IKEA FIXA User manual

FIXA
Design and Quality
IKEA of Sweden

2
13
13 14
1
64
57
7
3
8
9
10
12 11

A
B

ENGLISH 4
Original instructions
ΕΛΛΗΝΙΚΑ 12
Μετάφραση από το πρωτότυπο
κείμενο των οδηγιών.
中文 20
从最初说明翻译过来
繁中 26
使用說明翻譯
한국어 31
설명서 원문의 번역.
日本語 38
説明書の原文から翻訳
BAHASA INDONESIA 45
Diterjemahkan dari
instruksi aslinya.
BAHASA MALAYSIA 53
Diterjemah daripada
arahan asal.
 61
 

FIXA jigsaw
TECHNICAL SPECIFICATIONS
Voltage: Local mains voltage
Mains frequency: Local mains frequency
Power input: 400 W
Stroke rate at no load: 3000 strokes per
minute
Max. sawing depth (wood): 60 mm (2 3/8”)
Max. sawing stroke: 17.5 mm (11/16”)
Bevel cuts (left/right), max.: 45 °
Weight: 1.7 kg (3.75 lbs)
Vibration (according to EN 60745-1, EN
60745-2-11):
ah,CM.: 19.463 m/s2 k = 1.5 m/s2
ah,CW.: 15.34 m/s2 k = 1.5 m/s2
Noise (according to EN 60745-1):
Noise pressure level Lpa = 88.42 dB (A),
Kpa = 3 dB (A)
Noise power level Lwa = 99.42 dB (A),
Kwa = 3 dB (A)
LIST OF FEATURES
The numbering of the product features
shown refers to the illustration of the
jigsaw on the graphic page.
1. On/Off switch
2. Lock-on button
3. Scale
4. Base plate
5. Guide roller
6. Saw blade (for wood)
7. Holder for guide roller
8. Dust extraction connection
9. Dust extraction adapter
10. Grip
11. Allen key
12. Allen key holder
13. Socket head screws
14. Socket head screws
AREAS OF USE
This jigsaw is intended for making
separating cuts and cut-outs in wood,
plastic, soft metals, ceramic plates
and rubber while resting rmly on the
workpiece. Be sure to choose a saw blade
that is intended for the type of material
you are going to cut. The jigsaw is
suitable for straight and curved cuts with
mitre angles to 45°.
GENERAL SAFETY INSTRUCTIONS
General safety instructions for power
tools
WARNING!
Read all safety warnings and
all instructions. Failure to follow all the
warnings and instructions may result in
electric shock, re and/or serious injury.
Save all warnings and instructions for
future reference.
The term “power tool” in all of the
warnings listed below refers to your mains
operated (corded) power tool or battery
operated (cordless) power tool.
Work area safety
a. Keep work area clean and well lit.
Cluttered and dark areas invite accidents.
b. Do not operate power tools in
explosive atmospheres, such as in the
presenceofammableliquids,gases
or dust. Power tools create sparks which
may ignite the dust of fumes.
ENGLISH 4

c. Keepchildrenandbystanders
away while operating a power tool.
Distractions can cause you to lose control.
Electrical safety
a. Power tool plugs must match the
outlet. Never modify the plug in any
way. Do not use any adapter plugs
with earthed (grounded) power tools.
Unmodied plugs and matching outlets will
reduce risk of electric shock.
b. Avoidbodycontactwithearthed
or grounded surfaces such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric shock
if your body is earthed or grounded.
c. Do not expose power tools to rain or
wet conditions. Water entering a power
tool will increase the risk of electric shock.
d. Donotabusethecord.Never
use the cord for carrying, pulling or
unplugging the power tool. Keep the
cord away from heat, oil, sharp edges
or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool
outdoors, use an extension cord
suitableforoutdooruse. Use of a cord
suitable for outdoor use reduces the risk of
electric shock.
f. If operating a power tool in a damp
locationisunavoidable,usearesidual
current device (RCD) protected supply.
Use of an RCD reduces the risk of electric
shock.
Personal safety
a. Stay alert, watch what you are
doing and use common sense when
operating a power tool. Do not use
a power tool while you are tired or
undertheinuenceofdrugs,alcohol
or medication. A moment of inattention
while operating power tools may result in
serious personal injury.
b. Usepersonalprotectiveequipment.
Always wear eye protection. Protective
equipment such as dust mask, non-
skid safety shoes, hard hat, or hearing
protection used for appropriate conditions
will reduce personal injuries.
c. Prevent unintentional starting:
Ensure that the switch is in the off-
positionbeforeconnectingtopower
sourceand/orbatterypack,pickingup
or carrying the tool. Carrying power tools
with your nger on the switch or plugging
in power tools that have the switch on
invites accidents.
d. Remove any adjusting key or
wrenchbeforeturningthepowertool
on. A wrench or a key left attached to a
rotating part of the power tool may result
in personal injury.
e. Do not overreach. Keep proper
footingandbalanceatalltimes. This
enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g. If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of
these devices can reduce dust related
hazards.
5

Power tool use and care
a. Do not force the power tool. Use
the correct power tool for your
application. The correct power tool will
do the job better and safer at the rate for
which it was designed.
b. Do not use the power tool if the
switch does not turn it on and off.
Any power tool that cannot be controlled
with the switch is dangerous and must be
repaired.
c. Disconnect the plug from the power
sourceand/orthebatterypackbefore
making any adjustments, changing
accessories, or storing power tools.
Such preventive safety measures reduce
the risk of starting the power tool
accidentally.
d. Store idle power tools out of the
reach of children and do not allow
persons unfamiliar with the power tool
or these instructions to operate the
power tool. Power tools are dangerous in
the hands of untrained users.
e. Maintain power tools. Check for
misalignmentorbindingofmoving
parts,breakageofpartsandanyother
condition that may affect the power
tool’s operation. If damaged, have the
powertoolrepairedbeforeuse.Many
accidents are caused by poorly maintained
power tools.
f. Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
g. Use the power tool, accessories
andtoolbitsetc.,inaccordancewith
these instructions and in the manner
intended for the particular type of
power tool, taking into account the
working conditions and the work to
beperformed. Use of the power tool for
operations different from those intended
could result in a hazardous situation.
h)Holdthepowertoolbyinsulated
gripping surfaces, when performing an
operation where the cutting accessory
may contact with hidden wiring or its
own cord. Cutting accessory contacting a
“live” wire may make exposed metal parts
of the power tool “live” and could give the
operator an electric shock.
Service
a. Haveyourpowertoolservicedby
aqualiedrepairpersonusingonly
identical replacements parts.
This will ensure that the safety of the
power tool is maintained.
MACHINE-SPECIFIC SAFETY
INSTRUCTIONS
Safety Warnings for Jigsaws
Keep hands away from the sawing
range. Do not reach under the
workpiece. Contact with the saw blade
can lead to injuries.
Apply the machine to the workpiece
only when switched on. Otherwise there
is danger of kickback when the cutting tool
jams in the workpiece.
Payattentionthatthebaseplate(4)
rests securely on the material while
sawing. A jammed saw blade can break or
lead to kickback.
6

When the cut is completed, switch off
the machine and then pull the saw
bladeoutofthecutonlyafterithas
come to a standstill. In this manner you
can avoid kickback and can place down the
machine securely.
Useonlysharp,awlesssawblades.
Bent or unsharp saw blades can break or
cause kickback.
Do not use other accessories than saw
bladesforthejigsaw.
Donotbrakethesawbladetoa
stopbyapplyingsidepressureafter
switching off. The saw blade can be
damaged, break or cause kickback.
Usesuitabledetectorstodetermine
if utility lines are hidden in the work
area or call your local utility company
for assistance. Contact with electric
lines can lead to re and electric shock.
Damaging a gas line can lead to explosion.
Penetrating a water line causes property
damage or may cause an electric shock.
Secure the workpiece. A workpiece
clamped with clamping devices or in a vice
is held more secure than by hand.
Keep your workplace clean. Blends of
materials are particularly dangerous. Dust
from light alloys can burn or explode.
Always wait until the machine has
cometoacompletestopbefore
placing it down. The tool insert can jam
and lead to loss of control over the power
tool.
Never use the machine with a
damagedcable.Donottouchthe
damagedcableandpullthemains
plugwhenthecableisdamagedwhile
working. Damaged cables increase
the risk of an electric shock.
The jigsaw is double insulated.
Products sold in GB only: Your product is
tted with an BS 1363/A approved electric
plug with internal fuse (ASTA approved to
BS 1362). If the plug is not suitable for
your socket outlets, it should be cut off
and an appropriate plug tted in its place
by an authorised customer service agent.
The replacement plug should have the
same fuse rating as the original plug. The
severed plug must be disposed of to avoid
a possible shock hazard and should never
be inserted into a mains socket elsewhere.
Products sold in AUS only: Use a residual
current device (RCD) with a rated residual
current of 30 mA or less.
VIBRATION INFORMATION
Vibrationlevel
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given
in EN 60745. It may be used to compare
one tool with another and as a preliminary
assessment of exposure to vibration
when using the tool for the applications
mentioned in this manual. However, using
the tool for different applications, or with
different or poorly maintained accessories,
may signicantly increase the exposure
level.
An estimation of the level of exposure to
vibration should also take into account
the times when the tool is switched off or
when it is running but not actually doing
the job, as this may signicantly reduce
7

the exposure level over the total working
period.
Protect yourself against the effects of
vibration by maintaining the tool and its
accessories, keeping your hands warm,
and organising your work patterns.
DECLARATION OF CONFORMITY
We declare under our sole responsibility
that this product, FIXA jigsaw, is in
conformity with the following standards
or standardized documents: EN 60745-1,
EN 60745-2-11, EN 55014-1, EN 55014-2,
EN 61000-3-2, EN 61000-3-3, EN 62233,
in accordance with the provisions of the
directives 2006/42/EC, 2004/108/EC,
2006/95/EC, 2002/96/EC, 2011/65/EC.
Technical documentation at: IKEA of
Sweden AB, Box 702, Tulpanvägen 8,
SE-343 81 Älmhult, SWEDEN.
The undersigned is responsible for
compilation of the technical documentation
and makes this declaration on behalf of
IKEA of Sweden AB.
Christina Niemelä Ström
Business Area Manager
IKEA of Sweden AB
INSTRUCTIONS FOR USE
• Before any work on the machine itself,
pull the mains plug.
• Whenmountingthesawblade,wear
protective gloves. Danger of injury
whentouchingthesawblade.
Selecting a Saw Blade
Use only T-shank saw blades. The saw
blade should not be longer than required
for the intended cut. Be sure to choose a
saw blade that is intended for the type of
material you are going to cut.
InsertingtheSawBlade(seegureA)
Clean the shank of the saw blade before
in serting it. An unclean shank cannot be
fas tened securely.
Slacken the two socket head screws (13)
using the included Allen key (11). Insert
the saw blade in the saw blade holder as
far as possible. The teeth of the saw blade
must point upward and forward. Tighten
the two socket head screws (13) using the
Allen key.
While inserting the saw blade, pay
attention that the back of the saw blade is
positioned in the groove of the guide roller
(5).
Precise cuts are only possible when the
guide roller (5) faces closely but not too
tight against the back of the saw blade
(the saw blade (6) may not be bent by the
guide roller). If required, loosen the socket
head screws (14) and move the holder (7)
of the guide roller in such a manner that
the guide roller faces closely against the
back of the saw blade. Tighten the socket
head screws (14) again.
Check the tight seating of the saw
blade. A loose saw blade can fall out
and lead to inju ries.
Removing the Saw Blade
(seegureA)
Slacken the two socket head screws (13)
using the included Allen key (11). Remove
the saw blade (6) from the saw blade
8

holder. Tighten the two socket head screws
(13) using the Allen key (11).
Dust/Chip Extraction
Dusts from materials such as lead-
containing coatings, some wood types,
minerals and metal can be harmful to
one’s health. Touch ing or breathing-in the
dusts can cause aller gic reactions and/
or lead to respiratory infections of the
user or bystanders. Certain dusts, such
as oak or beech dust, are considered as
carcinogenic, especially in connection
with wood-treatment additives (chromate,
wood preservative). Materials containing
asbestos may only be worked by
specialists. Use dust extraction whenever
possible. Provide for good ventilation of
the work ing place. It is recommended to
wear a P2 lter-class respirator.
Observe the relevant regulations in your
country for the materials to be worked.
Connecting the Dust Extraction
Insert the dust extraction adapter (9) into
the dust extraction connection (8). Align
the 2 pins of the dust extraction adapter
with the holes in the dust exhaust of the
machine. Twist the dust extraction adapter
a quarter turn counter clockwise to lock it
into place.
Connect the hose of a vacuum cleaner to
the dust extraction adapter (9).
To remove the dust extraction adapter (9),
twist the dust extraction adapter a quarter
turn clockwise. Pull the dust extraction
adapter from the machine.
The vacuum cleaner must be suitable
for the ma terial being worked. When
vacuuming dry dust that is especially det-
rimental to health or carcinogenic, use a
special vacuum cleaner.
OPERATING MODES
Before any work on the machine itself,
pull the mains plug.
WARNING! To reduce the risk of
injury, never use the tool when the base
plate (4) is loose or removed.
Adjusting the Cutting Angle
(seegureB).
• The base plate (4) can be swivelled by
45° to the left or right for mitre cuts.
Insert a saw blade (6).
• Loosen the two socket head screws
(14) and lightly slide the base plate (4)
toward the vacuum connection (8). For
adjustment of precise mitre angles, the
base plate has adjustment notches on
the left and right at 0°, 15, 30 and 45°.
• Swivel the base plate (4) to the desired
position according to the scale (3).
Afterwards, push the base plate (4)
to the stop in the direction of the saw
blade (6). Other mitre angles can be
adjusted using a protractor but then the
adjustment notches do not work.
• Position the holder for the guide roller
(7) in such a manner that the guide
roller (5) faces against the back of the
saw blade. Precise cuts are possible only
when the guide roller faces closely but
not to tightly against the back of the saw
blade.
• Tighten the two socket head screws (14)
again.
Starting Operation
Observe correct mains voltage! The voltage
of the power source must agree with the
voltage specied on the nameplate of the
machine.
9
