Insignia KYS2000a User manual

www.insigniashowers.com Last Modied: 31/01/2022
INSTALLATION MANUAL
KYS2000a
Sauna Series
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installaon.
Replacements Parts: Inside of your warranty period visit:
hps://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts: Outside of your warranty period visit
hps://www.insigniashowers.com/replacement-parts.html
ATTENTION INSTALLERS:
These instrucons must be
le with the customer CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!

www.insigniashowers.com Last Modied: 31/01/2022
02
Contents
Thank you for your purchase 3
Electrical & Tool requirements 4
Box contents 5
Sauna Side Panel and Back Panel Install 6
Floor Placement 7
Bench Install 8
Bench Electrics Connecon 9
Bench Seat Install 10
Central Glass Paron Install 11
Fixed Glass Panel Install (Sauna) 12
Roof Install 13
Central Upright Connecon 14
Door Install (Sauna) 15
Door Handle Install (Sauna) 16
Roof Cover Install 17
Sauna Control Panel Instrucons 18
Sauna Room Safety Guide 19
WEEE Compliance Statement 20

www.insigniashowers.com Last Modied: 31/01/2022
03
Thank you for your recent purchase of an Insignia Sauna. Please read this booklet with
great care to ensure you get the best out of your build and have a Sauna that will last
for many years to come! Like everything, in order to obtain a rst class product that
will serve you well for many years, the eort and correctness put into the assembly
will reect in the quality of your nish.

www.insigniashowers.com Last Modied: 31/01/2022
04
• Scissors
• Knife
• Spirit Level
• Tape Measure
• Philips Screwdriver
• Electric Drill
• Safety Gloves
• Safety Glasses
Tools Required
Voltage Rang 220-240AC
Frequency Rang 50Hz
Power Rang 1597 Was
Total Amperage 6.67 Amps
Always consult a qualied Electrician before connecon as to suitability
Always Obtain Relevant Cercaon (minor Works Part P etc)
This Sauna / Shower must comply with current UK bathroom regulaons
Your electrical contractor will understand ALL legal requirements of connecon before undertaking any work or
installaon.
UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF
Note for electrician:
1) Connect within current laws and IP direcves.
2) (Preferred) Wire into isolated fused feed connecng directly to the house consumer/service box.
Always use protecon against electrical surge. Your shower should be treated the same as a home computer. A
surge protector should eradicate the possibility of burn out.
Subject to connecon type, electrical work needs to be signed o by a fully qualied operave by law. Failure to
adhere to this will not only void your electrical warranty for your sauna, but could void your house insurance.
Electrical Requirements Model KSY2000

www.insigniashowers.com Last Modied: 31/01/2022
05
What’s in the Boxes?
Contents Quanty
Roof
Floor
Middle Paron Glass Panel
Wooden Side Panel
Wooden Back Panel
Accessories
Door Handle
Door Hinge
Sauna Door
Central Upright Connector
Magnec Seal
Rear Door Seal
1
1
1
1
1
1
1
4
1
1
4
2
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.
Contents Quanty
Bench Top
Bench Side
Bench Front
1
1
1
[ ]
[ ]
[ ]

www.insigniashowers.com Last Modied: 31/01/2022
06
Step 1 — Installing the back and side panel (Sauna)
The panel connecon brackets are shown (above). Li
panels and locate the interlocking connecon brackets
and push the panel down to secure into posion. Locate
both panels onto the wooden side of the base.

www.insigniashowers.com Last Modied: 31/01/2022
07
Step 2 — Placing the oor into posion
Locate the oor and place into posion by
pushing it up to the side and back panel ghtly.

www.insigniashowers.com Last Modied: 31/01/2022
08
Step 3 — Installing the bench
Locate the bench front and place between the two
wooden struts on the side panel to secure it into posion.
Locate the bench side and place between the wooden
struts on the back panel to secure into posion.
On the inner side of the bench,
locate the 50mm screws and
secure the bench pieces to the
oor, panels and each other.
6 x 50mm Screws

www.insigniashowers.com Last Modied: 31/01/2022
09
Step 4 — Connecng the heater electrics
Locate the wires and connect together
before nishing the bench install.

www.insigniashowers.com Last Modied: 31/01/2022
10
Step 5 — Installing the bench topper
Locate the bench seat and slide into posion. The
underside of the bench top will have a grooved
recess which ts over the bench uprights.
2 x 60mm Screws

www.insigniashowers.com Last Modied: 31/01/2022
11
Step 6 — Installing the central glass paron
Locate the central glass paron panel
and slide it into the connecng upright
on the back panel.
Secure in posion by using the screw and spacer combo provided.
Place the plasc glass spacer through the glass, then the washer and
countersunk plasc head. Place the screw through all three and
screw to secure, then place the chrome nishing cap in posion.

www.insigniashowers.com Last Modied: 31/01/2022
12
Step 7 — Installing the front xed glass panel
Locate the front xed glass panel and
slide it into the connecng upright on
the le side panel.
Secure in posion by using the screw and spacer combo provided.
Place the plasc glass spacer through the glass, then the washer and
countersunk plasc head. Place the screw through all three and
screw to secure, then place the chrome nishing cap in posion.

www.insigniashowers.com Last Modied: 31/01/2022
13
Step 8 — Installing the Roof
Locate the roof and place in posion, then secure by using the screw
and spacer combo provided.
Place the plasc glass spacer through the glass, then the washer and
countersunk plasc head. Place the screw through all three and
screw to secure, then place the chrome nishing cap in posion.

www.insigniashowers.com Last Modied: 31/01/2022
14
Step 9 — Installing the Sauna/Shower front connecon upright
Locate the metal connecon upright and slot
it onto the central glass paron panel. This
will be a secure and ght t. If it is too ght,
slightly slacken o the roof connecon to
ease the upright into posion.
Ensure you reghten the roof aerwards.

www.insigniashowers.com Last Modied: 31/01/2022
15
Step 10 — Installing the Door
Unscrew to separate
Aach the door hinge to the xed glass panel before installing the door.
Li the door into posion and then x the door into the hinges. To realign the door, loosen the
bolts slightly, reposion and then reghten. Repeat this process unl alignment is perfect.
Locate the magnec seals into
posion as demonstrated to ensure
the door closes once installed.

www.insigniashowers.com Last Modied: 31/01/2022
16
Step 11 — Door Handle Install
Separate the door handle using an Allen key and
screwdriver. Once separated, align each handle
and the connecng pieces on either side of the
door and reconnect the handle.

www.insigniashowers.com Last Modied: 31/01/2022
17
Step 11 — Roof Cover/Electrics Install
Once the electrics have been
installed, locate the roof topper
and place in posion and screw
down using ST12 Screws.
Locate all wires on top of
the sauna and connect to
the corresponding
connecon from the wires
from the back and side
panels. Use the cable dies
to secure wires neatly to the
roof.
12 x 12mm Screws

www.insigniashowers.com Last Modied: 31/01/2022
18
12
34
5
6
7
8
9
10
11
12
13
14 15
Sauna Control Panel Instructions
Buon 1/2 (+/- Temp)
Cycle through desired temperature seng (max 60°C)
Buon 3/4 (+/- Time)
Cycle through desired me seng (max 99 mins)
Buon 5/6 (Sauna Heaters)
Press to acvate Sauna heaters. Pressing once will put the heaters on at 100%. Twice = 90%. Three mes = 80%. Four
mes = 70% and ve mes = O.
Buon 7 (Lights)
Press to cycle through the coloured lights. Each press will change colour unl a full cycle is completed and they turn o.
Buon 8 (Fan)
Press to turn the fan on, press again to turn it to auto and then a third me to turn it o.
Buon 9 (FM)
Press to turn on the radio. Press and hold to auto tune the radio staons. To change radio staon press tune.
Buon 10 (Audio Funcon)
Cycle through the audio funcon sengs, MP3, USB, Bluetooth or AUX. When playing music through Bluetooth or
USB simply use Tune (Buon 11/12) to change track.
Buon 11/12 (Tune)
Press and use the +/- to manually search. Hold the buons down for two seconds to speed scroll.
Buon 13/14 (Volume)
Press to cycle through the volume either up or down.
Buon 15 (Power)
Use to power the control panel on or o.

www.insigniashowers.com Last Modied: 31/01/2022
19
Sauna Usage & Safety Guide
1. Never leave children unaended in the Sauna.
2. Regulate the temperature of sauna before session - Pre-heat me 15-30 minutes (from room temperature 20c)
3. Never touch the heater panels whilst in operaon, possible burning may occur.
4. Recommended me of use 15-20 minutes per session
5. Stay hydrated during each Sauna session.
6. Exit the sauna immediately if feeling dizzy, faint or short of breath.
7. Do NOT use the sauna if you’re pregnant, have a heart condion, have low or high blood pressure. If you’re unsure consult
your GP before use.
8. If you have any underlying health condions which you feel could be aggravated by an increase in temperature, consult
your GP before use.
9. If you begin to have any issues with your health aer using a sauna, stop immediately and consult your GP regarding your
symptoms before connuing to use.
10. Consult your GP before using the steam room if you’re on medicaon at all, especially with drowsy side eects.
11. Never use this sauna if you have been drinking alcohol or under the inuence of other substances.
12. Do not put combusble material on the heaters at any me.
13. Always turn power supply o aer use.

www.insigniashowers.com Last Modied: 31/01/2022
20
All images are subject to copyright. Images may not be used in any way shape or form with out wrien permission from Maclean Internaonal Ltd. Images are NOT
permied to be saved, printed or uploaded. Violaon of copyright laws are punishable by law.
Insignia™ is a registered trademark of Maclean Internaonal Ltd, 9a Deans Road, Old Wolverton, Canon Industrial Park, Milton Keynes, Buckinghamshire, MK12 5NA, UK
The UK Waste Electrical and Electronic Equipment (WEEE) regulaons came into force on 2 January 2007. Under this new legislaon, producers of electrical and electronic
equipment (EEE) have to full certain obligaons.
Under the WEEE direcve Insignia is considered the producer of certain products we supply and in line with the demands of the legislaon we are pleased to oer the op-
portunity to return these products to us for treatment and recycling.
Insignia products will generally have an idenfying mark and the common crossed out wheelie bin label. We accept returns of all products carrying the Insignia brand. All
other products are either considered outside the scope of WEEE or Insignia is not technically the producer of these products. Insignia also accepts historic like-for-like WEEE
returns. All WEEE returned to Insignia will be recycled in appropriate treatment and recycling centres in accordance with the legislaon. If you wish to return any products to
us, please send your item(s) to our head oce.
Company Contract No. 326457
WEEE Producer No. CBDU64227
LABELING
Products labelled with the WEEE symbol (a crossed out “waste bin”) indicate that the nal user should not discard this product along with other
household waste, but that it must be collected and treated separately.
EU – Declaraon of Performance
Insignia declares that all its products complies with the essenal requirements and other relevant provisions of Direcve 305/2011/EC. A copy of the
Declaraon of performance is available from www.insigniarange.co.uk/ce.aspx
WEEE Compliance Statement
Returns Address for WEEE
Insignia
9a Deans Road, Old Wolverton, Canon Industrial Park, Milton Keynes, Buckinghamshire, MK12 5NA, UK
