Impex TC 3000 User manual

NOTE:
Please read all instructions
carefully before using this
product
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Warranty
Ordering Parts
Model
TC 3000
Retain This
Manual for
Reference
05-17-02
OWNER'S
MANUAL
POWER STATION
TC 3000
IMPEX FITNESS PRODUCTS
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: [phone] Fax: [phone]
www.impex-fitness.com
[email protected]

TABLE OF CONTENTS
BEFORE YOU BEGIN...................................................................................... 1
IMPORTANT SAFETY NOTICES..................................................................... 2
HARDWARE IDENTIFIER.....…....................................................................... 3
ASSEMBLY INSTRUCTIONS........................................................................... 4
EXPLODED DIAGRAM……………………………………………………………… 8
PARTS LIST......................................................................................................9
WARRANTY.................................................................................................…. 10
ORDERING PARTS.......................................................................................…10
BEFORE YOU BEGIN
Thank you for selecting the POWER STATION TC 3000 by IMPEX FITNESS
PRODUCTS. For your safety and benefit, read this manual carefully before using
the machine. As a manufacturer, we are committed to provide you complete
customer satisfaction. If you have any questions, or find there are missing or
damaged parts, we guarantee you complete satisfaction through direct assistance
from our factory. To avoid unnecessary delays, please call our TOLL-FREE
customer service number. Our Customer Service Agents will provide immediate
assistance to you.
1
Toll-Free Customer Service Number
1-800-999-8899
Mon. - Fri. 9 a.m. - 5 p.m. PST
www.impex-fitness.com
[email protected]m

IMPORTANT SAFETY NOTICE
PRECAUTIONS
This exercise machine is built for optimum safety. However, certain precautions apply whenever
you operate a piece of exercise equipment. Be sure to read the entire manual before you
assemble or operate your machine. In particular, note the following safety precautions:
1. Keep children and pets away from the machine at all times. DO NOT
leave children unattended in the same room with the machine.
2. Only one person at a time should use the machine.
3. If the user experiences dizziness, nausea, chest pain, or any other abnormal
symptoms, STOP the workout at once. CONSULT A PHYSICIAN
IMMEDIATELY.
4. Position the machine on a clear, leveled surface. DO NOT use the machine
near water or outdoors.
5. Keep hands away from all moving parts.
6. Always wear appropriate workout clothing when exercising. DO NOT wear
robes or other clothing that could become caught in the machine. Running
or aerobic shoes are also required when using the machine.
7. Use the machine only for its intended use as described in this manual. DO
NOT use attachments not recommended by the manufacturer.
8. Do not place any sharp object around the machine.
9. Disabled person should not use the machine without a qualified person or
physician in attendance.
10. Before using the machine to exercise, always do stretching exercises to
properly warm up.
11. Never operate the machine if the machine is not functioning properly.
WARNING: BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR PHYSICIAN.
THIS IS ESPECIALLY IMPORTANT FOR INDIVIDUALS OVER THE AGE OF 35 OR PERSONS
WITH PRE-EXISTING HEALTH PROBLEMS. READ ALL INSTRUCTIONS BEFORE USING
ANY FITNESS EQUIPMENT. IMPEX INC. ASSUMES NO RESPONSIBILITY FOR PERSONAL
INJURY OR PROPERTY DAMAGE SUSTAINED BY OR THROUGH THE USE OF THIS
PRODUCT.
SAVE THESE INSTRUCTIONS.
2

3

ASSEMBLY INSTRUCTION
Tools Required to Assemble the Machine: Two Adjustable Wrenches and Allen Wrenches
NOTE: It is strongly recommended this machine be assembled by two or more people to
avoid possible injury.
STEP 1 (See Diagram 1)
A.) Connect the Front Stabilizer (#1) to the Base Frame (#3). Secure it with two M10 x 3 ¾”
Carriage Bolts (#27), one Bracket (#14), two ∅¾” Washers (#35), and two M10 Aircraft Nuts
(#36). Repeat the same step to connect the Rear Stabilizer (#2) to the Base Frame (#3).
B.) Attach the Lower Vertical Frame (#4) to the Base Frame (#3). Secure it with two Triangle
Brackets (#13), one on each side of the Frame, five M10 x 3 ¾” Carriage Bolts (#27), ∅¾”
Washers (#35), and M10 Aircraft Nuts (#36).
C.) Insert the Foam Roll Tube (#12) halfway through the pivot on the Frame. Slide two Foam Rolls
(#25) onto the Foam Tube from both sides. Plug two Foam Caps (#24) to both ends.
D.) Attach the Non-slip Pad (#26) onto the top of the step on the Lower Vertical Frame.
DIAGRAM 1
4

STEP 2 (See Diagram 2)
A.) Attach Left Support Frame (#6) onto the Rear Stabilizer (#2). Secure it with a M10 x 2 ½” Allen
Bolt (#30) and ∅¾” Washer (#35) from the bottom up. Repeat the same step to install the
Right Support Frame (#7) to the Rear Stabilizer.
B.) Insert the Upper Vertical Frame (#5) into the Lower Vertical Frame (#4). Attach top of the Left
& Right Support Frame (#6) & (#7) to both sides of the Frame. Align the holes and secure the
Support Frames to the Vertical Frame with two M10 x 3 ¾” Carriage Bolts (#27), ∅¾”
Washers (#35), and M10 Aircraft Nuts (#36). Secure the Vertical Frame with two M10 x 3”
Carriage Bolts (#28), ∅¾” Washers (#35), M10 Aircraft Nuts (#36).
C.)Slide two Short Grips (#18) onto the curl handles on the Support Frames.
DIAGRAM 2
5

STEP 3 (See Diagram 3)
A.) Attach the Left Dip Support (#8) and Right Dip Support (#9) to the Upper Vertical Frame (#5).
Secure them with two M10 x 3 ¾” Carriage Bolts (#27), ∅¾” Washers (#35), and M10 Aircraft
Nuts (#36).
B.) Attach two Arm Pads (#15) to Left and Right Dip Supports. Secure each Pad with two M8 x 2
¼” Allen Bolts (#33) and ∅5/8” Washers (#34).
C.) Insert two Vertical Handles (#11) into the holes on the Dip Supports. Secure them with one
M10 x 5/8” Allen Bolt (#31) and ∅¾” Washer (#35) underneath each handle. Slide two ∅1”
Grips (#18) onto the Handles.
E.) Slide two Sleeves (#21) onto the Handles on the Dip Supports. Then slide two ∅1 3/8” Grips
(#17) onto the handles.
DIAGRAM 3
6

STEP 4 (See Diagram 4)
A.) Attach Backrest Pad (#16) to the Upper Vertical Frame (#5). Secure it with two M8 x 2 ¾” Allen
Bolts (#32) and ∅5/8” Washers (#34).
B.) Insert the Chin-up Bar (#10) into the top opening on the Upper Vertical Frame (#5). Secure it
with one M10 x 3 ¼” Allen Bolt (#29), two ∅¾” Washers (#35), and one M10 Aircraft Nut (#36).
C.) Slide two Chin-up Handle Grips (#20) onto both ends of the Bar (#10).
E.) Insert the 2 ½” End Cap (#37) to the opening on the Chin-up Bar (#10).
DIAGRAM 4
7

8

Parts list
KEY NO. DESCRIPTION Q’ty
1 Front Stabilizer 1
2 Rear Stabilizer 1
3 Base Frame 1
4 Lower Vertical Frame 1
5 Upper Vertical Frame 1
6 Left Support Frame 1
7 Right Support Frame 1
8 Left Dip Support 1
9 Right Dip Support 1
10 Chin Up Bar 1
11 Vertical Handle 2
12 Foam Roll Tube 1
13 Triangle Bracket 2
14 Bracket 2
15 Arm Pad 2
16 Backrest Pad 1
17 ∅1 ¼” Grip 2
18 ∅1” Grip 4
19 Manual 1
20 Chin-up Handle Grip 2
21 Sleeve 2
22 2 ¾” End Cap 4
23 2 ¼” End Cap 2
24 Foam Cap 2
25 Foam Roll 2
26 Non-slip Pad 1
27 M10 x 3 ¾” Carriage Bolt 13
28 M10 x 3 “ Carriage Bolt 2
29 M10 x 3 ¼” Allen Bolt 1
30 M10 x 2 ½” Allen Bolt 2
31 M10 x 5/8” Allen Bolt 2
32 M8 x 2 ¾” Allen Bolt 2
33 M8 x 2 ¼” Allen Bolt 4
34 ∅5/8” Washer 6
35 ∅¾” Washer 21
36 M10 Aircraft Nut 16
37 2 ½” End Cap 1
9
