Impex Marcy NS-6050RE Installation and operating instructions

NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Pack
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
NS-6050RE
Retain This
Manual for
Reference
151208
ASSEMBLY &
OWNER'S
MANUAL
TURBINE ROWER
NS-6050RE
IMPEX®INC.
2801 S. Towne Ave, Pomona, CA 91766
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[e-mail]

©IMPEX INC. www.impex-fitness.com
1
TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................…. 1
IMPORTANT SAFETY NOTICES..................................................................…. 2
WARNING LABEL PLACEMENT………………………………………………….. 3
HARDWARE PACK……….....…....................................................................…. 4
ASSEMBLY INSTRUCTIONS........................................................................…. 6
EXPLODED DIAGRAM………………………………………………………………. 11
PARTS LIST...................................................................................................…. 12
CARE, MAINTENANCE, AND STORAGE…………………………………………. 13
OPERATING NOTES………………………………………………………………… 14
COMPUTER…………………………………………………………………………… 15
EXERCISE GUIDELINES……………………………………………………………. 16
WARRANTY.................................................................................................……. 18
ORDERING PARTS.....................................................................................……. 18
BEFORE YOU BEGIN
Thank you for selecting the MARCY Turbine Rower NS-6050RE by IMPEX®INC. For
your safety and benefit, read this manual carefully before using the bike. As a
manufacturer, we are committed to provide you complete customer satisfaction. If you
have any questions, or find there are missing or damaged parts, we guarantee you
complete satisfaction through direct assistance from our factory. To avoid
unnecessary delays, please call our TOLL-FREE customer service number. Our
Customer Service Agents will provide immediate assistance to you.
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[e-mail]

©IMPEX INC. www.impex-fitness.com
2
IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before you assemble or operate your machine. In particular, note the following safety
precautions:
1. Keep children and pets away from the machine at all times. DO NOT leave
children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal symptoms,
STOP the workout at once. CONSULT A PHYSICIAN IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine near water
or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear robes or
other clothing that could become caught in the machine. Running or aerobic shoes are
also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO NOT use
attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or physician in
attendance.
10. Before using the machine to exercise, always do stretching exercises to properly warm
up.
11. Never operate the machine if the machine is not functioning properly.
12. Read all warnings posted on the machine.
13. Inspect the machine for worn or loose component prior to use. Tighten/replace any
loose or wore components prior to use.
14. Care should be taken in mounting or dismounting the exercise bike.
15. This exercise bike is for consumer and home use only.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE
OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL
INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES
NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY DAMAGE
SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
WARNING LABEL PLACEMENT

©IMPEX INC. www.impex-fitness.com
3
The Warning Labels shown here has been placed on the Rear Support.
If the labels are missing or illegible, please call customer service at 1-800-999-8899 for
replacement. Apply the labels in location shown.

©IMPEX INC. www.impex-fitness.com
4
HARDWARE PACK
NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.

©IMPEX INC. www.impex-fitness.com
5
COMPONENTS FOR ASSEMBLY

©IMPEX INC. www.impex-fitness.com
6
ASSEMBLY INSTRUCTION
•Tools Required For Assembling the Machine: One Crossing Wrench and two Allen
Wrenches provided by manufacturer.
•NOTE: It is strongly recommended that two or more people assemble this machine to
avoid possible injury.
STEP-1
A.) Attach the two Roller Wheels (#2) to the Main Frame (#1).
B.) Secure each Roller Wheel (#2) with one M8 x 1 ¾” Allen Bolt (#4) and one Nylon Nut (#2).
STEP-2
A.) Pull out the Lock Pin (#35). Attach the Rowing Rail (#45) to the bracket on Main Frame (#1).

©IMPEX INC. www.impex-fitness.com
7
B.) Insert a Rowing Rail Axle (#41) through the pivot on Rowing Rail. Secure the pivot to the bracket
with one M8 x ¾” Allen Bolt (#34) and one Ø⅝” Washers (#37) to each end of the Axle.
C.) Insert the Lock Pin (#35) back to hole the Rowing Rail in vertical position.
STEP-3

©IMPEX INC. www.impex-fitness.com
8
A.) Slide the Seat onto Rowing Rail (#45) and slowly down to the bottom.
B.) Attached one Bumper Stopper (#36) onto each Rail Track. Secure each Bumper Stopper with one
M8 x ¾” Allen Bolt (#34).
C.) Attach the Rear Support (#54) to the Rowing Rail (#45). Secure it with two M8 x 1 ⅝” Allen Bolts
(#42), one M8 x ⅝” Allen Bolt (#19), and three Ø ⅝” Washers (#43).
D.) Thread two Rear Leverage Knobs (#55) to the Rear Support (#54).
STEP-4
A.) Flip down the Rowing Rail to floor.

©IMPEX INC. www.impex-fitness.com
9
B.) Attach the Front Post (#9) to the Main Frame (#1) and secure it with four M8 x ⅝” Allen Bolts (#19).
C.) Attach the Left & Right Front Post Floor Cap (#8L/R) to Front Post. Secure each Cap with two ST5
x ¾” Self Tapping Screws (#10).
STEP-5
A.) Flip down the Front Post (#9) to floor.
B.) Pull out Lock Pin (#35) and flip down the Rowing Rail (#45) to floor.
C.) Adjust the two Rear Leverage Knobs (#55) to stabilize the Rear Support (#54) on floor.
STEP-6
A.) Plug the Left & Right Rowing Bar Holder (#11L/R) into the Front Post.
B.) Attach the Left Pedal (#14L) to the pivot on Main Frame (#1). Secure it with two M12 x 5 ½”
Socket Head Allen Bolt (#13). Repeat the same step to install Right Pedal (#14R).
