STATIONARY FAN HEATER 6-9-12-15kW
Operating Instructions
GB
Type 2060/2090/2120/2150
General recommendations
Read these instructions before using the appliance. Keep these instructions
in a safe place for future reference.
First time of use
While the manufacturing of the heaters, oil, residues adhere to the ele-
ments. The first time of use, these residues will be burnt off, thereby occa-
sionally triggering fire alarms. Precautions should be taken in order to pre-
vent this from happening.
Area of use
The SH 6-15 kW fan heaters are not intended for use other than indoors.
These heaters are appropriate for the heating of warehouses, workshops,
storage rooms, show rooms, etc.
Function
The air is carried through the heater by a fan and heated by non-corrosive
elements which are regulated by the built-in thermostat with at range of +5
- +35°C. The air speed is adjustable in three steps. Switching on or off, se-
lecting half or full output and regulating the RPM is performed through the
control box CB2, which is wall mounted for easy access. The appliance is
protected from overheating via a built-in temperature limiter. To reset, see
Overheating. Te heater is mounted on a wall with a bracket, which allows

2

3
Installation
The fan heater is intended for wall mounting. The appliance must not be
placed directly under a wall-outlet. The minimum distances given in fig.
1 and 2 must be kept. The fan heaters must not be mounted on the ceiling.
 Mark holes by means of the loose bracket.
Drill holes for the fixing plugs.
Mount the bracket.
Mount the fan heater on the bracket and adjust the heater to desired
vertical and horizontal position.
Screw the bottom bolt in and tighten all bolts.
Electrical installation
The electrical installation should be carried out by a qualified electrician in
conformity with prevailing regulations. The heaters must be connected to
3x400V~ via the CEE-plug, see the schematic. For connection between the
control box CB2 and a SH heater, the connection should be made with a
cable type H05VV5-F 0,75mm2or similar may be used. On the back of the
appliance there are two cable glands to be used for the connection to the
control box CB2. When several heaters are connected to each other and
controlled by a common control box CB2, it should be stated in the group
centre that “the fan haters are fed from more than one group supply”.
Safety
 Ensure that the area around the intake and the exhaust grille is kept free
from material which could prevent the air flow through the appliance.
 The appliance has hot surfaces during operation.
The appliance must not be covered either with clothes or similar material
since overheating of the appliance can result in a fire hazard.
Overheating
If the temperature limiter has been triggered due to overheating, reset as
follows:
 Disconnect the electricity from the heater.
 Investigate the matter and repair the fault.
 Reset by opening the lid and pushing the button on top of the tempera-
ture limiter until a click sound is heard.

4
Mounting on wall –fig 1.
Maintenance
The motor and other components are maintenance-free. Dust and dirt may
cause overheating and danger of fire. The appliance must be cleaned regu-

5
Mounting on wall –fig 1.
Mounting on wall –fig 2.
SH °
,
,
A B
C
Measurements in mm
SH6,SH9: A = 400 B = 460 C = 490
SH12,SH15: A = 450 B = 585 C = 560

6
