INSTALLATION MANUAL
RW103/RW104
Sauna Series
ATTENTION INSTALLERS:
These instrucons must be
le with the customer
30 Day Technical Support:
Call 01908 317512 and request technical support for aiding your
installaon.
Replacements Parts: Inside of your warranty period visit:
hps://www.insigniashowers.com, click support and make a
warranty claim.
Spares/Replacements Parts: Outside of your warranty period visit
hps://www.insigniashowers.com/replacement-parts.html
CHECK ALL CONTENTS BEFORE BUILD COMMENCES. NO RETURNS CAN BE MADE
ONCE THE BUILD HAS STARTED AS IT IS DEEMED ACCEPTANCE OF PRODUCT!

www.insigniashowers.com Last Modied: 07/10/2021
02
Contents
Thank you for your purchase 3
Electrical & Tool requirements 4
Box contents 5
Back Panel to Base Install 6
Right Side Panel Install 7
Bench Heater Install 8
Bench Install 9
Le Side Panel Install 10
Door Install 11
Roof Install 12
Connecng the Electrics 13
Control Panel Instrucons 14
Sauna Room Safety Guide 15
WEEE Compliance Statement 16

www.insigniashowers.com Last Modied: 07/10/2021
03
Thank you for your recent purchase of an Insignia Sauna. Please read this booklet with
great care to ensure you get the best out of your build and have a Sauna that will last
for many years to come! Like everything, in order to obtain a rst class product that
will serve you well for many years, the eort and correctness put into the assembly
will reect in the quality of your nish.

www.insigniashowers.com Last Modied: 07/10/2021
04
• Scissors
• Knife
• Spirit Level
• Tape Measure
• Philips Screwdriver
• Electric Drill
• Safety Gloves
• Safety Glasses
Tools Required
Voltage Rang 220-240AC
Frequency Rang 50Hz
Power Rang 2700 was
Amperage : 11.25 Amps
Always consult a qualied Electrician before connecon as to suitability
Your electrical contractor will understand ALL legal requirements of connecon before undertaking any work or
installaon.
UNDER NO CIRCUMSTANCES UNDERTAKE THIS YOURSELF WITHOUT CONSULTATION
Note for electrician: This product comes with pre-ed RCD unit. We leave it this way for you to connect it your own
way due to connued addions to current regulaons.
1) Connect within current laws and IP direcves. Subject to room locaon.
2) (Preferred) Wire into isolated fused feed connecng directly to the house consumer/service box.
Always use protecon against electrical surge. Your shower should be treated the same as a home computer. A surge
protector should eradicate the possibility of either the transformer or control panel being burnt out.
Subject to connecon type, electrical work needs to be signed o by a fully qualied operave by law. Failure to
adhere to this will not only void your electrical warranty for your sauna, but could void your house insurance
Electrical Requirements Model No RW103/RW104

www.insigniashowers.com Last Modied: 07/10/2021
05
What’s in the Boxes?
Contents Quanty
Floor
Roof
Seat
Front of Seat
Screw Pack
Le Side Panel
Right Side Panel
Back Panel
1
1
1
1
1
1
1
1
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
[ ]
40mm Screw
Wooden Dowel
18
19
[ ]
[ ]
VERY IMPORTANT
Have you got everything? If not please contact the Insignia directly on 01908 317 512.
Remember NEVER book your tradesman unl everything has arrived, been checked and is
present. No replacement/missing parts can be obtained free of charge during or aer the
build. Any claims can only be within the mescale permied (48 hours aer delivery) and
always BEFORE build.

www.insigniashowers.com Last Modied: 07/10/2021
06
Step 1 — Placing the base and the back panel in posion

www.insigniashowers.com Last Modied: 07/10/2021
07
Step 2 — Connecng the back panel to the right side panel
3x 40mm Screws
Please Note: Screws connect on the interior of the Sauna

www.insigniashowers.com Last Modied: 07/10/2021
08
Step 3 — Installing bench heater
Connect heater panel to back
panel using the wires below.
Slide the bench heater up against the wooden strut

www.insigniashowers.com Last Modied: 07/10/2021
09
Step 4 — Installing the seat
Slide the top of the seat into posion, resng on the wooden struts.

www.insigniashowers.com Last Modied: 07/10/2021
10
Step 5 — Installing the le side panel
3x 40mm Screws
Please Note: Screws connect on the interior of the Sauna

www.insigniashowers.com Last Modied: 07/10/2021
11
Step 6 — Installing the door
8x 40mm Screws
Please Note: Screws connect on the interior of the Sauna

www.insigniashowers.com Last Modied: 07/10/2021
12
Step 7 — Installing the Roof
The roof simply slots into posion.
Now the Sauna is assembled, take the wooden
dowels and insert over any screw to give the
Sauna a sleek and neat nish.

www.insigniashowers.com Last Modied: 07/10/2021
13
Step 8 — Connecng the power
The power box is located on the roof. Take all power cables from the
panel heaters and the control panel and connect together.
Connect the control panel to
the lights and speakers, located
in the roof. Also take the
thermostac probe and place
through the thermostac probe
holder, also located in the roof.

www.insigniashowers.com Last Modied: 07/10/2021
14
Control Panel Instructions
1234
567
8910 11
Buon 1/2 (Temperature)
Use the plus and minus buons to change the temperature your sauna will reach.
Buon 3/4 (Time)
Use the plus and minus buons to change the duraon of the sauna session, unl the heaters
automacally shut o.
Buon 5 (Memory)
Use this buon the play or pause the USB, Bluetooth or Radio audio.
Buon 6 (Lights)
Press once for roof light on. Press twice for roof light o and wall lights on. Press three mes for
roof lights on and wall lights on. Press four mes to turn all lights o.
Buon 7 (Sauna)
Use this buon to start the heaters for the sauna session
Buon 8 (Audio funcon)
Use to toggle between radio, Bluetooth and USB audio preferences
Buon 9/10 (Mode)
Use to change the volume, the music tack or radio staon
Buon 11 (Power)
Use to power the control panel on or o.
Radio Staon Tuning
Press the Memory buon (5) for 3 seconds aer the audio frequency ashes then press
again to automacally search. Once this process has been completed, staons will be
automacally saved in their designated posions.
Bluetooth connecvity:
Press the audio funcon buon (8) unl the display reads ‘bt’ and the Sauna
will search for a Bluetooth device. If previously paired, your device and Sauna
will sync together and you can begin playing music. To pair, search in your
phone for Bluetooth devices and pair with the Sauna.

www.insigniashowers.com Last Modied: 07/10/2021
15
Sauna Usage & Safety Guide
1. Never leave children unaended in the Sauna.
2. Regulate the temperature of sauna before session - Pre-heat me 15-30 minutes (from room temperature 20c)
3. Never touch the heater panels whilst in operaon, possible burning may occur.
4. Recommended me of use 15-20 minutes per session
5. Stay hydrated during each Sauna session.
6. Exit the sauna immediately if feeling dizzy, faint or short of breath.
7. Do NOT use the sauna if you’re pregnant, have a heart condion, have low or high blood pressure. If you’re unsure consult
your GP before use.
8. If you have any underlying health condions which you feel could be aggravated by an increase in temperature, consult
your GP before use.
9. If you begin to have any issues with your health aer using a sauna, stop immediately and consult your GP regarding your
symptoms before connuing to use.
10. Consult your GP before using the steam room if you’re on medicaon at all, especially with drowsy side eects.
11. Never use this sauna if you have been drinking alcohol or under the inuence of other substances.
12. Do not put combusble material on the heaters at any me.
13. Always turn power supply o aer use.

www.insigniashowers.com Last Modied: 07/10/2021
16
All images are subject to copyright. Images may not be used in any way shape or form with out wrien permission from Maclean Internaonal Ltd. Images are NOT
permied to be saved, printed or uploaded. Violaon of copyright laws are punishable by law.
Insignia™ is a registered trademark of Maclean Internaonal Ltd, 9a Deans Road, Old Wolverton, Canon Industrial Park, Milton Keynes, Buckinghamshire, MK12 5NA, UK
The UK Waste Electrical and Electronic Equipment (WEEE) regulaons came into force on 2 January 2007. Under this new legislaon, producers of electrical and electronic
equipment (EEE) have to full certain obligaons.
Under the WEEE direcve Insignia is considered the producer of certain products we supply and in line with the demands of the legislaon we are pleased to oer the op-
portunity to return these products to us for treatment and recycling.
Insignia products will generally have an idenfying mark and the common crossed out wheelie bin label. We accept returns of all products carrying the Insignia brand. All
other products are either considered outside the scope of WEEE or Insignia is not technically the producer of these products. Insignia also accepts historic like-for-like WEEE
returns. All WEEE returned to Insignia will be recycled in appropriate treatment and recycling centres in accordance with the legislaon. If you wish to return any products to
us, please send your item(s) to our head oce.
Company Contract No. 326457
WEEE Producer No. CBDU64227
LABELING
Products labelled with the WEEE symbol (a crossed out “waste bin”) indicate that the nal user should not discard this product along with other
household waste, but that it must be collected and treated separately.
EU – Declaraon of Performance
Insignia declares that all its products complies with the essenal requirements and other relevant provisions of Direcve 305/2011/EC. A copy of the
Declaraon of performance is available from www.insigniarange.co.uk/ce.aspx
WEEE Compliance Statement
Returns Address for WEEE
Insignia
9a Deans Road, Old Wolverton, Canon Industrial Park, Milton Keynes, Buckinghamshire, MK12 5NA, UK
