Infineon AIROC CYW20829 User manual

-
QUICK START GUIDE
AIROCTM CYW20829 Bluetooth® Low Energy SoC
Evaluation Kit
Kit contents
1. AIROC™ CYW20829 Bluetooth® Low Energy SoC
Evaluation Board (CYW9BTM2BASE3+CYW920829M2IPA2)
2. USB Type-A to Micro-B cable
3. Six jumper wires (five inches each)
4 . Quick start guide (this document)
CYW920829M2EVK-02
www.infineon.com/CYW920829M2EVK-02

Before you start
1. Ensure that you have the following:
–PC with USB 2.0 port
–UART terminal soware such as Tera Term or Minicom
–Download and install the AIROC™ Bluetooth® Connect
app from Play Store or iOS App Store.
2. Connect the KitProg3 USB connector (J5) to your PC.
3. Visit the kit webpage to download and install the required
soware.
4. Ensure the following jumper settings to select 3.3 V. and other
jumpers as default state.
5. Once the driver installation is complete, open the UART terminal
soware and set the COM port parameters to 8N1 and 115200
baud.
Run the AIROC™Bluetooth®Connect application
1. Turn ON Bluetooth® on your Android or iOS device.
2. Launch the AIROC™Bluetooth®Connect app.
3. Press the reset button (SW1) on the CYW920829M2EVK-02
board to send advertisements and when the “Advertisement
started” message on the serial terminal is displayed, confirm
that USER LED2 is blinking.
4. Swipe down on the AIROC™Bluetooth®Connect app
home screen to scan for Bluetooth® Low Energy peripheral
devices.
5. Your device (“Find Me Target”) appears on the home screen.
Tap to establish a Bluetooth® LE connection with the device.
6. The USER LED2 changes from blinking state to always ON state
aer establishing a successful connection with the device.
7. Select ‘Find Me Profile’ and select an Alert level.
The USER LED1 state is linked to the type of alert sent.
Jumper
J9
J10
J12
1 - 3
1 - 3
1 - 2
J13 1 - 2
J14 1 - 2
J17 1 - 2
Position
–No Alert: USER LED1 OFF
– Mild Alert: USER LED1 blinking
– High Alert: USER LED1 ON
Quick Start Guide Page 2 of 4
1USB cable connected to the
KitProg3 USB connector
2USB-UART COM port setup
AIROC™ Bluetooth®
Connect app – Android
AIROC™ Bluetooth® Connect app – iOS
3
4

1
2
3
4
5
6
7
89 10 11 12 13 14
15
16
17
18
19
20
21
22
23
2526 24
272829303132
AIROC™ CYW20829 Bluetooth® Low Energy SoC Evaluation Board details
1. Power LED (LED1)
2. KitProg3 USB Micro-B connector (J5)
3. KitProg3 programming mode selection button (SW3)
4. KitProg3 (PSoC™ 5LP) programmer
and debugger (CY8C5868LTI - LP039, U5)
5. VBAT voltage selection jumper (J9)
6. VIO_BASE voltage selection jumper (J10)
7. VDDPA voltage selection jumper (J12)
8. Analog mic (U13)**
9. Power header compatible with
Arduino Uno R3 (J1)
10. Reset button (SW1)
11. 10-pin MCU PROG/DEBUG header (J11)
12. Analog header compatible with
Arduino (J2)
13. User Button 1 (SW2)
14. Digital mic (U11)**
15. User Button 2 (SW4)
16. User LED 1 (LED3)
17. User LED 2 (LED4)
18. M.2 stand-o (MT1)
19. AIROC™ CYW20829 Bluetooth® and
Bluetooth® LE system on chip
20. M.2 E-key interface connector (J16)
21. RGB LED (LED5)
22. Thermistor (TH1)
23. Thermistor enable header (J14)
24. KP3 to I2C Bus connect/
NC Selection SW (SW5)
25. Peripheral enable header (J13)
26. SWD /SPI Selection SW (SW6)
27. VDDIO current measurement header (J17)
28. Six-axis IMU (U12)
29. QSPI flash memory (U14)*
30. Digital I/O headers compatible
with Arduino Uno R3 (J3, J4)
31. Extended GPIO header (J18)
32. KitProg3 status LED (LED2)
*Footprint only, not populated on the board
**Component is located at the bottom side of the board
Quick Start Guide Page 3 of 4

NC
VIO/IOREF
RST/RESET
V3.3/V3.3
V5.0/V5.0
GND/GND
GND/GND
NC/VIN
P4.0/SCL
P4.1/SDA
NC
GND/GND
P1.1/D13
P1.3/D12
P1.2/D11
P1.0/D10
P1.6/D9
P1.5/D8
GND
NC
P3.1
P3.0
P0.4
P0.3
P0.2
P0.5
P5.2
P1.1
P0.1/D7
P0.0/D6
P1.2/D5
P1.3/D4
P1.0/D3
P1.4/D2
P3.3/D1
P3.2/D0
P3.4/A0
P3.5/A1
P3.6/A2
P3.7/A3
P0.0/A4
P0.1/A5
P5.0/A6
P5.1/A7
CYW20829 I/Os
AIROC™ CYW20829 Bluetooth® Low Energy SoC Evaluation Board pinout
Date: 02 / 2024
All rights reserved. © 2024
Infineon Technologies AG
Document number: 002-37204 Rev. *B
See the kit guide available at www.infineon.com/CYW920829M2EVK-02 for more details.
Legend I/Os compatible with Arduino Uno R3
