BEFORE YOU BEGIN
Thank you for selecting the Competitor Bench CB200 by IMPEX FITNESS
PRODUCTS. For your safety and benefit, read this manual carefully before
using the machine. As a manufacturer, we are committed to provide you
complete customer satisfaction. If you have any questions, or find there are
missing or damaged parts, we guarantee you complete satisfaction through
direct assistance from our factory. To avoid unnecessary delays, please call
our TOLL-FREE customer service number. Our Customer Service Agents
will provide immediate assistance to you.
1
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]m

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply
whenever you operate a piece of exercise equipment. Be sure to read the entire manual
before you assemble or operate your machine. In particular, note the following safety
precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN
IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
12. A spotter is recommended during exercise.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR
PHYSICIAN. THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE
AGE OF 35 OR PERSONS WITH PRE-EXISTING HEALTH PROBLEMS. READ
ALL INSTRUCTIONS BEFORE USING ANY FITNESS EQUIPMENT. IMPEX INC.
ASSUMES NO RESPONSIBILITY FOR PERSONAL INJURY OR PROPERTY
DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS PRODUCT.
SAVE THESE INSTRUCTIONS.
2

Hardware Pack
3

ASSEMBLY INSTRUCTION
Tools Required Assembling the Machine: Two Adjustable Wrenches and One
Philips Screwdriver.
NOTE: It is strongly recommended two or more people assembling this machine to
avoid possible injury.
STEP 1 (See Diagram 1)
A.) Connect the Front Support (#5) to the Main Seat Support (#3). Secure the front hole
with one M8 x 1 5/8” Carriage Bolt (#28), Ø5/8” Washer (#26), and M8 Aircraft Nut
(#24). Secure the other hole with one M8 x 1 ¾” Carriage Bolt (#29), Diagonal Support
(#4), Ø5/8” Washer (#26), and M8 Aircraft Nut (#24).
B.) Secure the other end of Diagonal Support (#4) to the Front Support (#5) with one M8 x
2 1/8” Hex Bolt (#30), Ø5/8” Washer (#26) and M8 Aircraft Nut (#24).
C.) Connect the Main Seat Support (#3) to the Cross Brace (#2). Secure it with four M8 x
2 3/8” Hex Bolts (#18), one Bracket (#10), four Ø5/8” Washers (#26), and four M8
Aircraft Nuts (#24). DIAGRAM 1
4
STEP 2 (See Diagram 2)

A.) Place the Cross Brace (#2) in the mid-span of the two Upright Beams (#1).
B.) Secure each end of the Cross Brace with two M8 x 2 ½” Hex Bolts (#20), one Bracket
(#10), two Ø5/8” Washers (#26), and two M8 Aircraft Nuts (#24).
C.)Insert the Backrest Adjustment Bar (#11) through the selected holes for desired incline
position. DIAGRAM 2
5
STEP 3 (See Diagram 3)

A.) Attach the hole-side of Backrest Supports (#7) to the pivot on the Main Seat Support
(#3). Place the other end of Backrest Supports rest against the Backrest Adjustment
Bar (#11).
B.) Place the Backrest Board (#8) onto the Backrest Supports (#7). Secure it with four M6
x 1 5/8” Hex Bolts (#23) and ∅½” Washers (#25).
C.)Place the Seat (#9) onto the Main Seat Support (#3). Secure it with four M6 x 5/8”
Philips Screws (#22) and ∅½” Washers (#25).
DIAGRAM 3
6
STEP 4 (See Diagram 4)

A.) Attach the Leg Developer (#6) to the open bracket on the Front Support (#5).
Secure it with one M10 x 2 3/8” Hex Bolt (#21), ∅¾” Washer (#31), and M10
Aircraft Nut (#27).
B.) Insert two Foam Tubes (#13) halfway through the holes on the Leg Developer. Push
four Foam Rolls (#12) onto the Tubes.
DIAGRAM 4
7
EXPLODED DIAGRAM

8

PARTS LIST
KEY NO. DESCRIPTION Q’ty
1 Upright Beam 2
2 Cross Brace 1
3 Main Seat Support 1
4 Diagonal Support 1
5 Front Support 1
6 Leg Developer 1
7 Backrest Support 2
8 Backrest Board 1
9 Seat 1
10 Bracket 3
11 Backrest Adjustment Bar 1
12 Foam Roll 4
13 Foam Tube 2
14 Ø ¾” End Cap 4
15 Ø 1” End Cap 3
16 Rubber Bumper 1
17 1 ½” Square End Cap 3
18 M8 x 2 3/8” Hex Bolt 4
19 1” Square End Cap 4
20 M8 x 2 ½” Hex Bolt 4
21 M10 x 2 3/8” Hex Bolt 1
22 M6 x 5/8” Philips Screw 4
23 M6 x 1 5/8” Hex Bolt 4
24 M8 Aircraft Nut 11
25 ∅½” Washer 8
26 ∅5/8” Washer 11
27 M10 Aircraft Nut 1
28 M8 x 1 5/8” Carriage Bolt 1
29 M8 x 1 ¾” Carriage Bolt 1
30 M8 x 2 1/8” Hex Bolt 1
31 Ø ¾” Washer 1
