3.3.2 Input channels.........................................................................................................................18
3.3.3 Position, size, and masking.....................................................................................................20
3.3.4 Image quality...........................................................................................................................31
3.3.5 Input settings...........................................................................................................................36
3.3.6 Input timing.............................................................................................................................41
3.3.7 Output settings........................................................................................................................50
3.3.8 Audio ......................................................................................................................................59
3.3.9 EDID.......................................................................................................................................67
3.3.10 RS-232C communication.........................................................................................................74
3.3.11 LAN communication................................................................................................................77
3.3.12 Control commands..................................................................................................................81
3.3.13 Preset memory........................................................................................................................95
3.3.14 Bitmap ..................................................................................................................................101
3.3.15 Other settings........................................................................................................................108

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
5
1 About this Guide
This guide contains the procedure for controlling the MSD-701UHD / 702UHD / 801UHD / 802UHD using
commands via RS-232C communication or LAN communication.
Since descriptions in this document are for MSD-802UHD, there may be slight differences between the model
and other models.
The MSD series is devided into four models as shown in the table below.
[Table 1.1] Main differences among MSD-701UHD / 702UHD / 801UHD / 802UHD
Model
Number of I/Os
Front pnale
HDBaseT input Front panel OFF Keys
Input
Ouput
MSD-701UHD
7
1
No
Yes
MSD-702UHD
2
MSD-801UHD
8
1
Yes No
MSD-802UHD
2
■You can perform the following operations using communication commands.
・Switching channels.
・Setting I/O, audio, and EDID.
・Setting sending of external control command.
・Setting preset memory.
・Setting and displaying bitmaps
and others

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
6
2 Communication configuration and Specifications
2.1 RS-232C communication
2.1.1 RS-232C connector specification
Fixes RS-232C cable to the provided 3-pin terminal block and then connect it to the MSD.
AWG28 to AWG16 conductor gauge is recommended. The recommended wire strip length is 0.28 in. (7 mm).
If it is connected to a D-sub9 pin, cut RTS, CTS, DTR, and DSR (unused) as needed.
Tx
Rx
GND
RS-232C Tｘ
RS-232C Rx
GND
Up to 0.28"(7 mm)
[Fig. 2.1] Connecting RS-232C cable to 3-pin terminal block connector
2.1.2 RS-232C communication specification
[Table 2.1] RS-232C specification
Standard
RS-232C
Baud rate [bps]
4800 / 9600 / 19200 / 38400 [bps]
Data bit length [bit]
7 / 8
Parity check NONE, EVEN, ODD
Stop bit [bit]
1 / 2
X parameter Invalid
Flow control None
Delimiter CR LF (Carriage return and line feed, 0D and 0A in hex)
Communication method Full duplex

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
7
2.1.3 Setting up RS-232C communication
(1) Connect the MSD and the control device via an RS-232C cable.
(2) Set the RS-232C communication as follows:
・RS-232C communication: baud rate, data bit length, parity check, and stop bit
・Operation mode of RS-232C communication: “RECEIVER”
【Reference: User’s Guide】
(3) For the control device, set the same values in the same way as RS-232C communication (baud rate, data
bit length, parity check, and stop bit) in step (2) above.
(4) Send a communication command from the control device to the MSD in order to check the control status of
the MSD.
Step (3)
Laptop
(Controller)Step (2)
Step (1)
RS-232C cable
Step (4)
Communication
command
[Fig. 2.2] Setting RS-232C communication
■Operation example of RS-232C communication
Laptop
RS-232C cable
RS-232C cable Communication
command to MSD
Outputs control
command to external
device Twisted pair cable
Projector
RS-232C transmission between control devices.
HDC
series
receiver
[Fig. 2.3] RS-232C communication

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
8
2.2 LAN communication
2.2.1 LAN connector specification
It supports Auto MDI/MDI-X, which distinguishes/switches straight and cross cables automatically.
Pin assignments of LAN connector:
8
1
LAN connector
8-pin RJ-45 connector
(Rear panel)
Lights in green while link is established.
Blinks in green while data is being sent/received.Lights in orange if the send/receive rate is 100 Mbps.
Goes off if it is 10 Mbps.
RX+: Received Data+
N.C : Not connected
TX+: Transmitted Data+
Pin #
1
3
2
4
6
5
7
Signal Name
TX- : Transmitted Data-
N.C : Not connected
RX- : Received Data-
N.C : Not connected
N.C : Not connected
MDI
TX+ : Transmitted Data+
N.C : Not connected
RX+: Received Data+
RX- : Received Data-
N.C : Not connected
TX- : Transmitted Data-
N.C : Not connected
N.C : Not connected
MDI-X
8
[Fig. 2.4] LAN connector
2.2.2 LAN communication specification
[Table 2.2] Specification of LAN communication
Physical layer
10Base-T (IEEE802.3i) / 100Base-TX (IEEE802.3u)
Network layer
ARP, IP, ICMP
Transport layer
TCP
Port used for command control:23, 1100, 6000 to 6999
Port used for WEB browser control (HTTP):
80, 5000 to 5999
Application layer
HTTP, TELNET
Note: Up to 8 connections can be used simultaneously.

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
9
2.2.3 Setting up LAN communication
(1) Connect the MSD and the control device via a LAN cable.
(2) Set up LAN communication as follows:
・Set IP address and subnet mask
・Operation mode of LAN communication: “RECEIVER”
・TCP pot number: 23, 1100, 6000 to 6999
【Reference: User’s Guide】
(3) Establish the connection from the control device to the IP address and TCP port that are set to the
MSD in step (2) above.
(4) Send a communication command from the control device to the MSD in order to check the control
status of the MSD.
Step (2)
Step (1)
LAN cable
Step (4)
Communication
command
Step (3)
Laptop
(Controller)
[Fig. 2.5] Setting LAN communication
■Operation example of LAN communication
Projector
Outputs control command
to external device
Twisted pair cable
Laptop
LAN cable
Communication
command to MSD
LAN cable
HDC
series
receiver
Switching hub
Controller
Connection
1 2 3 4 5 6 7 8
[Fig. 2.6] LAN communication

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
10
2.2.4 The number of TCP-IP connections
The MSD series can connect up to eight connections (eight ports) simultaneously. If the MSD is controlled
from nine or more PCs, they may not be connected to the MSD normally, since the number of connections
that can be used is limited.
If you use nine connections or more, execute TCP-IP connection/close every time the communication
command is sent or received from the software of user’s side. By doing so, MSD’s ports are occupied or
released so that nine or more connections can be connected logically.
[Table 2.3] Increasing connections
Your PC software
MSD
TCP-IP connection →(Occupied by 1 port)
Send command (@xxx)
→
←Send back command
(@xxx)
TCP-IP close →(Release 1 port)
Note: If any command is not sent from the PC side to the MSD for 30 seconds, the MSD disconnects the
connection to avoid the limitation problem on the number of connections. As a result, connection needs to be
established again from the PC side after the current connection of the PC is disconnected.
(Since the number of ports in the MDS is eight, ports are occupied permanently if the PC is turned off while
connections are valid. To prevent this, the MSD disconnects connections if no communication command is
sent from the PC side.)

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
11
3 Command
3.1 Command outline
A command consists of “@” (“40” in hexadecimal), 3 one-byte alphabetical characters (upper and lower
cases), and parameters (one-byte numbers*). For some commands, several parameters can be specified or
no parameter is required. Processing is executed by sending a delimiter at the end of the command.
Example: @SPM,2
“,”( a comma, “2C” in hexadecimal) is indicated between a command and parameter and between two
parameters.
: delimiter CR LF (return+line feed, “0D” and “0A” in hex)
■If there is an error:
An error command is returned if an undefined command or wrong parameter is included.
Example: @SOT,1
@ERR,1
■Using as HELP
If only delimiter is sent, command list as the help command is returned.
Example:
--------------- HELP (1/13) ---------------
(CHANNEL SELECT Command)
@GSW / @SSW : Get/Set Input Channel
@GSV / @SSV : Get/Set Video Input Channel
@GSA / @SSA : Get/Set Audio Input Channel
--------------- HELP (2/13) ---------------
(OUTPUT TIMING Command)
@GOT / @GTD / @SOT : Get/Set Output Timing
@GUM / @SUM : Get/Set Monitor Aspect
@GAP / @SAP : Get/Set Aspect
@GAR / @SAR : Get/Set Aspect Restore Mode

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
12
3.2 Command list
■Error status
Command Function Page
@ERR
Error status
17
■Input channels
Command Function Page
@GSW / @SSW Switching video and audio channel simultaneously 18
@GSV / @SSV Switching video channel 19
@GSA / @SSA Switching audio channel 19
■Position, size, and masking
Command Function Page
@GOT / @SOT Output resolution 20
@GTD Actual output resolution 21
@GUM / @SUM Aspect ratio of sink device 22
@GAP / @SAP Aspect ratio 22
@GAR / @SAR Aspect ratio restoration 23
@GOV / @SOV Overscan 23
@GNP / @SNP Input position 24
@GNS / @SNS Input size 25
@GNM / @SNM Input masking 26
@IAS
Input automatic sizing
26
@GOP / @SOP Output position 27
@GOS / @SOS
Output size
27
@GOM / @SOM
Output masking
28
@OAS
Output automatic sizing
28
@GBC / @SBC
Background color
29
@GTP / @STP
Test pattern
30

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
13
■Image quality
Command
Function
Page
@GFL / @SFL
Sharpness
31
@GBR / @SBR Input brightness 31
@GCO / @SCO
Input contrast
32
@GHU / @SHU Hue 32
@GST / @SST Saturation 33
@GSU / @SSU Black level 33
@IDC Input default color 34
@GOB / @SOB Output brightness 34
@GOC / @SOC Output contrast 35
@GGM / @SGM Output gamma 35
@ODC
Output default color
36
■Input settings
Command Function Page
@GDT / @SDT No-signal-input monitoring 36
@GHE / @SHE HDCP input enabled/disabled 37
@GAI / @SAI Analog input type 37
@GID / @SID Automatic detection of input video interruption 38
@GIN / @SIN Signal selection of DVI input connector 38
@GIA / @SIA HDBaseT input long reach mode 39
@GFX / @SFX
Fixing settings for input signal
40
■Input timing
Command Function Page
@AIS / @AIT Automatic measurement 41
@GHT / @SHT The total number of horizontal dots 42
@GHS / @SHS Horizontal start position 43
@GHD / @SHD Horizontal display period 44
@GVS / @SVS Vertical start position 45
@GVD / @SVD Vertical display period 46
@GIS / @SIS
Automatic measurement of start position
47
@GSM / @SSM
Automatic measurement when unregistered signal is input
47
@RTT
Loading device data
48
@STT
Registering device data
48
@GTK / @STK
Tracking
49

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
14
■Output settings
Command
Function
Page
@GDM / @SDM
Output mode
50
@GUY / @SUY Synchronous signal output when no video signal is input 50
@GBO / @SBO
Output video when no video signal is not input
51
@GFF / @SFF Video switching effect 51
@GFT / @SFT Video switching speed 52
@GWC / @SWC Wipe color 52
@GVO / @SVO Vidoe output connector 53
@GEN / @SEN HDCP output 53
@GHR / @SHR The number of HDCP retries 54
@GDC / @SDC Deep Color 54
@GCE / @SCE
CEC connection
55
@HAU HDCP re-encryption 55
@GAU / @SAU
Priority of input channel automatic switching (OFF to ON)
56
@GOF / @SOF
Priority of input channel automatic switching (ON to OFF)
57
@GMT / @SMT
Masking time after automatic switching of input channel
57
@GAD / @SAD
Channel switching mode for input channel automatic switching
58
@GOA / @SOA
HDBaseT output long reach mode
58
■Audio
Command Function Page
@GSL / @SSL
Audio output level
59
@SOL Relative value of audio output level 59
@GOL
Limit status of audio output level
60
@GAM / @SAM
Audio output mute
60
@GAS / @SAS
Selecting audio input
61
@GSO / @SSO
Aduio input level
61
@SIL
Relative value of audio input level
62
@GIL
Limit status of audio input level
62
@GLO / @SLO
Output lip sync
62
@GLY / @SLY
Input lip sync
63
@GSF / @SSF
Sampling frequency
63
@GFD
Actual sampling frequency
64
@GDO / @SDO Audio output connector 64
@GAO / @SAO Digital audio output connector 65
@GMD / @SMD Multi channel audio output 65
@GCH / @SCH Priority of multi channel audio output 66
@GAT / @SAT Test tone 66

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
15
■EDID
Command
Function
Page
@GED / @SED
EDID
67
@GVF / @SVF Input resolution for PC 68
@GHF / @SHF
Input resolution for AV devices
69
@GDI / @SDI Deep Color input 70
@GAF / @SAF Audio format 71
@GSP / @SSP The number of speakers (cont’d) 73
@RME Copying EDID 73
■RS-232C communication
Command
Function
Page
@GCT / @SCT
RS-232C communication
74
@GCF / @SCF RS-232C communication mode 75
@GCD / @SCD RS-232C transmission between control devices 76
■LAN communication
Command
Function
Page
@GIP / @SIP
IP address
77
@GSB / @SSB
Subnet mask
77
@GGW /@SGW
Gateway address
78
@GLF / @SLF
LAN communication mode
79
@GLP / @SLP
TCP port number
80
@GMC MAC address 80
■Control commands
Command
Function
Page
@EXC
Executing control commands
81
@GDS / @SDS
Power button of sink device
81
@GEC / @SEC
Control command (Communication command)
82
@GEC / @SEC
Control command (Displaying received data)
84
@GEC / @SEC
Control command (contact closure)
86
@GEC / @SEC Control command (CEC) 87
@GRC / @SRC
Response command
88
@GCC / @SCC Control command link 89
@GTG / @STG Toggle operation 91
@GUP / @SUP Plane to be executed when powered ON 91
@GIT / @SIT Ineffective time during control command execution 92
@DEC Initializing registered command and link 92
@GTL / @STL Lighting condition of execution button 93
@GTF / @STF Blinking time of sink device power switch 94

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
16
■Preset memory
Command
Function
Page
@RCM
Loading crosspoint memory
95
@SCM / @SEM Saving channels to crosspoint memory 95
@GCM / @ECM
Editing crosspoint memory
96
@RCV Loading crosspoint memory (setting video channel) 96
@SCV / @SEV Saving crosspoint memory (Setting video channel) 97
@GCV / @ECV Editing crosspoint memory (Setting video channel) 97
@RCA Loading audio channel setting from crosspoint memory 98
@SCA / @SEA Saving crosspoint memory (Setting audio channel) 98
@GCA / @ECA Editing crosspoint memory (Setting audio channel) 99
@RPM Loading all settings 99
@SPM
Saving all settings
100
@SCP Copying output setting 100
@GMU / @SMU
Startup settings
101
■Bitmap
Command Function Page
@GBM / @SBM Outputting bitmap image 101
@GBB / @SBB Background color 102
@GBT / @SBT Aspect ratio 103
@GZP / @SZP Display position 104
@GBA / @SBA
Assigning input channel
105
@GPB / @SPB Startup bitmap 105
@GBD / @SBD
Dividing bitmap memory
106
@GBV
Bitmap memory status
106
@GFZ / @SFZ
Freeze
107
@CAP
Capturing input image
107
■Other settings
Command Function Page
@GLS / @SLS Operation lock 108
@GLM / @SLM
Setting operation to be locked
108
@GBZ / @SBZ
Buzzer
109
@GHP / @SHP
Power supply of HDBaseT input
109
@GSS
I/O status
110
@GES
Monitor’s EDID
114
@GIV
Version
114

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
17
3.3 Detailed descriptions
Commands for MSD-802UHD are shown in this section. For other models, use appropriate commands
according to the number of inputs and outputs.
3.3.1 Error status
@ERR
Error status
Description
Response in case the command is not executed.
Response @ERR, error
Parameter error: Error status
1 = Erroneous parameter format or value
2 = Undefined command or wrong format
3 = Currently cannot be used.
4 = Not used.
5 = The command could not be executed, because the control command was
not registered.
6 =The command could not be processed since another command was being
executed.
7 = Automatic measurement of input timing failed.
8 = Loading EDID from the sink device failed.
9 = Not used.
10 = The control command was stopped according to the stop condition.
11 = The control command was stopped since the number of retries exceeded
the set value of “RETRY”.
12 = The control command of PJLink was stopped since the password did not
match.
13 = The image could not be captured since the image size to be captured
exceeded the reserved memory size.
14 = Capturing input image failed.
Getting
example
Command
Response
@IOS
@ERR,2
Description @IOS is sent.
Command format error.
Remarks
－

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
18
3.3.2 Input channels
@GSW / @SSW
Switching video and audio channel simultaneously
Getting
Command
@GSW
Response
@GSW, video_1, audio_1, video_2, audio_2,
Setting
Command
@SSW, input_1, output_1 (, input_2, output_2)
Response
@SSW, input_1, output_1 (, input_2, output_2)
Parameter video_1-2: Video input channel
audio_1-2: Audio input channel
input_1-2 : Video and audio input channel
0 = OFF [Default], 1 = IN1 to 8 = IN8
output_1-4: Video and audio output channel
0 = All outputs, 1 = OUT1, 2= OUT2
Getting
example
Command
Response
@GSW
@GSW,2,2,0,0,
Description
Getting the video and audio input channels that are assigned to output channels.
OUT1: IN2, OUT2: OFF
Setting
example
Command
Response
@SSW,1,1
@SSW,1,1
Description
Setting IN1 video and audio to be output to OUT1.
Remarks －

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
19
@GSV / @SSV
Switching video channel
Getting Command @GSV
Response
@GSV, input_1, input_2
Setting Command @SSV, input_1, output_1 (, input_2, output_2)
Response
@SSV, input_1, output_1 (, input_2, output_2)
Parameter
input_1-2: Video input channel
0 = OFF [Default], 1 = IN1 to 8 = IN8
output_1-2: Video output channel
0 = All outputs, 1 = OUT1, 2 = OUT2
Getting
example
Command
Response
@GSV
@GSV,1,1
Description Getting the video I/O channel statuses.
OUT1 and OUT2: IN1
Setting
example
Command
Response
@SSV,1,1
@SSV,1,1
Description
Setting IN1 video to be output to OUT1.
Remarks
－
@GSA / @SSA
Switching audio channel
Getting Command @GSA
Response
@GSA, input_1, input_2
Setting Command @SSA, input_1, output_1 (, input_2, output_2)
Response
@SSA, input_1, output_1 (, input_2, output_2)
Parameter
input_1-4: Audio input channel
0 = OFF [Default], 1 = IN1 to 8 = IN8
output_1-4: Audio output channel
0 = All outputs, 1 = OUT1, 2 = OUT2
Getting
example
Command
Response
@GSA
@GSA,1,1
Description Getting the audio I/O channel status.
OUT1 and OUT2: IN1
Setting
example
Command
Response
@SSA,1,1
@SSA,1,1
Description Setting IN1 audio to be output to OUT1.
Remarks
－

MSD-701UHD / 702UHD / 801UHD/ 802UHD Command Guide
20
3.3.3 Position, size, and masking
@GOT / @SOT
Output resolution
Getting
Command
@GOT
Response
@GOT, resolution_1, resolution_2
Setting
Command
@SOT, ch_1, resolution_1 (, ch_2, resolution_2)
Response
@SOT, ch_1, resolution_1 (, ch_2, resolution_2)
Parameter resolution_1-2: Setting value of output resolution
0 = AUTO-A [Default], 1 =AUTO-B
2 = VGA@60 (640x480), 3 = SVGA@60 (800x600),
4 = XGA@60 (1024x768), 5 = WXGA@60 (1280x768),
6 = WXGA@60 (1280x800), 7 = Quad-VGA@60 (1280x960),
8 = SXGA@60 (1280x1024), 9 = WXGA@60 (1360x768),
10 = WXGA@60 (1366x768), 11 = SXGA+@60 (1400x1050)
12 = WXGA+@60 (1440x900), 13 = WXGA++@60 (1600x900),
14 = UXGA@60 (1600x1200), 15 = WSXGA+@60 (1680x1050),
16 = VESAHD@60 (1920x1080), 17 = WUXGA@60 (1920x1200),
18 = QWXGA@60 (2048x1152), 19 =WQHD@60 (2560x1440),
20 = WQXGA@60 (2560x1600), 21 = 480i@59.94 (720x480),
22 = 480p@59.94 (720x480), 23 = 576i@50 (720x576),
24 = 576p@50 (720x576), 25 = 720p@50 (1280x720),
26 = 720p@59.94 (1280x720), 27 = 720p@60 (1280x720),
28 = 1080i@50 (1920x1080), 29 = 1080i@59.94 (1920x1080),
30 = 1080i@60 (1920x1080), 31 = 1080p@50 (1920x1080),
32 = 1080p@59.94 (1920x1080), 33 = 1080p@60 (1920x1080),
40 = 2160p@24 (3840x2160), 41= 2160p@25 (3840x2160),
42 = 2160p@30 (3840x2160), 43 = 2160p@50 (3840x2160),
44 = 2160p@60 (3840x2160), 45 = 2160p@24 (4096x2160),
46 = 2160p@25 (4096x2160), 47 = 2160p@30 (4096x2160),
48 = 2160p@50 (4096x2160), 49 = 2160p@60 (4096x2160)
ch_1-2: Output channel
0 = All outputs, 1 = OUT1, 2= OUT2
Getting
example
Command
Response
@GOT
@GOT,8,32
Description Getting the set output resolution.
OUT1: SXGA, OUT2: 1080p 59.94 Hz
Setting
example
Command
Response
@SOT,1,11
@SOT,1,11
Description
Setting output resolution of OUT1 to SXGA+ 60 Hz.
Remarks －
