User’s manual –ENG
IN465 ROWER POWER MASTER
Safety Instructions

• To ensure the best safety of the exerciser,
regularly check it on damages and worn parts.
• If you pass on this exerciser to another person or if
you allow another person to use it, make sure that
that person is familiar with the content and
instructions in these instructions.
• Only one person should use the exerciser at a time.
• Before the first use and regularly make sure that all
screws, bolts and other joints are properly tightened
and firmly seated.
• Before you start your work out, remove all sharp
edged objects around the exerciser.
• Only use the exercise for your work out if it works
flawlessly.
• Any broken, worn or defective part must immediately
be replaced and/or the exerciser must no longer be
used until it has been properly maintained and
repaired.
• Parents and other supervisory persons should be
aware of their responsibility, due to situations which
may arise for which the exerciser has not been
designed and which may occur due to children’s
natural play instinct and interest in experimenting.
• If you do allow children to use this exerciser, be sure
to take into consideration and assess their mental
and physical condition and development, and above
all their temperament. Children should use the
exerciser only under adult supervision and be
instructed on the correct and proper use of the
exerciser. The exerciser is not a toy.
• Make sure there is sufficient free space around the
exerciser when you set it up.
• To avoid possible accidents, do not allow children to
approach the exerciser without supervision, since
they may use it in a way for which it is not intended
due to their natural play instinct and interest in
experimenting.
• Please note that an improper and excessive work
out may be harmful to your health.
• Please note that levers and other adjustment
mechanisms are not projecting into the area of
movement during the work out.
• When setting up the exerciser, please make
sure that the exerciser is standing in a stable
way and that any possible unevenness of the
floor is evened out.
• Always wear appropriate clothing and shoes
which are suitable for your work out on the
exerciser. The clothes must be designed in a
way so that they will not get caught in any part
of the exerciser during the work out due to
their form (for example, length). Be sure to
wear appropriate shoes which are suitable for
the work out, firmly support the feet and which
are provided with a non slip sole.
• Be sure to consult a physician before you start
any exercise program. He may give you
proper hints and advice with respect to the
individual intensity of stress for you as well as
to your work out and sensible eating habits.

Important Notes
• Assemble the exerciser as per assembly
instructions and be sure to only use the
structural parts provided with the exerciser and
designed for it. Prior to the assembly, make sure
the content of the delivery is complete by
referring to the parts list of the assembly and
operating instructions.
• Be sure to set up the exerciser in a dry and
even place and always protect it from humidity.
If you wish to protect the place particularly
against pressure points, contamination, etc., it is
recommended to put a suitable, non slip mat
under the exerciser.
• The general rule is that exercisers and training
devices are no toys. Therefore, they must only
be used by properly informed or instructed
persons.
•Stop your work out immediately in case of
dizziness, nausea, chest pain or any other
physical symptoms. In case of doubt, consult your
physician immediately.
• Children, disabled and handicapped persons
should use the exercise only under supervision
and in presence of another person who may
give support and useful instructions.
• Be sure that your body parts and those of other
persons are never close to any moving parts of
the exerciser during its use.
• When adjusting the adjustable parts, make sure
they are adjusted properly and note the marked,
maximum adjusting position, for example of the
saddle support, respectively.
• Do not work out immediately after meals!

Exploded Drawing
19
1
20 30
2
16
15
29
7
11
23
24
26
14
40
41
42
43
22
6
5
12
21
10
8
2933 21 10
25
10
14
22
4
3
27
9
33
39
13
10
18
10
14
17
14
10A
37 3639
32
34
31
10
14
10
14
38
28
35
25
35
44
45

Part List
part no. description q'ty part no. description q'ty
1 slide rail 1 23 left handlebar 1
2 seat 1 24 right handlebar 1
3 seat bracket 1 25 piston 2
4 cross bolt 4 26 carriage bolt 4
5 cross screw 5 27 computer fixing plate 1
6 small foot cap 5 28 foam 2
7 square plug for slide rail 2 29 foot cap 2
8 adjustable bracket 1 30 foot cap 2
9 computer 1 31 knob 2
10 flat washer 34 32 carriage bolt 2
10A flat washer 2 33 bolt 2
11 bolt 1 34 H hook 1
12 pin 1 35 bolt 4
13 sensor cable 1 36 cross axle 1
14 nylon nut 19 37 plastic ring 4
15 stabilizer 1 38 round end cap 2
16 foot cap 2 39 pedal 2
17 connecting axle 1 40 pulley protective plate 2
18 bolt 1 41 pulley 4
19 left supporting frame 1 42 bushing tube 2
20 right supporting frame 1 43 bushing for handlebar 4
21 bolt 6 44 bolt 2
22 plastic cover 2 45 bolt 4

Assem ly :
Step 1
Fix the square plug (7) onto both end of slide rail (1), foot cap (29) and (30) onto left
supporting frame (19) and right supporting frame (20)
STEP-1
19
29
1
7
20
30
7x2
29 x2
30 x2
16
15
16 x2
Step 2
Fix seat (2) onto slide rail (1) by seat bracket (3) and bolt (4);
Fix the adjustable bracket (8) with rail and stabilizer (15) by using flat washer (10), bolt (21),
pin(12),nut(14) and bolt (11)

STEP-2
1
2
2
3
4
M8*1.25*70L
M8*15L
( x1)
( x4)
12 x1
15
12
21
10
8
14 1110
D19 D19 M8
D19
M6*16L
( x4)
Step 3
Fix the connecting axle (17) with left & right supporting frame (19&20), slide rail (1) by
using
flat washer (10), bolt (21) & bolt (18).
Fix the left & right supporting frame (19&20) with slide rail (1) by flat washer (10),bolt
(26),nut(14)
Fix the small foot cap (6) with screw (5)
STEP-3
1
2021 10 101817
10 21 19
261014
D19 M8
M8*1.25*55L
( x4)
M8*15L
( x2)
D19
6
x3
M8*35L D19
( x1)
Step 4

Fix the left & right handlebar (23 &24), piston(25) and plastic cover (22)
with left & right supporting frame (19&20) by H hook (34), knob(31),bolt (33),
flat washer (10), nut (14)
STEP-4
19
24
25
23
22
33
34 35
25
35
14 10
20
M8*1.25*50L
( x2)
D19 D19 M8
M8*1.25*40L
( x4)
D19 D19 M8
Step 5
Fix the pedal (39) by connecting axle (36), plastic ring (37), spring washer (10A), nut (14)
Connect the sensor cable (13) with computer(9) and then insert the computer into the fixing
plate (27)
STEP-5
( x2)
D25 M8
9
14
10A
37 39
27
36
39 37 14
10A
37
(x4)
13

INSTRUCTION MANUAL OF COMPUTER LT-8120
031
034 036
TIME………………….00:00-99:59MIN PULSE*(IF HAVE)…………0-192T/M
SPEED…………0.0-99.9KM/H or ML/H ALORIES…………………0-9999K AL
DISTAN E……….0.000-999.9KM or ML
SELE T: This key lets you to select and lock on to particular function you want.
RESET: The key reset the value to zero by pressing the key.
OPERATION PRO EDURES:
1. AUTO ON/OFF
◆ The system turns on when any key is depressed or when it sensor an input
from the speed sensor.
◆ The system turns off automatically when the speed sensor has no signal
Input or no key are pressed for approximately 4 minutes.
2. RESET:
The unit can be reset by either changing battery or pressing the SELE T key
for 4 seconds.
3. SELE T:
To choose the S AN or LO K. if you do not want the scan mode, press the
SELE T key when the pointer on the function you want which begins blinking.
4. FUN TION:
TIME By pressing the SELE T key until the pointer advance to TIME.

Press the SELE T key once to lock on the TIME function. the colon
Stop blinking,
SPEED Press the SELE T key until the pointer advance to SPEED and blinking.
Press to SELE T key once the pointer should stop blinking and lock on
To the SPEED function,
DISTAN E Press the SELE T key until the pointer advances to DSTAN E and blinking.
Press the SELE T key once to lock on to the DISTAN E function.
PULSE: Press the SELE T key until the pointer should stop linking and lock on
(if have) to the PULSE function and also put ear-clip to ear about 5 seconds show
out.
ALORIES Press the SELE T key until the pointer advance to ALORIES and blinking.
Press the SELE T key once the pointer should stop blinking and lock on
to the ALORIES function.
S AN Automatic display of the following functions in the order shown:
TIME-SPEED-DISTAN E-PULSE (if have)- ALORIES (repeat)
5. BATTERY
This monitor uses one or two (if have PULSE function) batteries. You can
replace the batteries at the batteries are used up
