IEI Technology HPCIE-Q470 User manual

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 1
User Manual
Half-Size PICMG 1.3 CPU Card Supports LGA1200 10th Gen Intel®
Core™ i9/i7/i5/i3 /Pentium® /Celeron® CPU with Intel® Q470/Q470E,
DDR4 SO-DIMM, HDMI, USB-C, Dual Intel® 2.5GbE, USB 3.2, SATA
6Gb/s, M.2, HD Audio, Intel® AMT and RoHS
MODEL:
HPCIE-Q470
Rev. 1.00 –May 12, 2022

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 2
Revision
Date
Version
Changes
May 12, 2022
1.00
Initial release

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 3
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 4
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 5
Table of Content
1 INTRODUCTION.........................................................................................................11
1.1 INTRODUCTION......................................................................................................... 12
1.2 FEATURES................................................................................................................. 13
1.3 CONNECTORS ........................................................................................................... 14
1.4 DIMENSIONS............................................................................................................. 15
1.5 DATA FLOW.............................................................................................................. 16
1.6 TECHNICAL SPECIFICATIONS .................................................................................... 17
2 PACKING LIST........................................................................................................... 19
2.1ANTI-STATIC PRECAUTIONS...................................................................................... 20
2.2 UNPACKING PRECAUTIONS....................................................................................... 20
2.3 PACKING LIST........................................................................................................... 21
2.4 OPTIONAL ITEMS...................................................................................................... 22
3 CONNECTORS ........................................................................................................... 23
3.1 PERIPHERAL INTERFACE CONNECTORS..................................................................... 24
3.1.1 HPCIE-Q470 Layout ....................................................................................... 24
3.1.2 Peripheral Interface Connectors ..................................................................... 24
3.1.3 External Interface Panel Connectors............................................................... 25
3.2 INTERNAL PERIPHERAL CONNECTORS...................................................................... 26
3.2.1 ATX CPU 12V Power Connector..................................................................... 26
3.2.2 Internal Audio Connector for IEI Audio Module............................................. 27
3.2.3 RTC Battery Connector.................................................................................... 28
3.2.4 Chassis Instruction Connector......................................................................... 29
3.2.5 Digital Input/Output Connector....................................................................... 30
3.2.6 EC Debug Connector....................................................................................... 31
3.2.7 CPU Fan Connector........................................................................................ 32
3.2.8 Flash SPI ROM Connector.............................................................................. 33
3.2.9 Flash EC ROM Connector............................................................................... 34
3.2.10 Front Panel Connector .................................................................................. 35

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 6
3.2.11 I2C Connector................................................................................................. 36
3.2.12 LAN1 Link LED Connector............................................................................ 37
3.2.13 LAN2 Link LED Connector............................................................................ 38
3.2.14 RS-232/422/485 Serial Port Connector......................................................... 39
3.2.15 SATA 6Gb/s Connector................................................................................... 40
3.2.16 SMBus Connector .......................................................................................... 41
3.2.17 Speaker Connector......................................................................................... 42
3.2.18 Internal USB 2.0 Connector .......................................................................... 43
3.2.19 M.2 A-Key Slot............................................................................................... 44
3.2.20 M.2 M-Key Slot.............................................................................................. 46
3.3 EXTERNAL PERIPHERAL INTERFACE CONNECTOR PANEL ......................................... 48
3.3.1 External USB 3.2 Gen 1 Connectors (Type-A) ................................................ 48
3.3.2 External USB 3.2 Gen 2 Connector (Type-C).................................................. 49
3.3.3 External HDMI Connector .............................................................................. 50
3.3.4 Ethernet Connectors ........................................................................................ 51
4 INSTALLATION ......................................................................................................... 53
4.1ANTI-STATIC PRECAUTIONS...................................................................................... 54
4.2 INSTALLATION CONSIDERATIONS.............................................................................. 54
4.3 SOCKET LGA1200 CPU INSTALLATION................................................................... 56
4.4 SOCKET LGA1200 COOLING KIT INSTALLATION ..................................................... 59
4.5 SO-DIMM INSTALLATION ....................................................................................... 61
4.6 M.2 CARD INSTALLATION......................................................................................... 62
4.7 SYSTEM CONFIGURATION......................................................................................... 63
4.7.1 AT/ATX Power Mode Setting ........................................................................... 63
4.7.2 Clear CMOS Button......................................................................................... 64
4.7.3 BOIS Selection Switch...................................................................................... 65
4.7.4 Flash Descriptor Security Override Jumper.................................................... 66
4.7.5 USB Power Selection....................................................................................... 67
4.8 INTERNAL PERIPHERAL DEVICE CONNECTIONS........................................................ 68
4.8.1 SATA Drive Connection ................................................................................... 68

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 7
List of Figures
Figure 1-1: HPCIE-Q470 ...............................................................................................................12
Figure 1-2: Connector ..................................................................................................................14
Figure 1-3: Dimension (Unit: mm)...............................................................................................15
Figure 1-4: Block Diagram...........................................................................................................16
Figure 3-1: HPCIE-Q470 Layout ..................................................................................................24
Figure 3-2: ATX CPU 12V Power Connector Location..............................................................26
Figure 3-3: Internal Audio Connector Location.........................................................................27
Figure 3-4: RTC Battery Connector Location ............................................................................28
Figure 3-5: Chassis Instruction Connector Location................................................................29
Figure 3-6: Digital Input/Output Connector Location ...............................................................30
Figure 3-7: EC Debug Connector Location................................................................................31
Figure 3-8: CPU Fan Connector Location ..................................................................................32
Figure 3-9: Flash SPI ROM Connector Location .......................................................................33
Figure 3-10: Flash EC ROM Connector Location ......................................................................34
Figure 3-11: Front Panel Connector Location ...........................................................................35
Figure 3-12: I2C Connector Location ..........................................................................................36
Figure 3-13: LAN1 Link LED Connector Location.....................................................................37
Figure 3-14: LAN2 Link LED Connector Location.....................................................................38
Figure 3-15: RS-232/422/485 Serial Port Connectors Location................................................39
Figure 3-16: RS-232/422/485 Pinout............................................................................................40
Figure 3-17: SATA 6Gb/s Connector Location ..........................................................................40
Figure 3-18: SMBus Connector Location...................................................................................41
Figure 3-19: Speaker Connector Location.................................................................................42
Figure 3-20: Internal USB 2.0 Connector Location ...................................................................43
Figure 3-21: M.2 A-Key Slot Location.........................................................................................44
Figure 3-22: M.2 M-Key Slot Location.........................................................................................46
Figure 3-23: External Peripheral Interface Connector (EPIC) panel........................................48
Figure 3-24: External USB 3.2 Gen 1 Connectors Location .....................................................49
Figure 3-25: External USB 3.2 Gen 2 Connector Location .......................................................50
Figure 3-26: External HDMI Connector Location.......................................................................51

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 8
Figure 3-27: Ethernet Connectors Location ..............................................................................52
Figure 3-28: LAN LED Location...................................................................................................52
Figure 4-1: Disengage the CPU Socket Load Lever..................................................................56
Figure 4-2: Remove Protective Cover.........................................................................................57
Figure 4-3: Insert the Socket LGA1200 CPU..............................................................................58
Figure 4-4: Close the Socket LGA1200.......................................................................................58
Figure 4-5: Cooling Kit Support Bracket....................................................................................60
Figure 4-6: SO-DIMM Installation ................................................................................................61
Figure 4-7: Inserting The M.2 Module Into The Slot At An Angle ............................................62
Figure 4-8: Securing The M.2 Module.........................................................................................62
Figure 4-9: AT/ATX Power Mode Setting....................................................................................63
Figure 4-10: Clear CMOS Button Location.................................................................................64
Figure 4-11: BIOS Selection Switch Location............................................................................65
Figure 4-12: Flash Descriptor Security Override Jumper Location ........................................66
Figure 4-13: SATA Drive Cable Connection...............................................................................68
Figure 4-14: SATA Power Drive Connection..............................................................................69

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 9
List of Tables
Table 1-1: Technical Specification..............................................................................................18
Table 2-1: Packing List.................................................................................................................21
Table 2-2: Optional Items.............................................................................................................22
Table 3-1: Peripheral Interface Connectors ...............................................................................25
Table 3-2: External Interface Panel Connectors........................................................................25
Table 3-3: ATX CPU 12V Power Connector Pinouts .................................................................26
Table 3-4: Internal Audio Connector for IEI Audio Module Pinouts........................................27
Table 3-5: RTC Battery Connector Pinouts................................................................................28
Table 3-6: Chassis Instruction Connector Pinouts...................................................................29
Table 3-7: Digital Input/Output Connector Pinouts...................................................................30
Table 3-8: EC Debug Connector Pinouts ...................................................................................31
Table 3-9: CPU Fan Connector Pinouts .....................................................................................32
Table 3-10: Flash SPI ROM Connector Pinouts.........................................................................33
Table 3-11: Flash EC ROM Connector Pinouts..........................................................................34
Table 3-12: Front Panel Connector Pinouts...............................................................................35
Table 3-13: I2C Connector Pinouts..............................................................................................36
Table 3-14: LAN1 Link LED Connector Pinouts ........................................................................37
Table 3-15: LAN2 Link LED Connector Pinouts ........................................................................38
Table 3-16: RS-232/422/485 Serial Port Connector Pinouts.....................................................39
Table 3-17: SATA 6Gb/s Connector Pinouts..............................................................................41
Table 3-18: SMBus Connector Pinouts ......................................................................................41
Table 3-19: Speaker Connector Pinouts ....................................................................................42
Table 3-20: Internal USB 2.0 Connector Pinouts.......................................................................43
Table 3-21: M.2 A-Key Slot Pinouts ............................................................................................45
Table 3-22: M.2 M-Key Slot Pinouts............................................................................................47
Table 3-23: External USB 3.2 Gen1 Connector (Type-A) Pinouts............................................49
Table 3-24: External USB 3.2 Gen2 Connetor (Type-C) Pinouts..............................................50
Table 3-25: External HDMI Connector Pinouts..........................................................................51
Table 3-26: Ethernet Connector Pinouts....................................................................................52
Table 3-27: LAN LED Pinouts......................................................................................................52

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 10
Table 4-1: AT/ATX Power Mode Setting .....................................................................................63
Table 4-2: Clear CMOS Button Jumper Setting.........................................................................64
Table 4-3: BIOS Selection Switch ...............................................................................................66
Table 4-4: Flash Description Security Override Jumper ..........................................................66
Table 4-5: USB Power Setting .....................................................................................................67

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 11
Chapter
1
1Introduction

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 12
1.1 Introduction
Figure 1-1: HPCIE-Q470
The HPCIE-Q470 is a half-size PICMG 1.3 CPU card. It accepts a Socket LGA1200
10th/11th generation Intel® Core™ i9/i7/i5/i3, Pentium® or Celeron® processor and
supports two 260-pin 2933 MHz dual-channel DDR4 SO-DIMM, supporting up to 64G.
The HPCIE-Q470 provides dual 2.5GbE interfaces through the Intel® I225V. The
integrated Intel® Q470/Q470E chipset supports two SATA 6Gb/s drives with RAID 0/1
function. In addition, the HPCIE-Q470 includes HDMI 1.4 interface for display.
The HPCIE-Q470 provides rich I/O interfaces, including two USB 3.2 Gen 1 (5Gb/s) and
one USB3.2 Gen2 (10Gb/s) by USB Type-C on the rear panel, two USB 2.0 by pin
headers and two RS-232/422/485 connectors. M.2 A Key (2230) with PCIe Gen3 x2/USB
2.0 and M.2 M Key (2280/2242) with PCIe Gen3 x4 provide flexible expansion options.
High Definition Audio (HDA) support through IEI audio kit ensures HDA devices can be
easily implemented on the HPCIE-Q470.

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 13
1.2 Features
Some of the HPCIE-Q470 motherboard features are listed below:
▪Half-size PICMG 1.3 CPU card
▪10th/11th generation LGA1200 Intel® Core™ i9/i7/i5/i3, Pentium® or
Celeron® processor supported
▪Intel® Q470/Q470E chipset
▪Two 260-pin 2933 MHz dual-channel DDR4 SO-DIMM, supporting up to
64GB
▪Two Intel® PCIe 2.5GbE connectors
▪One HDMI display connector
▪One M.2 Akey (2230) with PCIe Gen3 x2 and USB 2.0
▪One M.2 M key (2280/2242) with PCIe Gen3 x4
▪Two SATA 6Gb/s connectors support RAID 0/1 function
▪Two USB 3.2 Gen 1 (5Gb/s) ports on the rear I/O
▪Two USB 2.0 ports via internal pin headers
▪Two RS-232/422/485 serial ports
▪High Definition Audio through IEI audio kit
▪RoHS compliant

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 14
1.3 Connectors
The connectors on the HPCIE-Q470 are shown in the figure below.
Figure 1-2: Connector

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 15
1.4 Dimensions
The main dimensions of the HPCIE-Q470 are shown in the diagram below.
Figure 1-3: Dimension (Unit: mm)

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 16
1.5 Data Flow
Figure 1-4 shows the data flow between the system chipset, the CPU and other components
installed on the motherboard.
Figure 1-4: Block Diagram

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 17
1.6 Technical Specifications
The HPCIE-Q470 technical specifications are listed 747Hbelow.
HPCIE-Q470
Half-Size PICMG 1.3 CPU Card Supports LGA1200 10th/11th Gen
Intel® Core™ i9/i7/i5/i3 /Pentium® /Celeron® CPU with Intel®
Q470/Q470E, DDR4 SO-DIMM, HDMI, USB-C, Dual Intel® 2.5GbE,
USB 3.2, SATA 6Gb/s, M.2, HD Audio, Intel® AMT and RoHS
CPU
LGA1200 10th/11th Gen Intel® Core™ i9/i7/i5/i3,Pentium® and
Celeron® Processor (Support up to 65w)
Chipset
Intel® Q470/Q470E
BIOS
AMI UEFI BIOS
Memory
Two 260-pin 2933 MHz Dual-channel DDR4 SO-DIMM, supporting
up to 64GB
Graphics Engine
10th Generation CML-S up to Intel® UHD Graphics 630, Intel® HD
9th Generation Display Engine based on 16 low power execution
units supporting DX2015, OpenGL 5.X and OpenCL2.x, ES 2.0
11th Generation RKL-SXe 12th Generation Graphics Architecture,
Intel® UHD Graphics 750,supports 12-bit end-to-end,and supports
AV1, VP9,HEVC 12b, HDR10, FP16
Display Output
1 x HDMI 1.4(up to 4096 x 2160@30Hz)
Ethernet
LAN1: Intel® I225V 2.5GbE controller
LAN2: Intel® I225V 2.5GbE controller
External I/O
Interface
2 x USB3.2 Gen1 (5Gb/s)
1 x USB3.2 Gen2 (10Gb/s) by USB Type-C
Internal I/O
Interface
2 x SATA 6Gb/s (Support RAID 0/1 )
2 x USB 2.0 (2x4 pin, P=2.0)
2 x RS-232/422/485 (2x5 pin, P=2.0) (RS-485 support AFC)
SMBus/ I²C
1 x SMBus (1x4 pin)
I²C
1 x I²C (1x4 pin)
Audio
1 x IAUDIO, support IEI AC-KIT-888S Audio Module (2 x 5 pin)
Front Panel
1 x Front panel connector (1x10 pin)
Power LED, HDD LED, Power Button, Reset Button
LAN LED
2 x LAN LED (1 x 2 pin)
Expansion
16-lane PCIe signal from CPU via golden finger
(supports x16, or x8 + x8, or x4 + x4 + x8)
4-lane PCIe signal from PCH via golden finger
(supports x4, or x1 + x1 + x1 + x1)
1 x M.2 A key (2230) with PCIe Gen3 x2/USB 2.0
1 x M.2 M key (2280/2242) with PCIe Gen3 x4
Digital I/O
1 x 12-bit digital I/O (2x7 pin)
TPM
Intel® PTT (TPM 2.0)
Fan Connector
1 x CPU fan connector (1x4 pin)

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 18
Chassis Open
1 x Chassis intrusion (1x2 pin)
Power Supply
5V/12V, ATX/AT power supply
Support AT/ATX mode
ErP/EuP compliant
Watchdog Timer
Software programmable, support 1~255 sec. system reset
Power
Consumption
[email protected]1A, [email protected], 1[email protected], 5V[email protected]
(Intel® Core™ i9-11900K CPU with 4 GB 3200 MHz DDR4 memory)
Operating
Temperature
0°C ~ 60°C
Storage
Temperature
-30°C ~ 70°C
Operating
Humidity
5% ~ 95%,non-condensing
Dimension
169 mm x 126 mm
Weight
GW:1000g / NW:420g
Table 1-1: Technical Specification

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 19
Chapter
2
2Packing List

HPCIE-Q470 Half-size PICMG 1.3 CPU Card
Page 20
2.1 Anti-static Precautions
WARNING!
Static electricity can destroy certain electronics. Make sure to follow the
ESD precautions to prevent damage to the product, and injury to the
user.
Make sure to adhere to the following guidelines:
▪Wear an anti-static wristband: Wearing an anti-static wristband can prevent
electrostatic discharge.
▪Self-grounding: Touch a grounded conductor every few minutes to discharge
any excess static buildup.
▪Use an anti-static pad: When configuring any circuit board, place it on an
anti-static mat.
▪Only handle the edges of the PCB: Don't touch the surface of the
motherboard. Hold the motherboard by the edges when handling.
2.2 Unpacking Precautions
When the HPCIE-Q470 is unpacked, please do the following:
▪Follow the anti-static guidelines above.
▪Make sure the packing box is facing upwards when opening.
▪Make sure all the packing list items are present.
