Imperial DABMAN i250 User manual

4746
Operating Manual
www.telestar.de
IMPERIAL DABMAN i250
E
Dabmann I 250_version1_DE_EN_NL_FR.indd 46 18.08.17 11:37

4746 IMPERIAL DABMAN i250
E
Operating Manual
TABLE OF CONTENTS
1. INTRODUCTION...................................48
2. SAFETY NOTICES .................................49
3. ITEMS SUPPLIED .................................53
4. ILLUSTRATIONS ..................................54
5. REMOTE CONTROL ...............................57
6. INSTALLATION....................................60
7. OPERATION ......................................62
7.1. Configuration.....................................62
7.2. Local Station .....................................69
7.3. Internet Radio....................................70
7.4. Media Center ....................................72
7.5. FM ..........................................73
7.6. DAB ..........................................74
7.7. AUX ..........................................76
7.8 Bluetooth ........................................77
7.8.1 Establish Bluetooth connection ...................77
7.8.2 Play media via Bluetooth .........................78
8. AIR MUSIC CONTROL .............................78
9. TROUBLESHOOTING ..............................83
10. DISPOSAL INSTRUCTIONS .......................86
11. FEATURES AND TECHNICAL DATA................87
12. SERVICE AND SUPPORT .........................90
13. CE MARKING....................................90
1. INTRODUCTIE ....................................94
Dabmann I 250_version1_DE_EN_NL_FR.indd 47 18.08.17 11:37

4948Operating Manual
E
1. INTRODUCTION
Thank you for purchasing the DABMAN i250. When you use the
DABMAN i250 for the rst time, please read these instructions
carefully, and retain them for reference in future. You will be able to
fully enjoy the many functions of the radio only if you follow the
instructions.
This operating manual will assist you with the
• correct
• safe
• optimal
use of the IMPERIAL DABMAN i250. We assume the user of the
radio has general knowledge related to the operation of consumer
electronics products.
Any person
• installing
• connecting
• operating
• cleaning
• disposing of
this radio must rst have taken notice of the entire contents of this op-
erating manual. Always keep this operating manual close to the radio.
Dabmann I 250_version1_DE_EN_NL_FR.indd 48 18.08.17 11:37

4948 IMPERIAL DABMAN i250
E
2. SAFETY NOTICES
Please read the safety notices carefully before operating the radio.
Please note all warnings and instructions both on the product and in
the operating manual.
2.1 Basic Safety notices
• In case of operating problems, disconnect the radio from the
power source.
• To avoid the risk of re or the danger of an electrical shock, do
not expose the radio to rain or to very humid, wet conditions.
• Do not open the housing of the product, otherwise you are at risk
of getting an electrical shock.
• Only connect the radio to the mains current via a correctly in
stalled 220– 240 V~, 50–60 Hz mains outlet.
• If you will not be using the radio for an extended period, discon
nect the external mains adapter from the mains outlet. Only pull
out the adapter, do not pull on the cable.
• In case of an electrical storm, disconnect the mains adapter of
the radio from the mains outlet.
• Should liquid or foreign objects fall into the radio, immediately dis
connect the mains adapter from the mains outlet. Have the
product checked by qualied personnel before resuming
operation. Otherwise you are in danger of getting an electrical
shock.
Dabmann I 250_version1_DE_EN_NL_FR.indd 49 18.08.17 11:37

5150Operating Manual
E
2. SAFETY NOTICES
• Please ensure the electrical outlet (plug) is easily accessible.
• Do not squeeze or sharply bend cable connections.
• If the mains cable is damaged, you must have the radio repaired
by an expert before using it again. Otherwise you are in danger of
getting an electrical shock.
• Never allow children to use the radio without supervision.
• Always leave maintenance or repair work to qualied personnel.
Ignoring this may endanger yourself and others.
• In case of operating problems, disconnect the radio from the
power supply.
• Obtain spare parts exclusively from the manufacturer.
• Changes to the product will result in a termination of liability by
the manufacturer.
• Remove protective foils/lms.
• Use only a dry cloth to clean the equipment
Note!
Note on disconnecting from mains supply. The product draws
power even when in standby mode. To completely disconnect the
product from the mains supply, the adapter must be
disconnected from the mains outlet.
Dabmann I 250_version1_DE_EN_NL_FR.indd 50 18.08.17 11:37

5150 IMPERIAL DABMAN i250
E
Correct positioning
• Place the radio on a rm, even surface.
• Avoid placing the radio close to sources of heat, e.g. radiators,
open res, e.g. candles, or devices with strong magnetic elds,
e.g. loudspeakers.
• Do not place any containers with liquids (e.g. vases) on the radio.
• Avoid places subject to direct sunshine or with a very high level
of dust.
• Do not cover the ventilation slots. Ensure adequate circulation of
air around the radio.
• Do not place any heavy objects on the radio.
• When moving the radio from a cold to a warm environment,
humidity may condense inside the radio. In this case you should
wait for an hour before operating the radio again.
• Place the mains cable in such a position that nobody will step on it
or trip over it.
2. SAFETY NOTICES
Dabmann I 250_version1_DE_EN_NL_FR.indd 51 18.08.17 11:37

5352Operating Manual
E
Correct handling of batteries
• Batteries may contain poisonous substances. Ensure batteries
are not handled by children. Children could place the batteries
in their mouth and swallow them. If a battery is swallowed, please
consult a doctor immediately.
• Leaking batteries may damage the remote control. If the radio is
not going to be used for an extended period, remove the
batteries.
• Batteries may contain poisonous substances. Batteries must be
disposed of in accordance with current legal regulations and with
consideration for the environment. Do not dispose of batteries in
your domestic waste.
• Do not expose batteries to open ames or extreme heat, as they
may explode.
• Always replace batteries by the same type.
2.2. Explanation of safety notices
You will nd the following categories of safety notices in the
operating manual:
Danger!
Notes marked with the word DANGER will warn you of possible
danger of injury to persons.
Instructions with the word NOTE will warn you of possible mate-
rial or environmental damage. These notes contain special advice
related to the economic operation of the receiver.
2. SAFETY NOTICES
Nr. Qty. Item
1 1 DABMAN i250
2 1 Remote control
3 1 External mains adapter
4 1 Operating manual
5 1 Guarantee card
Dabmann I 250_version1_DE_EN_NL_FR.indd 52 18.08.17 11:37

5352 IMPERIAL DABMAN i250
E
3. ITEMS SUPPLIED
1 2 3 4 5
Nr. Qty. Item
1 1 DABMAN i250
21
Remote control
31External mains adapter
4 1 Operating manual
5 1 Guarantee card
NL
D
E
Bedienungsanleitung
Operating Manual
Handleiding
Manuel d‘utilisation
www.telestar.de
F
IMPERIAL DABMAN i250
Sehrgeehrter Kunde,
wirbedanken uns, dass Sie sich für dieses hochwertige Produkt entschieden haben. Sollte es trotzdem
beidiesem Produkt zu einer Störung kommen, bitten wir Sie, sich zunächst an unsere technische Hotline
02102/1338-339zu wenden. Sollten wir das Problem über diesen Weg nicht lösen können, senden Sie
dasProdukt an folgende Anschrift ein:
GARANTIEKARTE
s s s s s
DigitalBOXEurope GmbH
Servicecenter
AmWeiher 14 (Industriegebiet)
D-56766Ulmen
DigitalBOXEurope GmbH
Servicecenter
AmWeiher 14 (Industriegebiet)
D-56766Ulmen
GARANTIEKARTE
s s s s s
Name
Absender BitteBlockschriftin GROSSBUCHSTABEN · Bitte Kästchen beachten
Vorname
PLZundOrt
TelefonmitVorwahl
UnterschriftdesKäufers
Gerätetyp
Verbleibtbeim Kunden
Garantiekarte_NORMA.indd 1 16.08.12 11:45
Dabmann I 250_version1_DE_EN_NL_FR.indd 53 18.08.17 11:37

5554Operating Manual
E
4. ILLUSTRATIONS
87
6
5 9
4
310 11 12 13
2
1
15
14 16
17
18
19
20 21
Dabmann I 250_version1_DE_EN_NL_FR.indd 54 18.08.17 11:37

5554 IMPERIAL DABMAN i250
E
4. ILLUSTRATIONS
1 Station memory button 5 / Next track
Switches to programme memory 5 in radio mode.
Selects the next track of a file. Hold down the button to
fast forward.
2 Station memory button 4 / Track back
Switches to programme memory 4 in radio mode.
Selects the previous track of a file. Hold down the button
to start high speed rewind.
3 Station memory button 3 / Play-Pause
Switches to programme memory 3 in radio mode.
Pauses or starts playback via USB disk
4. Station memory button 2 / Stop
Switches to programme memory 2 in radio mode.
Stops playback via USB disk
5. Station memory button 1 / Stop
Switches to programme memory 1 in radio mode.
6. Power on / off button
Use this button to turn on the device or to standby.
7. Bluetooth Mode indicator LED´s
Indicates the current Bluetooth status RX Receiver or TX
Transmitter
8. Menu button
Displays the menu of the device.
9 Mode
Switch the operating mode of the device between
Internetradio, DAB+, UKW, UPnP, AUX, Bluetooth and
USB here.
10./11. Navigation / Station selection
Navigate through the menu using these buttons or
choose the next station from the station list.
Dabmann I 250_version1_DE_EN_NL_FR.indd 55 18.08.17 11:37

5756Operating Manual
E
12. Volume control, Confirmation button
Change the volume with the dial or confirm menu entries
by pressing the button.
13. Display
14. Power switch
Here you can switch the radio on or off. The radio will be
disconnected from the power supply in position 0.
15. Mains adapter connection
To connect the radio with the mains adapter (supplied)
16. USB connection
Here you can connect the radio with a USB storage device
like USB HDD drive, USB Stick or USB CD/DVD drive in
order to reproduce music files from this.
17. LAN connection
Here you can connect the radio via a network cable
with an existing network in order to use the Internet radio
function. Alternatively the radio can also be
connected via WiFi
18. AUX IN
To connect an external audio source such as an MP3
player, smartphone etc. using the 3.5 mm AUX cinch cable
14. LINE OUT
Here you can connect the radio with a hi-fi amplifier or with
active loudspeakers in order to process the music
received through the radio via a sound system.
15. Headphone socket
Here you can connect a headphone, in order to listen to
music played on the radio via headphones. When headpho
nes are connected, music reproduction via the radio louds
peakers will be interrupted.
4. ILLUSTRATIONS
Dabmann I 250_version1_DE_EN_NL_FR.indd 56 18.08.17 11:37

5756 IMPERIAL DABMAN i250
E
5. REMOTE CONTROL
6
5
4
3
7
2
1
8
910 11
12
13
14 15
16
17
18
19
20
21
22
23
24
Dabmann I 250_version1_DE_EN_NL_FR.indd 57 18.08.17 11:37

5958Operating Manual
E
1. Standby button
Use this button to turn the device on or o.
2. Sleep
Use this button to turn the sleep timer of the unit on or o.
3. WPS button
With this button you can establish a W-LAN connection in
your home network.
4. Alarm
Use this button to activate the alarm clock function
5. Display dimmer
Adjusts the brightness of display
6. Local radio
7. UPnP
Enables the device‘s UPnP function.
8. Repeat
Use this button to repeat playback of one or more tracks
9. Shue
This activates random playback
10. Menu
Use this button to activate the device‘s menu
11. Mode
Switches between the various modes, FM Radio, Internet
Radio, My Music, DAB Radio
12. Enter
This button is used to conrm an entry
13. Navigation up/down - left/right
Use these buttons to navigate through the menu
14. Select previous track / rewind
Use this button to select the previous track or to rewind.
5. REMOTE CONTROL
Dabmann I 250_version1_DE_EN_NL_FR.indd 58 18.08.17 11:37

5958 IMPERIAL DABMAN i250
E
15. Select next track / fast forward
Use this button to select the next track or to fast forward.
16. Play
Starts or pauses playback
17. Mute
Mutes the device‘s volume to silent.
18. Stop
Stops playback
19. V+ volume
Increases the volume
20. Numerical keypad
21. V- volume
Decreases the volume
22. EQ equalizer function
You can activate the equalizer function and congure
custom sound settings using this button.
23. Language
You can change the menu language with this button.
24. Favourites button
Turns on one of the individually stored favourite channels.
5. REMOTE CONTROL
Dabmann I 250_version1_DE_EN_NL_FR.indd 59 18.08.17 11:37

6160Operating Manual
E
6. INSTALLATION
Please remove the parts carefully from the packaging. Check whe-
ther all parts are present.
Note: the radio can be controlled both by the keys on the radio as
well as via the remote control. The operation via the remote control
is more convenient and easy method of playing the DABMAN i250.
For this reason, this operating manual will focus of setting up and
operating the radio via the remote control supplied.
If the radio is connected to a network, it can also be controlled via
the application AirMusicControl App. This application is
available for Android and IOS operating systems. For more details
see Chapter 8.
6.1. Power supply
First, connect the mains adapter supplied with the corresponding
socket on the rear panel of the DABMAN i250. Now connect the
mains adapter to a 220V outlet. Then extend the telescopic anten-
na on the rear panel of the radio to its full extent, this will ensure the
best possible reception, if you wish to receive terrestrially broadcast
stations via the antenna.
6.2. Network connection
To use the Internet functions of the radio, it must be connected to
a network. You can establish the connection via a cable (LAN) or
via the integrated W-LAN receiver. If you are using a LAN cable,
connect this with the LAN socket (Point 12, page 11)
Dabmann I 250_version1_DE_EN_NL_FR.indd 60 18.08.17 11:37

6160 IMPERIAL DABMAN i250
E
6. INSTALLATION
6.3 Language selection
Switch on the power switch on the rear panel of the radio. The radio
will be switched on.
Use the Up/down keys of the remote control to select the menu
language. Confirm the menu language selected by pressing the
ENTER key on the remote control.
6.4. Checking the network
If you wish to connect the radio with your home network, confirm
the question displayed by pressing Yes. If this setting is selected, the
radio will check for available networks each time it is switched on.
6.5. Network configuration
To connect your radio with the network, confirm the question dis-
played by pressing Yes. If you do not wish ot connect the radio with
a network, you can bypass this menu item by selecting No.
6.5.1 Network selection
Select the type of connection to be used to connect the radio with a
network. If you have connected a LAN cable, select Cable Network,
and if you wish to establish a wi-fi connection (W-LAN) select Wirel-
ess Network.
When selecting a connection via W-LAN (wireless network) all
available networks will be displayed. Select the network with which
the connection is to be established
Enter the W-LAN key. Use the ▼▲ keys to select a symbol, continue
by pressing the ►key.
Confirm the entry by pressing ENTER.
Dabmann I 250_version1_DE_EN_NL_FR.indd 61 18.08.17 11:37

6362Operating Manual
E
Press the Menu key on the radio or on the remote control to go to the
main menu of the radio. The radio will automatically close the menu
after 10 seconds, and will revert to the radio mode previously selec-
ted, a display in the bottom right-hand corner will show the seconds,
counting backwards.
You can navigate around the menu using the ▼▲ ►◄ keys.
The main menu of the radio consists of the following menu items:
You can select the individual menu items using the ▸ ◂ arrow keys.
Conrm your selection by pressing the ENTER key.
7.1. Configuration
Press the Menu key on the radio or on the remote control, and use
the ►◄ keys to select Settings.
You can make individual settings for the radio under this menu item.
7. OPERATION
Dabmann I 250_version1_DE_EN_NL_FR.indd 62 18.08.17 11:37

6362 IMPERIAL DABMAN i250
E
7. OPERATION
7.1.1 Mode
Select the operating mode of the radio.
If you select the mode Radio Alarm, the radio will switch to a digital
clock on the display. Go to the menu item ALARM to congure the
radio as a radio alarm.
7.1.2 My MediaU Management
Here you can activate or deactivate the Mediau Management
function.
The MediaU Management function allows you to save an individual
station list, and to play these stations.
To set up and activate your station list, you will require a login on the
following Internet page: http://www.mediayou.net/
If your log-in is successful, you can register your radio.
To do this, please enter the MAC address of the radio as a serial
number. The MAC address of the radio can be found under the item
Information Center.
Whenever you have updated the web page, on which you can manage
and update your personal radio stations, please navigate your radio to
My MediaU Management to synchronize the changes.
Dabmann I 250_version1_DE_EN_NL_FR.indd 63 18.08.17 11:37

6564Operating Manual
E
7.1.3. Network
Here you can congure your network settings.
Use the ▼▲ keys to select the desired menu item, and conrm by
pressing ENTER.
The network will be congures as described under Point 6.4.
7.1.4. Date & Time
Here you can set the time and date.
7. OPERATION
Dabmann I 250_version1_DE_EN_NL_FR.indd 64 18.08.17 11:37

6564 IMPERIAL DABMAN i250
E
7. OPERATION
The radio is set to automatic time setting at the factory. When the
radio is connected to the Internet via a network, the time and date
will be synchronized automatically. In this case it is not necessary to
set the time.
7.1.5. Alarm
The radio can be used as a radio alarm.
This menu item allows you to set 2 wake-up times if desired. Also,
you can set whether the alarm is to go o at the set time with a
note, a melody, an Internet radio station, a DAB+ radio station or an
FM station.
When you have entered the alarm time, activate the radio alarm
function in the menu.
To stop the alarm, press the Enter key on the remote control, or
key 7 on the radio.
To do this, go to Settings and select the menu item Mode, and
switch the operating mode to radio alarm here. (Chapter 7.1.1.)
Dabmann I 250_version1_DE_EN_NL_FR.indd 65 18.08.17 11:37
