Introduction
Thank you for purchasing an Insignia universal laptop power
adapter. This adapter plugs into any AC power outlet anywhere
in the world, and provides a reliable power source to run your
laptop computer and charge its internal battery. Insignia
adapters are made using the highest quality components and
feature all of the necessary voltage and heat protection circuits
to ensure maximum levels of safety and efficiency.
NOTE: A physical adapter plug may be necessary to plug
into some AC power outlets outside of the United States,
but no voltage converter is needed anywhere in the world.
This adapter comes with a variety of numbered tips which
connect to the output cable of the adapter and control the
output voltage. To make sure that the proper voltage is delivered
to your laptop, you must always make sure that you are using the
correct tip for your specific laptop model. Read the following
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 2 Wednesday, April 2, 2014 6:59 AM

Universal Laptop Charger
3
www.insigniaproducts.com
instructions and refer to the Tip Compatibility Guide included
with this adapter to make sure you select the correct tip for your
laptop. You can also go to the Tip Wizard at
www.insigniaproducts.com for a complete listing of compatible
models.
CAUTION: This AC power adapter is not compatible with
Mac computers or laptops requiring more than 90 watts of
power.
Safety information
• Do not expose the power adapter to rain, moisture, or
excessive dust. It may cause shock hazards.
• Do not operate the adapter in direct sunlight.
• Operate the adapter in a well ventilated area. Maximum
ambient temperature around the power adapter must
not exceed 93.2° Fahrenheit (35° Celsius).
• Do not open the power adapter under any
circumstances. The power adapter is not intended to be
repaired in case of failure or component defect. There
are no internal serviceable parts.
• Discontinue use and contact our toll free help line for
assistance [phone] if any of the following should
occur:
• The adapter shuts down when it is plugged into the
device (LED turns off).
• The adapter's LED light blinks when the adapter is
plugged into an AC power outlet.
• A cord or plug is damaged or frayed.
• Do not use with laptops that require more than 90 watts
of power.
• Make sure to use the correct tip for your laptop listed in
the Tip Compatibility Guide. You can also go to the Tip
Wizard at www.insigniaproducts.com for a complete
listing of compatible models. Do not use a tip that is not
listed for your laptop.
• Keep away from children.
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 3 Wednesday, April 2, 2014 6:59 AM

4
NS-PWLC591/NS-PWLC591-C
www.insigniaproducts.com
Features
• Provides up to 90 watts of power
• Includes over-voltage, over-temperature, and short
circuit protection
• Powers laptops using a standard AC wall outlet
• Can be used anywhere in the world - no voltage
converter needed (an adapter plug may be necessary)
Package contents
• 90 Watt universal laptop power adapter with power
cord
•Sixtips
• Tip Compatibility Guide
•UserGuide
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 4 Wednesday, April 2, 2014 6:59 AM

Universal Laptop Charger
5
www.insigniaproducts.com
Using the AC power adapter
To use the AC power adapter:
1 Locate your laptop manufacturer and model from the
Tip Compatibility Guide, or go to
www.insigniaproducts.com and go to NS-PWLC591 to
find the Tip Wizard.
2 Identify the correct tip number for your laptop model.
CAUTION: The use of an incorrect tip may damage your
laptop. Do not use this product if you cannot locate your
laptop model in the Tip Compatibility Guide included with
this AC adapter or by using the Tip Wizard at
www.insigniaproducts.com. If you still have questions,
contact our toll-free help line for assistance at (877)
467-4289. This AC power adapter is not compatible with
Mac computers or laptops requiring more than 90 watts of
power.
DC input
jack
Tip
Output
cable
AC adapter
ACpower
outlet
LED
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 5 Wednesday, April 2, 2014 6:59 AM

6
NS-PWLC591/NS-PWLC591-C
www.insigniaproducts.com
NOTE: If the compatible tip for your device is not included
in the adapter package, one free tip can be ordered
through the Tip Wizard at www.insigniaproducts.com. Use
the Tip Wizard to locate the manufacturer and model and
you can order your complementary tip. If you are unable to
locate your laptop on the Tip Wizard or need assistance
please contact Insignia customer service at [phone].
3 Locate the specified tip from the tip bundle provided.
Each tip is clearly numbered.
4 Connect the selected tip to the end of the output cable,
making sure that the pins on the tip are aligned with the
holes in the cable. The ridge on the inside of the tip
should align with the groove in the output cable
connector. Make sure that the tip is pushed all the way
into the output cable's connector.
5 Plug the AC cord into an AC power outlet. The LED on
the adapter turns on, indicating that the adapter is
powered and ready.
IMPORTANT: If the adapter's LED does not turn on, or if it
blinks, discontinue use and contact our toll free help line for
assistance at [phone].
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 6 Wednesday, April 2, 2014 6:59 AM

Universal Laptop Charger
7
www.insigniaproducts.com
6 Plug the tip connected to the output cable into the DC
input jack on the side or back of your laptop. The
adapter powers the laptop and charges its battery.
FAQ for Insignia Adapters
What tip should I use for my laptop?
You can determine the correct tip for your laptop by referencing
the Tip Compatibility Guide included with the adapter or by
visiting the Tip Wizard at www.insigniaproducts.com. Locate
your laptop manufacturer and model and the correct tip will be
listed.
If you cannot find your specific laptop model please contact
Insignia customer service at [phone] for additional
assistance.
My tip is not included, how do I order a new
one?
First review the included Tip Compatibility Guide to locate the
correct tip for your specific laptop. You can also go to the Tip
Wizard at www.insigniaproducts.com for a complete listing of
compatible models. If the compatible tip for your laptop is not
included in the adapter package, one free tip can be ordered
through the Tip Wizard at www.insigniaproducts.com. Use the
Tip Wizard to locate your laptop manufacturer and model and
you can order your complimentary tip. If you are unable to locate
your laptop in the Tip Wizard please contact Insignia customer
service at [phone].
How do I connect the tip to the adapter cable?
After you have selected the correct tip for your laptop, connect
the tip to the output cable, making sure that the ridge on the
inside of the tip aligns properly with the groove in the output
cable connector. Additionally, the pins on the inside of the tip
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 7 Wednesday, April 2, 2014 6:59 AM

8
NS-PWLC591/NS-PWLC591-C
www.insigniaproducts.com
should be in line with the holes in the output cable. The tip
should be pushed firmly onto the cable until the tip and cable
meet and there is no gap.
What other laptops can I use this adapter for?
The Insignia Universal Power Adapter is compatible with
thousands of laptop models. A complete list of compatible
laptops can be viewed through the Tip Wizard at
www.insigniaproducts.com.
Why doesn't the tip fit into my laptop?
If the tip does not appear to fit into your laptop you may have
selected the incorrect tip for your laptop. The tip should fit
snugly inside the DC input jack on the side or back of your
laptop. If the tip does not fit into the jack, do not force the tip.
Confirm you have selected the correct tip for your laptop by
referencing the included Tip Compatibility Guide or visiting the
Tip Wizard at www.insigniaproducts.com. If you need additional
assistance please contact Insignia customer service at (877)
467-4289.
Will using an incorrect tip damage my laptop?
The tips are designed to be used with specific laptops and so you
should only use the tip that is designated specifically for your
laptop. The correct tip can be identified by using the online Tip
Wizard at www.insigniaproducts.com or by locating your specific
laptop in the included Tip Compatibility Guide.
The use of an incorrect tip may cause performance issues,
including the inability to charge the internal battery or power
the laptop, or the display of an error message on the laptop
screen. It is also possible that the use of an incorrect tip could
damage your laptop. For these reasons, it is necessary to use the
tip designed specifically for your laptop.
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 8 Wednesday, April 2, 2014 6:59 AM

Universal Laptop Charger
9
www.insigniaproducts.com
My laptop is less than 90 watts (e.g. 65 watts).
Will this adapter damage my laptop?
No, using this power adapter will not damage your laptop. This
adapter only supplies as much power as required by the laptop,
up to a maximum of 90 watts.
My laptop is more than 90 watts (e.g. 120
watts). Will this adapter damage my laptop?
This is a 90 watt adapter and it should NOT be used with laptops
that require more than 90 watts of power.
I notice that the adapter is warm when I use it. Is
this a problem?
During standard operation the adapter body may feel warm, and
this is normal. The adapter should always be placed in a
ventilated area in order to prevent over-heating.
If I leave the adapter plugged in when I'm not
using it does it waste energy?
This Insignia adapter meets EnergyStar and CEC V energy
requirements which means it is an energy-efficient product
designed to conserve power. When the adapter is plugged in
and not being used it draws less than 0.5W of power.
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 9 Wednesday, April 2, 2014 6:59 AM

10
NS-PWLC591/NS-PWLC591-C
www.insigniaproducts.com
Specifications
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of
this product is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply within the
limits for a class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
AC wall socket input cable 5.7’ (174 cm)
DC power output cable 3.9’ (119 cm)
AC input voltage 100~240V AC, 50-60Hz ~2.5 A
DC output voltage 19 Volts DC
DC output current 4.74 Amps maximum continuous
Output power 90 W maximum (AC)
Weight 9.8 oz. (277 g)
Adapter dimensions
(LxWxH)
5.0 x 2.2 x 1.3 inches
(126 x 56 x 32 mm)
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 10 Wednesday, April 2, 2014 6:59 AM

Universal Laptop Charger
11
www.insigniaproducts.com
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced technician for
help.
FCC warning
Changes or modifications not expressly approved by the party
responsible for compliance with the FCC Rules could void the
user’s authority to operate this equipment.
IC statement
This Class B digital apparatus complies with Canadian ICES-003;
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
Copyright
© 2014 Insignia. Insignia and the Insignia logo are trademarks of
BBY Solutions, Inc. Other brands and product names are
trademarks or registered trademarks of their respective holders.
Specifications and features are subject to change without notice
or obligation.
For service and support call [phone].
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 11 Wednesday, April 2, 2014 6:59 AM

12
NS-PWLC591/NS-PWLC591-C
www.insigniaproducts.com
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 12 Wednesday, April 2, 2014 6:59 AM

Universal Laptop Charger
13
www.insigniaproducts.com
One-year limited warranty -
Insignia
Definitions:
The Distributor* of Insignia branded products warrants to you, the original
purchaser of this new Insignia-branded product (“Product”), that the
Product shall be free of defects in the original manufacturer of the material
or workmanship for a period of one (1) year from the date of your purchase
of the Product (“Warranty Period”).
For this warranty to apply, your Product must be purchased in the United
States or Canada from a Best Buy branded or Future Shop branded retail
store or online at www.bestbuy.com, www.bestbuy.ca, or
www.futureshop.ca and is packaged with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for one year (365 days) from the date you
purchased the Product. Your purchase date is printed on the receipt you
received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the material or
workmanship of the Product is determined to be defective by an
authorized Insignia repair center or store personnel, Insignia will (at its sole
option): (1) repair the Product with new or rebuilt parts; or (2) replace the
Product at no charge with new or rebuilt comparable products or parts.
Products and parts replaced under this warranty become the property of
Insignia and are not returned to you. If service of Products or parts are
required after the Warranty Period expires, you must pay all labor and
parts charges. This warranty lasts as long as you own your Insignia Product
during the Warranty Period. Warranty coverage terminates if you sell or
otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy or Future Shop retail store
location, please take your original receipt and the Product to any Best Buy
or Future Shop store. Make sure that you place the Product in its original
packaging or packaging that provides the same amount of protection as
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 13 Wednesday, April 2, 2014 6:59 AM

14
NS-PWLC591/NS-PWLC591-C
www.insigniaproducts.com
the original packaging. If you purchased the Product from a Best Buy or
Future Shop online web site (www.bestbuy.com, www.bestbuy.ca, or
www.futureshop.ca), mail your original receipt and the Product to the
address listed on the web site. Make sure that you put the Product in its
original packaging or packaging that provides the same amount of
protection as the original packaging.
To obtain warranty service, in the United States call 1-888-BESTBUY,
Canada call 1-866-BESTBUY for Future Shop call 1-800-663-2275. Call
agents may diagnose and correct the issue over the phone.
Where is the warranty valid?
This warranty is valid only in the United States and Canada at Best Buy or
Future Shop branded retail stores or websites to the original purchaser of
the product in the county where the original purchase was made.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
•Installation
• Set up adjustments
• Cosmetic damage
• Damage due to weather, lightning, and other acts of God, such
as power surges
• Accidental damage
•Misuse
•Abuse
•Negligence
• Commercial purposes/use, including but not limited to use in a
place of business or in communal areas of a multiple dwelling
condominium or apartment complex, or otherwise used in a
place of other than a private home.
• Modification of any part of the Product, including the antenna
• Display panel damaged by static (non-moving) images applied
for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia to
service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA,
AAA, C etc.)
• Products where the factory applied serial number has been
altered or removed
• Loss or Theft of this product or any part of the product
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 14 Wednesday, April 2, 2014 6:59 AM

Universal Laptop Charger
15
www.insigniaproducts.com
• Display panels containing up to three (3) pixel failures (dots that
are dark or incorrectly illuminated) grouped in an area smaller
than one tenth (1/10) of the display size or up to five (5) pixel
failures throughout the display. (Pixel based displays may
contain a limited number of pixels that may not function
normally.)
• Failures or Damage caused by any contact including but not
limited to liquids, gels or pastes.
REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS YOUR
EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA SHALL NOT BE
LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR THE
BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT,
INCLUDING, BUT NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR
PRODUCT, LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES
NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE PRODUCT, ALL
EXPRESS AND IMPLIED WARRANTIES FOR THE PRODUCT, INCLUDING, BUT
NOT LIMITED TO, ANY IMPLIED WARRANTIES OF AND CONDITIONS OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THE
WARRANTY PERIOD. SOME STATES, PROVINCES AND JURISDICTIONS DO
NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS,
SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER
RIGHTS, WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
INSIGNIA is a trademark of Best Buy and its affiliated companies.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2014 Best Buy. All rights reserved.
Made in China
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 15 Wednesday, April 2, 2014 6:59 AM

INSIGNIA is a trademark of Best Buy and its affiliated companies.
Registered in some countries.
Distributed by Best Buy Purchasing, LLC
7601 Penn Ave South, Richfield, MN 55423 U.S.A.
©2014 Best Buy. All rights reserved.
Made in China
1-877-467-4289 (U.S. and Canada) or 01-800-926-3000 (Mexico)
www.insigniaproducts.com
V1 ENGLISH
14-0309
NS-PWLC591-NS-PWLC591-C_14-0309_MAN_V1_ENG.fm Page 16 Wednesday, April 2, 2014 6:59 AM
