Impex MARCY JD-3.1 User manual

NOTE:
Please read all instructions
carefully before using this
product
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
JD-3.1
Retain This
Manual for
Reference
150331
OWNER'S
MANUAL
MARCY JD-3.1
HYPER EXTENSION
BENCH
IMPEX INC.
2801 South Towne Avenue, Pomona, California 91766
Tel: [phone] Fax: [phone]
www.impex-fitness.com
support @impex-fitness.com

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................... 1
IMPORTANT SAFETY NOTICES..................................................................... 2
HARDWARE PACK……….....…....................................................................... 3
ASSEMBLY INSTRUCTIONS........................................................................... 4
EXPLODED DIAGRAM……………………………………………………………… 5
PARTS LIST...................................................................................................... 6
WARRANTY.................................................................................................…. 7
ORDERING PARTS.......................................................................................… 7
BEFORE YOU BEGIN
Thank you for selecting the MARCY JD-3.1 Hyper Extension Bench
by IMPEX INC. . For your safety and benefit, read this manual
carefully before using the machine. As a manufacturer, we are
committed to provide you complete customer satisfaction. If you
have any questions, or find there are missing or damaged parts, we
guarantee you complete satisfaction through direct assistance from
our factory. To avoid unnecessary delays, please call our TOLL-
FREE customer service number. Our Customer Service Agents will
provide immediate assistance to you.
1
IMPORTANT SAFETY NOTICE
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
support @impex-fitness.com

PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions
apply whenever you operate a piece of exercise equipment. Be sure to read the
entire manual before you assemble or operate your machine. In particular, note
the following safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN
IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT
YOUR PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS
OVER THE AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH
PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING ANY FITNESS
EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR
PERSONAL INJURY OR PROPERTY DAMAGE SUSTAINED BY OR
THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
2
HARDWARE PACK

3

ASSEMBLY INSTRUCTION
Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen
Wrenches
NOTE: It is strongly recommended two or more people assembling this machine to
avoid possible injury.
STEP 1 (See Exploded Diagram)
A. Insert the Rear Base Frame (#2) into the rear of Main Base Frame (#1). Attach the Rear
Post (#3) to the Main Base Frame. Align the holes then secure them together with five
M10 x 5/8” Hex Bolts (#11) and Ø ¾” Washers (#22).
B. Attach the Seat Post (#4) to the Main Base Frame (#1). Secure it with two M10 x 3” Hex
Bolts (#12), four Ø ¾” Washers (#22), and two M10 Aircraft Nuts (#15) from the side.
Secure it with two M10 x 5/8” Hex Bolts (#11), and Ø ¾” Washers (#22) from the top.
C. Attach the Seat Pad (#10) to the Seat Bracket (#6). Secure it with four M8 x ¾” Hex Bolts
(#13) and Ø 5/8” Washers (#14).
D. Attach the Seat Bracket (#6) to the Seat Post (#4). Then attached the Left and Right
Handlebars (#7) & (#8) to the Seat Post. Secure them with four M10 x 5/8” Allen Bolts
(#16) and Ø ¾” Washers (#22).
E. Slide the Leg Support Frame (#5) onto the Rear Post. Use the Lock Knob (#9) to lock it at
desired height.
F. Push two Foam Rolls (#17) onto the tube on the Leg Support Frame from both ends. Plug
a Foam Roll End Cap (#18) to each Foam Roll.
4

EXPLODED DIAGRAM
5

Parts list
KEY NO. DESCRIPTION Q’ty
1 Main Base Frame 1
2 Rear Base Frame 1
3 Rear Post 1
4 Seat Post 1
5 Leg Support Frame 1
6 Seat Bracket 1
7 Right Handle 1
8 Left Handle 1
9 Adjustment Knob 1
10 Seat Pad 1
11 M10 x 5/8” Hex Bolt 7
12 M10 x 3” Hex Bolt 2
13 M8 x ¾” Hex Bolt 4
14 Ø 5/8” Washer 4
15 M10 Aircraft Nut 2
16 M10 x 5/8” Allen Bolt 4
17 Foam Roll 2
18 Foam Roll End Cap 2
19 3” x 2 3/8” Sleeve 2
20 2 3/8” End Cap 1
21 Handle Grip 2
22 Ø ¾” Washer 15
23 2 3/8” Square End Cap 4
6

IMPEX INC.
LIMITED WARRANTY
IMPEX Inc. ("IMPEX") warrants this product to be free from defects in workmanship and material,
under normal use and service conditions, for a period of two years on the Frame from the date of
purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this
Warranty is limited to replacing or repairing, at IMPEX's option.
All returns must be pre-authorized by IMPEX. Pre-authorization may be obtained by calling
IMPEX Customer Service Department at 1-800-999-8899. All freights on products returned to
IMPEX must be prepaid by the customer. This warranty does not extend to any product or
damage to a product caused by or attributable to freight damage, abuse, misuse, improper or
abnormal usage or repairs not provided by an IMPEX authorized service center or for products
used for commercial or rental purposes. No other warranty beyond that specifically set forth
above is authorized by IMPEX.
IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or
in connection with the use or performance of the product or other damages with respect to any
economic loss, loss of property, loss of revenues or profits, loss of enjoyments or use, costs of
removal, installation or other consequential damages or whatsoever natures. Some states do
not allow the exclusion or limitation of incidental or consequential damages. Accordingly, the
above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied
warranties of merchantability or fitness for a particular purpose is limited in its scope and duration
to the terms set forth herein. Some states do not allow limitations on how long an implied
warranty lasts. Accordingly, the above limitation may not apply to you.
This warranty gives you specific legal right. You may also have other rights which vary from
state to state.
IMPEX INC.
2801 South Towne Avenue,
Pomona, California 91766
ORDERING REPLACEMENT PARTS
Replacement parts can be ordered by calling our Customer Service Department toll-free at 1-800-
999-8899 during our regular business hours: Monday through Friday, 9 am until 5 pm Pacific
standard time.
www.impex-fitness.com
support @impex-fitness.com
When ordering replacement parts, always give the following information.
1. Model
2. Description of Parts
3. Part Number
4. Date of Purchase
7
