Idmed ToFscan User manual

www.idmed.fr
Copyright 2021 - IDMED SAS. All rights reserved. No information or part of this document may be reproduced or transmitted in any form or by any means, without the prior written permission of IDMED.
Follow us
Always read the instruction manual before use.
Ref: TOF-QS-V2-EN - Revision : 04/2021
ToFscan and IDMED are registered trademarks owned by IDMED SAS.
MODES
The ATP is an automated mode that enables the measurement of light,
medium, and deep block of the patient.
The ATP adapts automatically TOF and PTC measurements depending on the
patient level of neuromuscular block.
To nd the ATP, go to the PTC menu and select ATP.
Press and hold the wheel button for 2 seconds to start the mode. There are no
other actions required thereafter.
To stop the ATP, press the wheel button and the device will automatically
interrupt the mode.
1
• TOF ratio T4/T1 (%)
• TOF count (x/4)
• Responses amplitude graph.
• Interval every 15s., 30s., 1min., 2min., 5min.
and 15min
ATP (Automated TOF/PTC)
2QUICK START
TOF / (TOF Auto)

Connect the sensor cable to the ToFscan
Prepare and clean the skin for electrodes placement
Ensure current is 50mA or patient adapted.
2
3
SET-UP
Place the electrodes on the ulnar nerve
4
• Space between electrodes: 2 to 5 cm (0.8in-2in)
• Red clamp = proximal electrode.
• Black clamp = distal electrode.
• Only a good impedance allows to use the
ToFscan in good condition.
Position the sensor
Position the splint at the last phalanx of the thumb
closely following the U-shape of the hand.
5
Ensure the skin is clean and healthy. Start to measure
7
• Press the wheel button to enter the menu.
• Start the electrical stimulation, press and hold the
wheel button for 2 seconds.
Connection of the sensor
(green = connected)
Electrode impedance level
(green = optimum)
Battery charge level
2-5 cm
Press the wheel button to switch on
1
Check displayed information
6
Results displayed according to the chosen mode
8
