Impex MARCY NS-6002RE Installation and operating instructions

NOTE:
Please read all
instructions carefully
before using this product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
NS-6002RE
Retain This
Manual for
Reference
180710
ASSEMBLY &
OWNER'S
MANUAL
Magnetic-Resistance
Rower
NS-6002RE
IMPEX®INC.
2801 S. Towne Ave, Pomona, CA 91766
Tel: [phone] Fax: [phone]
www.marcypro.com
[e-mail]

© IMPEX INC. www.marcypro.com
1
TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................…. 1
IMPORTANT SAFETY NOTICES..................................................................…. 2
WARNING LABEL PLACEMENT………………………………………………….. 3
HARDWARE PACK……….....…....................................................................…. 4
ASSEMBLY INSTRUCTIONS........................................................................…. 6
EXPLODED DIAGRAM………………………………………………………………. 10
PARTS LIST...................................................................................................…. 12
CARE, MAINTENANCE, AND STORAGE…………………………………………. 13
OPERATING NOTES………………………………………………………………… 13
COMPUTER…………………………………………………………………………… 14
EXERCISE GUIDELINES……………………………………………………………. 15
WARRANTY.................................................................................................……. 17
ORDERING PARTS.....................................................................................……. 17
BEFORE YOU BEGIN
Thank you for selecting the MARCY Magnetic-Resistance Rower NS-6002RE by
IMPEX®INC. For your safety and benefit, read this manual carefully before using the
bike. As a manufacturer, we are committed to provide you complete customer
satisfaction. If you have any questions, or find there are missing or damaged parts,
we guarantee you complete satisfaction through direct assistance from our factory. To
avoid unnecessary delays, please call our TOLL-FREE customer service number. Our
Customer Service Agents will provide immediate assistance to you.
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.marcypro.com
[email protected]

© IMPEX INC. www.marcypro.com
2
IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before you assemble or operate your machine. In particular, note the following safety
precautions:
1. Keep children and pets away from the machine at all times. DO NOT leave
children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms,
STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine near water
or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear robes or
other clothing that could become caught in the machine. Running or aerobic shoes are
also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO NOT use
attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or physician in
attendance.
10. Before using the machine to exercise, always do stretching exercises to properly warm
up.
11. Never operate the machine if the machine is not functioning properly.
12. Read all warnings posted on the exercise bike.
13. Inspect the exercise bike for worn or loose component prior to use. Tighten/replace any
loose or wore components prior to use.
14. Care should be taken in mounting or dismounting the exercise bike.
15. This exercise bike is for consumer and home use only.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE
OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES
NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE
SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.

© IMPEX INC. www.marcypro.com
3
WARNING LABEL PLACEMENT
The Warning Labels shown here has been placed on the Front Stabilizer.
If the labels are missing or illegible, please call customer service at 1-800-999-8899 for
replacement. Apply the labels in location shown.

© IMPEX INC. www.marcypro.com
4
HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
NO.
Description
Qty
Drawings
2
Carriage bolt M10x2⅛”
2
5
End cap for slide rail L/R
1/1
6
Flat washer - Large
3
7
Domed nut M10
2
8
Curved washer
2
19
Carriage bolt M8x1¾”
2
20
Hex head bolt M10x3⅛”
1
22
Collar
2
23
Allen bolt M8x¾”
2
24
Allen bolt M8x⅝”
8
25
Flat Washer - Small
8
34
Domed nut M8
2
52
Nylon nut M10
1
53
Knob M10
1
Allen wrench
2
Allen key 6mm
1

© IMPEX INC. www.marcypro.com
5
COMPONENTS FOR ASSEMBLY
NO:1
NO:28
NO:11
NO:26
NO:3 NO:17
NO:69
NO:9
NO:29 NO:55 NO:13L/R

© IMPEX INC. www.marcypro.com
6
ASSEMBLY INSTRUCTION
•Tools Required for Assembling the Machine: One Crossing Wrench and Allen Wrench,
provided by manufacturer.
•NOTE: It is strongly recommended that two or more people assemble this machine to
avoid possible injury.
STEP-1
⚫Attach the front stabilizer (3) to the main frame (1). Secure using two carriage bolts (2), two flat
washers (6) and two domed nuts (7).
⚫Insert the computer wire (16) through computer support tube (29), then attach the computer
support tube (29) to the main frame (1). Secure using 2 Allen bolts (24), 2 curved washers (8)
from the back side. Tighten the 2 sets of Allen bolt (24), flat washer (24) from lateral side.
3
6
7
1
2
24
29
8
24 24
25
25

© IMPEX INC. www.marcypro.com
7
STEP-2
⚫Connect the computer wire (16) to the back of the computer (9). Attach the computer (9) to
computer support tube (29) and tighten with four screws (12) which are
pre-assembled on the back of computer.
⚫Attach the slide rail (26) to the main frame (1). Secure using one hex head bolt (20), one flat
washer (6), one aircraft nut (52).
20
20 26
52
6
1
29

© IMPEX INC. www.marcypro.com
8
STEP-3
⚫Slide the seat (11) onto the slide rail (26). Attach two collars (22) to the back of the slide rail (26)
and securing with two Allen bolts (23).
⚫Attach the end caps (5L & 5R) to the back of the slide rail (26).
⚫Attach the rear support tube (28) to back of the slide rail (26). Secure using four Allen bolts (24)
and four flat washers (25).
⚫Remove two self-tapping screws (59) from the decorative cover (69) and secure the decorative
cover to the rear support tube (28) by using these two screws (59).
⚫Unfold the slide rail (26).
11 5R
5L 22
22
23
23
24
25
25 24
28
69
59 59
26
1

© IMPEX INC. www.marcypro.com
9
STEP-4
⚫Remove the two screws (27) and two self-tapping screws (59) from main frame.
⚫Attach the bottle holder (55) & decorative covers (13L/R) to the main frame (1). Secure using
four the self-tapping screws (45) which are pre-assembled on the left decorative cover. Then
tighten the two screws (27) and two self-tapping screws (59).
⚫Tighten the knob (53) to the joint of main frame. Noted: Thread it on clockwise.
53
55
13L
13R
59
59
45
45 45
45
1
STEP-5
⚫Attach the pedal support tube w/pedals (17) to the main frame (1). Secure using two carriage
bolts (19), two flat washers (25) and two domed nuts (34).
1
17
19
25
34

© IMPEX INC. www.marcypro.com
10
EXPLODED DIAGRAM
3
4R
67
11
19
20
20
24
25
26
28
29
30
31 33
32
34
35
1
2
4L
5R5L 5R
5L
22
22 22
22
23
23
23
23
24
25 25
25
52
53
6
855
9
24 24
25
25
12
13L 13R
59
59
45
45 45
59 24 69
70
45
10 17
14L 14R
15

© IMPEX INC. www.marcypro.com
11
EXPLODED DIAGRAM
38L
38R
48
51
18 18
36
37
54
56
57 58
59
63
65
66
67
68
61
62
64
39 39
43
41
40
40
41
42
42 44 46
45
45
45
45
45
45
45
47
50
49
59
59 59
60
45
68
31
31 31
31
31
54
25
71

© IMPEX INC. www.marcypro.com
12
NS-6002RE PARTS LIST
NO.
Description
Qty
1
Main frame
1
2
Carriage bolt M10x2⅛”
2
3
Front stabilizer
1
4L
End cap for front stabilizer L
1
4R
End cap for front stabilizer R
1
5L
End cap for slide rail L
2
5R
End cap for slide rail R
2
6
Flat washer - Large
3
7
Domed nut M10
2
8
Curved washer
2
9
Computer
1
10
End cap
6
11
Seat
1
12
Screw M5x½”
4
13L
Decorative cover L
1
13R
Decorative cover R
1
14L
Left pedal
1
14R
Right pedal
1
15
Self-tapping screw ST5x ¾”
4
16
Computer wire
1
17
Pedal support tube
1
18
Spring clutch bracket
2
19
Carriage bolt M8x1¾”
2
20
Hex head bolt M10x3⅛”
1
21
Sensor wire
1
22
Collar
4
23
Allen bolt M8x¾”
4
24
Allen bolt M8x⅝”
8
25
Flat Washer - Small
14
26
Slide rail
1
27
Screw M5x⅝”
6
28
Rear support tube
1
29
Computer support tube
1
30
Allen bolt M6x¾”
2
31
Aircraft nut M8
9
32
Wheel for seat support bracket
4
33
Axle for seat support bracket
4
34
Domed nut M8
2
35
Seat support bracket
1
36
Belt
1
37
Spring clutch w/rope
1
38L
Left chain cover
1
38R
Right chain cover
1
39
Flywheel adjustor
2
40
Aircraft nut M6
2
41
Eye bolt
2

© IMPEX INC. www.marcypro.com
13
42
Flange nut
2
43
Flywheel
1
44
Hex head bolt M8x4⅛”
1
45
Self-tapping screw 5x½”
14
46
Plastic bushing
2
47
Magnet assembly
1
48
Bumper for handlebar
1
49
Hex head nut
2
50
Hex head bolt M6x1”
1
51
Sensor bracket
1
52
Aircraft nut M10
1
53
Knob M10
1
54
End cap for chain cover
2
55
Bottle holder
1
56
End cap
1
57
Bearing
2
58
Powder spacer
2
59
Self-tapping screw 5x½”
8
60
Spring
1
61
Top cover for handlebar
1
62
Bottom cover for handlebar
1
63
Handlebar
1
64
Self-tapping screw
2
65
Idler pulley
1
66
Axle for Idler
1
67
Foam grip
2
68
End cap for handlebar
2
69
Decorative cover for rear support tube
1
70
Leveler
2
71
Tension knob
1

© IMPEX INC. www.marcypro.com
14
CARE, MAINTENANCE AND STORAGE
1. Inspect and tighten all parts each time you use the machine. Replace any worn parts
immediately.
2. This machine can be cleaned using a damp cloth and mild non-abrasive detergent. Do not use
solvents.
3. Store the rower IN-DOOR. Excess moisture and water would cause rust on the frame.
4. The rower shall be placed at least 24 inches away from the wall or/and any other object such
as furniture to provide safe access to and passage around the machine.
5. To avoid possible injury, the help of two or more people are needed when moving the machine
around.
6. Disposal Instructions –The equipment can be safely disassembled and disposed without
unreasonable hazards. Call your local recycle agency regarding details of recycling.
7. The maximum user weight is 300 lbs.
8. Assembled Dimension (L x W x H): 74.5” x 20” x 32”
OPERATING NOTES
TRANSPORT
The Rower has a pair of roller wheels on Front Stabilizer End Cap.
To move, fold up the Rower; carefully hold and tilt the Rower, and then roll.

© IMPEX INC. www.marcypro.com
15
COMPUTER
AUTO START / STOP
When exercise starts, the monitor will automatically turn on and display the progress. When
exercise stops, the monitor will automatically turn off after 4 minutes to save energy.
MODE-
1. Press “MODE” key, will automatically scan Time, Speed, Count, Calories, and ODO for every 4
seconds.
2. When Computer is in Scan mode, press “MODE” key to select Time, Count, or Calories
function.
SET-
Press SET key to set the targeted exercises value of Time, Count, and Calories.
RESET-
Press RESET key to reset Time, Count, or Calories value to zero.
DISPLAY:
Time Display the elapsed time. Max value is up to 99:59
Count Display the cumulated rows during current rowing exercise session.
Total Count Display the total rows of rowing exercise session from past to current.
Calories Display the calorie consumption in cal.
REPLACE BATTERY:
1. Always purchase the correct size and grade of battery most suitable for the intended use.
2. Replace all batteries of a set at the same time.
3. Clean the battery contacts and also those of the device prior to battery installation.
4. Ensure the batteries are installed correctly with regard to polarity (+ and -).
5. Remove batteries from equipment when not in use for extended periods of time.
6. Remove used batteries promptly.
7. The Computer requires two 1.5V (AAA) batteries. Batteries are not included in packaging.
8. If the display is not clear or only partial segments appeared, remove the batteries and wait for
15 seconds before re-install them.
9. The battery life is approx. 3 months under normal usage.
10.When the batteries are removed, all the functional values will reset to zero.
Note:
Please note all values on this computer are approximate and they are for comparison
purpose only. Do not use these values for any medical or rehabilitation purpose.

© IMPEX INC. www.marcypro.com
16
EXERCISE GUIDELINES
Using your MAGNETIC ROWER will provide you with several benefits, it will improve your physical
fitness, tone muscle and in conjunction with calorie-controlled diet help you lose weight.
1. The Warm Up Phase
This stage helps get the blood flowing around the body and the muscles working properly. It will
also reduce the risk of cramp and muscle injury. It is advisable to do a few stretching exercises as
shown below. Each stretch should be held for approximately 30 seconds, do not force or jerk your
muscles into a stretch - if it hurts, STOP.
2. The Exercise Phase
This is the stage where you put the effort in. After regular use, the muscles in your legs will
become more flexible. Work to your targeted heart rate but it is very important to maintain a
steady tempo throughout. The rate of work should be sufficient to raise your heartbeat into the
target zone shown on the graph below.
This stage should last for a minimum of 12 minutes though most people start at about 15-20
minutes
SIDE BENDS OUTER THIGH
INNER THIGH
FORWARD
BENDS
CALF / ACHILLES

© IMPEX INC. www.marcypro.com
17
3. The Cool Down Phase
This stage is to let your Cardio-vascular System and muscles wind down. This is a repeat of the
warm up exercise e.g. reduce your tempo, continue for approximately 5 minutes. The stretching
exercises should now be repeated, again remembering not to force or jerk your muscles into the
stretch.
As you get fitter you may need to train longer and harder. It is advisable to train at least three times
a week, and if possible space your workouts evenly throughout the week.
MUSCLE TONING
To tone muscle while on your MAGNETIC ROWER you will need to have the resistance set quite
high. This will put more strain on our leg muscles and may mean you cannot train for as long as
you would like. If you are also trying to improve your fitness you need to alter your training
program. You should train as normal during the warm up and cool down phases, but towards the
end of the exercise phase you should increase resistance making your legs work harder. You will
have to reduce your speed to keep your heart rate in the target zone.
WEIGHT LOSS
The important factor here is the amount of effort you put in. The harder and longer you work
the more calories you will burn. Effectively this is the same as if you were training to
improve your fitness, the difference is the goal.

© IMPEX INC. www.marcypro.com
18
IMPEX®INC.
LIMITED WARRANTY
IMPEX Inc. ("IMPEX®") warrants this product to be free from defects in workmanship and material, under normal use
and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only
to the original purchaser. IMPEX's obligation under this Warranty is limited to replacing or repairing, at IMPEX's option.
All returns must be pre-authorized by IMPEX. Pre-authorization may be obtained by calling IMPEX Customer Service
Department at 1-800-999-8899. All freights for products return to IMPEX must be prepaid by the customer. This
warranty does not extend to any product or damage to a product caused by or attributable to freight damage, abuse,
misuse, improper or abnormal usage or repairs not provided by an IMPEX authorized service center or for products
used for commercial or rental purposes. No other warranty beyond that specifically set forth above is authorized by
IMPEX.
IMPEX is not responsible or liable for indirect, special or consequential damages arising out of or in connection with the
use or performance of the product or other damages with respect to any economic loss, loss of property, loss of
revenues or profits, loss of enjoyments or use, costs of removal, installation or other consequential damages or
whatsoever natures. Some states do not allow the exclusion or limitation of incidental or consequential damages.
Accordingly, the above limitation may not apply to you.
The warranty extended hereunder is in lieu of any and all other warranties and any implied warranties of merchantability
or fitness for a particular purpose is limited in its scope and duration to the terms set forth herein. Some states do not
allow limitations on how long an implied warranty lasts. Accordingly, the above limitation may not apply to you.
This warranty gives you specific legal right. You may also have other rights which vary from state to state. Register
on-line www.marcypro.com/
IMPEX®INC.
2801 S. Towne Ave.
Pomona, CA 91766
ORDERING REPLACEMENT PARTS
Replacement parts can be ordered by calling our Customer Service Department toll-free at 1-800-999-8899 during our
regular business hours: Monday through Friday, 9 am until 5 pm Pacific standard time.
[email protected]
When ordering replacement part, always give the following information.
1. Model
2. Description of Parts
3. Part Number
4. Date of Purchase
