INOR APAQ R130 User manual

MEASURE OF SUCCESS
USER INSTRUCTIONS
Programmable
2-wire Transmitter
for Pt100 and Pt1000 Input
The user instruction must be read prior to adjustment and/or installation.
All information subject to change without notice.
4008101101 R01 2020-02
GENERAL INFORMATION
APAQ R130 is a low cost, non-isolated, easy-to-use 2-wire
temperature transmitter for Pt100 and Pt1000 input intended to be
used in industrial environment.
The transmitter is congured from a mobile device via NFC
communication, by using the app INOR Connect. Inor Connect is
available for free download on App Store, Google Play Store and
Huawei AppGallery.
MEASURE OF SUCCESS
DATA (short form)
CONFIGURATION
Before making a conguration of APAQ R130 you need to do
following:
1. Make sure that you have a mobile device with NFC
communication activated
2. Download the app INOR Connect to your mobile device
Required versions:
iOS Android
iOS 13 or later and Android 4.4 or later
Iphone 7 or later for NFC
Input 2-, 3-, 4-wire connection
Pt100 (IEC 60751,
α =0.00385) -200 to +850 °C / -328 to +1562 °F
Pt1000 (IEC 60751,
α =0.00385) -200 to +850 °C / -328 to +1562 °F
Adjustments - Zero Any value within range limits
Adjustments - Minimum span 20 °C / 36 °F
Output 4-20 mA, temperature linear
Sensor failure indication Upscale (≥21.0 mA) or downscale (≤3.6 mA)
NAMUR Compliance Current limitations and failure currents acc.
to NAMUR NE 43
Response time 0.4 to 26 s, adjustable ltering level
Ambient temperature
Storage and operation -40 to +85 °C / -40 to +185 °F
Galvanic isolation None
Power supply 6 to 32 VDC
Accuracy Max. ±0,15 K or ±0,15 % of span
Mounting Rail acc. to DIN EN50022, 35 mm
Vibration IEC 60068-2-6, 5 g
EMC EN 61326-1 and EN 61326-2-3
Conguration App INOR Connect via NFC
Factory settings
Input Pt100 3W, 0 to 100 °C
Output 4 to 20 mA
Sensor error indication Upscale
This product should not be mixed with other kind of scrap, after usage.
It should be handled as an electronic/electric device.
www.inor.com, www.inor.se
INOR Process AB, PO Box 9125, SE-200 39 Malmö, Sweden,
Phone: [phone], Fax: [phone], E-mail: [e-mail]
INOR Transmitter OY, Unikkotie 13, FI-01300 Vantaa, Finland,
Phone:[phone], Fax: [phone], E-mail: myynti@inor.
INOR Transmitter GmbH, Am See 24, D-47279 Duisburg, Germany,
Phone: [phone], Fax: [phone], E-mail: [email protected]
KROHNE Temperature Division INOR, 55 Cherry Hill Drive,
Beverly, MA 01915, United States
Phone: [phone], Fax: [phone], E-mail: [email protected]
R130
4. Once you have set the desired values in the
app, you transfer it to the transmitter by
clicking the transfer button and holding the
mobile device against the transmitter
until a green check box appears conrming
that the transfer has been completed.
Conguration procedure:
1. Launch the app by clicking on the App
icon or holding your mobile device
against the transmitter on the part of the
device where NFC is located
(only possible with Android).
2. Click on “Read Conguration” and hold
your mobile device against the trans-
mitter as explained in the rst section.
3. In the app you can edit the following:
a. Sensor type and number of wires
b. Measuring range
c. Upscale or downscale
Sensor error indication
d. Filter level
e. TAG-number
f. Password

INSTALLATION
MOUNTING
ORDERING INFORMATION
LIMITED WARRANTY
APAQ R130 RTD 70R1300011
OUTPUT LOAD DIAGRAM
APAQ R130 is designed to be mounted on a 35 mm DIN Rail according
to EN 60715 / DIN 50022.
!
CONNECTIONS
INOR Process AB, or any other aliated company within the Inor Group (hereinafter
jointly referred to as ”Inor”), hereby warrants that the Product will be free from
defects in materials or workmanship for a period of ve (5) years from the date of
delivery (”Limited Warranty”). This Limited Warranty is limited to repair or replace-
ment at Inor’s option and is eective only for the rst end-user of the Product. Upon
receipt of a warranty claim, Inor shall respond within a reasonable time period as to
its decision concerning:
1 Whether Inor acknowledges its responsibility for any asserted defect in
materials or workmanship; and, if so,
2 the appropriate cause of action to be taken (i.e. whether a defective
product should be replaced or repaired by Inor).
This Limited Warranty applies only if the Product:
1 is installed according to the instructions furnished by Inor;
2 is connected to a proper power supply;
3 is not misused or abused; and
4 there is no evidence of tampering, mishandling, neglect, accidental damage,
modication or repair without the approval of Inor or damage done to
the Product by anyone other than Inor.
This Limited Warranty is provided by Inor and contains the only express war-
ranty provided.
INOR SPECIFICALLY DISCLAIMS ANY EXPRESS WARRANTY NOT
PROVIDED HEREIN AND ANY IMPLIED WARRANTY, GUARANTEE
OR REPRESENTATION AS TO SUITABILITY FOR ANY PARTICULAR
PURPOSE, PERFORMANCE, QUALITY AND ABSENCE OF ANY HID-
DEN DEFECTS, AND ANY REMEDY FOR BREACH OF CONTRACT,
WHICH BUT FOR THIS PROVISION, MIGHT ARISE BY IMPLICATION,
OPERATION OF LAW, CUSTOM OF TRADE OR COURSE OF DEALING,
INCLUDING IMPLIED WARRANTIES OF MER-CHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE. EXCEPT AS PROVIDED HER-
EIN, INOR FURTHER DISCLAIMS ANY RESPONSIBILITY FOR LOSSES,
EXPENSES, INCONVENIENCES, SPECIAL, DIRECT, SECONDARY OR
CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE
OF THE PRODUCT.
Products that are covered by the Limited Warranty will either be repaired or replaced
at the option of Inor. Customer pays freight to Inor, and Inor will pay the return
freight by post or other “normal” way of transport. If any other type of return freight
is requested, customer pays the whole return cost.
The transmitters are delivered with either a default factory setting or
congured according to customer’s specication.
Maximum load depending on power supply
Formula for the max. permissible output load for APAQ R130:
R =(U-6)/0.022
Load
RTD RTD
Pt100 / Pt1000
2-wire connection
Pt100 / Pt1000
3-wire connection
RTD Pt100 / Pt1000
4-wire connection
DIMENSIONS
Mounting and removal of the transmitter
1. Fix the upper part of the transmitter onto the rail.
2. Press the lower part of the transmitter against the rail.
3. To remove the transmitter, use a screwdriver and bend
the locking under the transmitter downwards.
101.2 / 3.98
93.1 / 3.67
6.3 / 0.25
35 / 1.38
mm/inches
* Short terminals 1 and 2
on the transmitter,
max 50 Ω on each wire
*
Connect input, output and power
supply acc. to “CONNECTIONS”.
The cable is connected using spring-
cage connection. In order to minimize
measuring errors ensure that the cable
is securely fastened.
1. Insert a screwdriver into the opening
above the connection terminal block.
2. Insert the wire into the corresponing
connection terminal block.
