Impex EASY-STEP PLUS MS 90 User manual

NOTE:
Please read all instructions
carefully before using this
product.
Table of Content
Safety Notice
Hardware Identifier
Assembly Instruction
Exploded Diagram
Pans List
Warranty
Ordering Parts
Model
MS 90
Retain This
Manual for
Reference
April 11, 2000
OWNER'S
MANUAL
M==x<
EASY — STEP PLUS
IMPEX FITNESS PRODUCTS
14777 Don Julian Rd., City of Industry, CA 91746
Tel: [phone] Fax: [phone]
‘wow iimpex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN.
IMPORTANT SAFETY NOTICES.
HARDWARE IDENTIFIER.
ASSEMBLY INSTRUCTIONS...
EXPLODED DIAGRAM...
PARTS LIST.
WARRANTY.
ORDERING PARTS...
BEFORE YOU BEGIN
Thank you for selecting the EASY STEP PLUS by IMPEX FITNESS
PRODUCTS. For your safety and benefit, read this manual carefully
before using the machine. As a manufacturer, we are committed to
provide you complete customer satisfaction. If you have any questions, or
find there are missing or damaged parts, we guarantee you complete
satisfaction through direct assistance from our factory. To avoid
unnecessary delays, please call our TOLL-FREE customer service
number. Our Customer Service Agents will provide immediate assistance
toyou
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri., 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This
exercise
machine
is
built
for
optimum
safety.
However,
certain
precautions.
apply
whenever
you
operate
a
piece
of
exercise
equipment.
Be
sure
to
read
the
entire
manual
before
you
assemble
or
operate
your
machine,
In
particular,
note
the
following
safety
precautions:
1.
Keep
children
and
pets
away
from
the
machine
at
all
times.
DO
NOT
leave
children
unattended
in
the
same room
with
the
machine,
2.
Only
one
person
at
a
time
should
use
the
machine.
3.
If
the
user
experiences
dizziness,
nausea,
chest
pain,
or
any
other
abnormal
symptoms,
STOP
the
workout
at
once,
CONSULT
A
PHYSICIAN
IMMEDIATELY.
4.
Position
the
machine
on
a
clear,
leveled
surface.
DO
NOT
use
the
machine
near
water
or
outdoors.
5.
Keep
hands
away
from
all
moving
parts.
6.
Always
wear
appropriate
workout
clothing
when
exercising.
DO
NOT
wear
robes
or
other
clothing
that
could
become
caught
in
the
machine.
Running
or
aerobic
shoes
are
also
required
when
using
the
machine.
7.
Use
the
machine
only
for
it
intended
use
as
described
in
this
manual.
DO.
NOT
use
attachments
not
recommended
by
the
manufacturer.
8.
Do
not
place
any
sharp
object
arcund
the
machine.
9.
Disabled
person
should
not
use
the
machine
without
a
qualified
person
or
physician
in
attendance.
10.
Before
using
the
machine
to
exercise,
always
do
stratching
exercises
to
properly
warm
up.
11.
Never
operate
the
machine
if
the
machine
is
not
functioning
property.
WARNING:
BEFORE
BEGINNING
ANY
EXERCISE
PROGRAM,
CONSULT
YOUR
PHYSICIAN.
THIS
IS
ESPECIALLY
IMPORTANT
FOR
INDIVIDUALS
OVER
THE
AGE
OF
35
OR
PERSONS
WITH
PRE-EXISTING
HEALTH
PROBLEMS.
READ
ALL
INSTRUCTIONS
BEFORE
USING
ANY
FITNESS
EQUIPMENT.
IMPEX
INC.
ASSUMES
NO
RESPONSIBILITY
FOR
PERSONAL
INJURY
OR
PROPERTY
DAMAGE
SUSTAINED
BY
OR
THROUGH
THE USE
OF
THIS
PRODUCT.
SAVE THESE INSTRUCTIONS.

HARDWARE
IDENTIFIER
PLACE
WASHER,
END
OF
BOLT
,
OR
SCREW
ON
CIRCLE
TO
CHECK
FOR
CORRECT
SIZE.
MILLIMETERS
M6
O
Or
um)
INCHES
es
3/4"
REPLACEMENT
PARTS
Thank
you
for
purchasing
IMPEX
product.
Although
we
go
to
great
effort
to
ensure
the
quality
of
our
products,
occasionally
errors
or
omissions
occur.
Should
you
find
either
a
defective
or
missing
part
in
this
product,
please
contact
us
for
a
replacement
at
the
telephone
number.
QUESTION ?
@
"ET
1-800-999-8899
b
NOTE:
When
installing
a
Aircraft
Nut
{also
called
Nylon
or
Lock
Nut),
Please
use
two
adjustable
wrenches
to
tighten
down
the
Nut.
Hold
down
the
Bolt
with
one
wrench,
and
use
the
other
wrench
to
turn
the
Nut
clockwise.
Length
=
HEX
HEAD
BOLT
AIRCRAFT
FLAT
NUT
WASHER
ROUND
SQUARE
PLUG
PLUG

ASSEMBLY INSTRUCTION
Tools Required to Assemble tho Machine:
‘Two Adjustable Wrenches
One
Allen
Wrench
STEP1 (See Diagram 1)
A)
Lift
up
tho
Loft
Pedal.
Attach
the
Knob
Bolt
(#13)
to
the
front
of
the
Base
Frame,
Turn
the
Knob
clockwise
to
secure
the
Pedals.
Note:
The
height
of
the
pedals
can
be
adjusted
by
turning
the
Knob.
Clockwise
to
increase
the
height
and
counterclockwise
to
decrease
the
height
B.)
Attach
the
Twister
Plate
(#47)
to
the
bracket
in
front
of
the
Base
Frame,
Secure
it
with
one
M10x
3
1/8"
Bolt
(H9),
two
7/8
Washers
(#28),
and
one
MIO
Aircraft
Nut
(&37).
Do
not
oven
tighten
the
Nut
and
Bolt.
The
Twister
Plate
Frame
should
be
able
to
slide
on
the
Bolt,
Secure
tho
Twister
Plate
with
a
Pin
(450)
C.)
When
storing
the
Twister
Plate,
poll
the
Pin
out
then
pull
the
Plate
cut
and
upward
to
a
vertical
position.
Re-insert
the
Pin
to
secure
the
Plate.
DIAGRAM 1

STEP2
(See
Diagram
2)
A.)
Slide
the
Computer
Wire
(#22)
through
the
Lower
Frame
(#7).
Connect
the
Computer
Wire
(#22)
to
the
Sensor
Wire
(#21)
coming
out
of
the
Base
Frame
(#1).
Attach
the
Lower
Frame
(#7)
to
the
opening
on
the
Base
Frame.
Secure
it
with four
M8
x
5"
Allen
Bolts
(#35)
and
@%"
Washers
(#27).
Note:
If
the
holes
on
the
frame
are
hard
to
align,
spay
light
lubricant
such
as
WD40
to
help
reduce
the
friction.
B.)
Attach
two
Dumbbell
Racks
(#10)
to
the
Lower
Frame
(#7).
Secure
it
with four
M6
x
3/8”
Philip
Screws
(+39).
C.)
Draw
the
Computer
Wire
(#22)
through
the
Upper
Frame
(#5).
Attach
the
Upper
Frame
(#5)
to
the
Lower
Frame
(#7).
Secure
it
with four
M8
x
°/.”
Allen
Bolts
(#35)
and
Y
?4"
Washers
(#27).
D.)
Attach
the
Handlebar
(+6)
to
top
of
the
Upper
Frame
(#5).
Secure
it
with
two
M8
x
2
12"
Allen
Bolts
(#36)
and
Ø
Y”
Washers
(#27).
E.)
Pull
the
Computer
Wire
(#22)
through
the
Timer
Stand
(#18).
Connect
the
Computer
Wire
(#22)
to
the
Computer
(#15).
Attach
the
Timer
Stand
(#18)
to
the
Upper
Frame
(#5).
Secure
it
with
a
M6
x
3/8"
Screw
(#40).
Slide
the
Computer
(#15)
onto
the
Timer
Stand
(#18).
F.)
Slide
two
Foam
Rolls
(#24)
onto
the
Handlebar
(#6)
and
close
it
with
two
21"
Round
End
Caps
(+29).
DIAGRAM 2

MS 90 PARTS LIST
No.
Description
Q'ty
No.
Description
Q'ty
1
Base
Frame
38.
M8
Aircraft
Nut
6
2
Right
Pedal
Arm
39.
M6x3/8"
Phillip
Screw
4
3.
Left
Pedal
Arm
40.
M6
x
3/8”
Round
Screw
1
4.
Pulley
Bracket
41.
ST2
Screw
2
5
Upper
Frame
42.
3lb.
Dumbbell
2
6
Handlebar
43.
2ib.
Dumbbell
2
7.
Lower
Frame
44.
Twister
Plate
Stand
1
8.
91?"
Bushing
45.
Elliptical
End
Cap
2
9.
Pedal
46.
Bumper
2
10.
Dumbbell
Rack
47.
Twister
Plate
1
11.
—
Ql
Bushing
48.
M6
x
5/8"
Screw
2
12.
Cable
49.
M10
x
3
1/8"
Bolt
1
13.
—
Knob
Bolt
50.
Pin
1
14. M8 x 1 Y” Bolt
15. Computer
16.
2%"x
1%
End
Cap
17.
Axle
Cover
18.
Timer Stand
19. Hydraulic Shocks
20.
Rubber
Bumper
21. Sensor
22. Computer Wire
23.
M8
Regular
Nut
24.
Foam
Grip
25, Magnet
26. 1/2" Washer
272. O"Washer
28.
71/8"
Washer
29.
|
Q1"
Round
End
Cap
30.
2274
Round
End
Cap
31.
Pulley
32. M10x13/4' Bolt
33. M6 x 1% Bolt
34. M8 x14 Bolt
35. M8 x" Allen Bolt
36.
M8
x27
Allen
Bolt
37. M10 Aircraft Nut
a E SAGAN

IMPEX INC.
LIMITED WARRANTY
IMPEX
Ine.
(IMPEX)
warrants
this
product
to
be
free
from
defects
in
workmanship
and
material,
under
normal
use
and
service
conditions,
for
a
period
of
two
years
on
the
Frame
from
the
date
of
purchase.
This
warranty
extends
only
to
the
original
purchaser.
IMPEX's
obligation
under
this
Warranty
is
limited
to
replacing
or
repairing,
at
IMPEX's
option.
All
retums
must
be
pre-authorized
by
IMPEX.
Pre-authorization
may
be
obtained
by
calling
IMPEX
Customer
Service
Department
at
1-800-999-8899.
All
freights
on
products
retumed
to
IMPEX
must
be
prepaid
by
the
customer.
This
warranty
does
not
extend
to
any
product
or
damage
to
a
product
caused
by
or
attributable
to
freight
damage,
abuse,
misuse,
improper
or
abnormal
usage
or
repairs
not
provided
by
a
IMPEX
authorized
service
center
or
for
products
used
for
commercial
or
rental
purposes.
No
other
warranty
beyond
that
specifically
set
forth
Above
is
authorized
by
IMPEX.
IMPEX
is
not
responsible
or
liable
for
indirect,
special
or
consequential
damages
arising
out
of
or
in
connection
with
the
use
or
performance
of
the
product
or
other
damages
with
respect
to
any
economic
loss,
loss
of
property,
loss
of
revenues
or
profits,
loss
of
enjoyments
or
use,
costs
of
removal,
installation
or
other
consequential
damages
or
whatsoever
natures.
Some
states
do
not
allow
the
exclusion
or
limitation
of
incidental
or
consequential
damages.
Accordingly,
the
above
limitation
may
not
apply
to
you.
The
warranty
extended
hereunder
is
in
lieu
of
any
and
all
other
warranties
and
any
implied
warranties
of
merchantability
or
fitness
for
a
particular
purpose
is
limited
in
its
scope
and
duration
to
the
terms
set
forth
herein.
Some
states
do
not
allow
limitations
on
how
long
an
implied
warranty
lasts.
Accordingly,
the
above
limitation
may
not
apply
to
you.
This
warranty
gives
you
specific
legal
right.
You
may
also
have
other
rights
which
vary
from
state
to
state.
IMPEX INC.
14777 Don Julian
City of Industry, CA 91746
DERI REPLACI
Replacement
parts
can
be
ordered
by
calling
our
Customer
Service
Department
toll-free
at
1-
800-999-8899
during
our
regular
business
hours:
Monday
through
Friday,
9
am
until
5
pm
Pacific
standard
time.
Or,
e-mail
to
us
at
[email protected]
When
ordering
replacement
parts,
always
give
the
following
information.
1. Model
2. Description of Parts
3. Part Number
4.
Date
of
Purchase
