QUICK START GUIDE
LiteShow®WIRELESS FREEDOM FOR YOUR PROJECTOR.
LS_QSG.qxd 10/22/03 3:24 PM Page 1

InFocus LiteShow Quick Start Guide 1
‘This InFocus®LiteShow®Quick Start Guide contains the four simple steps you need to perform in order to project with-
out the burden of cables. If you have any problems, consult the "Troubleshooting" section of the LiteShow User’s Guide
or the program’s online Help. Technical Support contacts can be found in this document on page 14.
Step 1: Check Your Equipment
Before you get started, check the System Requirements for your projector, PC or Mac to make sure that you have all of
the proper equipment. Then, check the "Items for Installation" section on page 3 to be sure you have all of the Lite-
Show components that you need.
System Requirements
Projector
Projectors that work with LiteShow for wireless projection need an M1-D or M1-DA standard connector (see below).
The LiteShow adapter attaches to your projector via this connector. For a list of projectors that are compatible with
LiteShow, consult the "Compatible projectors" section in the "Appendix" of the LiteShow User’s Guide.
connector on your projector

2 InFocus LiteShow Quick Start Guide
PC
Your Windows-based PC needs to meet or exceed the following system requirements:
•Intel
®Pentium®III 800MHz minimum
•Microsoft
® Windows®2000/XP operating system
•64MBRAM
• 16MB or more of available disk space
• Wi-Fi compatible 802.11b wireless LAN adapter (integrated or PC card*) or USB wireless adapter
• CD-ROM drive for software installation
* You can purchase and install a wireless adapter, or purchase one with LiteShow and install it.
Macintosh
Your Mac must meet or exceed the following system requirements:
• Mac PowerBook® G4 or iBook®
•MacOS
®X version 10.1.5 or later, 10.2 or later recommended
•128MBRAM
• 16MB or more of available disk space
•AirPort
®wireless LAN adapter
• CD-ROM drive for software installation

InFocus LiteShow Quick Start Guide 3
Items for Installation
Please be sure to have the following items on hand before starting the installation process:
LiteShow
Quick Start
Guide
projector with M1-D or M1-DA
LiteShow adapter
LiteShow CD and this Quick Start Guide
connector
computer with
wireless LAN
adapter (integrated, PC card, or
USB wireless adapter)

4 InFocus LiteShow Quick Start Guide
Step 2: Attach the LiteShow adapter to your Projector
1Make sure that the projector you are going to attach LiteShow to is powered off.
2Attach the LiteShow adapter to the M1-D or M1-DA connector on the projector. Secure it to the projector with the
two thumbscrews. Be careful to not overtighten them.
3Power on the projector. Look for the LiteShow Splash Screen (shown on the next page) on the projected screen. The
LiteShow Splash Screen is a small window that appears in the upper left corner of the projected screen. If you can
see it, then you know that the projector is powered on, the M1-D or M1-DA connector is the active source, and that
a LiteShow adapter is connected to it.
thumbscrews
Connector
hinge

InFocus LiteShow Quick Start Guide 5
Once visible, the LiteShow Splash Screen displays the following informational items:
•Name: The name of the LiteShow adapter. The default is myLiteShow.
•Unique ID: A unique identification string that distinguishes your LiteShow adapter from others in the
area.
•WLAN: The name of the Wireless Local Area Network (WLAN) LiteShow is connecting to. The default
is LiteShow.
•Model: The model number of the projector the LiteShow adapter is attached to.
•Versio n : The LiteShow adapter’s current firmware version.
•IP: The LiteShow adapter’s IP address. It can be automatically assigned or manually assigned.
If you do not see the above image, try turning on the projector’s Auto-Source option, or consult the "Troubleshoot-
ing" section of the LiteShow User’s Guide or the online Help file.
LiteShow Splash Screen

6 InFocus LiteShow Quick Start Guide
Step 3: Install the LiteShow Manager™for
Windows
Mac users, see page 9 for installation information.
Note: You need to have Administrative privileges in order
to install the LiteShow Manager software. If you do not
have these privileges it is recommended that you log out of
your current account and log in as a user with Administra-
tive privileges or have a user of the computer with Admin-
istrative privileges install LiteShow Manager.
1If you are using the 3COM wireless card that came with
LiteShow, see page 13. If it is not already inserted,
attach your wireless PC card or USB wireless adapter to
your computer and wait for the computer to recognize
it. If you are using an embedded wireless radio, please
make sure that the radio is enabled.
2Insert the LiteShow CD into your PC’s CD drive. At the
LiteShow CD menu, select the LiteShow option in the
Software section to install LiteShow Manager.
3From the Welcome to LiteShow installation window,
click Next, then read and accept the License Agree-
ment.
Welcome to LiteShow
License Agreement
window
installation window
LiteShow CD Menu

InFocus LiteShow Quick Start Guide 7
4The Choose Destination Location window prompts
you to select a destination folder. It can be a folder you
name via the Browse button, or the default folder sug-
gested by the installation program. Click Next.
5The Ready to Install the Program window informs
you that during the installation, the monitor may
flicker as drivers are installed. This is not an unusual
occurrence when drivers are installed. Click the Install
button to continue.
Note: If you see the Digital Signature Not Found dialog
box, it does not indicate that there is a problem. Click the
Ye s button and continue the installation.
Choose Destination
Location window
Ready to Install the
Program window
Digital Signature
Not Found dialog box

8 InFocus LiteShow Quick Start Guide
6At the Installshield Wizard Complete window, you
can create a shortcut to the LiteShow Manager on the
desktop and/or launch the LiteShow Manager. Both
options are checked by default. Click Next to continue.
7If you checked the Launch LiteShow Manager option,
it opens the LiteShow Manager. If you did not check
the option, navigate to Start>Programs>InFocus and
click the LiteShow Manager to open it.
Installshield Wizard
Complete window

InFocus LiteShow Quick Start Guide 9
Step 3: Install the LiteShow Manager for
Macintosh
Windows users, see page 6 for installation information.
1Insert the LiteShow CD into your Mac's CD drive.
2Launch the Mac Installer by double-clicking its icon.
3Enter your password in the Authenticate window.
4View the ReadMe file.
5View and accept the License Agreement.
6Select the destination volume and click Continue to
install.
License Agreement
ReadMe file
window
window
Authenticate
window

10 InFocus LiteShow Quick Start Guide
Once the installation is complete, the LiteShow Manager
folder opens and provides instant access to the installed
LiteShow files. Click the LiteShow icon to open the Lite-
Show Manager.
LiteShow Manager
Destination window

InFocus LiteShow Quick Start Guide 11
Step 4: Project
Following the installation of the LiteShow software, the LiteShow Manager application opens. The LiteShow-enabled
projector that you installed the LiteShow Manager software for should appear in the list window.
Click the Scan button if you are not seeing your LiteShow-enabled projector. Within moments, the Projector list
should populate with the names of LiteShow adapters that are in range. To project via LiteShow, simply highlight your
LiteShow-enabled projector and click the Project button.
Note: If you have a wireless driver that only supports the Basic Feature set, the Scan button is disabled. See "Trouble-
shooting" in the User’s Guide or consult the online Help for more information.
LiteShow Manager
display LiteShow adapter settings
scan for available projectors on other networks
list of LiteShow projectors
connect to selected LiteShow projector
hide/display LiteShow Manager user preferences
close LiteShow Manager
display LiteShow help

12 InFocus LiteShow Quick Start Guide
If you want to make adjustments
If you want to make any adjustments to your LiteShow settings, you can make them in the LiteShow Settings window.
The LiteShow User’s Guide and the online Help program explain the options and functions available for you. Please
consult the "Projecting via LiteShow" and "Troubleshooting" sections in the User’s Guide for additional information.

InFocus LiteShow Quick Start Guide 13
Regarding the 3COM Adapter
If you purchased the 3COM/LiteShow bundled product, this topic is for you.
Installation
We recommend that you complete the following steps to install the 3COM wireless adapter:
1Insert LiteShow CD and click on the 3COM Wireless PC Card option.
2Wait to be prompted to install the 3COM wireless adapter.
3When the application asks you to insert the 3COM wireless adapter, do so.
4Follow the rest of the instructions for install.
Although the above procedure is recommended, the 3COM wireless adapter can also be installed in advance of insert-
ing the LiteShow CD.
1Insert the 3COM wireless adapter. The Windows Hardware Wizard displays.
2To finish the install, simply click the Next button on the first screen and on the next screen.
3Make sure that the check box is enabled for CD-ROM drives.
4Make sure the LiteShow CD is in the CD-ROM drive on your computer.
5Finish the Wizard by clicking Next until the driver is installed. A Windows dialog box, "Digital Signature Not
Found" may display during this process. The install will work fine if the Yes button is clicked when this dialog box
displays.

14 InFocus LiteShow Quick Start Guide
Troubleshooting for the 3COM Wireless Adapter
3COM Technical Support Knowledgebase: http://knowledgebase.3com.com/
If You Need Assistance
If you cannot find a solution in the LiteShow User’s Guide or the online Help file, check the Service and Support section
of our website at http://www.infocus.com/service.
You may also send us an e-mail at [e-mail]. Our World Wide Web address is
http://www.infocus.com.
Upgrades
For information on upgrading the LiteShow software and firmware, please visit the
http://updates.infocus.com website.
