PXE-9S2-R10
9-Slot PICMG 1.3 PCIe to PCI Bridge Backplane
User Manual Ver. 1.0
1. USB1, USB2: External 4 Port USB Connectors From the Mainboard
2. FAN1, FAN2, FAN3, FAN4 : Fan Connector
3. ATXCTL1 : Backplane to Mainboard ATX Power Control Connector
4. PWRBTN : Power on Button
2
●
1
■
5. RESET : Reset Button Connector
Apr. 19, 2013
PIN
DESCRIPTION
PIN
DESCRIPTION
1
USBVCC
2
GND
3
DATA-
4
DATA+
5
DATA+
6
DATA-
7
GND
8
USBVCC
7
5
3
1
●
●
●
■
●
●
●
●
8
6
4
2
PIN
DESCRIPTION
1
GND
2
+12V
3
NC
123
PIN
DESCRIPTION
1
GND
2
PSON#
3
5VSB
123
PIN
DESCRIPTION
1
GND
2
SHB_RST#
2
●
1
■
PIN
DESCRIPTION
1
GND
2
PWRBT#

2
6.PWRGD : Power Good Connector
7. SM-BUS : External System Management BUS Connector
2
●
1
■
8. CN1 : PCIE X16 SDVO Control Signal Pin
9. PWR1 : ATX Power Connector
ATX : ATX Power Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
+3.3 V
2
+3.3 V
3
GND
4
+5 V
5
GND
6
+5 V
7
GND
8
PWRGD_PS
9
5VSB
10
+12 V
11
+12 V
12
+3.3 V
13
+3.3 V
14
-12 V
15
GND
16
IO_PSON#
17
GND
18
GND
19
GND
20
N/A
21
+5 V
22
+5 V
23
+5 V
24
GND
2
●
1
■
1
2
3
■
●
●
PIN
DESCRIPTION
1
GND
2
PWRGD
PIN
DESCRIPTION
1
SMDAT
2
SMCLK
PIN
DESCRIPTION
1
EXP_EN
2
SDVO_CLK
3
SDVO_DAT
19
17
15
13
11
9
7
5
3
1
●
●
●
●
●
●
●
●
●
■
●
●
●
●
●
●
●
●
●
●
20
18
16
14
12
10
8
6
4
2

3
10, 12V1
11. PCI routing Table:
SIGNAL
REQ#
GNT#
IDSEL
INTA#
INTB#
INTC#
INTD#
PIN No.
B18
A17
A26
A6
B7
A7
A8
PCI1
REQ0#
GNT0#
AD31
B
C
D
A
PCI2
REQ1#
GNT1#
AD30
C
D
A
B
PCI3
REQ2#
GNT2#
AD29
D
A
B
C
PCI4
REQ3#
GNT3#
AD28
A
B
C
D
12. Notice:
a. Recommend to use 6mm width spacer to install
b. Torsion must less than 6lb-inch
PIN
NO.
DESCRIPTI
ON
PIN NO.
DESCRIPT
ION
1
+12V
2
GND
3
GND
4
+12 V

4
12. Dimension:
