INSTALLATION MANUAL
KY004 Infrared
Sauna Series
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installaon.
Replacements Parts: Inside of your warranty period visit:
hps://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts: Outside of your warranty period visit
hps://www.insigniashowers.com/replacement-parts.html
ATTENTION INSTALLERS:
These instrucons must be
le with the customer CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!

www.insigniashowers.com Last Modied: 03/10/2023
02
Contents
Thank you for your purchase 3
Electrical & Tool requirements 4
Box contents 5
Screw Pack Contents 6
Sauna Le Panel and Back Panel Install 7
Bench Heater Install 8
Bench Front Install 9
Heater Wires Install 10
Right Panel Install 11
Bench Cover Install 12
Back Rest Install 13
Glass Panels Install 14
Heater Cover Install 15
Front Panels Install 16
Roof Install 17
Door Cushioning Strip Install 18
Roof Cover Install 19
Door Handles Install 20
Door Magnet Brackets Install 21
Securing the Electrics 22
Electrical Connecons 23
Sauna Control Panel Instrucons 24
Remote Control Instrucons 26
Sauna Room Safety Guide 27
WEEE Compliance Statement 28

www.insigniashowers.com Last Modied: 03/10/2023
03
Thank you for your recent purchase of an Insignia Sauna. Please read this booklet with
great care to ensure you get the best out of your build and have a Sauna that will last
for many years to come! Like everything, in order to obtain a rst class product that
will serve you well for many years, the eort and correctness put into the assembly
will reect in the quality of your nish.

www.insigniashowers.com Last Modied: 03/10/2023
04
• Scissors
• Knife
• Spirit Level
• Tape Measure
• Philips Screwdriver
• Electric Drill
• Safety Gloves
• Safety Glasses
Tools Required
Voltage Rang 220-240AC
Frequency Rang 50Hz
Power Rang 1715 Was Sauna
Total Amperage 19.24 amps
Always consult a qualied Electrician before connecon as to suitability
Always Obtain Relevant Cercaon (minor Works Part P etc)
This Sauna must comply with current UK bathroom regulaons
Your electrical contractor will understand ALL legal requirements of connecon before undertaking any work or
installaon.
UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF
Note for electrician:
1) Connect within current laws and IP direcves.
2) (Preferred) Wire into isolated fused feed connecng directly to the house consumer/service box.
Always use protecon against electrical surge. Your shower should be treated the same as a home computer. A
surge protector should eradicate the possibility of burn out.
Subject to connecon type, electrical work needs to be signed o by a fully qualied operave by law. Failure to
adhere to this will not only void your electrical warranty for your sauna, but could void your house insurance.
Electrical Requirements Model KS004

www.insigniashowers.com Last Modied: 03/10/2023
05
What’s in the Boxes?
Contents Quanty
Roof
Le Panel
Back Panel
Right Panel
Front Panel Glass Door
Bench Front
Bench Top Seat
Door Handle
Floor Insert
1
1
1
1
1
1
1
1
1
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.

www.insigniashowers.com Last Modied: 03/10/2023
06
Screw Pack Contents
Contents Quanty
ST 50mm Screws
ST 35mm Screws
ST 12mm Screws
M 45mm Bolts
Wire Fixers
Nuts and Washers
8
2
17
2
5
2
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.

www.insigniashowers.com Last Modied: 03/10/2023
07
Step 1 — Installing the Back and Le Panels
Place the le and back panel in line and hook the
clip onto the knob and secure by pushing down the
lever.

www.insigniashowers.com Last Modied: 03/10/2023
08
Step 2 — Installing the Floor
Place the oor of the sauna in line with the ed
back and le panel.

www.insigniashowers.com Last Modied: 03/10/2023
09
Step 3 — Installing the Bench Front Panel
Slot the bench front panel between the grooves and t into place.

www.insigniashowers.com Last Modied: 03/10/2023
10
Step 4 — Connecng the Heater Wires
Once the bench panel is in place, locate the splier cable in
the screw bag & connect the heater wires as shown in the dia-
gram. Aach the earth cable on the pre ed nut & bolt.

www.insigniashowers.com Last Modied: 03/10/2023
11
Step 5 — Installing the Bench Seat
Slide the bench top between the grooves and push ll se-
cure against the back and le panels.

www.insigniashowers.com Last Modied: 03/10/2023
12
Step 6 — Installing the Right Panel
Repeat step 1 with the right panel.

www.insigniashowers.com Last Modied: 03/10/2023
13
Step 7 — Installing the Door Panel
Place the door panel in line with the latches and
secure with locking the latches.

www.insigniashowers.com Last Modied: 03/10/2023
14
Step 8 — Installing the Door Handles
Connect the front piece and the rst
part of the back piece for the inside of
the door, and ghten using the nuts.
Connect the second part of the back
piece and secure using the M 45 screws.
2 x M45mm
2 x Nuts and Washers

www.insigniashowers.com Last Modied: 03/10/2023
15
Step 9 — Installing the Roof
Carefully place the roof into the remaining space
making sure it is resng on all sides of the ed
ledges.

www.insigniashowers.com Last Modied: 03/10/2023
16
Step 10 — Connecng the Electrics
Connect the wires of the main power, con-
trol box, temperature control and ozone.

www.insigniashowers.com Last Modied: 03/10/2023
17
Step 11 — Installing the Roof
Secure the roof by screwing in the ST 50mm screws.
8 x ST 50mm

www.insigniashowers.com Last Modied: 03/10/2023
18
Step 12 — Installing the Door Cushioning Strip
Use the rubber bands to secure the wires to the
roof using the ST 12mm screws.
5 x ST 12mm

www.insigniashowers.com Last Modied: 03/10/2023
19
Step 12 — Electrical Connecons
14
15
2
3
13
10911 688
12
5
7
4
1
1. Main Power Supply
2. Group A : Connecons for back and leg heater
3. Group B : Connecons for front and side heater
4. Temperature Detector Wire
5. USB Input
6. Temperature Controller Wire
7. Antenna
8. Speaker Wires
9. Fan Wire
10. Ozone
11. Roof Light
12. CD/MP3 Wire
13. Control Panel Wire
14. AC220V Power Cord
15. Chromatherapy Lighng

www.insigniashowers.com Last Modied: 03/10/2023
20
12
34
5
6
7
8
9
10
11
12
13
14 15
Sauna Control Panel Instructions
Buon 1/2 (+/- Temp)
Cycle through desired temperature seng (max 60°C)
Buon 3/4 (+/- Time)
Cycle through desired me seng (max 99 mins)
Buon 5/6 (Sauna Heaters)
Press to acvate Sauna heaters. Pressing once will put the heaters on at 100%. Twice = 90%. Three mes = 80%. Four
mes = 70% and ve mes = O.
Buon 7 (Lights)
Press to cycle through the coloured lights. Each press will change colour unl a full cycle is completed and they turn o.
Buon 8 (Fan)
Press to turn the fan on, press again to turn it to auto and then a third me to turn it o.
Buon 9 (FM)
Press to turn on the radio. Press and hold to auto tune the radio staons. To change radio staon press tune.
Buon 10 (Audio Funcon)
Cycle through the audio funcon sengs, MP3, USB, Bluetooth or AUX. When playing music through Bluetooth or
USB simply use Tune (Buon 11/12) to change track.
Buon 11/12 (Tune)
Press and use the +/- to manually search. Hold the buons down for two seconds to speed scroll.
Buon 13/14 (Volume)
Press to cycle through the volume either up or down.
Buon 15 (Power)
Use to power the control panel on or o.
