INOR IPAQ-LX User manual

USER INSTRUCTIONS
86BIQ00006 2009-11
The transmitter is congured from a standard IBM compatible PC by
using the IPRO-Software version 4.14 or later. The latest version
of IPRO can be downloaded from http://www.inor.com. When the
transmitter is set from a PC no calibration is needed.
When calibrate/congure ”online” with the input con-
nected to hazardous area the ATEX certied version of IPRO-X
cable must be used.
The transmitter is polarity protected and will not be damaged by
connecting the power supply with the wrong polarity, but the output
will be 0 mA.
The maximum load in the output loop depends on the supply voltage,
see ”DATA shortform”
”Isolation input/output/PC” mentioned in the data sheet,
indicates signal isolation only. It shall not be interpreted as
an IS galvanic isolation like an isolating barrier. Therefore
ordinary care in selecting barrier and grounding should be
considered for the IPAQ-LX.
Sensor wire check: the transmitter uses a pulsating technique to
monitor sensor break or sensor shortened to avoid measuring errors.
This pulsating signal may interfere with some electronic calibrators.
By selecting ”Sensor Break = None” in the IPRO software and
download the conguration into the transmitter the pulsating signal
is turned off.
GENERAL INFORMATION
INTRODUCTION
IPAQ-L is a universal and intelligent 2-wire rail-mounted transmitter
for temperature and other measurement applications.
IPAQ-LX is the Intrinsic Safe version for use in Ex-applications.
IPAQ-L(mA) is a version for current input only, up to 50 mA.
DIMENSIONS
Intelligent 2-wire
DIN Rail Temperature & mA
Transmitters
CONFIGURATION
The IPAQ-L/LX transmitter must be powered, when you congure the
transmitter, (see ”Connections” g.1). If IPRO (the IPAQ software) isn’t
installed in your PC, install the software.
For keeping the safety of the internal circuits in the
IPAQ-LX, always use Ex-power supply or a zener barrier with
limitations according to Ex-data and IPRO-X conguration
cable when making a conguration.
When choosing differential temperature measuments with Pt100 be
sure to select ”sensor break” = none.
Conguration from PC is ”on-line”, that is, the transmitter can be con-
gured while in operation if the area is known to be non-hazardous.
The output is frozen while transmission from PC to IPAQ take place.
When transfer is done the transmitter uses the new parameters.
12
4
3
56
7
!
MEASURE OF SUCCESS
The user instruction must be read prior to adjustment and/or installation.
All information subject to change without notice.
MEASURE OF SUCCESS
This product should not be mixed with other kind of scrap, after usage.
It should be handled as an electronic/electric device.
www.inor.com, www.inor.se
INOR Process AB, PO Box 9125, SE-200 39 Malmö, Sweden,
Phone: [phone], Fax: [phone], E-mail: [e-mail]
INOR Transmitter OY, Unikkotie 13, FI-01300 Vantaa, Finland,
Phone:[phone], Fax: [phone], E-mail: jari.stadig@inor.
INOR Transmitter GmbH, Rodenbacher Chaussee 6,
DE-63457 Hanau-Wolfgang, Germany,
Phone: [phone], Fax: [phone], E-mail: inor[email protected]
INOR Transmitter Inc, 7 Dearborn Road, Peabody, MA 01960, USA,
Phone: [phone],
Fax: [phone], E-mail: [e-mail]
ATEX
!
!

CONNECTIONS
Item Part No.
IPAQ-L 70IPL00001
IPAQ-LX (ATEX) 70IPLX0001
IPAQ-LX (FM, CSA) 70IPLX1001
IPAQ-L(mA) Current input only 70IPL00003
Software and cable
Conguration kit IPRO with cables 70CFG00092
LIMITED WARRANTY
INOR Process AB, or any other afliated company within the Inor Group (her-
einafter jointly referred to as ”Inor”), hereby warrants that the Product will be
free from defects in materials or workmanship for a period of ve (5) years from
the date of delivery (”Limited Warranty”). This Limited Warranty is limited to
repair or replacement at Inor’s option and is effective only for the rst end-user
of the Product. Upon receipt of a warranty claim, Inor shall respond within a
reasonable time period as to its decision concerning:
1 Whether Inor acknowledges its responsibility for any asserted defect in
materials or workmanship; and, if so,
2 the appropriate cause of action to be taken (i.e. whether a
defective product should be replaced or repaired by Inor).
This Limited Warranty applies only if the Product:
1 is installed according to the instructions furnished by Inor;
2 is connected to a proper power supply;
3 is not misused or abused; and
4 there is no evidence of tampering, mishandling, neglect, accidenta da-
mage, modication or repair without the approval of Inor or damage
done to the Product by anyone other than Inor.
This Limited Warranty is provided by Inor and contains the only express war-
ranty provided.
INOR SPECIFICALLY DISCLAIMS ANY EXPRESS WARRANTY NOT
PROVIDED HEREIN AND ANY IMPLIED WARRANTY, GUARANTEE
OR REPRESENTATION AS TO SUITABILITY FOR ANY PARTICULAR
PURPOSE, PERFORMANCE, QUALITY AND ABSENCE OF ANY HIDDEN
DEFECTS, AND ANY REMEDY FOR BREACH OF CONTRACT, WHICH BUT
FOR THIS PROVISION, MIGHT ARISE BY IMPLICATION, OPERATION
OF LAW, CUSTOM OF TRADE OR COURSE OF DEALING, INCLUDING
IMPLIED WARRANTIES OF MER-CHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE. EXCEPT AS PROVIDED HEREIN,
INOR FURTHER DISCLAIMS ANY RESPONSIBILITY FOR LOSSES,
EXPENSES, INCONVENIENCES, SPECIAL, DIRECT, SECONDARY OR
CONSEQUENTIAL DAMAGES ARISING FROM OWNERSHIP OR USE
OF THE PRODUCT.
Products that are covered by the Limited Warranty will either be repaired or
replaced at the option of Inor. Customer pays freight to Inor, and Inor will pay
the return freight by post or other “normal” way of transport. If any other type
of return freight is requested, customer pays the whole return cost.
DATA (shortform)
ORDERING TABLE
IPAQ-LX EX-DATA
Approval Demko 03 ATEX 134461X
CE 0539 II (1)G [Ex ia] IIC
Control Drawing 88DRW00022
IPAQ-L/LX/L(mA) are designed to t on a standard DIN Rail.
IPAQ-LX must be installed in safe area.
Connect input, output and power supply acc. to g. 1-10.
INSTALLATION
Power supply: IPAQ-L, IPAQ-L(mA) 7.5 to 36 VDC
IPAQ-LX 8 to 30 VDC
Isolation in/out: 1500 VAC
Output: 4-20 mA
Operating temperature: -20 to +70 °C
T1 T2
6
+ -
5
mV
RTD
(Pt100)
T/C
RTD
100%
0%
RTD
RTD
(Pt100)
100%
0%
RTD
4-wire connection
Pt100
Diff temperature T1> T2
Potentiometer
3-wire connection
Potentiometer
4-wire connection
Voltage
mV
Thermocouple
Supply voltage U (VDC)
RTD
3-wire connection
Fig 3
Fig 4
Fig 5
Fig 6
Fig 7
Fig 8
Fig 9
IPAQ-L, IPAQ-L(mA) IPAQ-LX
!
!
Fig 1 Fig 2
IPAQ-L(mA)
R LOAD=(U-7.5)/0.22 IPAQ-L, IPAQ-L(mA)
R LOAD=(U-8)/0.22 IPAQ-LX
Fig 10 Current
mA
Approval FM, J.I. 0D6A8.AX, CSA 2007 Certicate 1863602
Class I, II and III, Division 1, Group A, B, C, D, E, F and G
Control Drawing 3-7852
Output (terminals 5-6)
(current loop)
Ui : 30 VDC
Ii : 100 mA
Pi : 0,9 W
Li : 0 mH
Ci : 1 nF
Input (terminal 1-2-3-4)
(Intrinsically safe sensor terminals)
Uo: 30 V
Io : 27 mA
Lo : 50 mH
Co :52 nF
The equipment must be electrically connected (terminal 5 and 6)
via a certied isolating interface/zener barrier -and shall be
placed outside the hazardous area.
1) Ri ≤ 10 Ω
1)
