IEI Technology AFL3-W07A-BT User manual

AFL3-W07A-BT Panel PC
Page I
User Manual
AFL3-W07A-BT
MODEL:
Flat Bezel Panel PC with Intel® Celeron
®
N2807 Dual-Core CPU,
Touchscreen, Dual USB 3.0, Dual GbE LAN, Dual RS-232,
HD Audio, Wi-Fi 802.11a/b/g/n/ac and RoHS
Rev. 1.05 - March 4, 2016
User Manual

AFL3-W07A-BT Panel PC
Page II
Revision
Date Version Changes
March 4, 2016 1.05 Updated Table 1-1: System Specifications
October 14, 2015 1.04 Changed touch controller
Added Section 3.11: OS Installation
Updated Chapter 4: BIOS Setup
July 23, 2015 1.03 Updated Table 6-13: Webcam Connector (CAM_USB1) Pinouts
June 30, 2015 1.02 Updated the following sections:
Chapter 2: Unpacking
Section 3.7.2: Panel Mounting
Section 3.7.3: Cabinet and Rack Installation
November 11, 2014 1.01 Updated Wi-Fi specification to 802.11a/b/g/n/ac
July 22, 2014 1.00 Initial release

AFL3-W07A-BT Panel PC
Page III
Copyright
COPYRIGHT NOTICE
The information in this document is subject to change without prior notice in order to
improve reliability, design and function and does not represent a commitment on the part
of the manufacturer.
In no event will the manufacturer be liable for direct, indirect, special, incidental, or
consequential damages arising out of the use or inability to use the product or
documentation, even if advised of the possibility of such damages.
This document contains proprietary information protected by copyright. All rights are
reserved. No part of this manual may be reproduced by any mechanical, electronic, or
other means in any form without prior written permission of the manufacturer.
TRADEMARKS
All registered trademarks and product names mentioned herein are used for identification
purposes only and may be trademarks and/or registered trademarks of their respective
owners.

AFL3-W07A-BT Panel PC
Page IV
Manual Conventions
WARNING
Warnings appear where overlooked details may cause damage to the
equipment or result in personal injury. Warnings should be taken
seriously.
CAUTION
Cautionary messages should be heeded to help reduce the chance of
losing data or damaging the product.
NOTE
These messages inform the reader of essential but non-critical
information. These messages should be read carefully as any directions
or instructions contained therein can help avoid making mistakes.
HOT SURFACE
This symbol indicates a hot surface that should not be touched without
taking care.

AFL3-W07A-BT Panel PC
Page 23
3.7.1 Wall Mounting
To mount the flat bezel panel PC onto the wall, please follow the steps below.
Step 1: Select the location on the wall for the wall-mounting bracket.
Step 2: Carefully mark the locations of the four screw holes in the bracket on the wall.
Step 3: Drill four pilot holes at the marked locations on the wall for the bracket retention
screws.
Step 4: Align the wall-mounting bracket screw holes with the pilot holes.
Step 5: Secure the mounting-bracket to the wall by inserting the retention screws into
the four pilot holes and tightening them (4Figure 3-9).
Figure 3-9: Wall-mounting Bracket

AFL3-W07A-BT Panel PC
Page 24
Step 6: Insert the four monitor mounting screws provided in the wall mount kit into the
four screw holes on the real panel of the flat bezel panel PC and tighten until the
screw shank is secured against the rear panel (4Figure 3-10).
WARNING:
Please use the M4 screws provided in the wall mount kit for the rear panel.
If the screw is missing, the thread depth of the replacement screw should
be not more than 4 mm.
Step 7: Align the mounting screws on the monitor rear panel with the mounting holes on
the bracket.
Step 8: Carefully insert the screws through the holes and gently pull the monitor
downwards until the monitor rests securely in the slotted holes (4Figure 3-10).
Ensure that all four of the mounting screws fit snugly into their respective slotted
holes.
NOTE:
In the diagram below the bracket is already installed on the wall.

AFL3-W07A-BT Panel PC
Page 25
Figure 3-10: Chassis Support Screws
Step 9: Secure the panel PC by fastening the retention screw of the wall-mounting
bracket. (4Figure 3-11).
Figure 3-11: Secure the Panel PC

AFL3-W07A-BT Panel PC
Page 26
3.7.2 Panel Mounting
To mount the AFL3-W07A-BT flat bezel panel PC into a panel, please follow the steps
below.
Step 1: Select the position on the panel to mount the flat bezel panel PC.
Step 2: Cut out a section corresponding to the size shown below. The size must be
smaller then the outer edge.
Figure 3-12: Cutout Dimensions
Step 3: Slide the flat bezel panel PC through the hole until the frame is flush against the
panel.
Step 4: Insert a M5*50 screw into the screw hole on the side of the panel mounting
bracket. Then, install the following components onto the screw in sequence.
See Figure 3-13.
Sequence Item Photo Instruction
1 Spring Install a spring onto the screw.
2 Nut
Tighten a nut until the spring is
compressed enough for plastic cap.
3 Plastic
cap
Tighten a plastic cap onto the end of
screw thread.

AFL3-W07A-BT Panel PC
Page 27
Step 5: Repeat Step 4 to install the other three screws into the sides of the two panel
mounting brackets.
Figure 3-13: Panel Mounting Kit Installation
Step 6: Align the panel mounting bracket screw holes with the VESA mounting holes on
the rear of the panel PC.
Step 7: Secure the two panel mounting brackets to the rear of the panel PC by inserting
the four retention screws into the VESA mounting holes and tightening them
(Figure 3-14).Step0:
NOTE:
The panel mounting kit described in this section is an optional item. To
purchase it, please contact an IEI sales representative.

AFL3-W07A-BT Panel PC
Page 28
Figure 3-14: Securing Panel Mounting Brackets
3.7.3 Cabinet and Rack Installation
The AFL3-W07A-BT flat bezel panel PC can be installed into a cabinet or rack. The
installation procedures are similar to the panel mounting installation. To do this, please
follow the steps below:
NOTE:
When purchasing the cabinet/rack installation bracket, make sure it is
compatible with both the AFL3-W07A-BT flat bezel panel PC and the
rack/cabinet into which the AFL3-W07A-BT is installed.
Step 1: Slide the rear chassis of the AFL3-W07A-BT flat bezel panel PC through the
rack/cabinet bracket until the frame is flush against the front of the bracket
(Figure 3-15).

AFL3-W07A-BT Panel PC
Page 29
Figure 3-15: Rack/Cabinet Bracket Installation
Step 2: Insert a M5*50 screw into the screw hole on the side of the rack mounting
bracket. Then, install the following components onto the screw in sequence.
See Figure 3-16.
Sequence Item Photo Instruction
1 Spring Install a spring onto the screw.
2 Nut
Tighten a nut until the spring is
compressed enough for plastic cap.
3 Plastic
cap
Tighten a plastic cap onto the end of
screw thread.
Step 3: Repeat Step 4 to install the other three screws into the sides of the two rack
mounting brackets.

AFL3-W07A-BT Panel PC
Page 30
Figure 3-16: Rack Mounting Kit Installation
Step 4: Align the rack mounting bracket screw holes with the VESA mounting holes on
the rear of the panel PC.
Step 5: Secure the two rack mounting brackets to the rear of the panel PC by inserting
the four retention screws into the VESA mounting holes and tightening them
(Figure 3-17).
NOTE:
The rack mounting kit described in this section is an optional item. To
purchase it, please contact an IEI sales representative.

AFL3-W07A-BT Panel PC
Page 31
Figure 3-17: Securing Rack Mounting Brackets
Step 6: Slide the panel PC with the attached rack/cabinet bracket into a rack or cabinet
(Figure 3-18).
Figure 3-18: Install into a Rack/Cabinet

AFL3-W07A-BT Panel PC
Page 32
Step 7: Once the panel PC with the attached rack/cabinet bracket has been properly
inserted into the rack or cabinet, secure the front of the rack/cabinet bracket to
the front of the rack or cabinet (Figure 3-18).
3.7.4 Arm Mounting
The AFL3-W07A-BT is VESA (Video Electronics Standards Association) compliant and
can be mounted on an arm with a 75 mm interface pad. To mount the AFL3-W07A-BT on
an arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation
that came with the mounting arm.
NOTE:
When purchasing the arm please ensure that it is VESA compliant and that
the arm has a 75 mm interface pad. If the mounting arm is not VESA
compliant it cannot be used to support the AFL3-W07A-BT flat bezel panel
PC.
Step 2: Once the mounting arm has been firmly attached to the surface, lift the flat bezel
panel PC onto the interface pad of the mounting arm.
Step 3: Align the retention screw holes on the mounting arm interface with those in the
flat bezel panel PC (4Figure 3-19).

AFL3-W07A-BT Panel PC
Page 33
Figure 3-19: Arm Mounting Retention Screw Holes
Step 4: Secure the AFL3-W07A-BT to the interface pad by inserting four retention
screws through the mounting arm interface pad and into the AFL3-W07A-BT.
Step0:
Figure 3-20: Arm Mounting

AFL3-W07A-BT Panel PC
Page 34
3.7.5 Stand Mounting
To mount the AFL3-W07A-BT using the stand mounting kit, please follow the steps below.
Step 1: Locate the screw holes on the rear of the AFL3-W07A-BT. This is where the
bracket will be attached.
Step 2: Align the bracket with the screw holes.
Step 3: To secure the bracket to the AFL3-W07A-BT insert the retention screws into the
screw holes and tighten them.
Figure 3-21: Stand Mounting (Stand-A/Bxx)
3.7.6 V-Stand Mounting
To mount the AFL3-W07A-BT using the V-Stand mounting kit, please follow the steps
below.
Step 1: Carefully mark the locations of the four V-Stand screw holes on the mounting
area. Drill four pilot holes at the marked locations for the V-Stand retention
screws.

AFL3-W07A-BT Panel PC
Page 35
Figure 3-22: Drill Pilot Holes for V-Stand
Step 2: Align the screw holes on the V-Stand with the VESA mount screw holes on the
system rear panel.
Step 3: Insert the four VESA mount screws into the four screw holes on the system rear
panel. Adjust the V-Stand to a proper position.
Step 4: Tighten until the screw shank is secured against the rear panel.
Figure 3-23: Secure V-Stand to System

AFL3-W07A-BT Panel PC
Page 36
Step 5: Align the V-Stand screw holes with the pilot holes on the mounting area. Mount
the V-Stand by inserting the retention screws into the four pilot holes and
tightening them.
Step 6: Adjust the V-Stand to have a best viewing angle to operate the system.Step0:
Figure 3-24: Secure V-Stand to Mounting Area
3.8 Powering On the System
To power on the system, follow the steps below:
Step 1: Connect the power cord to the power adapter. Connect the other end of the
power cord to a power source.
Step 2: Connect the power adapter to the power connector of the AFL3-W07A-BT.
Step 3: Locate the power button on the I/O panel.
Step 4: Hold down the power button until the power LED on the front panel turns on in
green. Step 0:
