Infineon TLE493D-P2B6 MS2GO User manual

TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
User Manual
About this document
Scope and purpose
This document provides an introduction to the 3D Magnetic Sensor 2 Go kit and should enable the reader to
eiciently carry out own evaluations with the 3D magnetic sensor TLE493D-P2B6.
Intended audience
This document is aimed at everyone who wants to work with the 3D Magnetic Sensor 2 Go evaluation kit.
User Manual Please read the Important Notice and Warnings at the end of this document
www.infineon.com 2021-06-18

Table of contents
User Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
About this document . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Table of contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1 Hardware overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2 Soware . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
1.3 Hardware extensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
2 EvalBoard description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Optional external power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 Pin header connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 EvalBoard schematics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
3Soware installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Driver installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4 3D magnetic sensor evaluation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4.1 Getting started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
4.2 Graph View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.3 Joystick view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4 Rotation view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.5 Linear movement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.6 Out of sha . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
5 Example code for developers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
6 XMC for Arduino . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Revision history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Disclaimer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Table of contents
User Manual 2
2021-06-18

1 Introduction
Infineon’s 3D Magnetic Sensor 2 Go is a compact evaluation kit to familiarize the user with the 3D Hall sensor
TLE493D-P2B6. In a short time the board is set up and own 3D magnetic measurements can be executed. All
required hardware is included and the soware can be downloaded for free from the Infineon web page.
This user manual describes the dierent parts of the board, the soware installation process and clarifies how
the Graphical User Interface (GUI) can be used to do first evaluations. Further it is shown where to find example
code and an Arduino library as a easy starting point for own developments.
1.1 Hardware overview
The 3D Magnetic Sensor 2 Go kit contains:
• The 3D evaluation board (EvalBoard) as shown in Figure 1, a ready-to-use printed circuit board (PCB) with
the 3D Hall sensor. The EvalBoard is based on the XMC2Go-Kit. More technical documents and detailed
description can be found at http://www.infineon.com/xmc2go
• A standalone 7x7x5 mm ferrite block magnet
To use the 3D Magnetic Sensor 2 Go kit the user has to acquire a USB cable with a micro USB connection-end for
the EvalBoard side and a conventional USB connection for the PC side.
50mm
14mm
Figure 1 3D Magnetic Sensor 2 Go EvalBoard
1.2 Soware
The required soware to run the kit can be found at the Infineon web site. For further information refer to the
chapter Soware installation.
The soware package contains:
• A Graphical User Interface (GUI) for sensor evaluation.
• Firmware to be flashed into the XMC microcontroller for the low level communication with the sensor.
• USB driver J-Link from Segger which is necessary to establish the USB connection.
This soware was designed to be used with Windows 7 and Windows 10. It is compatible with both 32-bit and
64-bit system types. Backward compatibility with older Windows versions is ensured only by the .NET platform
as specific tests were not conducted on older operating systems.
The USB protocols capabilities are defined by the Segger driver. Versions USB 2.0 and USB 3.0 are compatible.
The GUI is used to enable a communication between the sensor and the PC. The user can configure the sensor
to operate in dierent modes. In those modes the update rate of the magnetic field measured (X, Y and Z
components) and current consumption vary.
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Introduction
User Manual 3
2021-06-18

1.3 Hardware extensions
Additionally to the provided standalone magnet there are several dedicated extensions available that can be
mounted to the 3D Magnetic Sensor 2 Go kit.
Table 1 3D Magnetic Sensor 2 Go extensions
Type Orderable part number (OPN)
Joystick JOYSTICKFOR3D2GOKITTOBO1
Rotation knob ROTATEKNOB3D2GOKITTOBO1
Linear slider LINEARSLIDER2GOTOBO1
Out of sha OUTOFSHAFTFOR3D2GOTOBO1
Figure 2 Joystick and rotation knob extensions for the 3D Magnetic Sensor 2 Go kit
Joystick
The magnet used in the joystick extension is an axial magnetized magnet as shown in Figure 3. The magnet
material is ferrite, of class Y35, which is equivalent to a remanence of between 400 mT and 410 mT. The magnet
disk has a size of 5 mm diameter and 5 mm thickness. For more information about the magnet, please follow
this link:
https://www.supermagnete.de/eng/disc-magnets-ferrite/disc-magnet-5mm-5mm_FE-S-05-05
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Introduction
User Manual 4
2021-06-18

5 mm
5 mm
Figure 3 Magnet used in the Joystick extension
Rotation knob
The magnet used in the rotate knob extension is a diametrically magnetized magnet as shown in Figure 4. The
magnet material is Neodymium Iron Boron (NdFeB) of class N45. The magnet is protected against corrosion
with Nickel coating (Ni-Cu-Ni). The magnet size is 4 mm diameter and 10 mm thickness. For more information
about the magnet, please follow this link:
https://www.supermagnete.de/eng/rod-magnets-neodymium/rod-magnet-diameter-4mm-height-10mm-
neodymium-n45-nickel-plated_S-04-10-DN
10 mm
4 mm
Figure 4 Magnet used in the rotation knob extension
Out of sha
The magnet used in the out of sha extension is a diametrically magnetized ring magnet as shown in Figure 5 .
The magnet material is Neodymium Iron Boron (NdFeB) of class N45. The magnet is protected against corrosion
with Nickel coating (Ni-Cu-Ni). The magnet size is 10 mm outer diameter, 7 mm inner diameter and 3 mm
thickness. For more information about the magnet, please follow this link:
https://www.supermagnete.de/eng/ring-magnets-neodymium/ring-magnet-10mm-7mm-3mm_R-10-07-03-
DN
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Introduction
User Manual 5
2021-06-18

10 mm
7 mm
3 mm
Figure 5 Magnet used in the out of sha extension
Linear slider
The linear slider extension comes with two axial magnetized magnets of the same size as shown in Figure 6. The
first magnet material is Neodymium Iron Boron (NdFeB) of class N45. The magnet is protected against corrosion
with Nickel coating (Ni-Cu-Ni). The second magnet material is ferrite, of class Y35, which is equivalent to a
remanence of between 400 mT and 410 mT. Both magnet disk has a size of 5 mm diameter and 5 mm thickness.
For more information about the magnets, please follow this links:
https://www.supermagnete.de/eng/disc-magnets-neodymium/disc-magnet-5mm-5mm_S-05-05-N
https://www.supermagnete.de/eng/disc-magnets-ferrite/disc-magnet-5mm-5mm_FE-S-05-05
5 mm
5 mm
Figure 6 Magnet used in the linear slider extension
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Introduction
User Manual 6
2021-06-18

2 EvalBoard description
The evaluation board (EvalBoard) is a ready-to-use printed circuit board (PCB) which contains:
• The 3D magnetic sensor TLE493D-P2B6. For the availability of 3D Magnetic Sensor 2 Go kits with
dierent sensor variants check the Infineon web page: https://www.infineon.com/cms/en/product/sensor/
magnetic-sensors/magnetic-position-sensors/3d-magnetics/
• XMC1100 microcontroller based on ARM Cortex™-M0 at 48 MHz frequency connected to the 3D sensor.
• XMC4200 microcontroller based on ARM Cortex™-M4 at 144 MHz frequency used for debugging and USB
communication.
• Micro USB connector for power supply and communication with the Graphical User Interface (GUI).
• LED for indication of power supply and debugging.
• Two LEDs for user configuration.
• Voltage regulator, reverse current protection diode and ESD protection diode.
• Pin headers to access data lines (e.g. via oscilloscope, external microcontroller).
The dierent components and its location are shown in Figure 7. The 3D magnetic sensor can be separated
from the rest of the EvalBoard by cutting the break line.
pin header X3
user LED2
@P1.1
pin header X1
crystal for
debug IC
XMC4200 debug IC and
UART to USB bridge
voltage regulator and reverse
current protection diode
TLE493D-P2B6
mirco USB
connector
ESD protection
diode
power and
debug LED
XMC 1100
mircocontroller
pin header X2
user LED1
@P0.12
break
line
pin header
distance fits
to breadbord
Figure 7 Main components of the EvalBoard
2.1 Optional external power supply
The 3D Magnetic Sensor 2 Go EvalBoard is supplied via the USB cable. It is also possible to provide an external
power supply. If this is the case, a few considerations must be taken into account as described below.
The 3D Magnetic Sensor 2 Go EvalBoard must be supplied by external 5 Volt DC power supply connected to
the micro USB plug. The voltage regulator shis the voltage level to 3.3 V for the microcontrollers and the 3D
magnetic sensor. The Power & Debug LED indicates that the presence of the generated 3.3 V supply voltage.
Out of the box with the pre-programmed application and the on-board debugger in operation the EvalBoard
typically draws about 75 mA. This current can be delivered via the USB plug of a PC, which is specified to deliver
up to 500 mA. An on-board reverse current protection diode will ensure safe operation and protects the USB
port of the Laptop/PC in case power is provided through the pin header X1.
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
EvalBoard description
User Manual 7
2021-06-18

It is not recommended to apply an additional power supply to the VDD pin of X1 (3.3 V) when the board is
powered via USB, because the 3.3 V supply could drive against the on-board power supply. The VDD pin can
be used to power an external circuit. But care must be taken not to draw more current than 150 mA, which is
the maximum current the on-board voltage regulator can deliver. Aer power-up the Debug LED starts blinking.
In case there is connection to a PC with correctly installed drivers, the Debug LED will turn from blinking to
constant illumination.
2.2 Pin header connector
The pin headers X1 and X2 can be used to extend the evaluation board or to perform measurements on
the XMC1100. The order of pins available at X1 and X2 corresponds to the pinning schema of the XMC1100
microcontroller in the TSSOP-16 pin package. The pinning table is also printed onto the bottom side of the PCB
(depending on the version). The pin header X3 can be used to access directly the 3D magnetic sensor pins.
X1
X2
X3
P0.5 P0.0
3.3 V
GND
P2.11
P2.10
P2.9 P2.7
P0.6 P0.7 P0.8 P0.9
P0.14
P0.15
P2.0 P2.6
VDD (P1.0)
GND
SDA (P2.10)
SCL (P2.11)
Figure 8 EvalBoard pin header connectors
The 3D Hall sensor pins can be accessed via the pin headers as shown in Table 2.
Table 2 Pin header description for the 3D magnetic sensor (X3)
TLE493D-P2B6 pin
number
Pin name
on board
XMC1100 port pin Sensor pin description
1 SCL P2.11 Interface clock and \INT pin, open drain
3 GND GND Ground pin
4 +3V3 P1.0 Supply pin
6 SDA P2.10 Interface data pin, open drain
The XMC1100 port pins P0.12 and P1.1 are connected the two user LEDs and are not available on the pin
headers.
Table 3 Pins used for the user LEDs
LED XMC1100 port pin
LED1 P0.12
LED2 P1.1
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
EvalBoard description
User Manual 8
2021-06-18

2.3 EvalBoard schematics
The schematics of the dierent blocks from the EvalBoard of the3D Magnetic Sensor 2 Go kit are provided in
this chapter. They can be used to design customized PCBs. The user (integrator) is responsible for the correct
functioning on system level as well as for the validation and testing.
Figure 9 EvalBoard schematic: 3D magnetic sensor
Figure 10 EvalBoard schematic: the voltage regulator (for the power supply)
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
EvalBoard description
User Manual 9
2021-06-18

Figure 11 EvalBoard schematic: the LEDs for user configuration (connected to XMC1100 pins)
Figure 12 EvalBoard schematic: the XMC1100 microcontroller and pin headers
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
EvalBoard description
User Manual 10
2021-06-18

Figure 13 Sketch of the debug connection
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
EvalBoard description
User Manual 11
2021-06-18

Figure 14 EvalBoard schematic: the XMC4200 microcontroller and micro USB connector
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
EvalBoard description
User Manual 12
2021-06-18

3Soware installation
The following description guides through the installation procedure of the free evaluation soware for the 3D
Magnetic Sensor 2 Go kit.
Steps
1. Download the soware.
The instructions how to download the evaluation soware are included in the delivery package of the
sensor 3D magnetic sensor 2Go kit.
2. Start the installation process.
Browse to your download folder and extract the downloaded .zip file. Aerwards, double click on
the .msi file to start the installer. The window in Figure 15 pops up. Click "Next".
Figure 15 Start the soware installation
3. Read the license agreement carefully and tick the box to accept the terms. Click Next.
Figure 16 Accept the license agreement
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Soware installation
User Manual 13
2021-06-18

4. Choose your installation path. The soware requires the SEGGER J-Link driver and .NET framework
version 4.5 or later to be installed on your PC. If not yet available, check the respective items. Click Next
Figure 17 Select you installation folder
5. Confirm the installation settings by clicking on Install.
Figure 18 Confirm the installation
6. Once the installation is complete, click on Finish to close the installer.
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Soware installation
User Manual 14
2021-06-18

Figure 19 Installation finished
7. You can now start the evaluation soware. Open the start menu, browse to Infineon Technologies > 3D
Sensor 2go Kit and open the application by clicking on 3D 2Go.
Figure 20 Shortcut to the 3D Magnetic 2Go evaluation soware (GUI)
3.1 Driver installation
To enable the communication between the 3D Magnetic Sensor 2 Go kit it is necessary to install the J-Link driver
on your PC.
The driver is included in the GUI installer and will start automatically within the installation progress. In case of
issues, you can directly download the latest version from the SEGGER homepage:
https://www.segger.com/downloads/jlink
Steps
1. Start the installation. Invoke your downloaded driver executable or wait for the 3D Magnetic Sensor 2 Go
installer to open the window shown in Figure 21. Click on Next.
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Soware installation
User Manual 15
2021-06-18

Figure 21 J-Link driver setup
2. Read and accept the license agreement. Click on I Agree.
Figure 22 J-Link license agreement
3. Check that the "Install USB Driver for J-Link" option is active. Click on Next.
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Soware installation
User Manual 16
2021-06-18

Figure 23 J-Link installation options
4. Choose the installation folder. It is recommend to keep the default settings. Click on Install. Now the
installation should be executed.
Figure 24 J-Link choose install location
5. Once the installation is completed, close the installer by clicking on Finish.
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Soware installation
User Manual 17
2021-06-18

Figure 25 J-Link installation complete
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
Soware installation
User Manual 18
2021-06-18

4 3D magnetic sensor evaluation
This chapter describes how the GUI can be used to make first evaluations with Infineon's 3D magnetic sensor.
4.1 Getting started
Once the soware is installed, the following steps are necessary to do the first magnetic measurements.
Steps
1. Connect the EvalBoard to the PC via the USB cable. Use the micro USB port for the EvalBoard and USB
port for the PC. The power LED on the EvalBoard will switch on, indicating the EvalBoard is supplied with
enough power.
2. Open the 3D 2Go GUI by clicking the shortcut in the start menu. On the top le side you should find the
XMC2Go board in the list. If not, check that the EvalBoard is correctly connected to the PC and the J-Link
driver is installed. Click on the Connect to selected programmer button which is marked in Figure 26
to establish the connection with the 3D Magnetic Sensor 2 Go kit. The first time you connect the board,
a firmware will be downloaded to the XMC1100 which takes short time. This is indicated by the blinking
power LED on the EvalBoard.
Figure 26 Establish the connection to the EvalBoard
3. The GUI automatically detects the sensor type on the 3D Magnetic Sensor 2 Go kit. Dierent
configuration modes can be selected which are briefly described in Table 4 . For details refer to the
TLE493D-P2B6 data sheet and user manual. Aer you have selected the mode, click on Start to begin
with the measurements.
4.2 Graph View
The graph view displays the magnetic field measurements in X, Y and Z direction.
Figure 27 shows the graph view window. On the le hand side there are three histograms which plot the
magnetic field for each measured sample. On the right a table displays all measured data, including the
temperature. With the save button it is possible to export the measurement data into a .csv file. This is
especially helpful for processing the data aerwards. .
If a new mode should to be evaluated click the Stop button on the le control panel. Save the data and Clear it.
Select a new configuration and click again on Start to begin the new evaluation.
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
3D magnetic sensor evaluation
User Manual 19
2021-06-18

Figure 27 Graph view
TLE493D-P2B6 MS2GO
3D Magnetic Sensor 2 Go evaluation kit
3D magnetic sensor evaluation
User Manual 20
2021-06-18
